Respiray Wearable Air Purifier User manual

Copyright 2021Respiray Ltd.All rights reserved.
User Manual
Wearable Air Purifier
Read this User Manual fully and thoroughly before operating the
device.
ENG, EST, RUS

2
www.respiray.com
This User Manual includes the following
languages:
ENGLISH
EESTI
РУССКИЙ
(For other languages not present in this Manual please visit:
www.respiray.com/documentation)

3
This manual may contain
images or content different
from the model you
purchased. This manual is
subject to revision by the
manufacturer.
Table of Contents
1. Important Safety Instructions .................................................................................4
2. Overview of the Device............................................................................................6
2.1 Intended Use ....................................................................................................6
2.2 Items Included in the Package .........................................................................6
2.3 Device Description ...........................................................................................6
3. Operation ................................................................................................................8
3.1 Charging.........................................................................................................10
3.2 LED Indicator Lights .......................................................................................10
4. Maintenance.........................................................................................................11
4.1 Cleaning .........................................................................................................11
4.1.1 Cleaning the Face Shield..................................................................11
4.2 Battery............................................................................................................11
4.3 Replacing the filter .........................................................................................12
4.4 Storing the device...........................................................................................12
5. Frequently Asked Questions .................................................................................13
6. Troubleshooting....................................................................................................15
7. Warranty Information............................................................................................16
7.1 Customer Care...............................................................................................17
8. Specifications .......................................................................................................18
9. Disposal................................................................................................................18
10. Copyright ..............................................................................................................19
ENGLISH

4
1. Important Safety Instructions
Please read the precautions carefully before use.
Remove jewellery or other accessories from areas under the device.
Do not operate this product when driving or in a vehicle.
The device is not waterproof. Keep the device away from water.
oAvoid situations in which liquids may spill onto the device.
oDo not place or store the device and charging adapter where it can fall or be
pulled into water or any other liquid.
oDo not use the device while bathing or taking a shower.
oDo not attempt to charge the product when it is wet.
oIt is not recommended to use this device outdoors.
The device is optionally supplied with a charging adapter which should be
used with special attention to safety.
oAlways correctly use and maintain the internal lithium ion battery packs.
Failure to do so may result in fire or explosion or could adversely affect
respirator performance and result in injury, sickness or death.
oNever use the adapter if it has a damaged cable or plug, isn’t working properly,
or has been submerged in water. If that happens, unplug the adapter
immediately. Failure to unplug the charging adaptor may result in a fire, an
electric shock, or damage to the device.
oDo not charge the on-board battery with unapproved chargers, in enclosed
cabinets without ventilation, near flammable liquids or gasses, or near sources
of high heat
oDo not use, charge or store the device outside the recommended temperature
limits.
The Respiray wearable UV air purifier contains a Germicidal Ultraviolet Lamp
which generates UV-C radiation contained within the disinfection module.
Damage to the module may result in the escape of dangerous UV-C radiation.
UV-C may cause harm to the skin and eyes. Devices that are obviously
damaged must not be operated.
Only authorized personnel are permitted to perform repairs, no changes or
modifications to this device are allowed.

5
oDo not attempt to modify, open or repair the device. You may expose yourself
to dangerous electrical components and may cause harm to yourself.
oDo not use if the parts or accessories are not supplied by the manufacturer as
defined in the manual.
oContact Customer Service if the device is damaged or does not appear to be
working properly.
This device contains a rechargeable Lithium-ion battery which is a sensitive
component that can cause injury if damaged.
oDo not attempt to remove the battery. Damaging the battery may result in a
risk of explosion or fire.
oContact Respiray or an authorised reseller to replace the battery. Replacement
by a third party may lead to damage to the device. Use of unqualified battery
may present in a risk of fire, leakage, explosion or other hazards.
The WEEE directive requires that you dispose of this electrical device
(including all accessories and parts) at a designated recycling collection point
for electrical devices.
oDo not dispose of in domestic waste!
oThe battery unit should be disposed of and recycled in a safe manner!
Contraindications
Do not use if you:
ohave serious problems with blood circulation in the chest or neck area,
ohave broken or irritated skin or history of cancer, or potential skin
malignancies, or swollen, infected, or inflamed zones in places of contact with
the device,
ochronic pain from osteochondrosis,
ohave epilepsy.

6
2. Overview of the Device
2.1 Intended Use
This product is meant to be used as a wearable air purifier to inactivate airborne pathogens
in the ambient air in front of the wearer. This device is NOT a medical product and is not
meant to be used as one. It is not intended for use by medical professionals.
The product may only be used according to the instructions as described in this manual. All
use, other than that described in this manual, is seen as unintended use. Changes to the
product and the manual are reserved. For the most recent version of the manual, visit
www.respiray.com.
2.2 Items Included in the Package
o1× The Wearable Air Purifier
o2× Face shields (heights 15 and 20 cm)
o1× Spare filter
o1× Charging adapter with EU plug (optional)
o1× USB-C charging cable (optional)
o1× Quickstart guide
o1× User manual
2.3 Device Description
The device consists of three main parts: the front unit, which houses the disinfection (UV-
C) portion of the device, the fans and the electronics; the back unit, which contains the
batteries; and the optional face shield.

7
Part Name
Description
1
Face shield
Helps guide the moving air and covers the wearer’s
mouth and nose
2
Air inlet
Takes in unfiltered air
3
Power button
Controls to turn the device on or off and controls to
regulate the fan speed
4
Air outlet
Disinfected air is blown out
5
Clasp button
To detach the front and back units
6
Connector strap
Holds the two units together and connects them
7
Strap adjuster
Helps regulate the connector strap length
8
Filter cartridge
Houses the replaceable dust filter inside the device
9
Battery ventilation
Keeps the battery temperature low
10
USB-C charging port
Used to charge the device

8
3. Operation
STEP 1: Make sure the device is positioned correctly.
STEP 2: Optionally, the included face shield can be attached to the device using the built-in
magnets.
STEP 3: To detach the front and back units, release the strap by pressing the clasp button
and slide the units apart. Please note that the strap can be opened on just one side of the
device.

9
STEP 4: Place the device on your shoulders. Make sure that the face shield is
approximately 3-5 cm from your face.
STEP 5: Adjust the device to a comfortable position by regulating the length of the straps.
STEP 6: The device can be turned on or off by holding down the power button for 2
seconds. While the device is on, the power button can be pressed to change the fan speed.
STEP 7: Remove the face shield before taking off the device. To remove the device, press
the clasp button and push the modules apart.
Tips for using the device
Make sure that the device is in the correct position.
Choose suitable face shield height from two options added inside the box
based on which size is more comfortable to wear. The protection level of
different size face shields is identical.

10
3.1 Charging
Charge the device using a USB Type-C
charging cable via a power connector.
Charging time of the device is approximately
4 hours when using a fast charger, or 10
hours when using a normal power adapter.
For optimal charging speeds, look for
chargers with 15W or 18W power outputs
with complying cables.
•The battery shall only be charged in non-hazardous areas.
•Make sure you are not in an explosive atmosphere.
•Do not leave Respiray Wearable Air Purifier plugged into its charger for more
than one week at a time. Doing so may shorten the battery life.
3.2 LED Indicator Lights
The front top part of the device houses three typical indicator LEDs which are completely
safe and which are used to indicate the battery and fan speed levels. Blue lights display the
battery status and orange lights show the current fan speed.
Battery indicator light status
Description
Three blue lights
Battery is full
Two blue lights
Remaining battery level <60%
One blue light
Remaining battery level <30%
Left blue light pulsating
Remaining battery level <10%

11
Fan speed indicator light status
Description
Three orange lights
55 L/min airflow
Two orange lights
35 L/min airflow
One orange light
25 L/min airflow
4. Maintenance
4.1 Cleaning
Before cleaning the device, make sure it is turned off. To clean the device, gently wipe it with
a soft damp cloth. Do not use any abrasive cleaning products or detergents. To disinfect the
surface of the device, use medical alcohol and a microfibre cloth.
Be careful not to let any water inside the device, as this can damage the device.
Do not turn on the device before it is completely dry.
4.1.1 Cleaning the Face Shield
The face shield can be cleaned by using dish soap, warm water, and a soft cloth. After a
thorough cleaning, dry it by using a soft microfibre cloth. If you wish to sanitise your face
shield, 70% isopropyl alcohol wipes can be used. We recommend cleaning the face shield
after every use.
Do not use any household or window cleaners to clean the face shield as
that may damage it.
4.2 Battery
Respiray Wearable Air Purifier has an internal lithium ion (Li-ion) battery. The device has a
low battery alarm, which is triggered when the battery has approximately 10% left (3 beeps
with 1 second interval). When the battery voltage becomes extremely low, the purifier will
stop.
•Avoid mechanical shocks or impacts from any sharp or hard objects.
•Do not use or place Respiray Wearable Air Purifier in extreme heat, such as in
direct sunlight, near heat sources, etc. The battery will be damaged if its
temperature rises above 100°C
•Do not dispose of Respiray Wearable Air Purifier in a fire.
•Do not disassemble the product.

12
•Do not use Respiray Wearable Air Purifier if there are any signs of severe
mechanical damage.
IN THE EXTREMELY RARE CIRCUMSTANCE THAT BATTERY IS DAMAGED
AND ELECTROLYTE COMES IN CONTACT WITH EYES, FLUSH WITH WATER
IMMEDIATELY AND SEEK URGENT MEDICAL ATTENTION
4.3 Replacing the filter
As the filter is only there to keep dust and larger
particles away from our disinfection module, we only
recommend replacing it once a year. To replace the
filter, perform the following steps:
STEP 1: Screw off the two screws from the bottom of
the front unit of the device.
STEP 2: Pull out the filter frame.
STEP 3: Replace the filter and screw the cover back on.
One spare filter is included in the package and more can
be bought from our website (www.respiray.com) or by
contacting us at [e-mail]. We recommend
using a vacuum in front of the filter cartridge once a
month to get rid of larger particles and hair.
4.4 Storing the device
The device should be stored at room temperature (18-
28°C) and in a low-humidity environment (30-50%
relative humidity). For longer storing periods, it is also
recommended to discharge the device to around 50%
(2 battery indicator lights turned on) to preserve the
battery. Do not store the device around combustible or inflammable objects.

13
5. Frequently Asked Questions
1. What does your device do?
Our product is a wearable UV air purifier that creates a clean air zone around the
wearer’s face without covering their face or restricting their breathing.
2. How does it work?
It uses UV-C light to inactivate airborne pathogens (viruses, bacteria, fungi, etc.). UV-C is
a specific range of invisible light that has been known to have disinfectant properties for
decades. UV-C radiation destroys the genetic material of the pathogens to the point
where they are unable to reproduce or multiply.
3. Is your device effective against SARS-CoV-2 (COVID-19)?
The effectiveness of our disinfection module has been independently tested for S.
aureus and E. coli bacteria, resulting in 2.5 and 2.6 log reduction respectively (99.68%
and 99.89%) at 30 l/min throughputs. A UV-C LED manufacturer has run tests comparing
necessary light intensities to inactivate 99.9% pathogens and found that a similar UV-C
light dose was needed to inactivate both E. Coli bacteria and SARS-CoV-2 at 265 nm
(https://www.stanley-components.com/en/uvc_technology/). Other tests have also
shown that UV-C light is effective at inactivating SARS-CoV-2 (COVID-19).
4. UV light can be dangerous. How do you make sure that the device is safe?
Our parent company AS Ldiamon has over a decade of experience with optics and UV-C,
and also meets the standards for an ISO 13485:2016 certificate, meaning they are
internationally certified to manufacture and handle medical devices. Our device is
carefully shielded to be fully light-sealed, so no UV-C light can escape from the device.
Additionally, we have added numerous protective measures to ensure the safety of our
device.
5. UV light can produce ozone. Does your device produce any ozone?
Absolutely not. While at some wavelengths the energy of UV light is able to produce
ozone, this only happens at below 242 nm. The LEDs in our device emit a very narrow
range of UV-C light at 265 nm, which will produce no ozone. Furthermore, at
wavelengths of 242-315 nm, ozone is broken back into oxygen molecules instead,
reducing the ambient ozone in the air
(http://www.ccpo.odu.edu/SEES/ozone/class/Chap_5/index.htm). We
have also thoroughly measured our device with ozone metres to ensure that there are no
ozone emissions.
6. Is the device safe for kids?
Due to the size of the device, the device is not meant to be used by children under the

14
age of 12. Additional potential contraindications are described in Safety instructions of
the manual.
7. Should I be using the included face shield?
We recommend wearing the device with the face shield in most situations, as the shield
provides direct protection against coughs and sneezes. In lower-risk and stationary
situations, such as sitting alone at an office desk, the face shield is not necessary.
8. Are the included batteries replaceable?
No, currently the batteries are integrated and not replaceable. Please do not attempt to
separate the batteries from the casing or replace them.
9. How much air does the device clean?
The device cleans 30 litres of air every minute in Normal Mode, which is around 3-4
times more than an average person breathes in a minute. The maximum airflow of the
device is 55 litres of purified air.
10. Is the device water-resistant?
Our device is not water-resistant and is not meant to be used in humid or wet
environments.
11. How long do the UV-C LEDs last?
The UV-C LEDs in our device are expected to last for around 5 years with frequent use.
12. Can the device be used while charging?
Yes, the device can be used while charging.
13. What material is the device made of?
The casing is made out of high-quality PC/ABS plastic.
14. Are the straps replaceable?
As of now, the straps are not replaceable. However, they are made of high-quality
thermoplastic rubber and are expected to last for the lifetime of the product.

15
6. Troubleshooting
Problem
Solution
The device is not turning on.
oThe battery is discharged or needs
to be replaced. See the Battery
section of Maintenance for more
information.
The device is not charging.
oThe device is not connected to the
power outlet. Check the
connections between the device,
charging cable and wall adapter.
oSomething is obstructing the
charging port. Try cleaning the
port with a thin wooden or plastic
tool. DO NOT use a metal tool as it
may damage the port.
The device turns off earlier than
expected.
oYou might have been using the
fastest mode. During this mode
the device works less than 8
hours.
oThe device is not fully charged.
Check the Battery section of
Operation for more information.
Unusual smells coming from the
device.
oThe filters are dirty and need to be
cleaned or replaced. See the Filter
section of Maintenance.
oThe device or the face shield is
dirty and needs to be cleaned. See
Cleaning the Device.
The device is charging slowly.
oThe wall adapter does not support
18W fast charging. See the
Charging section of Operation for
our recommendations for the
power adapter.

16
All lights flash in alternate colors,
the device makes 8 beeps (1 sec
interval) and turns off.
oThe device has an unknown error.
Please get in contact the
customer support at:
www.respiray.com/contact
7. Warranty Information
Respiray OÜ, Mõisa 4, 13522, Tallinn (hereinafter referred to as „Respiray“) warrants that the
product is free from defective workmanship and parts for a period of two (2) years from the
date of the original purchase or the date of delivery, provided the product has been used,
cleaned and maintained in accordance with these instructions and Respiray’s
recommendations. This warranty does not include consumable parts, such as the filters,
which must be replaced regularly by the user.
This warranty does not cover:
oWhere the product has been used outside the intended use and our
recommendations,
oWhere damage has been caused by misuse, mishandling, accident or
excessive wear and tear.
Any claim under this warranty must be made within two (2) years of the date of the purchase
of the product.
If the buyer wishes to make a warranty claim, they should contact the relevant support
centre. The buyer will then receive further information about the processing of the warranty
claim, e.g. where they can send the product and what documentation is required.
A warranty claim shall only be considered if the buyer can provide Respiray, or an authorised
Respiray partner, with
oA copy of the invoice/purchase receipt, and
oThe original product.
The following are explicitly excluded from this warranty:
oDeterioration due to normal use or consumption of the product;
oAccessories supplied with this product which are worn out or used up through
proper use (e.g. batteries, rechargeable batteries, cuffs, seals, electrodes, light
sources, attachments and nebuliser accessories, filters, etc.);
oProducts that are used, cleaned, stored or maintained improperly and/or
contrary to the provisions of the instructions for use, as well as products that

17
have been opened, repaired or modified by the buyer or by a service centre not
authorised by OÜ Respiray;
oDamage that arises during transport between the manufacturer and customer,
or between the service centre and customer;
oProducts purchased as seconds or as used goods;
oConsequential damage arising from a fault in this product (however, in this
case, claims may exist arising from product liability or other compulsory
statutory liability provisions).
7.1 Customer Care
Please contact Respiray customer care service to report unexpected operations or events,
or any other problem with your device.
Our contact details are:
Country
Service number
Email
Estonia
[phone]
[e-mail]

18
8. Specifications
Technology
UV-C (LED 265 nm) disinfection
Active Pathogen
Reduction
99.8% at 55 litres/min
Airflow Rate 25-55 litres/min
Noise level 43~55 dB
Weight
Main Unit 450 gr
Battery Unit 500gr
Charging Unit
Output 12Vdc, 3A max
Battery Bus
3S2P Li-ion battery, 10.8V, 6400mAh
Service Life 3 years
Operating
conditions
Temperature: 15 - 40°C
Relative humidity: 15% - 75%
Atmospheric pressure: 700 - 1060hPa
IP 54
The product is protected against most dust ingress but is not
dust tight. The product is fully protected against solid objects
and splashing of water from any angle.
9. Disposal
Do not dispose of with household waste!
If your device reaches its End-of-Life stage, be sure to follow your country’s
laws for the disposal of electrical items.
The WEEE directive requires that you dispose of this electrical device
(including all accessories and parts) at a designated recycling collection point
for electrical devices. Please separate the battery module from the main unit.
This helps conserve natural resources, protect human health and help the
environment. Make sure that the device is in an uncharged state before
disposal. Do not place the device in the trash.
Dispose of the packaging separated into single type materials.
Dispose of the package cardboard and carton as wastepaper and film via the
recyclable material.

19
10. Copyright
Respiray and related marks and logos are trademarks and/or registered trademarks of OÜ
Respiray. For patent and other intellectual property information, see respiray.com/ip. ©
2020 OÜ Respiray.
CE marking: Respiray declares that this product conforms with the basic
requirements and relevant provisions of the European guidelines.
