Retekess T118 User manual

Power
Mute
History
Up
Down
Program
Delete
Call
RETEKESS T118 Wireless Calling System Manual
Functional Diagram
Parameter
Instructions for use
A. Preparation for use
Connect the power supply of the transmitter, put the pagers on charging base and connect the power
source. After charging for 10 minutes, then start to program.
B. Program
When all the pagers under power charging, press P, the screen will display “P---", then press ”999” and
press CALL, all pagers will be flashing to show program state.
Note: we must input P999 within 20 seconds in the charging state.
Input a number, and press CALL. For example: input 98, the host displays P098. Then press CALL, all
numbers on charging pagers will change to 98 and flash. Move the top pager away from the base, the
pager will long beep, and number 98 stops flashing. Program is done.
Repeat above operation to program other pagers.
If no operation within 1 minute, the device will quit program state. 1 pager can program 1 number only,
new number will replace the old one.
C. Use
Input number and press CALL, the corresponding pager will alarm to remind. If input wrong numbers,
press ← to delete.
Pressing DELETE button several times will return to calling mode.
D. Charging reminder:
The red light flashes in the charging state. When the RED light turns to always-on, it shows the pager is
fully charged
Silent mode
In SILENT mode, pagers vibrate and flash only when receives a call, no beep.
Pagers not in charging state will not change mode.
Pressing DELETE button several times will return to calling mode.
Call history
Press H, the LCD displays H and the last call number. Press UP/DOWN to check the last 10 number records.
Pressing DELETE button several times will return to calling mode.
Warnings
Local Government Regulations
When the radios are used as a consequence of employment, the Local Government Regulations requires
users to be fully aware of and able to control their exposure to meet occupational requirements. Exposure
awareness can be facilitated by the use of a product label directing users to specific user awareness
information. Your Retekess radio has a RF Exposure Product Label. Also, your user manual, or separate
safety booklet includes information and operating instructions required to control your RF exposure and to
satisfy compliance requirements.
Compliance with RF Exposure Standards (If appropriate, Reference to the actual product’s
Safety Marking)
Your Retekess radio is designed and tested to comply with a number of national and International standards
and guidelines (listed below) for human exposure to radio frequency electro-magnetic energy.
Host Pager
Power input
Transmitting frequency
Transmit power
Standby power
Button mode
Max number of pagers
DC5V/3A
433.92MHz
13dBm
150mW
Mechanical button
998
Operating Voltage
Receiving frequency
Stand-by current
Standby duration
Receiving sensitivity
Transmission distance
3.7V
433.92MHz
30mA
10h
-115dBm
500m-800m
ABS Prompt mode Vibration / buzzer
/ flashing light
Number of charging
pagers 10
Shell material
Charger Power DC 5V/3A
Dimensions 110*165*50mm Reminder time 30s
Buttons pressed Display on LCD Function Remark
Pagers must in
charging state
Pagers must in
charging state
MUTE+999+CALL
MUTE+000+CALL
S999
S000
All charging pagers
change to SILENT
mode
All charging pagers
change to NORMAL
mode
Before using this radio, read this guide which contains
important operating instructions for safe usage and RF
energy awareness and control for compliance with
applicable standards and regulations.
1 2

FCC ID
The FCC ID means: This radio complies with the IEEE (FCC) and ICNIRP exposure limits for occupational/
controlled RF exposure environments at operating duty factors of up to 50% talk-50% listen and is approved
for occupational use only.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and
(2) This device must accept any interference received, including interference that may cause undesired
operation.
Warning: Changes or modifications not expressly approved by the party responsible for compliance could
void the user's authority to operate the equipment.
NOTE
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to
Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference by
one or more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.
The CE marking means: Hereby, Henan Eshow Electronic Commerce Co.,Ltd. declares that the radio
equipment type is in compliance with the RED Directive 2014/53/EU and the ROHS Directive 2011/65/EU
and the WEEE Directive 2012/19/EU.
The full text of the EU declaration of conformity is available at the following internet address:
www.retekess.com
IC ID
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the
following two conditions:
(1) This device may not cause interference, and
(2) This device must accept any interference, including interference that may cause undesired operation of
the device.
In terms of measuring RF energy for compliance with these exposure guidelines, your radio generates
measurable RF energy only while it is transmitting (during talking), not when it is receiving (listening) or in
standby mode.
Avoid Choking Hazard
Small Parts. Not for children under 3 years.
Protect your hearing
• Use the lowest volume necessary to do your job.
• Turn up the volume only if you are in noisy surroundings.
• Turn down the volume before adding headset or earpiece.
Turn off your radio power in the following conditions
• Turn off your radio before removing (installing) a battery or accessory or when charging battery.
• Turn off your radio when you are in a potentially hazardous environments: Near electrical
blasting caps, in a blasting area, in explosive atmospheres (inflammable gas, dust particles,
metallic powders, grain powders, etc.).
• Turn off your radio while taking on fuel or while parked at gasoline service stations.
To avoid electromagnetic interference and/or compatibility conflicts
• Turn off your radio in any facility where posted notices instruct you to do so, hospitals or health
care facilities (Pacemakers, Hearing Aids and Other Medical Devices) may be using equipment
that is sensitive to external RF energy.
• Turn off your radio when on board an aircraft. Any use of a radio must be in accordance with
applicable regulations per airline crew instructions.
Avoid Burns
Antennas
• Do not use any portable radio that has a damaged antenna. If a damaged antenna comes into
contact with the skin when the radio is in use, a minor burn can result.
Batteries (If appropriate)
• When the conductive material such as jewelry, keys or chains touch exposed terminals of the
batteries, may complete an electrical circuit (short circuit the battery) and become hot to cause
bodily injury such as burns. Exercise care in handling any battery, particularly when placing it
inside a pocket, purse or other container with metal objects
Long transmission (If appropriate)
• When the transceiver is used for long transmissions, the radiator and chassis will become hot.
Safety Operation
Forbid
• Do not use charger outdoors or in moist environments, use only in dry locations/conditions.
• Do not disassemble the charger, that may result in risk of electrical shock or fire.
• Do not operate the charger if it has been broken or damaged in any way.
• Do not place a portable radio in the area over an air bag or in the air bag deployment area. The
radio may be propelled with great force and cause serious injury to occupants of the vehicle
when the air bag inflates.
To reduce risk
• Pull by the plug rather than the cord when disconnecting the charger.
• Unplug the charger from the AC outlet before attempting any maintenance or cleaning.
• Contact Retekess for assistance regarding repairs and service.
EU Importer
Name：Germany Retevis Technology GmbH
Address：Uetzenacker 29,38176 wendeburg
3 4
