Revalco 2RAE96L4C485E Series User manual

MULTIFUNCTION POWER MONITOR
2RAE96L4C485E
USER MANUAL

- 1 -
1 Introduction
Line voltage and THD% (total harmonic distortion) of all phases
Key factor and Crest factor
Line Frequency
Currents, Current demands and current THD% of all phases
Power, maximum power demand and power factor
Active energy imported and exported
Reactive energy imported and exported
Real time date and time
1.2 Pass-word protected set-up
RS485 Modbus setting
CT Ratio and secondary current
PT Ratio and secondary voltage
Pulse output setting
Demand Interval time
Supply system selection 1phase2wire, 3phase 3wires and 3phase 4wires
Energy and demand information reset
Changing Password setting
Auto scroll display interval setting
Wiring correction configuration
Date and time setting
Multi-tariff setting (optional)
2~60th Current and Voltage harmonic
1.3 Current Transformer Current ratio
The unit can be configured to operate with CT ratio between primary and secondary current is 1 and 2000.
There are two options of secondary current input: 1A or 5A
The multifunction panel meter 2RAE96L4C485E series is a top new-generation intelligent panel meter,
used not only in the electricity transmission and power distribution system but also in the power
consumption measurement and analysis in high voltage intelligent power grid.
This document provides operating, maintenance and installation instructions for the 2RAE96L4C485E
series. The unit measures and displays the characteristics of single phase two wires, three phase three
wires and three phase four wires supplies, including voltage, frequency, current, power and active and
reactive energy, imported or exported, Harmonic, Power factor, Max. Demand etc. Energy is measured in
terms of kWh, kVArh. Maximum demand current can be measured over preset periods of up to
60minutes. In order to measure energy, the unit requires voltage and current inputs in addition to the
supply required to power the product. The requisite current input(s) are obtained via current transformers
The 2RAE96L4C485E can be configured to work with a wide range of CTs, giving the unit a wide range
of operation. Built-in interfaces provide pulse and RS485 Modbus RTU outputs. Configuration is
password protected.
1.1 Measurement and display parameters

- 2 -
2. Start-up Screens
The first screen lights all display segments and can be used as a
display check
The second screen indicates the firmware installed in the unit
and its build number.
Next the unit performs a self-test and indicates if the test passes.
3. Measurements
The buttons operate as follows
Selects the Voltage and Current display screens
In Set-up Mode, this is the “Left” or “Back” button.
1.4 RS485 Serial –Modbus RTU
This uses an RS485 serial port with Modbus RTU protocol to provide a means of remotely monitoring and
controlling the 2RAE96L4C485E series.
Set-up screens are provided for setting up the RS485 port.
1.5 Pulse output
This provides 2 pulse outputs those clocks up measured active and reactive energy. The constant for both
output are configurable.

- 3 -
Select the Frequency and Power factor screens
In Set-up Mode, this is the “Up” button
Select the Power screens
In Set-up Mode, this is the “Down” button
Select the Energy display screens
In Set-up mode, this is the “Enter” or “Right” button
3.1 Voltage and Current
Each successive pressing of the button selects a new range:
Phase to neutral voltages
Phase to phase voltages
Current on each phase

- 4 -
Phase to neutral voltage THD%
Current THD% for each phase
Crest Factor
Key Factor
3.2 Frequency and Power Factor and Demand
Each successive pressing of the button selects a new range:

- 5 -
Total kW
Frequency
Power factor (total)
Power factor of each phase
Max. Power demand
Max. Current demand
3.3Power
Each successive pressing of the button select a new range:

- 6 -
Instantaneous active power (kW)
Instantaneous reactive power (kVAr)
Instantaneous Volt-amps (KVA)
Total kW, kVArh, kVA
3.4 Energy Measurements
Each successive pressing of the button selects a new range:
Total active energy in kWh

- 7 -
Total reactive energy in kVAh
Imported active energy in kWh
Exported active energy in kWh
Imported reactive energy in kVArh
Exported reactive energy in kVArh
4. Set-up
Long press button to enter the set-up interface
The default pass-word is 1000,if the input is wrong,the LCD displays ”PASS Err”
Press the button to exit set-up interface.
4.1 Set-up Mode
4.1.1 Modbus Address

- 8 -
(The address ranges from 001 to 247)
The default address is 001. press to activate the
modification.
use and buttons to set the address with the range
001~247,and pressing the button for confirmation.
Press to confirm the setting and press to return to the main set up menu.
4.1.2 Baud Rate
From the Set-up menu, use and buttons to select
the Baud Rate option.
The default is 9600bps.

- 9 -
Press to enter the selection routine. The Baud Rate
setting will flash
Use and buttons to choose Baud rate 2.4k. 4.8k,
9.6k, 19.2k, 38.4k
Press to confirm the setting and press to return to the main set up menu.
4.1.3 Parity
From the Set-up menu, use and buttons to select
the Parity option(ODD/EVEN/NONE)
Default is NONE
Press to enter the selection routine. The current setting
will flash.
Use and buttons to choose Parity (EVEN / ODD /
NONE)
Press to confirm the setting and press to return to the main set up menu.
4.1.4 Stop bits
From the Set-up menu, use and buttons to select
the Stop Bit option.(1/2)
Default it 1

- 10 -
Press to enter the selection routine. The current setting
will flash.
Use and buttons to choose Stop Bit (2 or 1)
Press to confirm the setting and press to return to the main set up menu.
4.2 CT
From the Set-up menu, use and buttons to select
the CT2 option(5A/1A). The screen will show the current CT
secondary current value.
Default is 5
Secondary CT setting
Press to enter the CT secondary current selection
routine.
(5A/1A)
Set CT Ratio Value Press to enter the CT1 set-up
interface
The range is from 0005~9999.
Default is 0005
Press to confirm the setting and press to return to the main set up menu.

- 11 -
4.3 PT
From the Set-up menu, use and buttons to select
the PT option. The screen will show the voltage Secondary PT
voltage value.
The range is from 100~500
Default is 400
Primary PT setting
The range is from 000400~500000
Default is 000400
Press to confirm the setting and press to return to the main set up menu.
4.4 Pulse output
This option allows you to configure the pulse output. The output can be set to provide a pulse for a
defined amount of energy active or reactive.
From the Set-up menu, use and buttons to select
the Pulse output option
.
Press to enter the selection routine. The unit symbol will
flash
Use and buttons to choose kWh or kVArh.

- 12 -
Press to confirm the setting and press to return to the main set up menu.
4.4.1 Pulse constant
Use this to set the energy represented by each pulse. Rate can be set to 1 pulse per
0.001kWh/0.01kWh/0.1kWh/1kWh/10kWh/100kWh.
(It shows 1 pulse = 0.001kWh/kVArh)
From the Set-up menu, use and buttons to select
the Pulse Rate option.
Press to enter the selection routine. The current setting
will flash
Use and buttons to choose pulse rate.
1 pulse = 0.001/0.01/0.1/1/10/100/1000kWh/kVArh
0.001/0.01/0.1/1/10/100 kWh/kVArh per pulse
Press to confirm the setting and press to return to the main set up menu.

- 13 -
4.4.2 Pulse Duration
(The default set-up is 200ms)
From the Set-up menu, use and buttons to select
the Pulse width option.
Press to enter the selection routine. The current setting
will flash.
Use and buttons to choose pulse
width(200/100/60ms)
Press to confirm the setting and press to return to the main set up menu.
4.5 DIT(Demand Integration Time)
This sets the period in minutes over which the current and power readings are integrated for maximum
demand measurement. The options are: 0(off), 5, 8, 10, 15, 30, 60 minutes
From the set-up menu, use and buttons to select
the dIT option. The screen will show the currently selected
integration time.
Default is 60

- 14 -
Press to enter the selection routine. The current time
interval will flash
Use and buttons to select the time required.
Press to confirm the setting and press to return to the main set up menu.
4.6 Backlit set-up
The meter provides a function to set the blue backlit lasting time.
The backlit lasting time is settable
Default lasting time is 60minutes
For example, if it’s set as 5, the backlit will be off in 5minutes
from the last time operation on the meter.
Notes: If it’s set as 0, the backlit will always be on.
Press to enter the selection routine. The current time
interval will flash
The options can be:
0/5/10/30/60/120minutes
Use and buttons to select the time required. Then press to confirm the set-up,

- 15 -
4.7 Supply System
Use this section to set the type of power supply being monitored.
From the Set-up menu, use and buttons to select
the System option. The screen will show the currently selected
power supply
Press to enter the selection routine. The current selection
will flash
Use and buttons to select the required system
option: 3P4W,3P3W or 1P2W
Press to confirm the setting and press to return to the main set up menu.
4.8 CLR
4.8.1 Clear kWh
From the Set-up menu, use and buttons to select
the reset option.
Press to enter the selection routine. The yes will flash.

- 16 -
Press to confirm the setting and press to return to the main set up menu.
4.8.2 Clear KVArh
From the Set-up menu, use and buttons to select
the reset option.
Press to enter the selection routine. The yes will flash.
Press to confirm the setting and press to return to the main set up menu.
4.8.3 Clear Max Demand
From the Set-up menu, use and buttons to select
the reset option.

- 17 -
Press to enter the selection routine. The YES will flash.
Press to confirm the setting and press to return to the main set up menu.
4.9 Change Password
Use the and to choose the change password
option
Press the to enter the change password routine. The new
password screen will appear with the first digit flashing
Use and to set the first digit and press to
confirm your selection. The next digit will flash

- 18 -
Use and to set the second digit and press
to confirm your selection. The next digit will flash
Use and to set the third digit and press to
confirm your selection. The next digit will flash.
Use and to set the forth digit and press to
confirm your selection.
Press to confirm the setting and press to return to the main set up menu.
4.10 Auto display in turns
From the set-up menu, use and buttons to select
page “SET AUTO”
Press the button to activate the modification on the time.
Options: 9000/8000/7000/6000/5000/4000/3000/2000/1000/500
Default is 2000mS, which means 2 seconds.
Use the and to set the auto display interval time.
Press to confirm the setting and press to return to the main set up menu.

- 19 -
4.11 Reverse connected current inputs correction setting.
From the Set-up menu, use and buttons to select
page “SET SYS CONT”
Press to enter Phase A , the default is FRD (forward)
Use and buttons to Phase B or C setting pages
Press button to confirm the setting and press to return to the main set up menu.
4.11.1 How to operate if phase A is reversely connected
Go to phase A setting page
