REVENTON TORNADO Series Guide

Technical documentation
DESTRATIFICATION FAN TORNADO SERIES
TORNADO XS1
TORNADO XS2
TORNADO XS3
TORNADO XS4
TORNADO XS5
TORNADO XS6
MODELS:

2.2 DEVICE DIMENSIONS
Ø h
TORNADO XS1 421 180
TORNADO XS2 466 190
TORNADO XS3 515 190
TORNADO XS4 567 250
TORNADO XS5 635 250
TORNADO XS6 705 250
1.INTRODUCTION
1.1 PRECAUTIONS
1.2 TRANSPORT
1.3 PACKAGE CONTENT
1.4 USE
2. DEVICE CHARACTERISTICS
2.1 CONSTRUCTION AND PRINCIPLE OF OPERATION
2.2 DEVICE DIMENSIONS
2.3 DEVICE TECHNICAL DATA
3. ASSEMBLY
3.1 GENERAL PRINCIPLES
3.2 MOUNTING HOLES
4. INSTALLATION INSTRUCTIONS
4.1 CONNECTION OF THE DEVICE TO THE ELECTRICAL SYSTEM
5. PRECAUTIONS & WARNINGS
6. CONTROLS
7. CONNECTION SCHEMES
8. TERMS OF WARRANTY
1. INTRODUCTION
Thank you very much for purchasing destratification fan TORNADO. We would
like to congratulate you on excellent choice. Please read and keep this manual.
1.1 PRECAUTIONS
The buyer and the user of the destratification fan Reventon Group brand should
read carefully the following instructions and proceed to the content
recommendations. Proceeding due to the following instruction guarantees
the correct usage and safety. In case of any doubts please contact directly
Reventon Group Sp. z o.o. [Ltd.]. The producer reserves the rights to make
changes to the technical documentation without previous notice. Reventon
Group Sp. z o.o. [Ltd.] is not responsible for the damages which occur due
to improper installation, not keeping the device in repair or using the device out
of line. The installation should be carried out by the professional installers,
who possess the qualifications to install these types of devices. The installers
are responsible for making the installation as instructed in the technical data.
In case of unserviceable please plug out the device and contact
with the authorized for repair person or the supplier. During the installation,
use, service and periodical inspections all regulations and safety rules
must be followed.
1.2 TRANSPORT
During the acceptance of goods, it is needed to check the device to exclude
any damages. During the transport, it is needed to use the proper equipment,
it is necessary to carry the device by two people. In case of any damages please fill
in the damage report in presence of the supplier.
1.3 PACKAGE CONTENT
- destratification fan
- instruction and warranty card
1.4 USE
In the heated high large-spaces the air mass is located in the upper part
of room, which causes the heat loss. Destratification fans also called the drop fans
or air mixers are used to save on heating. They steer the air back to work zone
at the same time they level out the air temperature in the high room, they also
limit the heat loss through the roof. They are used in production halls,
warehouses and logistic centres.
2. DEVICE CHARACTERISTICS
2.1 CONSTRUCTION AND PRINCIPLE OF OPERATION
Cylindrical casing: made of galvanized steel. It has mounting holes which make
it easy to assemble the destratification fan with e. g. mounting rods.
Diffuser 360°: made of galvanized steel. Using specially shaped air stators
the diffuser enables even air distribution in the room.
Axial blowing fan: made of galvanized steel. It has a single-phase motor
with the following parameters: protection degree IP44, rated current
0.65 - 3.5 A (depending on the model). The smallest device in the series
has diameter 350 mm while the biggest one has diameter 630 mm.
ENG
2.3 DEVICE TECHNICAL DATA
* measurement at the distance 5 m
3.
3.1.
During installation, ensure a free air flow to the device and do not restrict
the air stream supply. The figures below show the recommended distances
between the heater and building partitions:
ASSEMBLY
GENERAL PRINCIPLES
TECHNICAL DOCUMENTATION
Supply voltage [V] /
Supply frequency
[Hz]
Rated motor
current [A]
Motor speed
[rpm]
Motor power [W]
Protection
degree IP [-]
Net weight [kg]
Noise [dB]*
Maximum
vertical range [m]
TECHNICAL
DATA
Product code
TORNADO
XS1
Maximum
airflow [m3/h]
TORNADO
XS2
TORNADO
XS3
TORNADO
XS4
TORNADO
XS5
TORNADO
XS6
DT-XS1-1965 DT-XS2-1966 DT-XS3-1967 DT-XS5-1969 DT-XS6-1970DT-XS4-1968
2200
6
230/50
0.65
1400
129
44
3600
8
230/50
0.82
1380
180
44
4800
10
230/50
1.15
1350
250
44
6400
12
230/50
1.75
1320
380
44
7600
13
230/50
2.55
1300
550
44
9700
15
230/50
3.50
1360
750
44
6.0 7.5 10.0 11.5 15.5 21.0
52 55 57 59 60 63

3.2 MOUNTING HOLES
There are special mounting holes in the back flange of the fan. Using them,
it is possible to mount the device with e. g. mounting pins. In order to dampen
possible vibrations of the structure, it is recommended to use anti-vibration
mounts. Necessary assembly elements, suitable for this type of installation,
should be purchased independently.
4. INSTALLATION INSTRUCTIONS
4.1. CONNECTION OF THE DEIVCE TO THE ELECTRICAL SYSTEM
- all works concerning electrical installation should be made by the qualified
personnel (who possess required authorizations to install electrical equipment),
based on wiring schematic diagrams (see 7)
- the electrical installation of the building shall have a residual current device
- it is recommended to check the electric installation and controls before the first
start
5. PRECAUTIONS & WARNINGS
The precautions mentioned below must be strictly followed during operation
of the device:
- all works concerning electrical installation (disassembly, repair etc.) should
be made by the qualified staff, who possess the qualifications due to the domestic
and local norms, regarding electrical installations
- before service or exchange of the device it is obligatory to cut off the current
supply
- do not limit or cover the inlet and outlet of the device
- do not install, service the device with wet hands or barefoot
- the device should be kept out of reach of children and animals
- after operating time of the device, please utilize it concerning the local norms
and regulations
ź
- it is recommended to clean the device periodically (at least twice a year):
air stators, fan casing and blades clean from dirt
-failure to comply with cleaning obligations may have a negative effect
on technical parameters of the device and lead to loss of warranty
- if the device is not used for a longer time and lead to loss of warranty disconnect
the voltage supply
- the device is transported with the closed air stators. It is essential to open
them in at least for 30 % before first start:
ź opening the air stators of the diffuser 360° must be done by two hands
in parallel
6. CONTROLS
Usage of automatic control dedicated to the devices of Reventon Group gives
great possibilities of adjusting the efficiency of the unit in different, depending
on needs, degree of its operation automation. We can offer the following:
5 control levels: 80-105-135-170-230 V
Voltage/ Frequency: 230 V AC / 50 – 60 Hz
Maximum current output (depending on model):
1.2 A, 3 A, 5 A, 7 A, 14 A
Protection: thermal switch
Weight(depending on model):
1.45 kg, 2.5 kg, 4.5 kg, 5.5 kg or 10.5 kg
Degree of protection: IP 54
Fan speed controller HC
designed to change the single-phase fan's speed voltage controlled in industrial
supply and heating systems. It is available in several versions. The selection
of the appropriate model depends on the number of the devices
that have to be connected to the to one regulator – the total current
of the connected devices cannot exceed the maximum current flow
of the regulator.
Manual thermostat HC
controls operation of the heater destratification fan. It switches the unit
off automatically, when the set temperature is reached. The total current
of the connected devices cannot exceed the maximum current flow
of the thermostat.
Power supply/ Frequency: 230 V AC / 50 – 60 Hz
Maximum current: 3 A
Operating temperature: 0 - 40°C
Temperature control range: 10 - 30°C
Control accuracy: <1°C
Degree of casing's protection: IP 30
allows to connect a receiver with higher current consumption than permissible
current load of connected regulator.
Power supply/ Frequency : 230 V AC / 50 – 60 Hz
Maximum rated current: 16 A
Input: NO/COM
Input: SL Connection of a regulator
with the voltage relay 230 V
Dimension: 47 x 47 x 20 mm
Relay Module RM-16A

7. CONNECTION SCHEMES
1. Power
2. Main switch, overcurrent circuit breaker*
3. Destratification fan TORNADO
4. Manual thermostat HC
5. Fan speed controller HC
*main switch and safety fuses are not included in the set

8. TERMS OF WARRANTY
I. Producer Reventon Group Sp. z o.o. [Ltd.] grants the buyer a 24-month
warranty period for the following devices:
- destratification fan TORNADO XS1
- destratification fan TORNADO XS2
- destratification fan TORNADO XS3
- destratification fan TORNADO XS4
- destratification fan TORNADO XS5
- destratification fan TORNADO XS6
II. The terms of warranty are valid from purchasing the device (i.e. invoice /
another confirming document issue date) but not longer than 30 months
from leaving the producer's warehouse.
III. To obtain the service it is needed to provide or send to the producer scans
of the warranty card with stamp of installation company, document confirming
the purchase (eg. like copy of the invoice) and correctly filled the warranty form.
IV. The producer is committed to consider the claim within 14 working days since
the date of reporting (i. e. day when documents given in point III are provided).
V. In the exceptional cases, the producer reserves the right to extend the time
limit for examination of warranty, especially if the defect is not permanent
and its determination requires a longer period of time. The extension
must be notified by the producer before the end of the 14th working day.
VI. Under the guarantee the producer provides a repairment, replacement
or refund for the defective device within a specified time limit.
VII. Warranty does not cover the parts of the device subject to normal
maintenance and the following cases:
a) mechanical damage of the product
b) defects and damages through:
- improper storage or transport
- improper or non-compliant use and maintenance (i. e. inconsistent
with the manual)
- using the device in the improper conditions (too high humidity, too high
or too low temperature, impact of the surrounding, sun etc.)
- unauthorized (by the user or other unauthorized persons) repairs,
modifications or construction changes
- connecting equipment inconsistent with the technical documentation
- connecting additional equipment, which is not recommended by the producer
- improper power supply
c) elements which wear and tear such as discolor of the housing
If there is any of the above, claimant will be charged for transport
and / or repairs.
VIII. Any changes in the Warranty Terms, improper use of the product (careless
handling, exposure to liquids, moisture, corrosion), as well as traces
of selfrepairing (non by the Reventon Group) or alterations cause,
the warranty is not valid.
IX. Not following to any of warranty regulations makes the warranty not valid.
X. All correspondence, returns, complains should be send to the following
address: Reventon Group Sp. z o.o. [Ltd.], 556 Wyzwolenia Street, 43-340
Kozy, Poland or email address: [email protected].
The producer reserves the rights to make changes to the technical
documentation without previous notice.
