RevoAce GBC1729W Series User manual

OWNER’S MANUAL
Outdoor LP Gas Barbecue Grill
Model No. GBC1729W series
WARNING
FOR YOUR SAFETY:
1. Do NOT store or use gasoline or
other ammable liquids or vapors in
the vicinity of this or any other
appliance.
2. An LP cylinder not connected for
use shall not be stored in the vicinity
of this or any other appliance.
WARNING
FOR YOUR SAFETY:
For Outdoor Use Only! (outside any enclosure)
DANGER
If you smell gas -
1. Shut off gas to appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from
the appliance, immediately call your
gas supplier or your fire department.
Failure to follow these instructions
could result in fire or explosion
which could cause property damage,
personal injury or death.
Manufactured in China for: RevoAce Inc. Limited
Hong Kong, China
1.800.694.0013 • [email protected]
9:00 am to 5:00 pm Eastern time, Monday to Friday.
GBC1729W-OM-E-F100
Do not leave this appliance
unattended,especially cooking the
fatty meat and close the lid too long
time.
WARNING
CALIFONIA PROPOSITION 65
This product can expose you to
chemicals including benzene, which
is known to the State of California to
cause cancer. For more information,
go to www.P65Warnings.ca.gov.
Important Safeguard s.................... Page 2
Limited Warranty ........................... 5
Expanded View & Hardware ................ 6 & 7
Assembly Instructions........................ 8
Installing LP Gas Tank....................... 13
Operating Instructions....................... 14
Cleaning and Care ......................... 16
Troubleshooting ........................... 18
The use and installation must conform with local codes or,
in the absence of local codes, with either the National Fuel
Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane
Installation Code, CSA B149.1, or Propane Storage and
Handling Code, B149.2, or the Standard for Recreational
Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV
Series, Recreational Vehicle Code, as applicable.
This instruction booklet contains important safety
information. Please read and keep for future reference.
If you are assembling this unit for someone else, give
this manual to him or her to read and save for future
reference.
California Proposition 65: Handling the brass material
on this product exposes you to lead, a chemical known
to the State of California to cause cancer, and birth
defects or other reproductive harm. Wash your hands
after handling this product.
Table of Contents

2
FOR YOUR SAFETY
WWARNINGS:
1. Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage.
2. Read the installation, operation, and maintenance instructions thoroughly before installing or servicing this
equipment.
3. Failure to follow these instructions could result in re or explosion, which could cause property damage,
personal injury, or death.
4. This instruction manual contains Important information necessary for the proper assembly and safe use of
the appliance.
5. Read and follow all warnings and instructions before assembling and using the appliance.
6. Follow all warnings and instructions when using the appliance.
7. Keep this manual for future reference.
IMPORTANT SAFEGUARDS
WDANGER: Failure to follow the dangers, warnings and cautions in this manual may result in serious
bodily injury or death, or in a fire or an explosion causing damage to property.
WWARNINGS:
WThis grill is for outdoor use only, and should not be used in a building, garage or any other enclosed area.
WDo NOT operate, light or use this appliance within ten feet (3.05 m) of walls, structures or buildings.
WFor residential use only. This grill is NOT for commercial use.
WThis grill is not intended for and should never be used as a heater. TOXIC fumes can accumulate and cause
asphyxiation.
WThis grill is safety certified for use in the United States and/or Canada only. Do NOT modify for use in any
other location. Modification will result in a safety hazard and will void your warranty.
WThis grill is for use with liquid propane (LP) gas only. The conversion to or attempted use of natural gas in this
LP gas grill is dangerous, may cause bodily harm and will void your warranty.
WLP gas characteristics:
a. LP gas is flammable and hazardous if handled improperly. Become aware of the characteristics before
using any LP gas product.
b. LP gas is explosive under pressure, heavier than air, and settles/pools in low areas.
c. LP gas in its natural state has no odor. For your safety, an odorant is added that smells like rotten
cabbage.
d. Contact with LP gas can cause freeze burns to skin.
WApartment dwellers: Check with management to learn the requirements and fire codes for using a LP gas grill
in your apartment complex. If allowed, use outside on the ground floor with a ten foot (3.05 m) clearance from
any structure. Do NOT use on or under balconies.
WLP gas cylinder needed to operate. Only cylinders marked “propane” may be used.
WThe LP gas cylinder must be constructed and marked in accordance with the Specifications for LP-gas
Cylinders of the U.S. Department of Transportation (D.O.T.) or the National Standard of Canada, CAN/
CSA-B339, Cylinders, Spheres and Tubes for the Transportation of Dangerous Goods; and Commission.
WLP gas cylinder must be arranged for vapor withdrawal.
WThe LP gas cylinder must have a listed overfilling prevention device (OPD).
WOnly use LP gas cylinders equipped with a cylinder connection device compatible with the connection for
outdoor cooking appliances.
WThe LP gas cylinder must have a cylinder collar to protect the cylinder valve.
WNever use an LP gas cylinder with a damaged body, valve, collar or footing.
WThe LP gas cylinder should not be dropped or handled roughly.

3
IMPORTANT SAFEGUARDS
WDented or rusted LP gas cylinders may be hazardous and should be checked by your LP gas supplier prior to
use.
WLP gas cylinders must be stored outdoors out of the reach of children and must not be stored in a building,
garage or any other enclosed area. Your cylinder must never be stored where temperatures can reach over
125°F.
WDo NOT insert any tool or foreign object into the valve outlet or safety relief valve. You may damage the valve
and cause a leak. Leaking propane may result in an explosion, fire, severe personal injury or death.
WDo NOT block holes in sides or back of grill.
WNever keep an LP gas cylinder in a hot car or trunk. Heat will cause the gas pressure to increase, which may
open the relief valve and allow gas to escape.
WPlace dust cap on cylinder valve outlet whenever the cylinder is not in use. Only install the type of dust cap
on the cylinder valve outlet that is provided with the cylinder valve. Other types of caps or plugs may result in
leakage of propane.
WIf grill is not in use, the gas must be turned off at the supply cylinder and disconnected.
WDo NOT store a spare LP gas cylinder under or near this appliance.
WNever fill the cylinder beyond 80 percent full.A fire causing serious injury or damage to property may occur if
the above is not followed exactly.
WNever attempt to attach this grill to the self-contained LP gas system of a camper trailer, motor home or
house.
WNever use charcoal, lighter fluid, lava rocks, gasoline, kerosene or alcohol with this product.
WYour grill has been checked at all factory connections for leaks. Re-check all connections as described in
the “Operating Instructions” section, as shipping can loosen connections.
WCheck for leaks even if your unit was assembled for you by someone else.
WDo NOT operate if a gas leak is present. Gas leaks may cause a fire or explosion.
WYou must follow all instructions in the “Checking for Leaks” section before operating. To prevent fire or
explosion hazard when testing for a leak:
a. Always perform a leak test before lighting the grill and each time the cylinder is connected for use.
b. No smoking. Do NOT use or permit sources of ignition in the area while conducting a leak test.
c. Conduct the leak test outdoors in a well-ventilated area.
d. Do NOT use matches, lighters, or a flame to check for leaks.
e. The use of alcohol, prescription or non-prescription drugs may impair the consumer’s ability to properly
assemble or safely operate the appliance.
f. Strong odors, colds, sinus congestion, etc. may prevent the detection of propane. Use caution and
common sense when testing for leaks.
g. Do NOT use grill until any and all leaks are corrected.
If you are unable to stop a leak, disconnect the LP gas supply. Call a gas appliance serviceman or your
local LP gas supplier.
WThis grill is designed to operate at an inlet pressure of: 11 inches water column.
WDo NOT store or use gasoline or other flammable liquids or vapors within 25 feet (7.62 m) of this appliance.
WDo NOT use in an explosive atmosphere. Keep grill area clear and free from combustible materials, gasoline
and other flammable vapors and liquids.
WMinimum clearance from sides and back of unit to combustible construction is 36 inches (91.4 cm). Do NOT
use this appliance under any type of overhang or roof.
WIt is essential to keep the grill’s valve compartment, burners and circulating air passages clean.
WInspect grill before each use.

4
IMPORTANT SAFEGUARDS
WDo NOT alter grill in any manner. Any alteration will void your warranty.
WDo NOT use the grill unless it is COMPLETELY assembled and all parts are securely fastened and tightened.
WDo NOT build this model of grill in any built-in or slide-in construction. Ignoring this warning could cause a
fire or an explosion that can damage property and cause serious bodily injury or death.
WThis grill should be thoroughly cleaned and inspected on a regular basis.
WClean and inspect the hose before each use of the appliance. If there is evidence of abrasion, wear, cuts or
leaks, the hose must be replaced prior to operation.
WUse only the regulator and hose assembly provided.
WUse only factory-authorized parts. The use of any part that is not factory-authorized can be dangerous and
will void your warranty.
WDo NOT operate this appliance without reading “Operating Instructions” in this manual.
WDo NOT touch metal parts of grill until they have completely cooled to avoid burns, unless you are wearing
protective gear (pot holders, gloves, BBQ mittens, etc.).
WDo NOT install or use in or on boats or recreational vehicles.
WWhen cooking, fire extinguishing materials should be readily accessible. In the event of an oil/grease fire, do
NOT attempt to extinguish with water. Use type BC dry chemical fire extinguisher or smother with dirt, sand
or baking soda.
WDo NOT use grill in high winds.
WNever lean over the grill when lighting.
WDo NOT leave a lit grill unattended. Keep children and pets away from grill at all times.
WDo NOT leave grill unattended while preheating or burning off food residue on high. If grill has not been
cleaned, a grease fire can occur that may damage the product.
WDo NOT place empty cooking vessels on the appliance while in operation.
WUse caution when placing anything on the grill while the appliance is in operation.
WDo NOT attempt to move grill when in use. Allow the grill to cool before moving or storing.
WLP gas cylinder must be properly disconnected and removed prior to moving this grill.
WStorage of grill indoors is permissible only if the cylinder is disconnected, removed from the grill and properly
stored outdoors.
WAlways open grill lid carefully and slowly as heat and steam trapped within grill can cause severe burns.
WDo NOT attempt to disconnect the gas regulator from the cylinder or any gas fitting while the grill is in use.
WAlways place your grill on a hard, non-combustible, level surface. An asphalt or blacktop surface may not be
acceptable for this purpose.
WMove gas hoses as far away as possible from hot surfaces and dripping hot grease.
WKeep all electrical cords away from a hot grill.
WAfter a period of storage and/or nonuse, check for leaks, burner obstructions and inspect for any abrasion,
wear or cuts to the hose.
WFailure to open lid while igniting the grill’s burners, or not waiting 5 minutes to allow the gas to clear if the
grill does not light, may result in an explosive flame-up.
WNever operate grill without its heat plates installed.
WAlways use a meat thermometer to ensure food is cooked to a safe temperature.
WUse protective gloves when assembling this product.
WDo NOT force parts together as this can result in personal injury or damage to the product.
WNever cover entire cooking area with aluminum foil.
WDeaths, serious injury or damage to property may occur if the above is not followed exactly.

5
Limited Warranty
RevoAce Inc. Limited (“RA”) warrants to the original retail purchaser of this product, and to no other person, that if
this product is assembled, maintained, and operated in accordance with the printed instructions accompanying it,
then for a period of one (1) year for all remaining parts from the date of purchase, all parts in such product shall be
free from defects in material and workmanship. RA may require reasonable proof of your date of purchase. Therefore,
you should retain your sales slip or invoice. This Limited Warranty shall be limited to the repair or replacement of
parts, which prove defective under normal use and service and which RA shall determine in its reasonable discretion
upon examination to be defective. Before returning any parts, you should contact RA’s Customer Care Department
using the contact information listed below. If RA conforms, after examination, a defect covered by this Limited
Warranty in any returned part, and if RA approves the claim, RA will replace such defective part without charge. If
you return defective parts, transportation charges must be prepaid by you. RA will return replacement parts to the
original retail purchaser, freight or postage prepaid. This Limited Warranty does not cover any failures or operating
difculties due to accident, abuse, misuse, alteration, misapplication, improper installation or improper maintenance
or service by you or any third party, or failure to perform normal and routine maintenance on the product as set out in
this owner’s manual. In addition, the Limited Warranty does not cover damage to the nish, such as scratches, dents,
discoloration, rust or other weather damage, after purchase.
This Limited Warranty is in lieu of all other express warranties. RA disclaims all warranties for products that are
purchased from sellers other than authorized retailers or distributors, including the warranty of merchantability or the
warranty of tness for a particular purpose. RA ALSO DISCLAIMS ANY AND ALL IMPLIED WARRANTIES, INCLUDING
WITHOUT LIMITATION THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
RA SHALL HAVE NO LIABILITY TO PURCHASER OR ANY THIRD PARTY FOR ANY SPECIAL, INDIRECT, PUNITIVE,
INCIDENTAL, OR CONSEQUENTIAL DAMAGES. RA further disclaims any implied or express warranty of, and assumes
no responsibility for, defects in workmanship caused by third parties. This Limited Warranty gives the purchaser
specic legal rights; a purchaser may have other rights depending upon where he or she lives. Some jurisdictions
do not allow the exclusion or limitation of special, incidental or consequential damages, or limitations on how long a
warranty lasts, so the above exclusion and limitations may not apply to everyone. RA does not authorize any person or
company to assume for it any other obligation or liability in connection with the sale, installation, use, removal, return,
or replacement of its equipment, and no such representations are binding on RA.
Manufactured in China for: RevoAce Inc. Limited
Hong Kong, China
1.800.694.0013 • [email protected]
9:00 am to 5:00 pm eastern time, Monday to Friday.

6
1
15
31
23
26
29
19
36
10
4
7
11
20
21
25
8
30
30
2
17
18
9
5
13
13
14
14
27
16
Expanded View
12
22
28
24

7
AScrew M4x10 Nickel Plated Phillips Truss Head 4 pcs
BScrew M6x16 Nickel Plated Phillips Truss Head 10 pcs
CBolt M6x16 Nickel Plated Phillips Hex Head 8 pcs
DNut M10 Nickel Plated 2 pcs
EWing Nut M6 Nickel Plated 2 pcs
FWasher ø6.5x18 Nickel Plated 6 pcs
GWasher ø6.5x22 Nickel Plated 2 pcs
HLock Washer ø6.5 Nickel Plated 8 pcs
1Warming Rack G1025-010
2Cooking Grid G1329-010
3Heat Plate (3) G1203-010
4Lid Handle G1205-020
5Temperature Gauge B0104-JRE
6Lid* G1429-010
7Top Hinge (2)* B0120-A01
8Bottom Hinge (2)* G0822-010
9Tool Hook G1128-010
10 Left Side Shelf G1329-020
11 Grill Body Assembly* G1329-030
12 Main Burner (3)* G1329-040
13 Control Knob Bezel (4)* G1429-020
14 Control Knob (4) G1429-030
15 Grease Cup Support B0220-B02
16 Grease Cup B0219-A01
17 Regulator / Hose Assembly* B0308-A18
18 Right Side Shelf G1329-050
19 Side Burner Grid B0404-C03
20 Side Burner G1329-060
21 Left Cart Frame G1729-040
22 Foot (2) G1329-070
23 Rear Panel Support G1729-080
24 Cart Frame Support Wire (2) G1729-090
25 Front Panel G1429-050
26 LP Gas Tank Retainer Wire G1329-100
27 Right Cart Frame G1729-060
28 Lighting Rod* B0223-D02
29 Axle G1429-060
30 Wheel (2) B0302-F06
31 Handle Heat Plate G1329-110
* Pre-assembled
Hardware
Parts List
Tools Required for Assembly (Included)
#2 Phillips Head Screwdriver 1 pc
M10 Wrench 2 pcs

8 Assembly Instructions
DO NOT RETURN TO PLACE OF PURCHASE.
1
Attach Left Cart Frame
4
Attach Front Panel
3
Assemble Feet
2
Please have your owner’s manual and model number available
for reference.
Note: The model number is printed on a label which can be
found on the inside door, back or side of the cart assembly.
Assembly Tips:
1. Select an area where you will assemble this product.
To protect components, choose a smooth surface that’s
free of cracks or openings.
2. Spread out all parts.
3. Tighten all hardware connections by hand first. Then,
before completing each step, go back and fully tighten
all hardware. Be careful not to over-tighten. That could
damage surfaces or strip threads.
4. For best results, complete each step in the order
presented.
To complete assembly you will need:
• (1) Leak detection solution (instructions on how to
make the solution are included in the “Operating
Instructions” section of this manual).
• (1) Precision-filled LP gas grill tank with Acme Type 1
external threaded valve connection (standard grill size)
(not included).
Typical assembly is approximately one hour.

9
Attach Rear Panel Support
5
Attach Cart Frame Support Wire (2)
6
Attach Lid Handle Heat Plate, Handle and
Temperature Gauge
8
Attach Axle, Wheels and LP Gas Tank Retainer
Wire
7
Ex 2
Hx 2
Bx 2
Gx 2
D
H
E
G
B
1
2
Dx 2

10
Note: Leave 5 mm of bolt threads exposed. Note: Leave 5 mm of bolt threads exposed.
10
Attach Grill Body Assembly
9
12
11
Attach Tool Hook
Attach Right Side Shelf
Attach Left Side Shelf
Hx 6
Bx 6
Bx 2
Fx 6
B
B
CC
22
11
5mm
5mm
CC
HF
Cx 4 Cx 4

11
Note: Leave 5 mm of bolt threads exposed.
14
Attach Control Knob Bezel and Side Burner
Valve
13
15
Insert Side Burner, Igniter Wire and Side Burner
Grid
Insert Heat Plates and Cooking Grid
16
Attach Warming Rack and Control Knobs
A
A
11
22
33
5mm
Ax 2 Ax 2

12
Insert Grease Cup Support and Grease Cup
17

13
Operating Instructions
To operate, you will need one precision-filled standard grill LP gas tank with external valve threads.
20 lb
9 Kg
17.9 in. / 45.5 cm
12.2 in. / 31 cm
WLP gas tank must be properly disconnected and
removed prior to moving this grill.
CAUTION
Securing LP Gas Tank
Secure tank by sliding the tank retainer wire over shoulder of LP gas
tank.
Inserting LP Gas Tank
Place precision-filled LP gas tank upright into the notches in the right
cart frame so the tank valve is facing the gas line connection.
Connecting LP Gas Tank
1. Before connecting, be sure there is no debris caught in the head
of the LP gas tank, head of the regulator valve or in the head of
the burner or burner ports.
2. Connect regulator/hose assembly to tank by turning knob
clockwise until it stops.
Disconnecting LP Gas Tank
1. Before disconnecting, make sure the LP gas tank valve is
“CLOSED.”
2. Disconnect regulator/hose assembly from LP gas tank by
turning knob counterclockwise until it is loose.
WCAUTION: LP gas tank must be properly
disconnected and removed prior to moving this
grill.
3. Place the protective cap cover on the LP tank and store the tank
outdoors in a well ventilated area out of direct sunlight.

14
Figure 1：Main Burners
Burner/
Venturi Tube
LP Gas
Valve with
Orice
LP Gas
Connection
Figure 2: Side Burner
LP Gas
Connection
Valve Soft Pipe
Connection
LP Gas
Valve with
Orice
Burner/
Venturi
Tube
Figure 3
Figure 4
X
XX
XX
Figure 5
Lighting
Rod
Match
Operating Instructions
Checking for Leaks
Burner Connections
1. Make sure the regulator hose and valve connections are securely fastened to the burner and the
tank.
2. Visually check the connection between the burner/venturi tube and orifice.
3. Make sure the burner/venturi tube fits over the orifice.
WWARNING: Failure to inspect this connection or follow these instructions
could cause a fire or an explosion which can cause death, serious bodily
injury or damage to property.
4. Please refer to diagram for proper installation (Figure 1).
5. If the burner/venturi tube does not rest flush to the orifice, as shown.
Tank/Gas Line Connection
1. Make 2-3 oz. of leak detection solution by mixing one part liquid dishwashing soap with three
parts water.
2. Make sure control knobs are in the “ OFF” position (Figure 3).
3. Connect LP gas tank per “Installing LP Gas Tank” section.
4. Turn LP gas tank valve to “OPEN.”
5. Spoon several drops of solution, or use a squirt bottle, at all “X” locations (Figures 1, 2 and 4).
a. If any bubbles appear, turn LP gas tank valve to “CLOSED,” reconnect and re-test.
b. If you continue to see bubbles after several attempts, turn LP gas tank valve to “CLOSED” and
disconnect LP gas tank, per “Disconnecting LP Gas Tank” section.
c. If no bubbles appear after one minute, turn LP gas tank valve to “CLOSED,” wipe away solution
and proceed.
Operating Main Burners
First Use
1. Make sure all labels, packaging and protective films have been removed from the grill.
2. Remove manufacturing oils before cooking on this grill for the first time by operating
the grill for at least 15 minutes on (HIGH) with the lid closed. This will “heat clean” the
internal parts and dissipate odors.
Lighting
WCAUTION: Keep outdoor gas cooking appliance area clear and free from
combustible materials, gasoline and other flammable vapors and liquids.
WCAUTION: Do NOT obstruct the flow of combustion and ventilation air.
WCAUTION: Check and clean burner/venturi tubes for insects and insect
nests. A clogged tube can lead to a fire.
WCAUTION: Attempting to light the burner with the lid closed may cause an
explosion.
1. Open lid.
2. Check for obstructions of airflow to the burners. Spiders, insects and webs can clog the burner/
venturi tube. A clogged burner tube can lead to a fire.
3. All control knobs must be in the “ OFF” position (Figure 3).
4. Connect LP gas tank per “Installing LP Gas Tank” section.
5. Turn LP gas tank valve to “OPEN.”
6. Push and turn control knob to (HIGH). the burner should light. Repeat up to three times.
7. If ignition does not occur in 5 seconds, turn burner control knob “ OFF,” wait 5 minutes, and
repeat lighting procedure.
8. If igniter does not light burner, use a lit match secured with the lighting rod (included with grill) to
light burners. Access the burners through the cooking grid and heat plates. Position lit match near
side of burner (Figure 5).
Important: Always use the lighting rod (included) when lighting burners with a match.
9. After lighting, observe the burner flame. Make sure all burner ports are lit and flame height
matches illustration (Figure 6).
Note: Each burner lights independently - repeat steps 5-9 for the other burners.

15
Figure 6
Burner
Flame Slight
Yellow
Slight
Blue
Dark
Blue
Operating Side Burner
NOTE: Side burner can be used while main burners are operating.
Never use side burner as a grill.
WCAUTION: Maximum weight for side burner and side shelf is 33 lbs.
WCAUTION: Using pots larger than 6 quarts in capacity could exceed weight limit of the side burner shelf,
resulting in failure of grill cart components.
WCAUTION: Do NOT lean on the side burner shelf.
WCAUTION: Attempting to light the burner with the lid closed may cause an explosion.
Lighting
1. Open lid.
2. Check for obstructions of airflow to the burners. Spiders, insects and webs can clog the burner/venturi tube A clogged burner tube can
lead to a fire.
3. Control knob must be in the “ OFF” position (Figure 3).
4. Connect LP gas tank per “Installing LP Gas Tank” section.
5. Turn LP gas tank valve to “OPEN.”
6. Push and turn control knob to (HIGH). The burner should light. If not, repeat up to three
times.
7. If ignition does not occur in 5 seconds, turn burner control knob “ OFF,” wait 5 minutes and
repeat lighting procedure.
8. If igniter does not light burner, use a lit match secured with the lighting rod (included with
grill) to light burners. Position the lit match near side of the burner (Figure 7).
Important: Always use the lighting rod (included) when lighting burner with a match.
Figure 7
Lighting
Rod
Match
Operating Instructions (Continued)
WCAUTION: If burner flame goes out during operation, immediately turn the control knobs to the “ OFF”
position, LP gas tank valve “CLOSED” and open lid to let the gas clear for 5 minutes before re-lighting.
Turning Off
1. Turn LP gas tank valve to “CLOSED.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the LP gas is burned.
3. Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
Controlling Flare-ups
WCAUTION: Putting out grease fires by only closing the lid is not possible.
1. If a grease fire develops, turn control knobs to the “ OFF” position and
LP gas tank valve “CLOSED.” Do NOT use water on a grease fire. This can
cause the grease to splatter and could result in serious burns, bodily
harm or other damage.
2. Do NOT leave grill unattended while preheating or burning off food residue on (HIGH). If grill has not
been cleaned, a grease fire can occur.
WWARNING: When cooking, fire extinguishing materials should be readily accessible. In the event of an oil/
grease fire, use type BC dry chemical fire extinguisher or smother with dirt, sand or baking soda. Do NOT
attempt to extinguish with water.
Flare-ups are a part of cooking meats on a grill and add to the unique flavor of grilling.
Excessive flare-ups can over-cook your food and be dangerous.
Important: Excessive flare-ups result from the build-up of grease in the bottom of your grill.
If a grease fire occurs, close the lid AND turn the control knob(s) to “ OFF” until the grease burns out. Be careful when opening the lid as
sudden flare-ups may occur.
If excessive flare-ups occur, do NOT pour water onto the flames.
Minimize Flare-ups:
1. Trim excess fat from meats prior to cooking.
2. Cook high fat content meats on (LOW) setting or indirectly.
3. Ensure that your grill is on a hard, level, non-combustible surface and the grease is allowed to drain into grease receptacle.

16
9. After lighting, observe the burner flame. Make sure all burner ports are lit and flame height matches illustration (Figure 6).
WCAUTION: If burner flame goes out during operation, immediately turn the control knob to the “ OFF”
position and LP gas tank valve “CLOSED” and open lid to let the gas clear for 5 minutes before re-lighting.
Turning Off
1. Turn LP gas tank valve to “CLOSED.”
2. Turn control knob clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the LP gas is burned.
3. Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
Cooking
1. Open lid and ignite the side burner per “Lighting” instructions.
2. Adjust control knob to desired flame height.
3. Place pan on center of grid.
4. Cook and adjust temperature as needed.
5. Turn grill off per “Turning Off” instructions.
Operating Instructions (Continued)
Cleaning and Care
WCAUTION:
1. All cleaning and maintenance should be done when grill is cool and with the fuel supply disconnected.
2. Do NOT clean any grill part in a self-cleaning oven. The extreme heat will damage the finish.
3. Do NOT enlarge valve orifices or burner ports when cleaning the valves or burners.
Notices
1. This grill should be thoroughly cleaned and inspected on a regular basis.
2. Abrasive cleaners will damage this product.
3. Never use oven cleaner to clean any part of grill.
Before Each Use:
1. Keep the grill area clean and free from any combustible materials, gasoline, and other flammable vapors and liquids.
2. Do NOT obstruct the flow of the combustion of LP gas and the ventilation of air.
3. Keep the ventilation opening(s) of the LP gas tank area free and clear from debris.
4. Visually check the burner flames to make sure your grill is working properly (Figure 8 ).
5. See sections below for proper cleaning instructions.
6. Check for obstructions of airflow to the burners. Spiders, insects and webs can clog the burner/venturi tube. A clogged burner tube can
lead to a fire.
Cleaning Surfaces
1. Wipe surfaces clean with mild dishwashing detergent or baking soda mixed with water.
2. For stubborn surfaces, use a citrus-based degreaser and a nylon scrubbing brush.
3. Rinse clean with water.
4. Allow to air dry.
Cleaning Main Burners
1. Turn LP gas tank valve to “CLOSED.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the gas is burned.
3. Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
4. Remove cooking grids and heat plates.
5. Remove burners by removing the fasteners, which secure the burners to the grill bottom.
6. Lift burners up and away from gas valve orifice.
7. Disconnect wire from spark electrode.

17
Cleaning Side Burner
1. Turn LP gas tank valve to “CLOSED.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the gas is burned.
3. Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
4. Remove side burner grid.
5. Remove burner by removing the screws that secure the burner to the side shelf.
6. Lift burner up and away from gas valve orifice.
7. Clean venturi of burner with small bottle brush or compressed air.
8. Remove all food residue and dirt from burner surface.
9. Clean any clogged ports with a stiff wire (such as an opened paper clip).
10. Inspect burner for any damage (cracks or holes). If damage is found, replace with new
burner from manufacturer.
11. Re-install burner(s). Checking to insure that gas valve orifice is correctly positioned
inside each burner/venturi tube. Also, check position of spark electrode.
12. Replace cooking grid(s).
13. Connect LP gas tank per “Installing LP Gas Tank” section.
14. Perform leak test per “Checking for Leaks” section.
Figure 8
Burner Flame Conditions
Use this chart to see if your burners need to be
cleaned.
1-2 in. /
25.4 - 50.8 mm
Normal: Soft blue flames with yellow
tips between 1 in. - 2 in. height.
Needs cleaning: Noisy with hard
blue flames.
Has to be replaced: Wavy with
yellow flames.
Cleaning and Care (Continued)
8. Clean venturi of each burner with small bottle brush or compressed air.
9. Remove all food residue and dirt from burner surface.
10. Clean any clogged ports with a stiff wire (such as an opened paper clip).
11. Inspect burners for any damage (cracks or holes). If damage is found, replace with new
burner(s) from manufacturer.
12. Re-install burner(s). Checking to insure that gas valve orifice is correctly positioned
inside each burner/venturi tube. Also, check position of spark electrode.
13. Replace heat plate(s) and cooking grid(s).
14. Connect LP gas tank per “Installing LP Gas Tank” section.
15. Perform leak test per “Checking for Leaks” section.
Before Storing
1. Turn LP gas tank valve to “CLOSED.”
2. Turn all control knobs clockwise to the “ OFF” position.
Note: A “poof” sound is normal as the last of the gas is burned.
3. Disconnect LP gas tank per “Disconnecting LP Gas Tank” section.
4. Clean all surfaces.
5. Lightly coat the burner(s) and cooking grid(s) with cooking oil to prevent excess rusting.
6. If storing the grill indoors, disconnect the LP tank per “Disconnecting LP Gas Tank” section.
7. Place the protective cap cover on the LP tank and store the tank outdoors in a well-ventilated area out of direct sunlight.
8. If storing the grill indoors, cover the grill and store in a cool dry place.
9. If storing the grill outdoors, cover the grill with a grill cover for protection from the weather.

18
Troubleshooting
Problem Possible Cause Prevention/Cure
Burner will
not light using
igniter
• LP gas tank valve is closed
• Make sure regulator is securely attached to the LP gas tank
per “Installing LP Gas Tank,” then turn LP gas tank valve to
“OPEN”
• LP gas tank is low or empty • Exchange, refill or replace LP gas tank
• LP gas leakage
• Turn LP gas tank valve to “CLOSED”
• Wait 5 minutes for gas to clear
• Follow “Checking for Leaks” section
• Wires or electrode covered with cooking residue • Clean wire and/or electrode with rubbing alcohol
• Electrode and burners are wet • Wipe dry with cloth
• Electrode cracked/broken - sparks at crack • Replacement part(s) may be needed
• Wire loose or disconnected • Reconnect wire or replacement part(s) may be needed
• Wire is shorting (sparking) between ignitor and electrode • Replacement part(s) may be needed
• Bad igniter • Replacement part(s) may be needed
Burner will
not light with
match
• No gas flow
• Check if LP gas tank is empty
A. If empty, exchange, refill or replace LP gas tank
B. If LP gas tank is not empty, refer to “Sudden drop in gas
ow or reduced ame height” (see below)
• LP gas tank is low or empty • Exchange, refill or replace LP gas tank
• LP gas
• Turn LP gas tank valve to “CLOSED”
• Wait 5 minutes for gas to clear
• Follow “Checking for Leaks” section
• Coupling nut and regulator not fully connected
• Turn the coupling nut about one-half to three-quarters
additional turn until solid stop. Tighten by hand only - do NOT
use tools
• Obstruction of gas flow • Clear burner/venturi tube
• Check for bent or kinked hose
• Disengagement of burner to valve • Reengage burner and valve
• Spider webs or insect nest in venturi • Clean burner/venturi tube
• Burner ports clogged or blocked • Clean burner ports
Sudden drop
in gas flow or
reduced flame
height
• Out of gas • Exchange, refill or replace LP gas tank
• Overfilling prevention device may have been activated
1. Turn control knobs to “ OFF”
2. Wait 30 seconds and light grill
3. If ames are still too low, reset the overlling prevention
device:
a. Turn control knob(s) “ OFF”
b. Turn LP gas tank valve to “CLOSED”
c. Disconnect regulator
d. Turn control knobs to (HIGH)
e. Wait 1 minute
f. Turn control knobs to “ OFF”
g. Reconnect regulator and leak check connections,
being careful not to fully open valve
h. Light grill per “Lighting” section
Irregular flame
pattern, flame
does not run
the full length
of burner
• Burner ports are clogged or blocked • Clean burner ports
Flame is yellow
or orange
• New burner may have residual manufacturing oils • Burn grill for 15 minutes on (HIGH) with the lid closed
• Spider webs or insect nest in venturi • Clean venturi
• Food residue, grease, etc. on burners • Clean burner
• Poor alignment of valve to burner/venturi tube • Ensure burner/venturi tube is properly engaged with valve
Flame goes out
• High or gusting winds • Do not use grill in high winds
• Low on LP Gas • Exchange, refill or replace LP gas tank
• Overfilling prevention device may have been activated • Refer to “Sudden drop in gas flow or reduced flame height”
(see above)

19
Troubleshooting (Continued)
Flare-up
• Grease buildup • Remove and clean all grill parts per “Cleaning and Care”
section
• Excess fat in meat • Trim fat from meat before grilling
• Excessive cooking temperature • Adjust to lower cooking temperature
Persistent
grease fire • Grease trapped by food buildup around burner system
• Turn control knobs to “ OFF”
• Turn LP gas tank valve to “CLOSED”
• Leave lid in closed position and let re burn out
• After grill cools, remove and clean all parts per “Cleaning
and Care” section
Flashback
(fire in burner
tube(s))
• Burner and/or burner/venturi tube are blocked
• Clean burners and/or burner/venturi tube
Inside of lid is
peeling (like
paint peeling)
• Baked on grease buildup has turned to carbon and is
flaking off. • Clean all grill parts per “Cleaning and Care” section.
Problem Possible Cause Prevention/Cure

20
