Contents
Walldisplay 217
General & Insatllation advice
Savety Guidelines
Feller EDIZIOdue 4217.M
Advice & Installing
Connection plan 4217.M
GIRA JUNG Merten M217
Advice & Installing
Available Designs
Connection plan M217
Installation
Connection plan display/ keypad
Configuration
M217 IR receiver on/off
Adressing 217
A/B operation
Adress settings
M217 Menu Control
Operating with Softkeys
Display contrast
Main menu
Timer menu
Timer programming
Sleep function
Music Server
A) Selection by ABC..
B) Selection by Album
C) Selection by Artist
D) Selection by Genre
E) Selection by Playlist
Jump to track
Repeat
Shuffle
Guarantee and Delivered items
Care
Technical data
1-A
2-A
3-A
1-B
1-B
2-B
3-B
1-C
1-C
2-C
2-C
3-C
4-C
5..-8-C
9-C
9-C
9-C
10-C
11-C
11..18-C
18-C
19-C
20-C
20-C
21-C
22-C
23-C
24-C
25-C
25-C
26-C
26-C
27-C

Walldisplay 217 Re:control
Walldisplay 217
Please read these instruction
through completely and care-
fully before setting the unit up.
General
Ideally, the wall display is
combined with the M218 keypad
to enable simply and logical
operation of your music equip-
ment.
The four softkeys are assigned
different operating functions,
depending on the menu selection
The Main menu shows infor-
mation about the current
program, e.g. Tuner, CD. The
basic operations such as CD,
Tuner, Track+-, Volume, etc. are
carried out using a connected
keypad or through a Revox IR
remote control.
The Timer menu organises timed
processes in the Multiroom
system, e.g. time, day, volume,
source, etc., while the Server
menu allows you to control the
Music server.
The IR receiver that is integrated
in the display transfers the control
signals to the Multiroom
equipment.
M217 Installation advice
The ideal installation height for
the M217 Display is 140 ± 10 cm
(55 ± 4 in) measured to the
centre of the display.
This results in a good viewing
angle, even for slightly shorter
people, and a comfortable
operation of the combination of
M217 display and M218 keypad.
The M218 keypad should be
installed below the M217 Display.
Multiroom Planner
The complete addressing of
additional room amplifiers and the
corresponding wall displays can be
calculated using the free-of-charge
Multiroom Planner software from
Revox. With this software, you can
plan and calculate the whole house
requirements in the shortest time. In
addition, you can present and save
your data very easily with the
backup and print functions. You can
get the software from our download
area on www.revox.de
N
N
NE
E
EW
W
W

Walldisplay 217 Re:control
Safety Guidelines
An incorrect installation of this
device in an environment with
low voltage devices (230V) can
cause serious health issues and/
or material damage.
This device should only be
connected to extra low voltage
and never to low voltage (230V)
circuits .
The product should only be
installed, connected or removed
by qualified personnel. Qualified
personnel are people who,
through their training,
experience and knowledge of
corresponding norms, directives
and accident prevention
guidelines, are authorised to
carry out the required activities
and who can recognise and
avoid potential dangers.
The details and instructions
contained in this Installation
manual must always be taken
into account to prevent danger
and damage.
Installation
Installation of the wall display
in combination with a low
voltage device (power
connection) should only be
carried out if you are certain
that the unit is isolated from
the power source.
Installation should be carried out
in accordance with the valid
national domestic installation
guidelines, e.g. NIN.
In particular, the directive NIN
4.9.1.ff is valid if the wall display is
to be combined with a low voltage
device with power connection.
Combinations with low voltage
devices are only permitted if
these devices also have a simple
basic insulation.

Re:control
1-A
Feller EDIZIOdue 4217.M
The Swiss company Feller offers
the 4217.M wall display from their
EDIZIOdue series, which is
compatible with the REVOX
Multiroom system. All the colours
from the EDIZIOdue series are
available.
The wall display should be
installed in combination with the
4218-M keypad. A connection
cable is supplied with the Feller
4217/4218.XXX.2x1 wall
combination.
Combi solution
4217.M + 4218.M
Advice
The IR receiver must be activated
if the wall display is used on its
own without a 4218.M keypad. In
this case, the DIL switch 1 on the
back of the wall display must be
switched on (IR on).
Revox recommends the use of
ITPlus® RJ45 sockets for the
interface to theM51 main system
and/ or the M219 additional room
amplifier. Single socket = 1198-
118.XXX.ITS; double socket =
1198-428.XXX.ITS.
The 1900-0.XXX throughway
boxes are recommended for
speaker cable.
Please note
The EDIZIODue wall display may
not be used to switch 230V low
voltages.

Re:control
2-A
1 2 3 4 5 6
Installation procedure
You should avoid
applying any pressure
to the display during
or after installation.
1) Install the mounting fixture
(5) with the fixing plate (4)
onto the recessed box or the
surface mounted box on the
wall.
2) Strip the insulation off the
U72 installation cable and
feed it through the mouting
fixture (5).
3) Connect the cable to the
screwed terminal block.
4) Connect the terminal block
with the print connector on
the back of the operator
panel (1).
5) Locate the operator panel
(1) with its frame (3) onto the
mounting fixture (5), so that
the locating springs (2) on
the panel (1) line up with the
slots in the mounting fixture.
6) Press the operator panel (1)
onto the mounting fixture (5)
until the springs clip into
place.

Re:control
3-A
Connection plan 4217.M
Setup and operation
The wall display must be
connected to the M51 Revox
source management or a Revox
M219 Additional room amplifier
for setup.
Advice
Information about and support for
setup and operation can be found
in the Revox manuals. Your
contact point for further questions
is your nearest Revox dealer
Revox Switzerland AG, 8105
Regensdorf, www.revox.ch.
Technical data
Technical data
Build-in depth 20 mm
Protection IP20 in accordance
with IEC529;
Dry installation
Temperatures Operation:
-5°C to +45°C
Storage:
-25°C to +70°C
Cable Installation cable
U72 ABG
1 x 4 x 0.5mm²
DIL switches Factory settings
1: IR off
2: AB operation off
3: Address off
4: Address off

M217 Re:control
1-B
Revox offers the M217 for the
Central European market in
different designs from the Gira,
Jung and Merten companies. You
can see from the list on the right,
which designs are available from
each of the manufacturers.
The wall display should be
installed in combination with the
M218 wall-mounted operating
panel.
A connection
cable is supplied
with the M217/
M218 combination
solution.
Combination solution
M217 + M218
Available designs
GIRA Standard 55
GIRA E2
GIRA Event
GIRA Esprit
Colours: All colours
JUNG CD 500 / universal
JUNG CD plus
JUNG LS990 / LS plus
Colours: Alpine white
Other colours and designs are available
on request at additional cost, if applicable.
Merten M-SMART
Merten M-ARC
Merten M-PLAN I/II
Merten M-PLAN glass frame
Colours: Polar white
Other colours and designs are available
on request at additional cost, if applicable.

M217 Re:control
2-B
Installation procedure
1) Screw the mounting fixture
(4) onto the recessed or
surface mounted box.
2) Strip the insulation off the
installation cable and feed it
through the mounting fixture
(4).
3) Connect the cable to the
Phoenix screwed terminal
block.
4) Connect the terminal block
with the print connector on
the back of the operator
panel (1).
5) Locate the operator panel (1)
with its frame (3) onto the
mounting fixture (4), so that the
clip connectors (2) on the panel
(1) line up with the cut-out (5) in
the mounting fixture (4).
6) Press the operator panel (1)
onto the mounting fixture (4)
until the clip connectors clip
into place.
You should
avoid applying
any pressure
to the display
during or after
installation.

M217 Re:control
3-B
Connection plan M217
Setup and operation
The wall display must be
connected to the M51 Revox
source management or a Revox
M219 Additional room amplifier
for setup.
Advice
Information about and support for
setup and operation can be found
in the Revox manuals. Your
contact point for further questions
is your nearest Revox dealer or
Revox GmbH, tel: [phone]-
8704-0, www.revox.de.
Technical data
Technical data
Build-in depth 20 mm
Temperatures Operation:
-5°C to +45°C
Storage:
-25°C to +70°C
Cable Installation cable
U72 ABG
1 x 4 x 0.5mm²
DIL switches Factory settings
1: IR off
2: AB operation off
3: Address off
4: Address off

M217 Display unit Re:control
1-C
2
1

The cabling for the combination
of the 217 display and the 218
keypad should be done as
shown in the drawing. With the
combination solution, the 218
keypad only has a connection to
the 217 display. There is no
direct connection to the
Additional room amplifier.
Connection comes pre-
assembled with the combination
solution.

The connection is made
according to the Chapters A
and Bin the Installation manual.
Tip
Before laying cable, you
should check whether this cable
is suitable for an RJ11 socket.
Cabling the display to the wall-mounted keypad

M217 Display unit Re:control
2-C
M217 Configuration
The basic settings for the M217
are made with the four DIL
switches on the back of the unit.
Use a small screwdriver or the
point of a ballpoint pen to set
the switches.
Important
The addressing of the M217
and the M219 must be setup
correctly to ensure error free
operation. The configuration
must be done while the unit is
removed from the power,
otherwise any changes made
will not be effective.
NO Function Factory setting
1 M217 IR eye on/off On
2 A/ B operation Off
3 M217 Address Off
4 M217 Address Off
Please note:
ON is with the
switch in the
upper position.
M217 Infrared receiver on/off
If you are combining the M217 display with the M218 remote control,
which also has an IR receiver, one of the two IR receivers must be
disabled, as otherwise IR commands will be carried out double.
In some cases, e.g. in buildings with glass internal walls, it can be
advantageous to switch of the IR receiver on the M217, in order to
avoid conflicts with other devices.
The only switch that can be set during operation of the unit is DIL
switch 1for the IR receiver.
IR Function DIL switch
1
DIL position
IR - On On
1
IR - Off Off
1
With the M217, the integrated IR receiver is located in the lower
right-hand display field.

M217 Display unit Re:control
3-C
M217 Address setting
Connection to the M51
If the M217 is connected directly to the M51 the address setting is not
significant. The M51 recognises the M217 automatically.
Connection to the M219 Additional room amplifier
If, on the other hand, the M217 is to be connected to a M219 Additional
room amplifier, address setting is very important. The M217 address
defines which M219 should be communicated with. In this way, the M217
address is set through DIL switches 3 & 4, based on the M219’s
address.
The 218 keypad is not taken into account during addressing as it has no
own address. The 218 keypad can always be connected to a M219
Additional room amplifier or a 217 display.
Example: If the M219 has address 2, address 2 must also be set at the
M217 Display.
Address DIL switch
3
DIL switch
4 DIL position
1 Off Off
43
2 Off On
43
3 On Off
43
4 On On
43
Within in one zone, all 217s must have different addresses as otherwise
there can be communication problems. The diagrams shown from Page
5-C cover all combinations of the 217 with the M219 Additional room
amplifier. In order to ensure problem-free operation, the build up of the
individual multiroom zones must be carried out in this way
The maximum number of M217 in any one zone is restricted to 4.
The revisal of a correct addressing is made in the Setup menu of the
M51, category Multiroom / Version. All attached devices (M219 and/or
M217) must be listed in the respective zone.
Use the free-of-charge Multiroom Planner software
from Revox for the addressing. You will find more
about this on Page 1 or under www.revox.de.

M217 Display unit Re:control
4-C
A/B Operation: 2 displays control one Additional room amplifier
The Multiroom system from Revox allows one M219 to be controlled by
two 217s, the so-called A/B operation. In this way, for example, an 217
could be installed on each side of the bed.
In A/B operation, the second 217 has the same address set through DIL
switches 3 & 4 as the first 217, but with DIL switch 2 activated. In this
way, the first 217 works in Aand the second in Boperation.
This setting is defined through DIL switch 2.
Operation DIL switch
2
DIL position
A Off
2
B On
2
Both M217 Displays are simply connected in parallel to the M219.
Exception: No A/B operation is possible if connection is made to the M51

M217 Display unit Re:control
5-C
M217 Address setting
The following 7 layouts show
the possible combinations of the
M217 with the M219 Additional
room amplifier in one zone.
The combination can be
different in each zone.
The address and the correct
DIL switch settings for that
address are always shown next
to the M217 or the M219
8 xM219 - 0 xM217
7 x M219 - 1 xM217
6 xM219 - 2 xM217
5 xM219 - 3 xM217
4 xM219 - 4 xM217
4 xM219 - 2+2 xM217
4 xM219 - 2+1+1 xM217
Please note
A maximum of 8 addresses
can be defined per zone.
8 xM219 - 0 xM217

M217 Display unit Re:control
6-C
7x M219 - 1 xM217 6 xM219 - 2 xM217

M217 Display unit Re:control
7-C
5 xM219 - 3 xM217 4 xM219 - 4 xM217

M217 Display unit Re:control
8-C
4 xM219 - 2+2 xM217 4 xM219 - 2+1+1 xM217

M217 Display unit Re:control
9-C
M217 Menu control
The M217 menu fulfills three
tasks.
The first task is the display of
information about the current
music program. This can, for
example, be info about the
tuner or the CD that is currently
playing.
The second task is the
operation of the timer, including
the Sleep function. The M217
offers 4 independent timers for
each room.
The third task is the
operation of the music server
that can be integrated in the
Multiroom system.
This graphic shows the M217 display
while the tuner is active
Operating with Softkeys
Softkeys are used for control so
that the M217 display remains
clear to use, in spite of the large
number of options available.
A Softkey is a key that can be
assigned different functions
depending on which menu is
currently active. This avoids an
overcrowded display as only
current important functions are
displayed.
Furthermore, the Revox-menu
control is designed in such a
clear and simple way as to
make the operation of the M217
intuitive.
Setting the display contrast
The contrast of the display is
adjusted by Revox to an optimal
reading angle.
Depending upon installation
position it can occur however
that a stronger or weaker
contrast attitude supplies the
better reading off result.
This contrast attitude can later
be made with the help of the
softkeys in the Standby or
operating mode (except server
operation).
