Reyee Ruijie RG-NBS3100 Series Installation and operating manual

Ruijie RG-NBS3100 Series Switches
RG-NBS3100-24GT4SFP&RG-NBS3100-24GT4SFP-P&RG-NBS3100-
8GT2SFP&RG-NBS3100-8GT2SFP-P
Hardware Installation and Reference Guide
surge
DocumentVersion:V1.1
Date: 2022-11-16
Copyright © 2023RuijieNetworks

Copyright
Copyright © 2022RuijieNetworks
All rights arereservedin this documentand this statement.
Without the priorwritten consentof Ruijie Networks,anyorganization orindividual shallnotreproduce,extract,
back up,modify, or propagate the content of this document in anymanner or in anyform, or translate it into other
languages orusesomeorallparts of the documentforcommercialpurposes.
,, andother Ruijienetworks logos aretrademarks ofRuijieNetworks.
All other trademarks or registered trademarks mentioned in this document are owned bytheir respective owners.
Disclaimer
The products,services, or features you purchase aresubject to commercial contracts and terms, andsome orall
of the products,services, or features described in this documentmaynot be available for you to purchase or use.
Except for the agreementinthe contract, RuijieNetworks makes noexplicitorimplicitstatementsorwarranties
with respectto the contentof this document.
The content of this documentwill beupdated from time to timedue toproduct versionupgrades or other reasons,
RuijieNetworks reserves the rightto modifythe content of the documentwithoutanynoticeor prompt.
This manual is designed merelyas auserguide.RuijieNetworks has tried its bestto ensuretheaccuracyand
reliabilityof the content whencompilingthis manual,butit does notguarantee that the content of the manual is
completelyfree of errors or omissions,andallthe information in this manualdoesnotconstituteanyexplicit or
implicitwarranties.

Preface
Thank you for usingourproducts.This manualwillguideyouthroughtheinstallationofthe device.
This manual describesthefunctionalandphysicalfeatures andprovides thedevice installation steps,hardware
troubleshooting,moduletechnicalspecifications,andspecifications andusageguidelines forcables andconnectors.
Audience
It is intended for the users who have some experience in installing and maintaining network hardware. At the same time, it
is assumedthattheusers arealreadyfamiliarwiththerelatedterms andconcepts.
Obtaining Technical Assistance
RuijieNetworks website:https://www.ruijienetworks.com/
Technicalsupportwebsite:https://www.ruijienetworks.com/support
Caseportal:https://caseportal.ruijienetworks.com
Community:https://community.ruijienetworks.com
Technicalsupportemail:[e-mail]
Skype: [e-mail]
Related Documents
Document
Description
Configuration Guide
Describes networkprotocolsandrelated mechanismsthatsupportedbythe
product, with configurationexamples.
CommandReference
Describes therelatedconfigurationcommands,includingcommandmodes,
parameterdescriptions,usageguides,andrelatedexamples.
Conventions
1. Signs
The signs usedin this documentaredescribedas follows.
Warning
An alert that calls attention to importantrules andinformation thatif not understoodorfollowed can resultin
data loss orequipmentdamage.
Caution
An alert that calls attentionto essential information thatifnot understoodorfollowedcan resultin function
failure or performance degradation.
Note
An alert that contains additional orsupplementaryinformationthatif not understoodorfollowed will notleadto
serious consequences.

Specification
An alert that contains a description ofproductor versionsupport.
2. Note
This manualprovides installation steps,troubleshooting,technical specifications,andusageguidelines for
cables and connectors. Itis intended for users whowant to understand theabove and have extensive experience
in networkdeploymentandmanagement,andassumethatusers arefamiliarwith relatedterms andconcepts.

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
1
1 Product Overview
RG-NBS3100 Series Switches
Model
10/100/1000
Base-T Ethernet Port
1000Base-XSFP
Port
Console Port
Fan Module
Power
Module
RG-NBS3100-2
4GT4SFP
24
4
N/A
N/A
Single
RG-NBS3100-2
4GT4SFP-P
24 (PoE+ support)
4
N/A
2
Single
RG-NBS3100-8
GT2SFP
8
2
N/A
N/A
Power
adapter
RG-NBS3100-8
GT2SFP-P
8 (PoE+ support)
2
N/A
N/A
Single
The SFP port is downward compatiblewith100Base-FX.
1000Base-Tis downward compatible with100Base-TXand 10Base-T.
1.1 RG-NBS3100-24GT4SFP
Technical Specifications
Model
RG-NBS3100-24GT4SFP
CPU
Built-inCPU, single-core processor,and 500MHz
Flash Memory
16 MB
SDRAM
DDRIII 256 MB
Optical Module
The coppercableis not supported.See AppendixB.
The supported module type may change at anytime. ConsultRuijieNetworksforthe latest
information.
SFP Port
1000Base-X
100Base-X
Power Supply
AC input
Rated voltage range: 100 V to 240V
Maximum voltage range: 90V to 264 V
Frequency: 50/60 Hz
Ratedcurrent: 0.6 A
Input Leakage
Current
≤3.5 mA
EEE
Supported
PoE
Not supported
Power
21 W

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
2
Consumption
Temperature
Operating temperature:0°Cto 50°C (32°F to +122°F)
Storagetemperature:-40°Cto +70°C (-40°F to +158°F)
Humidity
Operating humidity:10% to 90% RH
Storagehumidity: 5% to 95%RH
Fan
Not supported
Temperature
Alarm
Not supported
Certification
CE
Dimensions
(W x D x H)
440mmx 165mmx 44 mm
Weight
≤2.4 kg
Device operation ina residential environmentmaycauseradiointerference.
Product Appearance
On the front panel,the RG-NBS3100-24GT4SFPEthernetswitchprovides twenty-four 10/100/1000Base-TEthernet
ports andfour SFP ports.On the back panel,it provides an AC powerport.
Figure1-1 Appearanceof the RG-NBS3100-24GT4SFP
Front Panel
Figure1-2 Front Panel of the RG-NBS3100-24GT4SFP

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
3
5
Note:
1. System status LED
2. Resetbutton
3. 10/100/1000Base-TEthernetport
4. 1000Base-XSFP port
5. Nameplate on thebottom of the device
The switchrestarts afterthe resetbutton is pressedforless than 2 seconds.
The switch restores the defaultfactory settings after the resetbutton is pressed for more than 5 seconds (until the
status LED blinks).
Back Panel
Figure1-3 Back Panel of the RG-NBS3100-24GT4SFP
Note:
1. Power cord retention clips
2. Three-hole AC power receptacle
3. Protective earthingterminal
Nameplate(on thebottom of the device)
This device relies onthe separateprotectiveearthing terminal.
The device installationmustbepermanentlygrounded.
The device must be intended to be used in a location with equipotential bonding (such as a telecommunication
center, a dedicatedcomputerroom,ora restrictedaccess area).
Heat Dissipation
The RG-NBS3100-24GT4SFP adopts natural heat dissipation, therebyensuring normal operation. You must reserve 10
cm distancespace atboth sides and the backplane ofthe cabinet to allow airflow. It is recommended that you clean the
device onceevery three months toavoid dustfrom blockingvents.
LED
LED
Panel Identification
State
Meaning

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
4
LED
Panel Identification
State
Meaning
System status LED
Status
Off
The switchis not receivingpower.
Blinkinggreen
(0.5 Hz)
The switch is running,butis not connectedto
RuijieCloud.
Blinkinggreen (10
Hz)
The switchis being upgradedorinitialized.
Solidgreen
The switchis connectedto Ruijie Cloud.
10/100/1000Base-T
Ethernet port status
LED
1–24
Off
The port is not connected.
Solidgreen
The portis connected ata rate of 10/100/1000
Mbps.
Blinkinggreen
The port is receivingor transmitting traffic.
SFP port status LED
25–28
Off
The port is not connected.
Solidgreen
The portis connected ata rate of 100/1000
Mbps.
Blinkinggreen
The port is receivingor transmitting traffic.
1.2 RG-NBS3100-24GT4SFP-P
Technical Specifications
Model
RG-NBS3100-24GT4SFP-P
CPU
Built-in CPU, single-coreprocessor,and 500MHz
Flash Memory
16 MB
SDRAM
DDRIII 256 MB
Optical Module
The coppercableis not supported. See AppendixB.
The supported module typemay change at anytime. ConsultRuijie Networksforthe latest
information.
SFP Port
1000Base-X
100Base-X
Power Supply
AC input
Rated voltage range: 100 V to 240V
Maximum voltage range: 90V to 264 V
Frequency: 50/60 Hz
Ratedcurrent: 6 A
Input Leakage
Current
≤3.5 mA
EEE
Supported
PoE
PoE/PoE+ support
Ports 1 to 24supportPoE/PoE+ with the maximum poweroutputof30 W per port.
The overall maximum outputpowerofPoE/PoE+ is 370 W.
PoE Mode
Mode A (datapairs 1-2 and 3-6)
Power
Consumption
21 W with no PoE load
443W with PoE full load

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
5
Temperature
Operating temperature:0°Cto 50°C (32°F to +122°F)
Storagetemperature:-40°Cto +70°C (-40°F to +158°F)
Humidity
Operating humidity:10% to 90% RH
Storagehumidity: 5% to 95%RH
Fan
Supported
Temperature
Alarm
Not supported
Certification
CE
Dimensions
(W x D x H)
440mmx 293mmx 44 mm
Weight
≤4.5 kg
Device operation ina residential environmentmaycauseradiointerference.
The high temperature label indicates that the devie must be installed in the restricted area when the
ambienttemperatureexceeds 50°C .
Product Appearance
On the front panel,the RG-NBS3100-24GT4SFP-PEthernetswitchprovides twenty-four 10/100/1000Base-TEthernet
ports andfour SFP ports.On the back panel,it provides an AC powerport.
Figure1-4 Appearance of the RG-NBS3100-24GT4SFP-P
Front Panel
Figure1-5 Front Panelof the RG-NBS3100-24GT4SFP-P

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
6
6
Note:
1. System status LED
2. PoE mode switch-overbutton
3. Resetbutton
4. 10/100/1000Base-TEthernetport
5. 1000Base-XSFP port
6. Nameplate on thebottom of the device
The switchrestarts afterthe resetbutton is pressedforless than 2 seconds.
The switch restores the defaultfactory settings after the reset button is pressed for more than 5 seconds (until the
status LED blinks).
When the button is turned to the left position (Mode 1), the LED indicates the switching status of the port. When
the LED is solidgreen,thelink is Up.Whenthe LED blinks green,datais beingtransmittedorreceived.
When the button is turned to the right position (Mode 2),the LED indicates the PoE status of ports. When the LED
is solidgreen, the PoE-supported ports aresupplying power.When theLED blinks green,the power of the ports is
overloaded.
Back Panel
Figure1-6 Back Panel of the RG-NBS3100-24GT4SFP-P
Note:
1. Power cord retention clips
2. Three-hole AC powerreceptacle
3. Protective earthing terminal
This device relies onthe separateprotectiveearthing terminal.
The device installationmustbepermanentlygrounded.
The device must be intended to be used in a location with equipotential bonding (such as a telecommunication
center, a dedicatedcomputerroom,ora restrictedaccess area).
Heat Dissipation
The RG-NBS3100-24GT4SFP-P adopts fans for heat dissipation, therebyensuring normal operation. You must reserve
10 cm distance space atboth sides and the back plane ofthe cabinetto allow airflow. It is recommended thatyou clean
the device onceevery three months toavoid dustfrom blockingvents.
Figure1-7 Flow Scheme ofHeat Dissipation

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
7
LED
LED
Panel Identification
State
Meaning
System status LED
Status
Off
The switchis not receivingpower.
Blinkinggreen
(0.5 Hz)
The switchis running,butthe alarm of
insufficientPoEpowerprompts.
Blinkinggreen (10
Hz)
The switchis being upgradedorinitialized.
Solidgreen
The switchis connectedto Ruijie Cloud.
10/100/1000Base-T
Ethernet port status
LED
1–24
Off
The port is not connected.
Solidgreen
The portis connected ata rate of 10/100/1000
Mbps.
Blinkinggreen
The port is receivingor transmitting traffic at a
rate of 10/100/1000Mbps.
RJ45 port PoE
status LED
1–24
Off
PoE is not enabled.
Solidgreen
PoE is enabled.The port is operational.
Blinkinggreen
The port has a PoE fault of overload.
SFP port status LED
25F–28F
Off
The port is not connected.
Solidgreen
The port is connected.
Blinkinggreen
The port is receivingor transmitting traffic.
1.3 RG-NBS3100-8GT2SFP
Technical Specifications
Model
RG-NBS3100-8GT2SFP
CPU
Built-inCPU, single-coreprocessor,500 MHz
Flash Memory
16 MB
SDRAM
DDRIII 256 MB

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
8
Optical Module
The coppercable is not supported.See AppendixB.
The supported module typemay change at anytime. ConsultRuijie Networksforthe latest
information.
SFP Port
1000Base-X
100Base-FX
Power Supply
Adapter input
Rated voltage range: 100 V to 240V
Maximum voltage range:90V to 264 V
Frequency: 50/60 Hz
Ratedcurrent: 1 A
Adapter output
Ratedvoltage range: 12V DC
Rated current range:1 A
EEE
Supported
PoE
Not supported
Power
Consumption
8W
Temperature
Operating temperature:0°Cto 50°C (32°F to +122°F)
Storagetemperature:-40°Cto +70°C(-40°F to +158°F)
Humidity
Operating humidity:10% to 90% RH
Storagehumidity: 5% to 95%RH
Fan
Not supported
Temperature
Alarm
Not supported
Accessing Optical
Module
Information
Not supported
Certification
CE
Earth Leakage
Current
≤0.25 mA
Dimensions
(W x D x H)
260mmx 120mmx 43.6 mm
Weight
1.2 kg (with package)
Device operation ina residential environmentmaycauseradiointerference.
Product Appearance
On the front panel,the RG-NBS3100-8GT2SFPEthernet switchprovides eight10/100/1000Base-TEthernetports,two
SFP ports,oneresetbutton, and oneDC powerport.
Figure1-8 Appearance of the RG-NBS3100-8GT2SFP

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
9
Front Panel
Figure1-9 Front Panel of the RG-NBS3100-8GT2SFP
8
Note:
1. System status LED
2. Resetbutton
3.10/100/1000Base-TEthernetport
4. Copperport status LED
5. 1000Base-XSFP port
6. SFP port status LED
7. DC powerport
8. Nameplate on thebottom of the device
The switchrestarts afterthe resetbutton is pressedforless than 2 seconds.
The switch restores the default factory settings after the resetbutton is pressed for more than 5 seconds (until the
status LED blinks).
Back Panel
Figure1-10 Back Panel of the RG-NBS3100-8GT2SFP

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
10
Note:
1. Protective earthing terminal
2. Holefor anti-theft lock
This device relies onthe separateprotectiveearthing terminal.
The device installationmustbepermanentlygrounded.
The device must be intended to be used in a location with equipotential bonding (such as a telecommunication
center, a dedicatedcomputerroom,ora restrictedaccess area).
Heat Dissipation
The RG-NBS3100-8GT2SFPadopts naturalheatdissipation,therebyensuringnormaloperation.Youmustreserve10
cm distancespace at bothsides and the backplane of the cabinet to allow airflow. It is recommended thatyou clean the
device onceevery three months toavoid dustfrom blockingvents.
LED
LED
Panel Identification
State
Meaning
System status LED
Status
Off
The switchis not receivingpower.
Blinkinggreen
(0.5 Hz)
The switch is running,butis not connectedto
RuijieCloud.
Blinkinggreen (10
Hz)
The switchis being upgradedorinitialized.
Solidgreen
The switchis connectedto Ruijie Cloud.
10/100/1000Base-T
Ethernet port status
LED
1–8
Off
The port is not connected.
Solidgreen
The portis connected ata rate of 10/100/1000
Mbps.
Blinkinggreen
The port is receivingor transmitting traffic at a
rate of 10/100/1000Mbps.
SFP port status LED
9F–10F
Off
The port is not connected.
Solidgreen
The port is connected at a rate of 100/1000
Mbps.
Blinkinggreen
The port is receivingor transmitting traffic at a
rate of 100/1000 Mbps.
1.4 RG-NBS3100-8GT2SFP-P
Technical Specifications
Model
RG-NBS3100-8GT2SFP-P
CPU
Built-in CPU, single-core processor,500 MHz
Flash Memory
16 MB
SDRAM
DDRIII 256 MB
Optical Module
See AppendixB.
The coppercableis not supported.
The supported module typemay change at anytime. ConsultRuijie Networksforthe latest

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
11
information.
SFP Port
1000Base-X
100Base-FX
Power Supply
AC input
Rated voltage range: 100 V to 240V
Maximum voltage range: 90V to 264 V
Frequency: 50/60 Hz
Ratedcurrent: 2A
Powercord: 10A
EEE
Supported
PoE
PoE/PoE+ support
Ports 1 to8support PoE/PoE+ with the maximum power output of 30 W perport. Port 9 does not
supportPoE.
The overall maximum outputpowerofPoE/PoE+ is 125 W.
PoE Mode
Mode A (datapairs 1-2 and 3-6)
Power
Consumption
11W with noPoE load;
145W withPoE full load
Temperature
Operating temperature:0°Cto 50°C (32°F to +122°F)
Storagetemperature:-40°Cto +70°C (-40°F to +158°F)
Humidity
Operating humidity:10% to 90% RH
Storagehumidity: 5% to 95%RH
Fan
Not supported
Temperature
Alarm
Not supported
Accessing Optical
Module
Information
Not supported
Certification
CE
Input Leakage
Current
≤1.5 mA
Dimensions
(W x D x H)
300mmx 220mmx 43.6 mm
Weight
2 kg (with package)
Device operation ina residential environmentmaycauseradiointerference.
The high temperature label indicates that the devie must be installed in the restricted area when the
ambienttemperatureexceeds 50°C .
Product Appearance

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
12
On the front panel,the RG-NBS3100-8GT2SFP-PEthernet switchprovides 810/100/1000Base-TEthernetports,2
SFP ports,1 resetbutton, and 1 PoE modeswitch-overbutton.On the back panel,itprovides an AC powerport.
Figure1-11 Appearanceof the RG-NBS3100-8GT2SFP-P
Front Panel
Figure1-12 Front Panel of the RG-NBS3100-8GT2SP-P
9
Note:
1. System status LED
2. Port modeLED
3. PoE modeswitch-overbutton
4. Resetbutton
5. 10/100/1000 Base-TEthernetport
6. Copperport status LED
7. 1000Base-XSFP port
8. SFP port status LED
9. Nameplate on thebottom of the device
The switchrestarts afterthe resetbutton is pressedforless than 2 seconds.
The switch restores the defaultfactory settings after the reset button is pressed for more than 5 seconds (until the
status LED blinks).
When the PoE mode switch-over button is pressed, the port mode LED turns on, indicating the PoE mode of the
port. When the PoE mode switch-over button is released, the port mode LED turns off, indicating the switching
mode of the port.
Back Panel
Figure1-13 Back Panel of the RG-NBS3100-8GT2SFP-P

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Product Overview
13
Note:
1. Protective earthing terminal
2. Hole for anti-theft lock
3. Power cordretentionclips
4. Three-hole AC powerreceptacle
This device relies onthe separateprotectiveearthing terminal.
The device installationmustbepermanentlygrounded.
The device must be intended to be used in a location with equipotential bonding (such as a telecommunication
center, a dedicatedcomputerroom,ora restrictedaccess area).
Heat Dissipation
RG-NBS3100-8GT2SFP-Padopts naturalheatdissipation,therebyensuringnormaloperation.You mustreserve10
cm distancespace at bothsides and the backplane of the cabinet to allow airflow. Itis recommended thatyou clean the
device onceevery three months toavoid dustfrom blockingvents.
LED
LED
Panel Identification
State
Meaning
System status LED
Status
Off
The switchis not receivingpower.
Blinkinggreen
(0.5 Hz)
The switch is running,butis not connectedto
RuijieCloud.
Blinkinggreen (10
Hz)
The switchis being upgradedorinitialized.
Solidgreen
The switchis connectedto Ruijie Cloud.
Port modeLED
LED Mode
Off
Switching mode.
Solidgreen
PoE mode.
10/100/1000Base-T
Ethernet port status
LED
1–8
Off
The port is not connected.
Solidgreen
The portis connected ata rate of 10/100/1000
Mbps.
Blinkinggreen
The port is receivingor transmitting traffic at a
rate of 10/100/1000Mbps.
RJ45 port PoE
status LED
1–8
Off
PoE is not enabled.
Solidgreen
PoE is enabled.The port is operational.
Blinkinggreen
The port has a PoE fault of overload.
SFP port status LED
9F–10F
Off
The port is not connected.
Solidgreen
The portis connected ata rate of 100/1000
Mbps.
Blinkinggreen
The port is receivingor transmitting traffic at a
rate of 100/1000 Mbps.

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Preparation before Installation
14
2 Preparation before Installation
2.1 SafetySuggestions
To avoid personalinjuryanddevice damage,carefullyread the safetysuggestionsbefore you installtheRG-NBS3100
series.
The following safetysuggestionsdonotcover all possibledangers.
2.1.1 Installation
Keepthe chassis cleanandfreefrom anydust.
Do notplacethe equipmentinawalkingarea.
Do not wear loose clothes or accessories that may be hooked or caught by the device during installation and
maintenance.
Turn off allpowersuppliesandremovepowersockets andcables before installingoruninstallingthedevice.
2.1.2 Movement
Do notfrequentlymovethe device.
When moving the device, note the balanceandavoid hurting legs andfeet or straining theback.
Before moving the device, turn off allpowersupplies anddismantle all powermodules.
2.1.3 Electricity
Observe local regulations and specifications when performing electric operations. Relevant operators must be
qualified.
Before installing the device, carefullycheck anypotential danger in thesurroundings, such as ungrounded power
supply,and damp orwet ground or floor.
Before installing the device, find out the location of the emergency power supply switch in the room. First cut off
the powersupplyin the caseof an accident.
Try to avoid maintainingtheswitchthatis poweredon alone.
Be sure to make a careful check beforeyou shutdownthe powersupply.
Do notplacethe device ina damplocation.Donotlet anyliquid enterthe chassis.
Any nonstandard and inaccurate electric operation may cause an accident such as fire or electrical shock, thus
causingsevere evenfatal damages tohumanbodiesand thedevice.
Direct or indirecttouchthrough a wet objecton high-voltageandmains supplymaybringa fatal danger.
If a power supply system is equipped with a leakage protector (leakage current switch or breaker), the rated
leakage action current of each leakage protector is twice greater than the maximum leakage current of all the
power supplies in the system. For example, if a system is equipped with twenty identical power supplies, the
leakage currentof each power supplyis equal to or less than 1.5 mA, and the total leakage current of the system
is 30 mA. A leakage protector with 30 mA rated action current supports less than ten power supplies (that is,

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Preparation before Installation
15
action current of the leakage protector/2/maximum leakage current of each powersupply= 30/2/1.5 = 10). In other
words, the leakage protector with 30 mA rated action current supports no more than ten power supplies. In this
case, the twenty power supplies in the system require at least two leakage protectors with 30 mA rated action
current and each leakage protectorsupports ten power supplies. If powersupplies in asystem differ in models, the
rated leakage action current of each leakage protectordivided bytwo is greater than the sum ofmaximum leakage
current of all the powersupplies. The rated leakage non-action current of a leakage protectormust be 50% of the
leakage action current. The leakage protector with 30mArated leakage action current is usedas an example. The
rated leakage non-action current must be 15 mA. When the leakage current falls below 15 mA, the protector
should not act. Otherwise, misoperation may easily occur due to high sensitivity and thus the leakage protector
trips,devices are poweredoff, and services areinterrupted.
To guarantee personal safety, the rated leakage action current of each leakage protector in the system must be
equal to or less than 30 mA(human bodysafety current is 30 mA). When twice of the total leakage currentofthe
system is greaterthan 30 mA, the system mustbeequippedwith two or more leakageprotectors.
For details of the leakagecurrentvalue of each powersupplymodel,seeChapter 1Product Overview.
2.1.4 ESD
To prevent ElectronicStatic Discharge (ESD),pay attentionto the following points:
Propergroundingofgroundingscrews on thebackpanelof the device, andthree-wire single-phase socketwith
protective earth wire(PE) usedas theAC powersocket.
Indoordustprevention
Properhumidityconditions
2.1.5 Laser
The RG-NBS3100 series switches support varying models of optical modules (Class I laser products) sold on the
market.Improperuse of optical modules maycausedamage.Therefore,payattention to the followingpoints:
When a fiber transceiver works, ensure that the port has been connected to an optical fiber or is covered with a
dustcap, to keep out dustandavoid burningyour eyes.
When the optical module is working, do not pull out the fiber cable or look directly into the transceiver. The
transceiveremits laserlightthatmayhurt your eyes.
Do not stare into any optical port under any circumstances because this may cause permanent damage to your
eyes.
2.2 InstallationSite Requirements
The installationsitemustmeetthefollowing requirementtoensure normalworkingandaprolongeddurablelife ofthe
switch.
2.2.1 Ventilation
For the RG-NBS3100series,a sufficientspace (atleast10 cm distancefrom both sides andtheback planeof the
cabinet)shouldbereservedat the ventilationopenings toensurenormal ventilation.After various cables have been
connected,they shouldbearrangedintobundles orplacedon the cablingrack to avoid airflowblocking.It is

Ruijie RG-NBS3100 SeriesSwitchesHardware Installation andReferenceGuide Preparation before Installation
16
recommendedthatyou cleanthe switchat regularintervals (likeonce every three months).Inparticular,avoid dust
from blockingthe screenmesh onthebackof the cabinet.
2.2.2 Temperature and Humidity
To ensure the normal operation and prolong the service lifeof the RG-NBS3100series switch, keep proper temperature
andhumidityin the equipmentroom.
If the equipment room has temperature and humiditythat do not meet the requirements for a long time, the equipment
maybe damaged.
In an environment with a high humidity, insulating materials may have bad insulation or even leaking electricity.
Sometimesthematerialsmaysufferfrom mechanicalperformancechangeandmetallicparts maygetrusted.
In an environment with a low humidity, insulating strips maydryand shrink.Static electricitymayoccur easilyand
endangercircuits onthedevice.
In an environment with a high temperature, the router is subject to more serious harm. Its performance may
degradesignificantlyandvarious hardwarefaults mayoccur.
The ambient temperature and humidity of the RG-NBS3100 series switch must meet the requirements listed in Table
2-1.
Table2-1 Temperature and HumidityRequirements ofthe RG-NBS3100 Series Switch
Temperature
Relative Humidity
0°C to 50°C (32°F to 122°F)
10%to 90%
The requirements for thesampling site ofthe temperature and humidityin the operating environmentofthe device
are as follows:
There is no protective plateat the front or back of the rack.
The vertical heightis 1.5 m above the floor.
The distancefrom thefront panel of the device is 0.4 m.
2.2.3 Cleanness
Dust poses a severe threatto the running of the device. The indoor dust falling on the device maybe absorbed bythe
static electricity, causing bad contact of the metallic joint. Such electrostatic absorptionmayoccur more easilywhen the
relative humidity is low. This affects the device lifecycle and causes communication faults. Table 2-2 lists the
requirementsforthe dustcontent andgranularityin the equipmentroom.
Table2-2 Requirements forthe DustContentand Granularityin the EquipmentRoom
Dust
Unit
Density
Diameter ≥0.5 μm
Particles/m3
≤3.5×106
Diameter ≥5 μm
Particles/m3
≤3×104
Apart from dust, the salt, acid, and sulfide in the air in the equipment room must also meet strict requirements. This is
because such poisonous substances may accelerate the corrosion of the metal and the aging of some parts. The
equipment room should be protected from the intrusion of harmful gases such as sulfur dioxide, sulfured hydrogen,
nitrogendioxide,and chlorine.Table 2-3 lists therequirements.
Table2-3 Requirements for HarmfulGases inthe EquipmentRoom
