Reynolds Building Systems Best Barns Elm R Safety guide

This manual is copyrighted. Under the copyright laws, this manual
may not be copied, in whole or in part, without consent from Reynolds
Building Systems, Inc. © Copyright 2016
the Elm R
revised July 28, 2021
10' x 12'
Best Barns
Assembly Book
Manufactured by Reynolds Building Systems, Inc.
205 Arlington Drive - Greenville, PA 16125

Tongue Edge
LAP Edge
Tool List
Hammer & Phillips Screwdriver
Framing Square & Level
Hand Saw
Power Drill/Screwdriver
Measuring Tape
2-6' Step Ladders
measure from here When measurements are given for a board
length, it is from the longest side.
Always wear safety glasses when cutting or nailing!
The siding is made in 4x8 sheets with grooves
cut into the face, the long edge is beveled so
that the siding overlays where they butt.
To identify which edge we want you to use, we
will refer to the edge as either the 'LAP' Edge
or the Tongue Edge. Nail siding with 6d galv.
nails, spaced 12" apart.
IMPORTANT INFORMATION - Read This First
Thank you for your purchase. I want you to be completely satisfied with your building. The
2x4s are imported from Europe because they grade lumber four sides. If you are dissatisfied
with lumber you receive we will replace it.
Read the instructions before starting the assembly of the building. If you have any questions
about assembling the kit, call 800-245-1577. Business hours (8:00-5:00 ET) Monday thru
Friday.After business hours call 724-866-HELP (4357).
The material that is included in our kit is listed on the back page. The optional floor package,
if purchased, will be supplied by a local lumber supplier. This will be a separate delivery.
Our kit does not include shingles, the quantity needed is listed on the back page. The siding
is primed. You will need to apply a finish coat using latex acrylic paint.
Some of the framing lumber was used in the shipping pallet. Unpack the material from the
pallets, then unscrew the top 2x4s. The bit for the screws is packed in the hardware bag. The
2x4s will be used for wall bracing and tie plates.
Most buildings are installed on a wood floor and the siding was designed to extend over the
wood flooring. If the foundation is a concrete floor cut the siding flush with the bottom of
the wall plate to prevent the concrete from contacting the siding.
Before building, obtain a building permit and check all pertinent building code regulations.

It is important that the floor be level and square.
Before nailing the flooring, measure the floor
diagonally (corner to corner). Then measure
the opposite corners. These measurements will
be the same if the floor is square (187-1/2").
2. Cut (10) ten 2x4-10' floor joist to 9'-9". Treated lumber may be thicker than 1-1/2". Take this
into account when cutting the length of floor joists. Shorten joist measurements if necessary
to obtain 12'-0" building width.
1. Treated lumber is not cut to exact length. Cut (2) two 2x4-12' boards to 12'-0".
Layout for 16" on center joist spacing. 'X' marks where floor joist will be placed.
Construction Details for Optional Floor System
Check local building codes in your area, the construction may have to change. For a concrete slab,
install sill sealer as a moisture barrier between the concrete and the wall plates. Foam sill sealer can
be purchased at home centers in rolls 3-1/2" or wider.
Material Description 10' x 12' Floor
2x4 Treated Headers 2 pcs. 12'
2x4 Treated Floor Joist 10 pcs. 10'
Flooring 5/8" 4x8 4 pcs. 4x8
8d Screw Floor Nails 1 lb. 8d
16d Galv. Box Nails 1 lb. 16d
If necessary use bricks, patio stones or similar material to level or provide additional support
to the floor. If your ground has low areas consider adding gravel and or 4x4 treated timbers
to rest the floor on. If you use 4x4 timbers you will need (3) three pieces 12' long.
3. Install the floor joist, over the 'X' marks, between the 12' long joist headers. Use 16d galv.
deck nails.
!
!
Joist 9' - 9" Long
2x4-12' Joist Header
12' - 0" Floor Length
10' - 0" Floor Width
Leveling Blocks
4' x 8'
4' x 4' 4' x 8'
2' x 4'
XX
XX
X
X
16"15-1/4"
Joist Header X
X
16"

XX
XX
X
X
A
AB
B
X
X
X
X
Step 1 Assemble Back Wall
1. Position (4) four 60" boards together and indicate with 'X' marks, where the wall studs
will be located. Mark the ends that will butt together with the letters 'A' and 'B'.
2. Install 72" wall studs between the top and bottom plates. Assemble wall frames with
10d sinkers. Use (2) two nails at end of each wall stud.
24"
23-1/4"
60" Wall Plate
X
X
60" Wall Plate
24"
11-1/4"
X
X
X
X
Siding Extends 3/4" Below Plate
LAP Edge
60" Wall Plate
Tongue Edge
Cut Edge
AB
3. Nail both wall frames together
using 10d sinkers.
4. Square frame, measure diagonally (corner to corner). The measurement should be 141-1/2".
5. Select a 36-3/4" wide siding panel with a 'tongue' edge. Install this panel with the 'Cut' edge
flush with the end of the wall frame. Install siding flush with the 2x4 top plate. Use 6d galv.
nails spaced 12" on center.
6. Install a full width x 75-3/4" long siding panel next.
7. Install a 36" x 75-3/4" siding panel last. If
necessary trim panel flush with 2x4.

A
A
B
B
X
X
XX
XX
LAP Edge
X
X
X
X
Step 2 Assemble Side Walls
4. Repeat to assemble another sidewall panel.
68-1/2" Wall Plate
24"
19-3/4" 24"
23-1/4"
68-1/2" Wall Plate
LAP Edge
LAP Edge
1. Position (4) four 68-1/2" boards together and indicate with 'X' marks, where the wall studs
will be located. Mark the ends that will butt together with the letters 'A' and 'B'.
72" Wall Studs
2. Install 72" wall studs between the top and bottom plates. Assemble wall frames with 10d
sinkers. Nail both wall frames together.
AB
X
X
X
X
X
X
Siding Extends 3/4" Below Plate
68-1/2" Wall Plate
Siding Extends 3-1/2"
Beyond Frame
3. Square wall frame. The measurement should be 156-1/4". Install (3) three full width siding
panels. Install the first siding panel with the 'LAP' edge extending 3-1/2" past the end of the
wall frame. The last panel should extend 3-1/2” past frame. The siding should extend 3/4" below
the bottom plate and flush with the top plate.

Step 4 Assemble Roof Trusses
Step 3 Assemble Front Wall Frames
1. Cut (2) two 27-3/4" long boards from (1) one 72" long 2x4 board.
2. Cut (2) two 72" 2x4s to a length of 69-1/2" used for header supports.
1. Place (2) two 62" long 2x4 boards with angled ends together as shown below. If possible,
hold in place with 2x4 blocks as shown. Make sure the trusses measure 10'-0" wide when
assembled to fit properly when installed.
2. Secure the tops together with a wood gusset. Nail the gusset to the 2x4s with (14) fourteen
6d common nails. Angle nail slightly so nails do not protrude through the 2x4 boards.
3. Repeat above steps to assemble (6) six more trusses.
Wood Gusset
2x4-62" Boards
Tip: If possible, temporarily screw 2x4 blocks to the floor. Short 2x4s, that may have an angle on
one end, supplied in the kit for this purpose. This will secure the truss boards in position so all the
trusses will be assembled the same. Use the 2-1/2" deck screws packed in the kit.
4. Select (5) five trusses and apply wood gussets to the opposite side.
2x4 Block
2x4 Blocks
X
X
X
XX
X
X
11-1/4"
60" Wall Plate
13-1/2"
27-3/4" Wall Plate
3. Position one 27-3/4” board cut above and a 60" long 2x4 together
and mark where wall studs will be located. See detail above.
4. Assemble front wall using (3) three 72" long 2x4s and a 69-1/2"
long header support. Place 2x4s over the 'X' marks and nail using
10d sinkers.
5. Repeat steps 3-4 to assemble another front wall frame.
27-3/4” Wall Plate
69-1/2” Header Support

2. Remove 2x4 blocks. Save blocks,
some will be used when installing
gables. The remaining (2) two
trusses with one gusset will be used
in a later step.
4. Install a 67-1/2" door header between
the front wall panels. Secure with 10d
sinkers. Nail through the top 2x4 plate
and the wall stud.
Step 6 Set Walls
1. Erect wall panels. IMPORTANT: Make sure walls are plum and square. Secure wall panels
together at the corners. Use (4) four 10d sinkers per corner. Nail wall panels to the floor. Nail
through the bottom plate. Space 10d sinkers 24" apart.
Step 5 Install Collar Ties
1. Select (3) three trusses that have gussets installed
on both sides and install a 1x4-72" long primed board
on one side as shown. Use (4) four 6d common nails
on each end.
1x4 Collar Tie
Board is Primed
2x4 Wall Brace
67-1/2" Door
Header
2. Remove the (2) 2x4s screwed to the
pallet. Use thes to brace the walls
next to door opening. The bit for the
screws is in the hardware bag.
3. Use (2) two of the 2x4s boards to
brace the door walls to hold them
straight. Save the 2x4s, they will be
used in a later step

Step 8 Install Tie Plates on Front and Back Walls
1. Cut (2) two 26-1/2" long 2x4s from a 2x4-60" board.
2. Install a 26-1/2" long 2x4 over the front wall.
3. Install a 60" long 2x4 next and finish with another 26-1/4" long 2x4.
4. Repeat to install tie plates on the back wall.
26-1/2" Tie Plate
Step 7 Install Tie Plates on Side Walls
1. Cut a 2x4-78” removed from pallet in half and install (1) one 39” board over the sidewall. Install
the 2x4 flush with the 2x4 wall plate on the front wall. Use 10d sinkers spaced 12" apart.
2. Install a 78" 2x4 from pallet next. Cut to fit the second 39” board.
3. Repeat to install tie plates on the opposite side wall.
2x4 Cut to Fit
60" Tie Plate
2x4-78" Tie Plate
Flush with
Top Plate
2x4-39" Tie Plate

3. Install a 2x4 block on the opposite side wall and secure the truss.
Step 9 Install Siding on Front Wall
1. Select a 12-1/2" siding panel with a 'Tongue' edge and install at the front left corner. Cut edge
will be flush with side wall siding. Install a 15-3/4" siding panel with a 'LAP' edge next. Cut
edge should be flush with door opening.
2. Install (2) two 4-3/4" x 32-1/4" siding panels over the door opening. Bottom of siding should
be flush with door opening. Trim will cover where the siding panels butt together in the center.
3. Install the 16-1/2" panel
with the 'cut' edge flush
with the door opening.
4. Install last siding panel.
Cut Edge
Cut Edge
Cut Edge
12-1/2" Siding with 'Tongue' edge
Step 10 Install Roof Gable
Install 2x4 Block
15-3/4" Siding with 'LAP' edge
1. Select a truss with a gusset installed on one side. Position this truss with
the gusset facing towards the inside of the building and flush with 2x4s
on back wall.
2. Install a 10" to 12" long 2x4 block on a side wall using 10d sinkers.
Secure the truss to the 2x4 block with (2) two 10 sinkers.

2. Repeat Steps 10 thru 12 to install
the gable on the front wall.
Step 11 Install 'Z' Flashing
Step 12 Install Roof Gable Siding
60" Long 'Z' Flashing
Roof Gable
Back Wall Siding
Siding extends 1/2” above truss
‘Tongue’ edge
Install (2) two 60” pieces of 'Z' flashing across
the top of the siding on the back wall siding.
Secure in place using 6d galv. nails spaced 12”
apart. The ends will be covered by corner trim.
1. Install gable siding on the roof gable using 6d galv.
nails. The gable siding should extend no more than
1/2" above the 2x4 frame and 1-1/2" past gable ends.
1-1/2" Past End
of Gable

The first and last truss will not have a collar tie attachd.
Step 14A Install Trusses
Step 13 Install 2x4 Truss Headers
1. Place a 72" long 2x4 on top of the siding on the sidewall. It will butt against the siding on
the roof gable. Nails this 2x4 to the 2x4 tie plate with 10d sinkers.
2x4-72" Board
Roof Gable
Side Wall Siding
2. Remove a 2x4 used to brace the front
wall. Cut to fit and install next to the
2x4 installed above.
3. Repeat to install 2x4s on the opposite
side wall.
1. Starting from back wall install the first truss (without a collar tie) measuring 21-3/4" from the
face of the 2x4 on back gable and the left side of 2x4 truss. Secure the trusses using 2-1/2"
screws and 10d sinkers, See Detail 'A' on next page.
2. Install the remaining trusses measuring 24” from left side to left side of each truss. Last truss
will not have a collar tie.
24"
21-3/4" 24"
2x4 Truss Header
Truss with
Collar Tie
Left Side
Left Side
Side Wall
Back Wall

Using a 2-1/2" screw, secure all trusses to
2x4 Truss Header installed in Step 11. Toe
nail truss into 2x4 tie plate using 10d sinkers.
Step 15 Install 1x4 Fascia
3. Repeat to install 1x4 fascia on the
opposite side wall.
Detail 'A'
2x4 Truss Header
Step 14B Install Trusses Continued
1x4 Fascia Trim
1. Install 72" long 1x4 fascia trim over the 2x4 Truss Headers. Install 1x4 trim boards flush with
the bottom of the 2x4 and flush with face of siding on the front gable.
2. Cut a 74" long 1x4 to fit and install flush with the face of siding on the back gable.

1. Install the first 4x6 roof sheathing panel against the back of
of gable siding. Note: Using a straight edge install the top
edge of the roof sheathing flush with the face of the 1x4
fascia. See Detail 'B'.
Air
Space
Truss
Shingles
Install roof sheathing with 7d sinkers, space nails 12" apart. When installing
sheathing across the top, insert a plyclip into the roof sheathing between each
truss. The top row of sheathing will be about 1" below the ridge to allow for
optional ridge venting. See detail below.
Step 16 Install Roof Sheathing
48"x 72" 48"x 72"
15"x 48" 15"x 48" 15"x 48"
Roof Ridge
Detail 'B'
4' x 6'
Siding
Roof Sheathing
2x4 Truss
Header
Straight Edge
1x4 Fascia
2. Install a 15" x 48" sheathing panel at the top.
3. Continue to install sheathing per layout below.
4. Repeat on opposite side. Plyclip
15" x 48"
See supplier of shingles to
purchase ridge venting.
Install roof sheathing on each side of the
building as per pattern on right.

Step 17 Install Trim
1. Install 64-3/8" long 1x4 gable trim flush with the top of the roof sheathing
on the front and back. Use 6d galv. nails spaced 12" apart.
2. Install 75-3/4" long 1x3 corner trim, on the side
walls, flush with the face of the siding on the front
and. Repeat for back wall.
3. Install 77-1/4" long 1x4 corner trim on front wall,
flush with the face of the side wall trim. Repeat for
back wall.
Siding Will Extend Below Trim
75-3/4" Long 1x3 Corner Trim
77-1/2" Long 1x4 Corner Trim
72" Long 1x3 Door Trim
4. Install (2) two 72" long 1x3 trim boards, with top edge 3/4"
above door opening, along each side of the door opening. Use
6d galv. nails. Tack these boards with a couple nails; you may
want to move the trim later when you install the doors.
5. Install a 72" long 1x3 trim board centered across the top of
the vertical trim. 3/4" of siding will be revealed at top of door.

Step 18 Install Doors & Hardware
3. Before fastening the hinges to the side trim,
temporarily prop the doors in the opening. Leave
a space at the top and bottom of the doors and
between the doors and the side trim to allow
room for the doors to expand due to humidity.
If your door opening is out of square, the space
around the doors will not be even. You can
remove and re-position the side trim to make
allowances for this. The side trim does not have
to be flush with the frame of the door opening.
You can move the trim in or out to make the
door spacing equal.
4. Determine position of hinges and install to side
trim with 2" screws.
5. Installdoor haspon doubledoors.When properly
installed the hasp will fold in half to receive
locking latch and the screw heads will be
covered.
6. Install a barrel bolt on the lower back of
the door to secure this door in place when
closed. You will need to drill a hole for
the round shaft to drop into.
7. Install another barrel bolt at the top of the
door.
Barrel Bolt on the
back of left door
Left Door
Siding Extends Past Trim
1. Locate the door that has a 2x4 fastened, on edge, to the
back side of the door. When doors are closed this 2x4 will
be in the center where doors meet. Lay the door with the
trim facing up and install (3) three 5" hinges to the right
side. To position the hinge properly, hold the rectangular
plate against the frame. Use 1-1/4" black screws.
2. Install hinges on the left side of the other door.
Fold Hasp to Cover
Screws

5 bdl. Roof Shingles 6 pcs. Roof 'drip' edge
Material Purchased By Owner
Elm R Packing List for 10' x 12'
2
