RF-Lambda REMC0M3GW100 User manual

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
Wideband EMC Configurable Dual Band Power Amplifier
0.02GHz-3GHz Total Bandwidth
Band 1 0.02GHz-0.8GHz / Band 2 0.8GHz-3GHz
Electrical Specifications (TA=+25⁰C)
Product Description
REMC0M3GW100 is a wideband EMC power amplifier with a total
frequency range of 0.02 to 3GHz.
The amp can be configured for 0.02GHz to 0.8GHz or 0.8GHz to 3GHz.
The power output of this amplifier is 50dBm typical. The typical small signal
gain is 55dB with a flatness of ±2.0dB. This performance is achieved
through the use of GaN devices.
The power amplifier’s input and output connectors are N-Female. This
product has a calibration feature which enables customer to obtain great
performance through time and temperature changes.
The operating temperature of this product is within 0⁰C to +50⁰C.
Features
•Wideband EMC Solid State Power Amplifier
•Small Signal Gain 55dB Typical
•Output Saturation Power 50dBm Typical
•Supply Voltage 110/220 VAC
•50 Ohm Matched Input/Output
•Overvoltage Protection
•Overcurrent Protection
Typical Applications
•Wireless Infrastructure
•Military and Aerospace Applications
•Test Instrumentation
•Radar Systems
•5G Wireless Communications
•Microwave Radio Systems
•TR Modules
•Research and Development
•Cellular Base Stations
Note: Only one frequency band could be selected at a time. The EMC power amplifier works on either Band1 or Band2.
Parameter Min Typ Max Min Typ Max Units
Frequency Range 0.02 0.8 0.8 3 GHz
Small Signal Gain 50 55 50 55 dB
Gain Flatness ±2.0 ±3.0 ±2.0 ±3.0 dB
Gain Variation Over Temperature (0⁰C to +50⁰C)±3.0 ±3.0 dB
Input VSWR 2 2 :1
Output 1dB Compression Point (P1dB) 49 48 dBm
Saturated Output Power (Psat) 49.5 51 49.5 50.5 dBm
Supply Current (220V AC) 2.0 5.0 2.0 5.0 A
Power Added Efficiency (PAE) 20 20 %
Turn On/Off Speed (Switch Disable) ON 250 250 ns
OFF 250 250 ns
Turn On/Off Speed (Drain Disable) ON 250 250 us
OFF 25 25 us
Turn On/Off Speed (Gate Disable) ON 50 50 us
OFF 250 250 us
Weight 63.7 Max. lbs.
Impedance 50 Ohms
Input / Output Connectors N-Female
Package 3U Rack-mount/Tabletop Chassis

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
Parameter Rating
Supply Voltage Range 90VAC to 264VAC
*RF Input Power (RFIN) Psat –Large Signal Gain
*Maximum RF input power is set to assure safety of amplifier. Input power may be increased at own risk to achieve full power of amplifier. Please
reference gain and power curves.
**For vibration testing details please see additional information section.
Absolute Maximum Ratings
Environmental Specifications and Test Standards
Parameter Description
Operational Temperature 0⁰C to +50⁰C
(Case Temperature)
Storage Temperature -40⁰C to +85⁰C
Thermal Shock 0⁰C →+50⁰C
(5 Cycles / 10 hours)
**Random Vibration MIL-STD-202G
Table 214-I, Test Condition Letter C
1.5 Hours Per Axis
High Temperature Burn In Temperature +50⁰C for 72 Hours
Shock 1. Weight >20g, 50g half sine wave for 11ms, Speed variation 3.44m/s 2. Weight <=20g, 100g Half sine wave for 6ms, Speed variation 3.75m/s
3. Total 18 times (6 directions, 3 repetitions per direction).
Altitude Standard: 30,000 Ft (Epoxy Sealed Controlled Environment)
Optional: Hermetically Sealed (60,000 ft. 1.0 PSI min)
Hermetically Sealed
(Optional) MIL-STD-883 (For Hermetically Sealed Units)
1. Connect input and output with 50 Ohm source/load.
(In band VSWR < 1.9:1 or >10dB return loss.)
2. Connect Power Cable
3. Turn On Back Panel AC Power Supply Switch
4. Press Front Panel Power Switch to Power Display
Bias Up Procedure Bias Down Procedure
1. Press Front Panel Power Switch to Power Off Display
2. Turn Off Back Panel AC Power Supply Switch
3. Remove Power Cable (If Moving Equipment)
4. Disconnect input and output with 50 Ohm source/load. (In
band VSWR < 1.9:1 or >10dB return loss.)

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
Typical Performance Plots
Gain
Gain(0.02-0.8GHz)
Input VSWR(0.02-0.8GHz)
Note: Small signal VNA measurements include attenuators to protect equipment
Isolation (0.02-0.8GHz) Isolation(0.8-3GHz)
Gain(0.8-3GHz)
Input VSWR(0.8-3GHz)

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
Typical Performance Plots
Gain vs. Output Power CW(0.02-0.8GHz)
Saturation Power vs. Frequency CW(0.8-3GHz)
Saturation Power vs. Frequency CW(0.02-0.8GHz)
PndB vs. Frequency CW(0.02-0.8GHz) PndB vs. Frequency CW(0.8-3GHz)
Gain vs. Output Power CW(0.8-3GHz)

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
Typical Performance Plots
Pout vs. Pin(0.02-0.8GHz)
3rd Harmonic Wave Output Power(0.8-3GHz)
3rd Harmonic Wave Output Power(0.02-0.8GHz)
2nd Harmonic Wave Output Power(0.02-0.8GHz) 2nd Harmonic Wave Output Power(0.8-3GHz)
Pout vs. Pin(0.8-3GHz)

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
Typical Performance Plots
4th Harmonic Wave Output Power(0.02-0.8GHz) 4th Harmonic Wave Output Power(0.8-3GHz)

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
Typical Performance Plots
Right IM3 vs. Pout (0.02-0.8GHz)
Delta IM3 vs. Pout (0.02-0.8GHz)
Left IM3 vs. Pout(0.02-0.8GHz)
Note: IM3 test performed with 1MHz tone spacing
Left IM3 vs. Pout(0.8-3GHz)
Right IM3 vs. Pout (0.8-3GHz)
Delta IM3 vs. Pout (0.8-3GHz)

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
Typical Performance Plots
The Gate-Enable Rise Time is 250 us @+25℃(0.8-3GHz) The Gate-Enable Fall Time is 50 us @+25℃(0.8-3GHz)
Switch control port: D-sub 15 PIN #10(Switch Disable) .
The yellow curve is the switch control signal, the blue curve is RF output envelope.
The Switching Rise Time is 250 ns @+25℃(0.8-3GHz)
The drain control port：D-sub 15 PIN #3 (Drain Disable).
The yellow curve is the drain control signal, the blue curve is RF output envelope.
The Switching Fall Time is 250 ns @+25℃(0.8-3GHz)
The Drain-Enable Rise Time is 25 us @+25℃(0.8-3GHz) The Drain-Disable Fall Time is 250 us @+25℃(0.8-3GHz)
The gate control port：D-sub 15 PIN #2 (Gate Disable).
The yellow curve is the gate control signal, the blue curve is RF output envelope.

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
EMC Equipment Specifications
Front Panel ON/OFF switch
RF Input (N-Female)
LCD
RF Output (N-Female)
Gain Adjustment Knob
GND
Keypad
Rear Panel
AC power supply switch
Main AC connector
GND connector
USB-A Port (work log)
USB-A Port (N/A)
LAN Port(remote control)
USER CONTROL
DB-15 Connector
TTL control signals
See page below for more information
USB-B Port (remote control)
-55dB Coupling

REMC0M3GW100
RF-LAMBDA USA LLC: www.rflambda.com
Sales: [email protected] Technical: [email protected]
Rev 4. 10-11-2023 | Subject to change without notice
Select The Frequency Range
Switching On The Instrument
Please follow the instructions on the front panel LCD screen after switching on the power.
Touch the “CONFIRM” button on the LCD screen to continue. Or press “1” on keypad to
continue.
Front Panel LCD Screen Display
Follow the steps below to select the 0.02-0.8GHz working frequency range:
Touch the “[1] Freq. Range I:0.02-0.8GHz” button and the “ENTER” button on the LCD
screen to continue. Then, touch the “CONFIRM” button on the LCD screen to continue.
Follow the steps below to select the 0.8-3GHz working frequency range:
Touch the “[2] Freq. Range II:0.8-3GHz” button and the “ENTER” button on the LCD screen
to continue. Then, touch the “CONFIRM” button on the LCD screen to continue.
