Wiring in Power Lines
 120VAC systems: 120VAC systems are prewired using a standard 110V plug with supplied
+13.5VDC adapter.
 +12VDC Systems: The +12V adapter cord can be used for +12V systems by simply cutting the
cord to length and wiring the lead with the white stripe to +12V and the
black only lead to Ground. *Note–Optional power converter may be nec-
essary for non-standard voltage.
 24VAC Systems: Use special connectors; contact us at [phone]
General Information:
The radio remote control that you are installing can be used for most electrical
switching and control applications. Before beginning the installation
and testing you should check that each item listed below is available
and in good condition.
1. Antenna: Magnetic mount antenna with 15ft of cable.
2. Receiver: Usually pre-wired inside for most systems.
3. Transmitter: Hand-held controller with pushbuttons.
4. Batteries: (2) AA NiMH battery rechargeable for transmitter.
*****Batteries need charged prior to first use*****
Operator may use (2) AA alkaline batteries instead.
YellowJacket Pro System
Remote Control Installation/Setup
Maintenance Notes
 The receiver box should be kept dry and should be periodically dusted off.
 Check the transmitter’s batteries weekly. Only use two (2) AA alkaline or equivalent rechargeable
batteries. When the batteries are weak the Transmitter’s LED will light on red and off slowly and
you may notice some reduced operating range.
 Clean the antenna periodically with mild soap and water; do not immerse in water. Allow to dry
completely before use.
 If unit is to be returned for service, please clean the transmitter and the receiver before sending it
back. Visit www.rfhero.com/request-rma.php to issue an RMA for system maintenance.
1.
2.
3.
4.
For help with installation or service
Phone: [phone]
Web: www.rfhero.com
Email: [e-mail]
Wiring In Control Lines
RFHero™ remote systems are wired to work with a variety of
insulation machines. To easily adapt to other makes and models, please use the provided UAX-
100 adapter cable and simply use the correct plug end for your machine. The most popular wiring
convention that many insulation machine manufactures use is:
Green–Common Voltage
White–Blower/Air
Black-Material Feed
To utilize the UAX-100 simply use the following color code:
UAX-100
Green
Brown
Blue
Function
Common Voltage
Air/Blower
Material Feed
Machine Side
Green
White
Black
FCC ID: QIA-YJPRO
IC: 21464-YJPRO
M/N: YJPRO3B
This device complies with
Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (i.)
this device may not cause harmful
interference, and (ii.) this device must
accept any interference received, that

Front View
Antenna
Connector
Power
Connector
Power
LED
Communications
LED
Operating Instructions
1. Place two (2) AA batteries in the transmitter. The LED on top will flash red a few times. Once this
stops, pressing any button on the transmitter will cause the LED on top to rapidly flash green.
2. Plug the YellowJacket Pro receiver power adapter into a powered outlet, then into the
YellowJacket Pro receiver. The Power LED (red) should now be lit.
3. After a few seconds the Communications LED should flash green three (3) times. If it flashes any
other number of times, then the mode is wrong. Please contact RFHero Support to quickly and
easily resolve this.
4. Pressing a button on the transmitter will cause the LED on the top of the transmitter to flash green
to indicate that the signal has been sent.
5. The Communications LED on the receiver will flash green/red (may appear orange) to indicate that
a valid message has been received from the transmitter. You may also be able to hear the relay
click inside the receiver. If the lid is removed from the receiver, you will also see the relay’s LED
turn on and off as the transmitter’s buttons are pressed.
6. If the Communications LED flashes red only, the transmitter is not paired with this receiver.
Please follow the directions on the next page titled, “Pairing the YellowJacket Pro Receiver and
Transmitter”.
7. Your system is now operational and ready for use!
YellowJacket Pro Receiver
Top View
Learn
Button
Fuse Tester
(w/Spare Fuse)
Fuse Tester
LED
Relay 1 LED
Relay 2 LED
Relay 1
Fuse
Relay 2
Fuse
Relay 1
Relay 2

This System Qualifies for
Manufacturer Support
www.rfhero.com/support.php
Email: [email protected]
Phone: [phone]
1. Remove the lid on the YellowJacket Pro receiver by unscrewing the four (4) Philips head screws
(one in each corner).
2. Repeat steps 1 & 2 of the “Operating Instructions” section on the previous page. You have 60
seconds to complete the Learn Mode procedure once step 2 is complete.
3. After the Communications LED flashes three (3) times, press and hold the Off button on the
transmitter.
4. Press and hold the Learn button in the YellowJacket Pro receiver.
5. Release the Off button on the transmitter for five (5) seconds.
6. Press the Off button on the transmitter again.
7. Release the Off button on the transmitter and the Learn button on the YellowJacket Pro receiver.
8. The Communications LED on the YellowJacket Pro receiver should now flash green/red (may
appear orange) when a button on the transmitter is pressed.
9. Replace the lid and screws on the YellowJacket Pro receiver.
10. The transmitter and YellowJacket Pro receiver are now paired together.
Pairing the YellowJacket Pro Receiver and Transmitter (Learn Mode)
ATTENTION!
This section contains the pairing instructions for REPLACING or ADDING an additional remote
transmitter. Your new transmitter and receiver are already paired from the factory and this
procedure is unnecessary for a new YellowJacket Pro kit.
Basic Troubleshooting
 If the transmitter’s LED flashes red slowly several times then stops, the batteries should be re-
placed or recharged.
 Make sure that the red Power LED is lit when the YellowJacket Pro receiver is plugged in.
 If operational range seems reduced, check the antenna for a broken wire or loose connection.
 Verify that the YellowJacket Pro receiver blinks green three (3) times anytime power is turned on.
 Verify that the control cable is securely connected, properly wired and undamaged.
 Be sure to check relay and fuses if any controls are not working.
 All units contain a built-in fuse tester and spare fuse. Refer to YellowJacket Top View
on previous page.
 Please visit www.rfhero.com and click on the Support tab for more help.
 Contact us for more assistance at [phone], or email us at [e-mail]
