RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 1 973.334.3100
RFL3200 UK-10, Ten Port Unmanaged Ethernet Switch
User Guide
Table of Contents
1. Warranty Information ......................................................................................................... 2
2. Overview – Key Features .................................................................................................... 3
3. Safety Instructions ............................................................................................................. 4
4. Installing the 3200 UK-10 ................................................................................................... 6
5. Power and Ethernet Connections ........................................................................................ 9
6. Operating the Unit ............................................................................................................ 12
7. Standards, Specifications and Compliances ...................................................................... 14
8. Ordering Information ........................................................................................................ 15
Important: The RFL 3200 UK-10 Unmanaged Ethernet Switch contains no user serviceable parts. Attempted
service by unauthorized personnel shall render all warranties null and void. If problems are experienced with
this product please contact RFL using the contact information below for assistance.
RFL Electronics Inc.
353 Powerville Road
Boonton TWP, NJ 07005-9151, USA
Phone [phone]
Fax [phone]
Email: [email protected]
Trademark information:
“Ethernet” is a trademark of Xerox Corporation.
Copyright ©2010 RFL Electronics Inc. All rights reserved.

1. Warranty Information
•Warranty Statement
The RFL3200 UK-10 Unmanaged Ethernet Switch comes with a three-year warranty from the date of shipment and is
warranted against defects in material and workmanship for three years. During the warranty period RFL will repair or, at its
option, replace components that prove to be defective at no cost to the customer, except the shipping cost of the failed
assembly. All equipment returned to RFL Electronics Inc. must have an RMA (Return Material Authorization) number,
obtained by calling the RFL Customer Service Department at 973.334.3100 or e-mail [email protected] A
defective part should be returned to the factory, shipping charges prepaid, for repair or replacement FOB Boonton, N.J.
RFL warrants product repair from three-years from the date of repair or the balance of the original factory warranty,
whichever is longer.
This warranty does not apply if the equipment has been damaged by accident, neglect, misuse, or causes other than
performed or authorized by RFL Electronics Inc.
This warranty specifically excludes damage incurred in shipment to or from RFL. In the event an item is received in
damaged condition, the carrier should be notified immediately. All claims for such damage should be filed with the carrier.
NOTE
If you do not intend to use the product immediately, it is recommended that it be opened immediately after receiving and
inspected for proper operation and signs of impact damage.
This warranty is in lieu of all other warranties, whether expressed, implied or statutory, including but not limited to implied
warranties of merchantability and fitness for a particular purpose. In no event shall RFL be liable, whether in contract, in
tort, or on any other basis, for any damages sustained by the customer or any other person arising from or related to loss of
use, failure or interruption in the operation of any products, or delay in maintenance or for incidental, consequential,
indirect or special damages or liabilities, or for loss of business or other financial loss arising out of or in connection with
the sale, lease, maintenance, use, performance, failure or interruption of the products.
•FCC Statement
NOTE: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the
user will be required to correct the interference at his own expense.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part
15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used
in accordance with the instructions, may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 2 973.334.3100

2. Overview – Key Features
Designed to operate in harsh substation environments, the RFL 3200 UK-10 Unmanaged Ethernet
Switch provides eight 10/100 Base TX RJ-45 electrical ports and two 10/100/1000 Base TX RJ-45
electrical ports with parallel SFP cages. The SFP cages will allow LC fiber heads to be installed for
100 or 1000 Mb/s operation. Optionally four of the 10/100 RJ-45 ports can be provided with fiber
heads. Each Ethernet port has LED indicators that show if the port is linked, whether there is activity
and the data transfer speed. The RFL3200 carries a 3-year warranty.
Rear Compression Block for
Power and Ground Connections
Four RJ-45 Electric Connectors
are always installed here
Four pairs of Fiber connectors or
four RJ-45 Electrical connectors
can be installed here
GigE high speed connections for
either two RJ-45 electric connectors
or two SFP cages for fiber heads
LED Indicators
for Ethernet
ports
Green Power
ON Light
The RFL3200 UK-10 Unmanaged Ethernet Switch features:
•Plug-and-play installation.
•Switching full and half-duplex support.
•Auto-negotiation and auto crossover on all ports.
•High performance non-blocking operation.
•Automatic learning and aging of up to 8192 MAC addresses.
•IEEE 802.3 compliant.
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 3 973.334.3100

3. Safety Instructions
Keep Away from Live Circuits
Operating personnel should never remove covers. Component replacement and internal
adjustments must be done by qualified RFL service personnel only.
Do not Operate in an Explosive Atmosphere or in Wet or Damp Areas
!
Do not operate the product in the presence of flammable gases or fumes, or in any area that is wet
or damp. Operating any electrical equipment under these conditions can result in a definite safety
hazard.
Do not Substitute Parts or Modify Equipment
!
There are no serviceable parts in the RFL3200 UK-10, do not install substitute parts or make
unauthorized modifications to the equipment. The product may be returned to RFL for service and
repair, to ensure that all safety features are maintained.
Read the User Guide
!
Operators should read this User Guide before attempting to use the equipment, to learn how to use
the equipment properly and safely.
Throughout this User Guide, warnings appear before procedures that are potentially dangerous, and
cautions appear before procedures that may result in equipment damage if not performed properly.
The instructions contained in these warnings and cautions must be followed exactly.
Warning!
Follow all of your company’s policies and procedures regarding the installation of AC powered or
DC powered equipment. If there is a conflict between any procedure in this manual and your
company’s safety rules, then your company’s safety rules must take priority.
Warning!
For DC operations and AC operations where neutral cannot be reliably identified, readily
accessible double pole disconnects and overcurrent devices must be installed between the building
wiring and the RFL3200 UK-10.
For AC operations where the neutral can be reliably identified, readily accessible single pole
disconnects and overcurrent devices must be installed between the building wiring and the
RFL3200 UK-10.
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 4 973.334.3100

Warning!
The unit is intended to be permanently connected to supply mains by properly rated wiring in
accordance with applicable local and national codes (e.g. CEC, NEC etc).
Warning!
The chassis of the unit shell be reliably bonded to protective ground.
Warning!
The RFL 3200 UK-10 may use third party SFP Class 1 Laser Modules. These modules may be
purchased through RFL or third parties. The class 1 certification originates with the SFP
manufacturer, not RFL. Read the following safety information and any additional safety
information included with the modules.
Class 1 Laser Products supplied by RFL are not considered dangerous and comply with the
following standards:
US 21 CFR 1040.10 and 1040.11
IEC 60825-1: 2007
Laser light can potentially cause serious eye damage. The lasers used in the RFL 3200 UK-10
produce light that is invisible to the naked eye. It should be assumed that the laser is active at all
times and it is imperative that the technician never look into the end of the fiber or the aperture
with the naked eye or with optical instruments.
CAUTION
Any installation using an enclosed cabinet with a swing-out rack must be securely fastened to the
floor. This will prevent the cabinet from falling forward when the rack is moved outward.
CAUTION
If your RFL3200 UK-10 has Optical Fiber Heads always replace the protective covers when the
unit is not in use.
NOTICE
RFL products are not designed for safety critical direct control of nuclear reactors and should not
be used as such.
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 5 973.334.3100

4. Installing the 3200 UK-10
The RFL 3200 UK-10 is primarily designed for installation in a 1U rack, however it can also function
in an office or lab environment un-mounted. Mounting ears (brackets) are provided for installation in
a standard 19 inch rack. Optionally, DIN rail and wall mounting can be accommodated. If the
RFL3200 UK-10 is to be stored for an extended period before being installed, precautions to prevent
corrosion must be taken. This is especially important in humid climates.
After unpacking and inspecting the equipment for any shipping damage it should be securely mounted
in its operating location. The various mounting options are listed below. Note RFL does not supply
mounting hardware apart from the items listed. Other mounting options may be available, contact RFL
at [email protected]
Application Description
Standard 19” Rack Mounting Mounting Brackets (2) and 4 screws for mounting
the brackets to the RFL3200 UK-10.
DIN Rail Mounting Adapter Kit installed under the unit.
Wall Mounting Mounting Brackets (2) and 4 screws for mounting
the brackets to the RFL3200 UK-10.
Ordering information can be found on page 15 with a complete list of RFL3200 UK-10 options and
their corresponding Smart Numbers.
Standard Rack Mounted Applications
CAUTION
Any installation using an enclosed cabinet with a swing-out rack must be securely fastened to the
floor. This will prevent the cabinet from falling forward when the rack is moved outward.
Space requirements are shown in the following illustration which depicts a typical 19” rack
installation.
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 6 973.334.3100

Mount the brackets to the RFL3200 UK-10 with the screws provided as shown below.
8.18
(20.8)
Mounting Ears (Brackets) are
provided for mounting in a
standard 19" rack
1.75
(4.45)
7.19
(18.3)
Inches
(cm)
Attach the brackets with the
screws provided
The specified operating temperature of the RFL3200 UK-10 is -30°C to +75°C (-22°F to +167°F).
Operation at higher temperatures may affect reliability and performance. Units installed in enclosed
cabinets should be well ventilated. When operating at temperatures above 55°C (131°F) a full 1U of
chassis space must be left open above the installed RFL3200 UK-10.
DIN Rail Installation
When installation in a metric DIN type rack or cabinet is required, RFL provides an adapter that is
conveniently mounted under the unit as shown below. Carefully install onto the DIN rail and snap into
place.
DIN Mounting Clip
located on bottom of
RFL3200 UK-10
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 7 973.334.3100

Wall Mounting
Brackets are provided for mounting the RFL3200 UK-10 to a wall as shown below.
Attach the brackets with
the screws provided
Because of the many different wall materials available, RFL does not provide wall mounting
hardware. It is the customer’s responsibility to securely mount the RFL3200 UK-10 to the wall.
Mount the unit in the required location allowing enough space for convection cooling.
Un-mounted Unit
When installed in a lab or workplace setting ensure that there is an unobstructed view of the front
of the unit for observation of the LED indicators. Keep an open area around the unit so that
cooling by convection can occur while the RFL3200 UK-10 is in operation.
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 8 973.334.3100

5. Power and Ethernet Connections
The following section describes how to connect power to the RFL3200 UK-10.
Before beginning the installation note the following:
•Before proceeding with the connection of power to the RFL3200 UK-10 ensure that the power
wires to be installed are disconnected at their source.
•Ensure that the power supply installed in your RFL3200 UK-10 will operate at the
available input power.
•Follow all of your company’s policies and procedures regarding the installation of AC powered
or DC powered equipment. If there is a conflict between any procedure in this Users Guide
and your company’s safety rules, then your company’s safety rules must take priority.
Connecting Power
The RFL3200 UK-10 has a label located on the rear of the unit above the compression block that
indicates which power supply was installed in the unit before leaving the factory.
Before proceeding with the power and ground wire installation check the power supply label to
ensure that the unit will operate at the input voltage available.
WARNING!
The RFL3200 UK-10 must be properly grounded as described on the following page before
attempting to connect input power. Improper ground connections may result in system
malfunctions, equipment damage, or electrical shock.
For DC operations and AC operations where neutral cannot be reliably identified, readily accessible
double pole disconnects and overcurrent devices must be installed between the building wiring and
the RFL3200 UK-10.
For AC operations where the neutral can be reliably identified, readily accessible single pole
disconnects and overcurrent devices must be installed between the building wiring and the
RFL3200 UK-10.
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 9 973.334.3100

Power and ground connections are made to the compression block on the rear of the RFL3200
UK-10 as shown below.
Compression block on rear of
the RFL3200 UK-10
+
-
Power Supply Label
1. Before proceeding with the connection of power to the RFL3200 UK-10 ensure that the
power wires to be installed are disconnected at their source.
2. If the unit is installed in a traditional cabinet type location with a station battery supply,
connect a ground wire to the rack ground; connection type and location will vary by
installation. The grounding wire should be kept as short and straight as possible, to keep its
resistance and inductance to a minimum.
3. Carefully remove the 3-pin compression block plug from its socket, being careful not to
damage the pins.
4. The RFL3200 UK-10 is designed for permanently wired installation in restricted access
locations only.
The RFL3200UK-10 contains fuses on both supply poles that are intended for replacement
by qualified personnel only. The following fuses are recommended
19-32V 115V, 5x20 mm, 2 amp
38-150V 250V, 5x20 mm, 1 amp
200-300V 250V, 5x20 mm, 0.25 amp
5. Strip back and connect the positive and negative leads from the station battery to the
positive and negative connections on the compression block. If an AC supply is used the
negative and positive markings can be ignored. When installing power and protective earth
connections, expose no more than 0.2” (5mm) of bare wire. Twist the wires to prevent
strands from escaping and use care when inserting the wires into the connector. Inspect the
wires prior to energizing to ensure no strands have escaped.
6. Reinstall the compression block into its socket.
Before connecting the power at its source, check the following:
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 10 973.334.3100

RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 11 973.334.3100
1. Is the unit grounded correctly?
2. Is the polarity of the input power correct?
3. Have the power wires been inspected as described in step 5.
4. Is the unit ventilated correctly?
The RFL3200 UK-10 may now have power applied.
Ethernet Connections
Make the necessary LAN and WAN Ethernet connections as required. When installing fiber optic
ST connectors, make sure the connectors are properly aligned before twisting to lock in place.
For Ethernet LED indicators see the next section.
Optical Connectors – Distance Options
LAN Ports 5 to 8
Fiber Heads if
installed
RFL Smart
Number
Option and
RFL Part
Numbers
Wavelength/
Mode Connector
Type RX Sensitivity TX
Power System
Gain
Typical
Distance
(3dB
margin)
100 Base-FX 2
1310 nm
Multimode ST -33.9 to
-31dBm
-22.5 to -14dBm
Average into
50µm fiber
-19 to -14dBm
Average into
62.5µm fiber
14dB12 km
(1.2 mi)
WAN Ports 9 & 10
SFP Base Units, if
installed, available
options
SFP-100 Base-FX B
(104358-1)
1310 nm
Multimode LC -30dBm
(max)
-15.7dBm
(typical) 14dB 2 km
(1.2 mi)
SFP-100 Base-LX C
(104358-2)
1310 nm
Singlemode LC -31dBm
(max)
-15 to
-8dBm 20dB 10 km
(6.2 mi)
SFP-100 Base-FX D
(104358-3)
1310 nm
Singlemode LC -34 to
-10dBm -5 to 0dBm 19dB 40 km
(24.8 mi)
SFP-100 Base-ZX E
(104358-4)
1550 nm
Singlemode LC -34 to
-10dBm -5 to 0dBm 19dB 80 km
(49.7)
SFP-1000 Base-SX F
(104359-1)
850 nm
Multimode LC -19dBm
(max)
-9.5 to
-3dBm 13dB 550 m
(1800 ft)
SFP-1000 Base-LX G
(104359-2)
1310 nm
Singlemode LC -19dBm
(max)
-9.5 to
-3dBm 13dB 10 km
(6.2 mi)
SFP-1000 Base-FX H
(104359-3)
1310 nm
Singlemode LC -9 to
-27dBm -2 to 3dBm 17dB 40 km
(24.8 mi)
SFP-1000 Base-ZX I
(104359-4)
1550 nm
Singlemode LC -24dBm
(max) 0 to 5dBm 21dB 80 km
(49.7)
Notes: 1. For 50μm fiber.

CAUTION
If your RFL3200 UK-10 has Optical Fiber Heads installed, always reinstall the protective covers
when the unit is not in use.
6. Operating the Unit
It is important to note the numbering convention of the Ethernet ports as shown below.
RFL Electronics Inc.
RFL 3200 UK-10
PWR
TX RX
1234
5678
TX TX TX
RX RX RX
5678
1234910
Power indicator will show green
when power is applied to unit
LED indicators for
ports 1 through 8 GigE ports 9 and 10 have
integral LED indicators
In the example shown, ports 5 through 8 have fiber heads installed. These ports can be ordered from
the factory as RJ-45 Electrical Connectors.
LAN Ports 1 – 8 LED Indicators
LED indicators 1 through 8 have two functions and will show the following:
a. The state of the Ethernet connection and;
b. The connection speed.
LED Condition Status
LED ON Port is linked and functioning
LED Blinking There is activity on the port
a.
LED OFF There is NO connection on the port
Color Status
Yellow 100 Mbps
b. Red 10 Mbps
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 12 973.334.3100

WAN GigE Ports 9 and 10 LED Indicators
When SFP Base Units are installed in the SFP cages at ports 9 and 10 the RJ-45 connectors are
disabled.
SFP -100/1000 Base Unit (typical)
The integral LED indicators will continue to show status for the fiber heads however. The LED
indicators are shown below.
Right green LED
indicator
Left green LED
indicator
LED indicators 9 and 10 have two functions and will show the following:
Left LED Right LED Status
Off Off There is no link on the port
Green Off 1000 Mb/s link
Blinking green Off 1000 Mb/s data transfer
Off Green 100 Mb/s link
Off Blinking green 100 Mb/s data transfer
Green Green 10 Mb/s link
Blinking green Blinking green 10 Mb/s data transfer
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 13 973.334.3100

7. Standards, Specifications and Compliances
RFL 3200 UK-10 Environmental Compliances
IEC 61850-3
IEEE 1613
RFL 3200 UK-10 Agency Approvals
ISO 9001: 2000 certified.
CE Marking: EMC, LVD.
Emissions: FCC Part 15 (Part A).
EN55022 (CISPR22 Class A).
Safety: EN 60950-1.
Laser Eye Safety: CDRH, Complies with 21 CFR Chapter 1,
Subchapter J.
IEC 60825-1 : 2007
Ethernet Port Specifications
802.3i 10 Base-T.
802.3u 100 Base-TX, 100 Base-FX.
802.3x Duplex and Flow Control
802.3AB 1000 Base-T
Power Supply Specifications
Supply Voltage: 19 – 32 Vdc.
38 – 150 Vdc / 96-132 Vac (50 or 60 Hz).
200 – 300 Vdc / 200 – 275 Vac (50 or 60 Hz).
Maximum Input Power: 15 W Continuous.
Operating Temperature: -30º C (-22º F) to 75º C (167º F). Convection cooling only.
Operating Humidity: 90% RH Non Condensing @ 40º C (104º F).
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 14 973.334.3100

8. Ordering Information
RFL 3200 Smart Number Description: UK 10
Chassis with Main Board and Main Power Supply Smart
Number
24 Vdc w/Compression Block 1
38 – 150 Vdc /110 Vac w/Compression Block 2
200 - 300 Vdc/220 Vac w/Compression Block 3
10/100 Ethernet Switch LAN Ports (1 – 8)
8 – RJ-45 10/100 Base TX 1
4 – Optical 100 Base FX MM ST, 4 – RJ-45 10/100 Base –TX 2
Ethernet Switch WAN Port 9 and 10 Option
Electrical RJ-45 10/100/1000 Base TX A
1 – SFP – 100 Base – FX, 1310nm, 2km/1.2mi MM LC Conn. B
1 – SFP – 100 Base – LX, 1310nm, 10km/6.2mi SM LC Conn. C
1 – SFP – 100 Base – FX, 1310nm, 40km/24.9mi SM LC Conn. D
1 – SFP – 100 Base – ZX, 1550nm, 80km/49.7mi SM LC Conn. E
1 – SFP – 1000 Base – SX, 850nm, 550m/1800ft MM LC Conn. F
1 – SFP – 1000 Base – LX, 1310nm, 10km/6.2mi SM LC Conn. G
1 – SFP – 1000 Base – FX, 1310nm, 40km/29.4mi SM LC Conn. H
1 – SFP – 1000 Base – ZX, 1550nm, 80km/49.7mi SM LC Conn. I
Mounting
Wall Mount 1
19 Inch Rack 2
DIN Rail Mount 3
Customer Resource Center
The RFL Electronics Inc. "On-line Customer Resource Center" has been created to provide customers
with "real-time" information necessary to keep RFL equipment operating optimally. The Resource
Center contains Application Notes, Service Notices, Product Bulletins, Software Downloads, Software
Upgrades, Technical Product Manuals and Sales Brochures, in a convenient and easy-to-use location
on our web site. The Resource Center will be updated regularly, so the latest information is always at
your fingertips. Registration is free, easy, and ensures your access to the Resource Center at any time.
To register please use the link provided on this page.
Once registered at the "Customer Resource Center", RFL will automatically notify you via e-mail
when new products are released, or when downloadable documents are available for the categories you
have selected. RFL will alert you with important Service Notices that could improve the performance
of your product or make you aware of special considerations when applying RFL products in certain
applications.
RFL Members Area
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 15 973.334.3100

Disposal
When disposing of the equipment, it should be done in strict accordance with all local and national
regulations for the disposal of electrical and electronic equipment. The printed circuit boards should
be separated for recycling.
Rev. Description Date Approval
Beta New Document Release (No ECO release)
6-16-09 TG
Beta
Second revision (No ECO release)
9-18-09 TG
11-17-09
Changes to Safety Instructions and Power connections.
Marketing review. Add Smart Numbers.
Initial ECO Release.
11-17-09 TG
10-6-10
Changes to Safety Instructions as per CSA.
NOTICE
The information in this publication is proprietary and confidential to RFL Electronics Inc. No part of this
publication may be reproduced or transmitted, in any form or by any means (electronic, mechanical, photocopy,
recording, or otherwise), or stored in any retrieval system of any nature, unless written permission is given by
RFL Electronics Inc.
This publication has been compiled and checked for accuracy. The information in this publication does not
constitute a warranty of performance. RFL Electronics Inc. reserves the right to revise this publication and make
changes to its contents from time to time. We assume no liability for losses incurred as a result of out-of-date or
incorrect information contained in this publication.
RFL Electronics Inc.
353 Powerville Road
Boonton Township, NJ 07005-9151, USA
Phone: [phone]
www.rflelect.com
RFL3200 UK-10
Printed in U.S.A.
Revised October 6, 2010
Part Number MC32KUK10UG
RFL3200 UK-10 User Guide RFL Electronics Inc.
October 6, 2010 16 973.334.3100
