RGB Laserverkoop XS-1000 User manual

Model: XS-1000 Full
diode RGB LASER
User's Manual
This product manual contains important information about the safe installation and use of this
product. Please read and follow these instruction carefully and keep this manual in a safe place
for future reference.
Security warning
..
When unpacking and before disposing of the carton, check if there is any transportation
damage before using the product. Should there be any damage caused by transportation,
consult your dealer and do not use the apparatus. WARNING: The laser projector can only be
used with an emergency stop system. If there is any problem the laser should be switched off
directly . Never shine the laser in your eyes or in the eyes of other people. RGB Laser verkoop
is not responsible for how this laser projector is used, The laserist is at all times responsible for
its safe use!

The second channel for three colors instructions :
The second channel for seven colors instruction :
This equipment is not waterproof,keep it from rain,moisture and liquids.
Do not install the product or project the beam onto inflammable
surfaces.Minimum distance is 5 M
The product is only intended for installation,operation and maintenance by
qualified personnel.
Product should install in a cool place.Keep away from the wall 50cm
Avoid direct exposure to the light from the lamp.The light is harmful to eyes.
Keep the optical system clean.Do not touch the laser reflect lens with bare
hands.Do not use any alcohol liquid or any other liquit to clean the optical
system.Use medicinal absorbent cotton to clean it.
Please do not attempt to dismantle and/or modify the product inner
structure.Otherwise,would not provide 1 year of free warranty.
Electrical connection must only be carried out by qualified personnel.
Before installation,ensure that the voltage and frequency of power supply match
the power requirement of the product.
It is essential that each product is correctly earthed and that electrical installation
conforms to all relevant standards.
Do not connect this device to any other types of dimmer apparatus.
Make sure that the power-cord is never crimped or damaged by sharp edges.
Never let the power-cord come into contact with other cables.Only handle the
power-cord by the plug.Never pull out the plug by tugging th power-cord
There is no user serviceable parts inside the product,do not open the housing and
never operate the product with the cover removed.
If you have any questions,don't hesitate to consult our dealer or manufacturer.
Blank and Laser
off
0~5
Laser off
6~15
Red
16~25
Green
26~35
Yellow
36~105
single color(random ), values 105
is the fastest speed
106~175
3 color(random ), values 175 is
the fastest speed
176~245
Flow color, values 245 is the
fastest speed
246~255
default color
Blank /laser off
0~5
Laser off
6~10
White
11~15
Red
16~20
Yellow
21~25
Green
26~30
Cyan
31~35
Blue
36~40
Violet
41~110
single color(random ), values 110 is
the fastest speed
111~180
7 color(random ), values 180 is the
fastest speed
181~250
Flow color, values 250 is the fastest
speed
251~255
default color

XS series laser adopts embedded technology which enable laser
moving,scaling,rotating,turn spin and gradually draw,animation,text,broken pen,wave
laser effect can be achieved easily.
Unique functions as following:
1.Through DMX-512 Controller,you can select auto or sound control mode or to play
built-in laser effects.
2.Through menu to set up scanner speed,laser color,X opposition,Y opposition
3.Unique sound control technology.Laser effect can response according to sound
rhythm
Product technical parameters
Item NO: XS1000
1.Voltage:AC90~240V 50~60HZ±10%
2.Power consumption:80W
3.Laser source:full diode laser diode.
4.Laser power /wavelength: 1x 230-400mW Red (638nm)
1x80~120mW OSRAM Green (532nm )
1 x 600-800mW Blue (445nm )
5.Colors:RGB full color
6.Modulating signal:Analoog 50k
7.Laser Patterns:256 pieces built-in laser patterns
8.DMX Channel:12CH
9.Scanner system:20kpps
10.Control signal:DMX-512 international standard signal
11.Control mode:Music,auto,master-slave and DMX-512l,ILDA Control
12.Cooling system:fan
13.Operation environement :Indoor
14.Operation temperature:-10°C～40°C
15.Ｎet Weight :1.95kg
16.Dimension Size : 20 x 15 x 10 cm
The Second channel for single color instruction :
6 X- axis rotation
0--127
Manual movement
128--255
Auto rotate, The speed of the plunger proportional to the value
7.Y- axis rotation
0--127
Manual movement
128--255
Auto rotate, The speed of the plunger proportional to the value
8 .Pattern rotation
0--127
Manual movement
128--191
Clockwise motion, The speed of the plunger proportional to the
value
192--255
Counterclockwise motion, The speed of the plunger
proportional to the value
9 .Zoom
0--85
Pattern from small to larger, The speed of the plunger
proportional to the value
86--170
Pattern from larger to small , The speed of the plunger
proportional to the value
171--255
Auto loop zoom, The speed of the plunger proportional to the
value
10 .Pattern size
0--255
0—Default size,1-- Minimum size,255-- Maximum size
11.Dot display
0--255
0—Dot not display,1—Dot Minimum brightness
display
255—Dot Minimum brightness display
12.Slow draw
0--127
Auto Slow draw 1, The speed of the plunger
proportional to the value
128--255
Auto Slow draw 2, The speed of the plunger
proportional to the value
Blank/Laser off
0~15
laser off
16~25
no blank
26~135
Color flow effect, values 135 is the fastest flow
speed
136~245
Strobe effect, values 245 is the fastest speed
246~255
default blank

DMX Channel Chart 12 CHS :
Channel
DMX 512
Fig
Control Function
1.Mode Select
0~49
Music Trigger
0--49
Music trigger
50--99
Auto trigger（Beam）
100--149
Auto trigger（Pattern）
160--199
Manual mode，Music trigger
200--255
Auto mode
2. Blank /Laser off
0--255
Single color (laser off-No blank- Flow
blank-Strobe blank-- Default color---
0--255
3color (laser off—red—green--yellow--Default
color—single color(random )—3
color(random)-Flow blank-default color)
3 . Pattern select
0--255
Max 256 pieces Patterns
4 X-axis movement
0--127
Manual movement
128--191
Auto Move Down, The moving speed of the
plunger proportional to the value
192--255
Auto Move Up, The moving speed of the plunger
proportional to the value
5..Y-axis
Movement
0--127
Manual movement
128--191
Auto Move Right, The moving speed of the plunger
proportional to the value
192--255
Auto Move Left, The moving speed of the plunger
proportional to the value
Product packing list
These items are packed together with the lighting fixture.
Upon unpack,please check：
Laser light X 1 Set
Power cable X 1 Pcs
Product manual X 1 Pcs
DMX Connection method
DMX control signal connection must be made with a two core-screened
cable,with each core having at least a 0.5mm diameter.Please use the product's
signal cable OUT and IN as connection.The signal OUT and IN cables connection
shown as above picture.
Note:Please do not connect the signal cable OUT and IN in other way except
above shown.

This product accepts digital control signals in protocol DMX512(1990).The
amount of lighting fixtures connected in parallel is no more than
32.Connect the DMX controller's Output to the first lighting fixture's Input cable
with a 2 core XLR signal cable(Shown as above ),connect the first lighting fixture's
Output cable to the second lighting fixture's Input cable and connect the
rest light fixtures in the same way.Eventually,connect the last lighting
fixture's Output cable to a DMX terminator
Under DMX-512 signal control mode,the last lighting fixture's DMX Output must be
connected with a DMX terminator.This prevents electrical noise from disturbing and
corrupting the DMX control signals.The DMX terminator is simply an XLR
connector with a 120(ohm ) resistor connected across pins 2 and
3,which is then plugged into the output socket on the last projector in the
chain.Then connections are illustrated above.
ILDA control signal connection method:
Connection built through product male/female DB 25 degree socket.Like above
picture. In addition to the above connections, ILDA signal cannot be connected in any
other way.
Back panel introduction
ILDA control mode
Connect ILDA signal,the lighting fixtures will automatically switchover to
ILDA working mode.This lighting fixtures' ILDA signal cable connection
way is compliant to international standard.
DMX Channel Chart :
DIP switch: Address 1-10 Pin
1 ~ 10
Function
0,0,0,0,0,0,0,0,0,0
Sound Mode
1,0,0,0,0,0,0,0,0,0
Auto Mode
0,0,1,0,0,0,0,0,0,0
Slave Mode
1,1,0,0,0,0,0,0,0,0
Graphic Mode
x,x,x,x,x,x,x,x,x,1
DMX 512 Control

Maintenance
To prolong the life of the product,it is very important to do
maintenance work.The environment is hash outdoors,or if the product is
idle for a long time,damp,smoke or particularly dirty surroundings can cause
greater accumulation of dirt on its cover and housing.So it should be cleaned
to maintain an optimum light output and at the same time to prevent it from
corrupted by acid gas.
Friendly notice:Do not use any organic solvent,e.g.alcohol to
clean housing of the apparatus.
Troubleshooting
Note:This product is under warranty for 1 year(From the date of delivery),
1 years after can provide paid maintenance services. But if it is because of
natural disasters or user's operation not according to manual. We won't
provide warranty. RGB Laser verkoop give no warranty. Defect machine
must ship back to factory on client cost.
Problems
Action
The product doesn't
switch on
Power connection is not correct.Re-connect the
power.
Power supply is damaged or abnormal.Call a
qualified personnel to fix it.
Connection of control board is not correct.Call a
qualified personnel to fix it.
The product can
turn on,but no light
coming out.
Control mode is wrongly setting up.Resetting it
according to instruction book
Control section is damaged.Call a qualified
personnel to fix it.
The beam appears
dim
The product is too hot.Take ventilation measures
to make it cool.
