RGBlink DXP H1010 User manual

DXP H1010 User Manual
1
DXP H1010
User Manual
Article No: RGB-RD-UM-DXP H1010 E000
Revision No: V1.0

DXP H1010 User Manual
2
Content
Declarations ............................................................................................................................................................ 3
FCC/Warranty ..................................................................................................................................................3
Operators Safety Summary ............................................................................................................................. 4
Installation Safety Summary ........................................................................................................................... 4
Chapter 1 Your Product ...........................................................................................................................................6
1.1 Product Overview ......................................................................................................................................6
1.2 Front Panel ................................................................................................................................................ 7
1.3 Rear Panel ......................................................................................................................................... 8
1.4 Application Diagram ..........................................................................................................................9
Chapter 2 Install Your Product .............................................................................................................................. 10
2.1 Plug in Signals ..........................................................................................................................................10
2.2 Plug in Main Power ................................................................................................................................. 10
2.3 Turn on Your DXP H1010 ......................................................................................................................... 10
Chapter 3 Use Your Product ..................................................................................................................................11
3.1 OLED Panel Function: ..............................................................................................................................11
3.2 Main MENU Option: ................................................................................................................................11
3.2.1 SWITCH：(Default: 1 2 3 4 5 6 7 8 9 10) ......................................................................................12
3.3.2 SCENE ........................................................................................................................................... 12
3.3.3 EDID: (Default: LPCM-2CH) .......................................................................................................... 12
3.3.4 Ethernet ....................................................................................................................................... 13
3.3.5 REMOTE ID：(Default ID 4) ..........................................................................................................14
3.3.6 AUDIO SELECT: (Default H) ...........................................................................................................15
3.3.7 SYSTEM INFO: ...............................................................................................................................15
3.4 Remote Control.......................................................................................................................................15
3.4.1 IR01 .............................................................................................................................................. 15
3.4.2 Console .........................................................................................................................................16
3.5 Ethernet Control ..................................................................................................................................... 18
Chapter 4 Ordering Codes .....................................................................................................................................21
4.1 Product ....................................................................................................................................................21
Chapter 5 Support .................................................................................................................................................22
5.1 Contact us ............................................................................................................................................... 22
Chapter 6 Appendix .............................................................................................................................................. 23
6.1 Specification ............................................................................................................................................23
6.2 Terms & Definitions .................................................................................................................................24
6.3 Revision History .......................................................................................................................................27

DXP H1010 User Manual
3
Thank you for choosing our product!
This User Manual is designed to show you how to use this video processor quickly and make use of all the features. Please
read all directions and instructions carefully before using this product.
Declarations
FCC/Warranty
Federal Communications Commission (FCC) Statement
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant to Part 15 of the FCC
rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not
installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area may cause harmful interference, in which case the user will be responsible
for correcting any interference.
Guarantee and Compensation
RGBlink provides a guarantee relating to perfect manufacturing as part of the legally stipulated terms of guarantee. On
receipt, the purchaser must immediately inspect all delivered goods for damage incurred during transport, as well as for
material and manufacturing faults. RGBlink must be informed immediately in writing of any complains.
The period of guarantee begins on the date of transfer of risks, in the case of special systems and software on the date of
commissioning, at latest 30 days after the transfer of risks. In the event of justified notice of compliant, RGBlink can repair the
fault or provide a replacement at its own discretion within an appropriate period. If this measure proves to be impossible or
unsuccessful, the purchaser can demand a reduction in the purchase price or cancellation of the contract. All other claims, in
particular those relating to compensation for direct or indirect damage, and also damage attributed to the operation of
software as well as to other service provided by RGBlink, being a component of the system or independent service, will be
deemed invalid provided the damage is not proven to be attributed to the absence of properties guaranteed in writing or due
to the intent or gross negligence or part of RGBlink.
If the purchaser or a third party carries out modifications or repairs on goods delivered by RGBlink, or if the goods are handled
incorrectly, in particular if the systems are commissioned operated incorrectly or if, after the transfer of risks, the goods are
subject to influences not agreed upon in the contract, all guarantee claims of the purchaser will be rendered invalid. Not
included in the guarantee coverage are system failures which are attributed to programs or special electronic circuitry
provided by the purchaser, e.g. interfaces. Normal wear as well as normal maintenance are not subject to the guarantee
provided by RGBlink either.
The environmental conditions as well as the servicing and maintenance regulations specified in this manual must be complied
with by the customer.

DXP H1010 User Manual
4
Operators Safety Summary
The general safety information in this summary is for operating personnel.
Do Not Remove Covers or Panels
There are no user-serviceable parts within the unit. Removal of the top cover will expose dangerous voltages. To avoid
personal injury, do not remove the top cover. Do not operate the unit without the cover installed.
Power Source
This product is intended to operate from a power source that will not apply more than 230 volts rms between the supply
conductors or between both supply conductor and ground. A protective ground connection by way of grounding conductor in
the power cord is essential for safe operation.
Grounding the Product
This product is grounded through the grounding conductor of the power cord. To avoid electrical shock, plug the power cord
into a properly wired receptacle before connecting to the product input or output terminals. A protective-ground connection
by way of the grounding conductor in the power cord is essential for safe operation.
Use the Proper Power Cord
Use only the power cord and connector specified for your product. Use only a power cord that is in good condition. Refer cord
and connector changes to qualified service personnel.
Use the Proper Fuse
To avoid fire hazard, use only the fuse having identical type, voltage rating, and current rating characteristics. Refer fuse
replacement to qualified service personnel.
Do Not Operate in Explosive Atmospheres
To avoid explosion, do not operate this product in an explosive atmosphere.
Installation Safety Summary
Safety Precautions
For all DXP H1010 processor installation procedures, please observe the following important safety and
handling rules to avoid damage to yourself and the equipment.
To protect users from electric shock, ensure that the chassis connects to earth via the ground wire provided in
the AC power Cord.
The AC Socket-outlet should be installed near the equipment and be easily accessible.

DXP H1010 User Manual
5
Unpacking and Inspection
Before opening DXP H1010 processor shipping box, inspect it for damage. If you find any damage, notify the
shipping carrier immediately for all claims adjustments. As you open the box, compare its contents against the
packing slip. If you find any shortages, contact your sales representative.
Once you have removed all the components from their packaging and checked that all the listed components
are present, visually inspect the system to ensure there was no damage during shipping. If there is damage,
notify the shipping carrier immediately for all claims adjustments.
Site Preparation
The environment in which you install your DXP H1010 should be clean, properly lit, free from static, and have
adequate power, ventilation, and space for all components.

DXP H1010 User Manual
6
Chapter 1 Your Product
1.1 Product Overview
DXP H1010 is a true 4K HDMI Matrix Switcher which allows to route any of 4 HDMI sources to any 4 HDMI
displays! The 10x10 HDMI Matrix switch is a complete HDMI routing solution for True 4K HDMI systems. It
supports resolution up to 4K 60Hz @ 4:4:4 and effortless control through Ethernet control, Android App
Control, IR remote control, RS-232 and the front panel.
Key Feature
Connects up to 10 HDMI sources to 10 HDMI display monitors
HDMI 2.0 with 3D, HDCP 2.2 & DVI1.1 Compliant
Ultra-high-definition video up to 4K 60Hz @ 4:4:4 18Gbps (6Gbps per color)
Support HDR10, Dolby Vision, HLG
Supports up to, Dolby TrueHD, Dolby ATMOS, DTS-HD MA, DTS:X, LPCM 7.1 @ 192KHz
Supports ARC (Audio Return Channel) function
Multiple control methods: Front panel buttons/ IR remote control/ WebGUI Control/ iOS/Android App
Control and RS232 Control
Built-in OLED screen & LED button at front panel provides quick view of all port connection
Rack mountable( 1U design)
S/PDIF coaxial audio outputs allow audio to be de-embedded from HDMI outputs
Support HDMI cable lock on each HDMI input/output port

DXP H1010 User Manual
7
1.2 Front Panel
No.
Feature
LED Status
Description
1
IR Receiver
N/A
Receiving IR remote signal
2
POWER
Blue ON
Power ON
Red ON
Standby
3
OLED Display
N/A
Display operating status or Menu.
4
UP Button
N/A
Go up direction in Menu.
DOWN Button
Go down direction in Menu.
LEFT Button
Go left direction in Menu.
RIGHT Button
Go right direction in Menu.
ENTER Button
Execute selected function
MENU Button
Blue ON
Press to enter Menu or display current operating status
Press and hold 3 seconds to enable/disable KEYLOCK
SCENE Button
Save/Load scene
ALL Button
Select all output
OFF Button
Turn off select output
5
OUTPUT Buttons
Blue ON
Press these buttons to select the desired output
Monitor connected
OFF
No monitor connected
6
INPUT Buttons
Blue ON
Press these buttons to select the desired input
Video input detected
OFF
No video input

DXP H1010 User Manual
8
1.3 Rear Panel
1
INPUT HDMI
N/A
HDMI input port 1~10
2
OUTPUT HDMI
N/A
HDMI output port 1~10
3
Audio
N/A
SPDIF audio output port 1~2
4
IR
N/A
External IR receiver
5
CONSOLE
N/A
RS232 command control / Firmware update
6
FW
N/A
Firmware update
7
SET
N/A
Set
8
RJ45
N/A
WEB control interface
9
DC JACK
N/A
Power input
Notice
* In standby mode, IR remote cannot control matrix but power on matrix only
* Please press ENTER to execution any change of menu settings

DXP H1010 User Manual
9
1.4 Application Diagram

DXP H1010 User Manual
10
Chapter 2 Install Your Product
2.1 Plug in Signals
Connect input signals and output display to the product before all devices are powered on. Tighten connector screws/locks
where provided.
2.2 Plug in Main Power
Connect IEC cable to device and plug into wall socket. Turn on power at wall socket.
2.3 Turn on Your DXP H1010
The device will enter to the boot interface, and OLED display will show as below.
10 X 10 HDMI MATRIX
Version V1.00

DXP H1010 User Manual
11
Chapter 3 Use Your Product
3.1 OLED Panel Function:
Power on Main Screen
10 X 10 HDMI MATRIX
Version V1.00
After power on, the main screen will show matrix name and version information.
The matrix will back to main screen if no operations in 30 seconds
Channel Switching:
OUTPUT 1 2 3 4 5 6 7 8 9 10
INPUT 1 2 3 4 5 6 7 8 9 10
Press OUTPUT 1~10 to select HDMI output (multiple selections) then press INPUT 1~10 (single selection), press ENTER to
execute.
Key Lock:
KEYLOCK!
Press MENU button for 3 seconds to enable/disable key lock function.
3.2 Main MENU Option:
1. SWITCH
2. SCENE
3. EDID
4. ETHERNET
5. REMOTE ID
6. AUDIO SELECT
7. SYSTEM INFO
8. USB UPDATE
Operation:
Press UP or DOWN key to move to select an item for setting and press ENTER key to enter into subpage.
When the selected sub-page setting is completed, press the MENU button to return to the main page

DXP H1010 User Manual
12
3.2.1 SWITCH：(Default: 1 2 3 4 5 6 7 8 9 10)
OUTPUT 1 2 3 4 5 6 7 8 9 10
INPUT 1 2 3 4 5 6 7 8 9 10
This function is used to switch the input/output port. Enter the SWITCH menu. Press the ENTER key, then the OLED second line
INPUT will flash. Press LEFT or RIGHT button to select the output to be modified. Then press UP or Down button to select the
input port. After that, press ENTER to confirm setting.
3.3.2 SCENE
OUTPUT SAVE
INPUT LOAD
SCENE function provides 10 sets of channel setting to fast reload for different application.
SAVE
Save current channel setting, press UP or DOWN to select the number and ENTER to save.
It will show input number and status of audio selection.
At main screen you could use IR01 remote button Bto enter SCENE function, button 7~* (output) to select port number 1~4 to
save, or use Up/Down button to select 5~10.
SAVE 1 2 3 4 5 6 7 8 9 10
SCENE#1 2H 3H 4A XA 5H 7A 9X 10H 1A 6X
LOAD
Reload saved scenes, press UP or DOWN to select the number and ENTER to load.
It will show input number and status of audio selection.
At main screen you could use IR01 remote button Bto enter SCENE function, button 1~4 (input) to select port number 1~4 to
load, or use Up/Down button to select 5~10.
LOAD 1 2 3 4 5 6 7 8 9 10
SCENE#1 2H 3H 4A XA 5H 7A 9X 10H 1A 6X
3.3.3 EDID: (Default: LPCM-2CH)
Because the player output display resolution will be based on TV EDID, this Matrix provides two default EDID modes:”BUILD-IN
MODE”and “COPY MODE”.
BUILD-IN MODE
COPY MODE
BUILD-IN MODE:
This mode supports video resolution up to 4K 60Hz, audio format support LPCM-2CH、 LPCM-7.1、 AC3、 DTS. After enter BUILD-IN
MODE menu, press UP or DOWN key to select then press ENTER to confirm setting.
1.1080P 2CH
2.1080P MULTI
3.4K30 2CH
4.4K30 MULTI
5.4K60 2CH
6.4K60 MULTI
Player - 4
Player - 3
Player - 2
Player - 1
HS10M-4K6G
HDMI – 4
EDID
HDMI – 3
EDID
HDMI – 2
EDID
HDMI – 1
EDID
1.1080P 2CH
2.1080P MULTI
3.4K30 2CH
4.4K30 MULTI
5.4K60 2CH
6.4K60 MULTI

DXP H1010 User Manual
13
COPY MODE：
To fully support the TV resolution and audio mode, the matrix provides “copy mode”to copy TV EDID for input source reference.
When use the copy mode, recommend copying the lowest resolution TV EDID. Otherwise it may cause no picture display if the TV
resolution is not able to support higher resolution.
After entering COPY MODE menu, press UP or DOWN button to select the OUTPUT (1 to 4) and press ENTER, then press UP or
DOWN button to select the INPUT (1 to 4 or ALL) and press ENTER to confirm. If selected output not connected with monitor it
will show “NO OUT X HPD”and return to upper menu when press ENTER.
COPY MODE
From OUTPUT : 1
COPY MODE
To INPUT : 1
It will show EDID Write ERROR if update failed, or EDID WRITE OK if success.
3.3.4 Ethernet
*1. IP ADDRESS
2. SUBNET MASK
3. GATEWAY
4. DHCP CLIENT
5. MEDIA TYPE
6. MAC FILTER
IP Address: (Default: 192.168.0.10)
IP Address
192.168. 0.10
This function can be setup MATRIX host intranet ”IP Address”, press the ENTER, the left-most number of second row will flash,
then press the UP or DOWN button to change the numbers, press LEFT or RIGHT to move to another location, the move to a
position number will flash, press ENTER to complete the setting.
Subnet Mask: (Default 255.255.255.0)
Subnet Mask
255.255.255.000
This function can be setup MATRIX host intranet “Subnet Mask”, press the ENTER, the left-most number of second row will
flash, then press the UP or DOWN button to change the numbers Press the ENTER, , press LEFT or RIGHT to move to
another location, the move to a position number will flash, press ENTER to complete the setting.
HS10M-4K6G
HDMI - OUT 4
HDMI - OUT 3
HDMI - OUT 2
HDMI - OUT 1
Player - 4
Player - 3
Player - 2
Player - 1
HDMI - IN4
LPCM-2CH
HDMI - IN3
LPCM-2CH
HDMI - IN2
LPCM-2CH
HDMI - IN1
TV1 EDID
From OUTPUT: 1
To INPUT: 1
TV1 EDID

DXP H1010 User Manual
14
Gateway: (Default 192.168.0.1)
Gateway
192.168. 0. 1
This function can be setup MATRIX host intranet “Gateway”, press the ENTER, the left-most number of second row will flash, then
press the UP or DOWN button to change the numbers Press the ENTER, press LEFT or RIGHT to move to another location, the
move to a position number will flash, press ENTER to complete the setting.
DHCP Client: (Default Disable)
DHCP Client
Disable
When DHCP Clients setup at “Enable”, the MATRIX host will automatically get IP Address, Subnet Mask, Gateway, if setup at
“Disable”, the MATRIX Host IP Address need go through “ETHERNET”menu to set IP Address, Subnet Mask, Gateway, to press the
ENTER, the second row will flash, then press the UP or DOWN to select DISABLE, ENABLE, then press ENTER to complete the
setting.
Media Type: (Default 100M)
Media Type
100M
This function can be setup MATRIX host intranet “Media Type, press the ENTER, the second row will flash, then press the UP or
DOWN button to select 10M, 100M, AUTO, press ENTER to complete the setting.
MAC Filter: (Default Disable)
MAC FILTER
DISABLE
MAC Filter can be setup with registered MAC Address in order to connect the MATRIX host Web UI, MAC Address required by the
Web page to fill in, this function can only be setup at “DISABLE”,“ENABLE”, then to press the ENTER, the second row will flash,
then press the UP or DOWN to select DISABLE, ENABLE, then press ENTER to complete the setting.
3.3.5 REMOTE ID：(Default ID 4)
This function must be set to match the Matrix remote control IR01 with the matrix itself. A conflict with other devices remote
control is avoided.
After entering REMOTE ID menu, press ENTER, the OLED LINE 1 number will flash. Then Press UP or DOWN button to select the
number, and then press ENTER to confirm.
When finish REMOTE ID setting, MATRIX remote control IR01 must also set the same ID in order to operation in normal.
IR Remote setting: Press and hold the POWER button, then press the number button which can be set from 0 to 9, total 10
groups.
These settings on IR01 remote control have to be done the first time you use the IR01 or when you change the batteries.
REMOTE ID 4
＋

DXP H1010 User Manual
15
3.3.6 AUDIO SELECT: (Default H)
This function can set the output of SPDIF to HDMI (H) or ARC (A).
OUTPUT 1 2 3 4 5 6 7 8 9 10
AUDIO H H H H H H H H H
3.3.7 SYSTEM INFO:
Display DXP H1010 firmware version
* 1.MAIN V1.00
2.WEB V1.00
3.CPLD V1.00
4.IN1 V1.00
5.IN2 V1.00
6.IN3 V1.00
7.IN4 V1.00
8.IN5 V1.00
8. IN5 V1.00
9. IN6 V1.00
10.IN7 V1.00
11.IN8 V1.00
12.IN9 V1.00
13.IN10 V1.00
14.OUT1 V1.00
15.OUT2 V1.00
16.OUT3 V1.00
17.OUT4 V1.00
18.OUT5 V1.00
19.OUT6 V1.00
20.OUT7 V1.00
21.OUT8 V1.00
22.OUT9 V1.00
23.OUT10 V1.00
3.4 Remote Control
3.4.1 IR01
1. To command the matrix locally, setup the remote control IR01 ID with the same code of the Matrix.The default code is 4.
(Power+4)
2.Warning: These settings have to be done the first time you use the IR01 or when you change the batteries.
IR ID setup : press and hold POWER button , then press Number key
Remote control button define:
Symbol Function
Power Power on/Standby
LEFT LEFT
RIGHT RIGHT
UP UP
DOWN DOWN
ENTER ENTER
MENU MENU
A ALL
B LOAD SCENE
Quick key 1

DXP H1010 User Manual
16
Quick key 2
Quick key 3
Quick key 4
Quick key 5
Quick key 6
Quick key 7
Quick key 8
Quick key 9
OFF
Quick key 10
Quick key:
For example: to switch output port 1 to input port 4, press 1 (OUTPUT 1) and then press 4 (INPUT 4).
*Under using quick key operation, OLED screen will jump to the output / input setting page; it won’t allow using the front panel
button to operate the DXP H1010.
3.4.2 Console
DXP H1010 support RS232 and TCP/IP control by same command as below:
For RS232 CONSOLE:
Connect the RS232 CONSOLE port to the COM port of the host by a F/M RS232 straight cable (pin 2 to pin 2; pin 3 to pin 3, pin 5
to pin 5).
Communication format is 9600,8, N, 1 (9600 bps, 8 data bits, no parity check, 1 stop bit)
For Ethernet TCP/IP(Winsock)
Default IP address: 192.168.0.10, Port:47011
Operation Instruction format:
Command + △(Space) + Parameter + Enter
[Command] [Description]
------------------------- -------------------------------------------
POWER△[d] Power on/off
TX01△[b] Set Input #n to output 1
TX02△[b] Set Input #n to output 2

DXP H1010 User Manual
17
TX03△[b] Set Input #n to output 3
TX04△[b] Set Input #n to output 4
TX05△[b] Set Input #n to output 5
TX06△[b] Set Input #n to output 6
TX07△[b] Set Input #n to output 7
TX08△[b] Set Input #n to output 8
TX09△[b] Set Input #n to output 9
TX10△[b] Set Input #n to output 10
IR_ID△[i] Set IR remote ID
SAVE△[a] Save scene to #n
LOAD△[a] Load scene from #n
LOCK△[d] Panel button& IR remote control Lock/Unlock
SET_DHCP△[d] DHCP client on/off
IPADDRESS△[n.n.n.n] Set Matrix IP address
SUBNETMASK△[n.n.n.n] Set Matrix subnet mask
GATEWAY△[n.n.n.n] Set Matrix gateway
MEDIATYPE△[m] Network speed select
MACFILTER△[d] MAC filter on/off
STATUS Show connection status
VERSION Show firmware version
HELP Help
[Symbol] [Parameter]
------------------------- -------------------------------------------
a 00~10
b 00=off, 01~10
d 00=off, 01=on
i 00~09=0~9
m 00=auto, 01=10M, 02=100M
n 0~255
Example:
-To route input 4 to output 1, send the following string:
TX1△04[Enter]
(HEX code: 54 58 30 31 20 30 34 0D)
-To put in standby the matrix, send the following string:

DXP H1010 User Manual
18
POWER△00[Enter]
(HEX code: 50 4F 57 45 52 20 30 30 0D)
Commands are case insensitive.
The Matrix will reply OK once string is correct, NG in case of incorrect string
3.5 Ethernet Control
Initial IP Configuration
1. Setup MATRIX IP Address same as your PC with same domains.(Default 192.168.0.10)
MATRIX IP Address method, please refer. to “ETHERNET”Chapter
2. Input IP Address on a web page, you could link to the Web UI of the MATRIX host.
3. Web UI Operation :
SWITCH SETTING:
Power : Control MATRIX power on and standby.
Output : Display output 1~10, it can change the display name by the Aliases page.
Input : Display input 1~10, this field is a drop down menu, this field is a drop-down menu,
a drop-down menu include Input 1 ~ 10 and OFF, It can change the display name by the
Aliases page.
Reload : Get MATRIX host message.
Advanced : Enter into the “Advanced”page.
Apply : Complete the setting
All Port : Set all output from input 1~10 or off at once.

DXP H1010 User Manual
19
Advanced:
IP address : Change IP address
Subnet mask : Change Subnet mask
Gateway IP : Change Gateway IP
Media Type : Change 10 / 100 / Auto detect
DHCP Client : When setup at Enable, the MATRIX host will automatic get IP Address、Subnet Mask、Gateway,
If setup at Disable, the MATRIX host IP Address、Subnet Mask、Gateway need to set from Advanced page.
Auto Reset : The terminal connection people will be 4 users on line at same time, this function could setup the
linking time to avoid long time linking and other user can not used. When over the setting link time, the terminal will
automatically disconnect the link. . (0: no time setup, 1 ~ 255 Minute time range that can be setup)
Scene : Click to enter Scene setup page
MAC Filter : Enter to MAC Filter to setup page
Aliases : Enter to Aliases to setup page
Device Name : Can change device name
Back : Jump back SWITCH SETTING page
Online :Terminal connection users display, the max. 4 users on line.
Aliases:
Aliases page can change input/output name, enter Apply to finish the setting after change .The new name will update and
correspond to SWITCH SETTING page Output / Input.
Press Back jump back to advanced page.

DXP H1010 User Manual
20
MAC Filter:
MAC Filter can be setup as registered MAC Address to link MATRIX host Web UI，the max. up to 10 groups MAC Address
After MAC Address fill in, select Enable and press Apply to complete the setting.
Press Back jump to advanced page.
Scene:
Save : Save 10 set of channel settings
Load : Reload 1 of the channel settings
Update: Refresh the status of Load
Back : Back to Advanced page
