RGBlink ASK nano RX User manual

Specification
Power
HDMI
Supported Input Resolution
Power
HDMI
Output Resolution
MicroUSB
5V DC 500mA
Max 2.5W
HDMI 1.3
800×600@60 |1024×768@60 |
1280×720@60 |1280×800@60 |
1280×960@60 | 1280×1024@60 |
1400×1050@60 |1600×1200@60 |
1920×1080@60
MicroUSB
5V DC 500mA
Max 2.5W
HDMI 1.3
1920×1080@60
Transmitter
Receiver
65 7 8
Q: What if the pairing of TX and RX fail?
A:
●Press the switch on ASK nano RX to switch mode.
●Power the ASK nano TX by Micro-USB cable.
Q: Why is there higher latency and picture distortion compare to HDMI cable?
A:
●Wireless transmission is a process of signal encoding and decoding,
therefore,signal latency and picture distortion is unavoidable.
Q: What if Android phone projection does not work?
A:
●Press the switch button on ASK nano RX to switch the casting mode.
Q: What is the differences between the two cast Mode?
A:
● TX/DLNA/AirPlay Mode
ASK nano TX or iOS phone can cast in this mode
Android phone can only project pictures and videos in this mode.
●Miracast Mode
Android phone can cast in this mode
ASK nano TX and iOS phone could not cast in this mode
Trouble Shooting
Cast from iOS
1. Confirm ASK nano RX is in the TX/DLNA/AirPlay mode.
●
See the current mode above the TV graphic on the display/product
2. Connect iOS device to ASK nano RX from Wi-Fi Settings.
●
Wi-Fi Network:「ASK nano-XXXXXX」
●
Password: 12345678
3. From Quick Settings, select 「Screen Mirroring」to mirror the display.
Settings Wi-Fi
Wi-Fi
ASK nano-XXXXXX
i
Screen
Mirroring
Screen Mirroring
ASK nano-XXXXXX
Android
Tips
Most laptops are able to power ASK nano TX directly from the HDMI port. In
the event ASK nano TX does not power up, connect the USB micro port to a
USB source/port.
Cast from Android
1. Set ASK nano RX mode to Miracast.
●
See the current mode above the TV graphic on the display/product
2. Connect to Android device to ASKnano RX Wi-FI.
●
Wi-Fi Network:「ASK nano-XXXXXX」
●
(no password required)
3. Choose [Screen Cast] or [Wireless Projection] on the Android device.
Wi-Fi
Use Wi-Fi
XXXXXX
XXXXXX
XXXXXX
XXXXXX
ASK nano XXXXXX

In the Box
ASK nano TX
ASK nano RX
micro USB Cable
HDMI Extender (plug to socket)
1
1
2
1
Overview
1. HDMI plug (connect to laptop)
2. Cast button
○
Short press to start/stop projecting
3. Indicator light
4. Antenna
○
Unfold to enhance signal
5. Micro USB for power supply
ASK nano TX Transmitter
2 3 4
1
2
3
5
4 9
6
7
8
10
Status Meaning
Solid Red Powered
Blinking Red Waiting for connection
Solid Blue Connected
6. HDMI plug (connect to display )
7. Mode Switch Button
○
Short press to switch between
TX/DLNA/AirPlay & Mode
8. Indicator light
9. Antenna
○
Unfold to enhance signal
10. Micro USB for power supply
ASK nano RX Receiver
Status Meaning
Blinking Blue Ready for casting
Quick Start
STEP 1 : connect ASK nano RX (Receiver)
STEP 2 : connect from a Transmitting Device
●
Project or extend from a laptop with ASK nano TX
●
Mirror & Cast from an Android device via Miracast
●
Mirror & AirPlay from an iOS device
STEP 1 : connect ASK nano RX (Receiver)
1. Connect ASK nano RX HDMI to the HDMI port of TV or projector.
2. Connect ASK nano RX micro USB to a USB port on the display or other
USB power source(not included).
STEP 2 : Start casting
1. Connect ASK nano TX to laptop HDMI port.
2. Power ASK nano TX with micro USB cable.
3. Wait and it will connect automatically.
Project or Extend Laptop Display with ASK nano TX
Step 1
PC/MAC
IOS
TV or projector
Connect ASK nano RX \ to
adisplay or projector
Step 2
Start casting, projecting or
mirroring from your choice of device
Android
TV or projector
ASK nano RX
microUSB
PC/MAC
ASK nano TX
blue
①
microUSB
②
②
③
①
