Rheem Everhot 2A1 Series Technical Document

This water heater must be installed and serviced by a qualified person.
Please leave this guide with the householder.
Owner’s Guide
and
Installation Instructions
Stainless Steel
Electric Domestic Water Heater

An electronic copy of these Owner’s Guide and Installation Instructions
is available upon request.
PATENTS
This water heater may be protected by one or more patents or registered designs
in the name of Rheem Australia Pty Ltd or Aquamax Australia Pty Limited.
TRADEMARKS
® Registered trademark of Rheem Australia Pty Ltd.
TM Trademark of Rheem Australia Pty Ltd.
Note: Every care has been taken to ensure the accuracy in preparation of this
publication. No liability can be accepted for any consequences,
which may arise as a result of its application.
RHEEM AUSTRALIA PTY LTD A.B.N. 21 098 823 511
www.rheem.com.au
For Service Telephone 131 031 AUSTRALIA 0800 657 335

3
CONTENTS
HOUSEHOLDER
This booklet contains important information about your new water heater,
including terms of the Everhot warranty.
We recommend you read pages 8 to 24,
and the terms of the Everhot warranty on pages 4 to 7.
The other pages are intended for the installer but may be of interest.
Warranty .......................................................................................4
Safety, Warnings, Installation Notes .........................................8
About Your Water Heater ..........................................................12
Maintenance Requirements ......................................................16
Water Supplies...........................................................................18
Save A Service Call ...................................................................22
Installation..................................................................................25
Connections –Plumbing ..........................................................34
Connections –Electrical...........................................................39
Commissioning..........................................................................41
Draining The Water Heater .......................................................42

4
EVERHOT ELECTRIC DOMESTIC MAINS PRESSURE
WATER HEATER WARRANTY - AUSTRALIA ONLY
EVERHOT STAINLESS STEEL ELECTRIC 2A1 MODELS
1. THE EVERHOT WARRANTY –GENERAL
1.1 This warranty is given by Rheem Australia Pty Limited ABN 21 098 823 511 of
1 Alan Street, Rydalmere New South Wales.
1.2 Rheem offer a trained and qualified national service network who will repair or
replace components at the address of the water heater subject to the terms of
the Everhot warranty. Rheem Service, in addition can provide preventative
maintenance and advice on the operation of your water heater. The Rheem
Service contact number is 131031, with Contact Centre personnel available
24 hours, 7 days a week to take your call and if necessary to arrange a service
call for during normal working hours Monday to Friday (hours subject to
change).
1.3 For details about this warranty, you can contact us on 131031 or by email at
[email protected] (not for service bookings).
1.4 The terms of this warranty and what is covered by it are set out in sections 2
and 3 and apply to water heaters manufactured after 1st April 2019.
1.5 If a subsequent version of this warranty is published, the terms of that warranty
and what is covered by it will apply to water heaters manufactured after the
date specified in the subsequent version.
2. TERMS OF THE EVERHOT WARRANTY AND EXCLUSIONS TO IT
2.1 Rheem may reject a claim under this warranty in its sole discretion if:
a) You do not arrange for a major service to be conducted on your water
heater in the fifth year after installation, in accordance with Rheem’s
recommendation in the Owner’s Guide and Installation Instructions; and
b) The fault giving rise to the warranty claim would have been detected and
rectified during that major service.
2.2 The decision of whether to repair or replace a faulty component is at Rheem’s
sole discretion.
2.3 If you require a call out and we find that the fault is not covered by the Everhot
warranty, you are responsible for our standard call out charge. If you wish to
have the relevant component repaired or replaced by Rheem, that service will
be at your cost.
2.4 Where a failed component or cylinder is replaced under this warranty, the
balance of the original warranty period will remain effective. The replacement
does not carry a new Everhot warranty.

EVERHOT ELECTRIC DOMESTIC MAINS PRESSURE
WATER HEATER WARRANTY - AUSTRALIA ONLY
5
EVERHOT STAINLESS STEEL ELECTRIC 2A1 MODELS
2.5 Where the water heater is installed outside the boundaries of a metropolitan
area as defined by Rheem or further than 25 km from either a regional Rheem
branch office or an Accredited Rheem Service Agent's office, the cost of
transport, insurance and travelling between the nearest branch office or
Rheem Accredited Service Agent’s office and the installed site shall be the
owner’s responsibility.
2.6 Where the water heater is installed in a position that does not allow safe or
ready access, the cost of that access, including the cost of additional materials
handling and/or safety equipment, shall be the owner’s responsibility. In other
words, the cost of dismantling or removing cupboards, doors or walls and the
cost of any special equipment to bring the water heater to floor or ground level
or to a serviceable position is not covered by this warranty.
2.7 This warranty only applies to the original and genuine Everhot water heater in
its original installed location and any genuine Everhot replacement parts.
2.8 The Everhot warranty does not cover faults that are a result of:
a) Accidental damage to the water heater or any component (for example: (i)
Acts of God such as floods, storms, fires, lightning strikes and the like; and
(ii) third party acts or omissions).
b) Misuse or abnormal use of the water heater.
c) Installation not in accordance with the Owner’s Guide and Installation
Instructions or with relevant statutory and local requirements in the State
or Territory in which the water heater is installed.
d) Connection at any time to a water supply that does not comply with the
water supply guidelines as outlined in the Owner’s Guide and Installation
Instructions.
e) Repairs, attempts to repair or modifications to the water heater by a person
other than Rheem Service or a Rheem Accredited Service Agent.
f) Faulty plumbing or faulty power supply.
g) Failure to maintain the water heater in accordance with the Owner's Guide
and Installation Instructions.
h) Transport damage.
i) Fair wear and tear from adverse conditions (for example, corrosion).
j) Cosmetic defects.

EVERHOT ELECTRIC DOMESTIC MAINS PRESSURE
WATER HEATER WARRANTY - AUSTRALIA ONLY
6
EVERHOT STAINLESS STEEL ELECTRIC 2A1 MODELS
2.9 Rheem may reject a claim under this warranty in its sole discretion if a third
party solar diverter is connected to the water heater.
2.10 Subject to any statutory provisions to the contrary, this warranty excludes any
and all claims for damage to furniture, carpet, walls, foundations or any other
consequential loss either directly or indirectly due to leakage from the water
heater, or due to leakage from fittings and/ or pipe work of metal, plastic or
other materials caused by water temperature, workmanship or other modes of
failure.
2.11 If the water heater is not sized to supply the hot water demand in accordance
with the guidelines in Everhot’s water heater literature, any resultant fault will
not be covered by the Everhot warranty.
3. WHAT IS COVERED BY THE EVERHOT WARRANTY
FOR THE WATER HEATERS DETAILED IN THIS DOCUMENT
3.1 Rheem will repair or replace a faulty component of your water heater if it fails
to operate in accordance with its specifications as follows:
What components
are covered
The period from the
date of installation
in which the fault
must appear in
order to be covered
What coverage
you receive
Everhot Stainless Steel electric 2A1 models
All components
(all installations)
Year 1
Repair and/or replacement of
the faulty component, free of
charge, including labour.
The cylinder
(if the water heater is
installed in a single-family
domestic dwelling)
Years 2 to 10
Replacement cylinder, free of
charge. Installation and repair
labour costs are the
responsibility of the owner.

EVERHOT ELECTRIC DOMESTIC MAINS PRESSURE
WATER HEATER WARRANTY - AUSTRALIA ONLY
7
EVERHOT STAINLESS STEEL ELECTRIC 2A1 MODELS
4. ENTITLEMENT TO MAKE A CLAIM UNDER THIS WARRANTY
4.1 To be entitled to make a claim under this warranty you need to:
a) Be the owner of the water heater or have consent of the owner to act on
their behalf.
b) Contact Rheem Service without undue delay after detection of the defect
and, in any event, within the applicable warranty period.
4.2 You are not entitled to make a claim under this warranty if your water heater:
a) Does not have its original serial numbers or rating labels.
b) Is not installed in Australia.
5. HOW TO MAKE A CLAIM UNDER THIS WARRANTY
5.1 If you wish to make a claim under this warranty, you need to:
a) Contact Rheem on 131031 and provide owner’s details, address of the
water heater, a contact number and date of installation of the water heater
or if that’s unavailable, the date of manufacture and serial number (from
the rating label on the water heater).
b) Rheem will arrange for the water heater to be tested and assessed on-
site.
c) If Rheem determines that you have a valid warranty claim, Rheem will
repair or replace the water heater in accordance with this warranty.
5.2 Any expenses incurred in the making of a claim under this warranty will be
borne by you.
6. THE AUSTRALIAN CONSUMER LAW
6.1 Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure
and for compensation for any other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired or replaced if the goods fail to
be of acceptable quality and the failure does not amount to a major failure.
6.2 The Everhot warranty (set out above) is in addition to any rights and remedies
that you may have under the Australian Consumer Law.

8
SAFETY, WARNINGS, INSTALLATION NOTES
It is important you read the following safety and warnings information.
SAFETY AND WARNINGS
•This water heater is only intended to be operated by persons who have the
experience or the knowledge and the capabilities to do so.
•This water heater is not intended to be operated by persons with reduced
physical, sensory or mental capabilities i.e. the infirm, or by children. Children
should be supervised to ensure they do not interfere with the water heater.
•If the electrical conduit to the water heater is damaged, it must be replaced
by a qualified person in order to avoid a hazard. Phone Rheem Service or
their nearest Accredited Service Agent to arrange for an inspection.
•This water heater uses 220 V –240 V a.c. power for the electrically operated
components. The removal of the front cover(s) will expose 220 V –240 V a.c.
wiring. It must only be removed by a qualified person.
•This water heater is supplied with a thermostat, an over-temperature cut-out
and a combination temperature pressure relief valve. These devices must not
be tampered with or removed. The water heater must not be operated unless
each of these devices is fitted and is in working order.
The Everhot warranty may not cover faults if relief valves or other safety
devices are tampered with or if the installation is not in accordance with
these instructions.
•DANGER: The operation of the over-temperature cut-out on a thermostat
indicates a possibly dangerous situation. If the over-temperature cut-out
operates, it must not be reset and the water heater must be serviced by a
qualified person.
•The water heater will operate until a water temperature of 60°C to 75°C for
250 and 315 models or 60°C to 80°C for 050 models is reached, depending
upon the thermostat setting.
Refer to “How Hot Should The Water Be?” on page 12 and “Temperature
Adjustment” on page 13.
•The lever on the temperature pressure relief valve and expansion control
valve (if fitted) requires to be operated every six (6) months to clear any
deposits and to ensure the valve and its drain line are not blocked.
Refer to “Relief Valves” on page 9 and “Minor Maintenance Every Six
Months” on page 17.
•For continued safety of this water heater it must be installed, operated and
maintained in accordance with the Owner’s Guide and Installation
Instructions.

SAFETY, WARNINGS, INSTALLATION NOTES
9
•Servicing of a water heater must only be carried out by qualified personnel.
Phone Rheem Service or their nearest Accredited Service Agent.
•Only a person qualified to install or service a water heater should drain the
water heater, if this is required.
•Do not modify this water heater.
RELIEF VALVES
Temperature Pressure Relief Valve
This water heater incorporates a temperature
pressure relief valve located near the top of the
water heater. This valve is essential for the water
heater’s safe operation.
It is possible for the valve to discharge a quantity
of water through the drain line during each
heating period. This quantity should be equal to
approximately 1/50 of the hot water used, as
water expands by this volume when heated.
Expansion Control Valve
In many areas, including South Australia and
scaling water areas, it is mandatory an
expansion control valve is fitted to the cold water
line to the water heater.
The expansion control valve will discharge the
quantity of water from its drain line during the
heating period instead of the temperature
pressure relief valve as it has a lower pressure
rating.
Valve Operation
Continuous leakage of water from either valve
and its drain line may indicate a problem with the
water heater. Refer to “Temperature Pressure
Relief Valve or Expansion Control Valve
Running” on page 23.
Warning: Never block the outlet of either valve or their drain lines for any
reason. A relief valve drain must be left open to atmosphere, and be installed in
a continuously downward direction.
In locations where water pipes are prone to freezing, the relief valve drain line
must be insulated and not exceed 300 mm in length before discharging into a
tundish through an air gap.
lift until water
flows from the
drain line –
lower gently
drain
line

SAFETY, WARNINGS, INSTALLATION NOTES
10
Operate the easing lever on the temperature pressure relief valve and expansion
control valve once every six (6) months to clear any deposits and ensure the
valve and its drain line are not blocked. It is very important the lever is raised
and lowered gently. Refer to “Minor Maintenance Every Six Months” on
page 17.
Warning: Water discharged from the temperature pressure relief valve drain
line will be hot. Exercise care to avoid any splashing of water by standing clear
of the drain line’s point of discharge when operating either valve’s easing lever.
DANGER: Failure to operate the easing lever on the relief valve once every
six (6) months may result in the water heater cylinder failing, or under certain
circumstances, exploding.
If water does not flow freely from the drain line when the lever is lifted, then the
water heater must be checked. Phone Rheem Service or their nearest Accredited
Service Agent to arrange for an inspection.
The temperature pressure relief valve should be replaced at intervals not
exceeding five (5) years and the expansion control valve should be checked for
performance or replaced at intervals not exceeding five (5) years. The checking
of the valves performance or replacement should occur more frequently in areas
where there is a high incidence of water deposits. Refer to “Water Supplies” on
page 18.
INSTALLATION NOTES
This water heater must be installed:
•by a qualified person,
•in accordance with the installation instructions,
•in compliance with the Plumbing Code of Australia (PCA) and Plumbing
Standard AS/NZS 3500.4,
▪This water heater is designed for indoor or outdoor installation.
▪This water heater is intended to be permanently connected to the water
mains and not connected by a hose-set. A braided flexible hose or semi-
flexible connector may be used for connection to the water heater, where
permitted by AS/NZS 3500.4.
•in compliance with the Australian / New Zealand Wiring Rules AS/NZS 3000,
▪Isolation switches must be installed in the electrical circuit to the water
heater in accordance with the Wiring Rules, so the water heater can be
switched off.
