ECLIPSE™FROM RHEEM-R D WATER HEATERS
Discover the Difference.
Discover the Eclipse!
Eclipse heavy-duty electrics feature a longer life,
a lighter weight and is more durable and energy efficient
than any commercial water heater ever made.

Longer Life
The new Eclipse carries an unprecedented 10-year
limited tank warranty – more than three times the
standard commercial warranty. That means big
savings for end users.
Lighter Weight
Who says heavy duty has to be heavy weight?
The new 85-gallon Eclipse checks in at 170 lbs.
The 105-gallon only 185 lbs., less than half the weight
of competitive models in its class. And that makes
the Eclipse easier to move, easier to handle and
easier to install.
More Efficient
The new Eclipse uses extra foam
insulation from top to bottom to
reduce heat loss. Both innovations
save energy and lower operating costs
– better than any other heavy duty
commercial electric.
Eclipse
Heavy-duty electric water heater
With its exclusive 10-year limited
tank warranty and many other
features, the Rheem-Ruud Eclipse
completely overshadows
the competition.
Pete Colletti, regional facilities manager for
Boddie-Noell Enterprises, shown with the
Rheem-Ruud Eclipse Commercial Electric
Water Heater at the Hardee’s restaurant at
Azalea Plaza in Wilmington, North Carolina.

Eclipse Construction Features
•Composite tank and high density polyethylene dent
and scratch resistant jacket.
•No anode rod required.
•Models are in two sizes with capacity of 85 or 105
gallons in 42 total variations.
•Input options are: 12.4, 18, or 24 kW.
•Voltage options are 208, 240 or 480 VAC in either
single phase or 3-phase and 277 VAC in single
phase only.
•Element wattages are 3100, 4500 or 6000 in each of
the four voltages. The elements are low watt density
design (46, 67, 90 watts/sq. in.) with stainless
(Inconel) sheath.
•The four Inconel elements are spaced on the front
along a vertical line for easy access.
•The power control circuits use 2 surface mounted
thermostats and operate in two stages so that a
lower control thermostat is for the lower two
elements and an upper control is for the upper two
elements. The lower element will provide recovery
for all needs and the upper two will kick in
additionally for larger demands.
•170º F maximum delivered temperature.
•System Sentinel LED indicators are provided
for each element to show power on.
•A switch is provided in the control circuit for
installation dry fire protection. See label.
•A temperature and pressure relief valve is
installed on top of the unit.
•3/4” full port, full flow brass drain valve.
•Standards approved to UL 1453 and UL/NSF 005.
Eclipse Specifications
REC VERY CAPACITIES
Recovery at various temperature rises
TEMPERATURE RISE
EQUIVALENT
M DEL NUMBER INPUT KW BTU/HR UNITS 40°F 50°F 60°F 70°F 80°F 90°F 100°F 110°F 120°F
ME85-12 12.4 42,309 GPH 126 100 84 72 63 55 50 45 42
ME85-18 18 61,420 GPH 186 149 124 106 93 83 74 68 62
ME85-24 24 81,893 GPH 248 199 165 142 124 110 99 90 83
ME105-12 12.4 42,309 GPH 126 100 84 72 63 55 50 45 42
ME105-18 18 61,420 GPH 186 149 124 106 93 83 74 68 62
ME105-24 24 81,893 GPH 248 199 165 142 124 110 99 90 83
DIMENSI NAL INF RMATI N
All dimensions shown in inches
CAPACITY MAX. DELIVERED WATER HEATER WATER HEATER HEIGHT T APPR X. SHIPPING
M DEL NUMBER INPUT KW GALL NS TEMPERATURE HEIGHT DIAMETER WATER C NNECTI N WEIGHT (LBS.)
ME85-12 12.4 85 170º 66-1/4 28-1/4 70-1/4 170
ME85-18 18 85 170º 66-1/4 28-1/4 70-1/4 170
ME85-24 24 85 170º 66-1/4 28-1/4 70-1/4 170
ME105-12 12.4 105 170º 66-1/2 30-1/4 70-3/4 185
ME105-18 18 105 170º 66-1/2 30-1/4 70-3/4 185
ME105-24 24 105 170º 66-1/2 30-1/4 70-3/4 185
ELECTRICAL CHARACTERISTICS
FULL L AD CURRENT – IN AMPERES
NUMBER ELEMENT NUMBER NUMBER 208V 240V 277V 480V
M DEL NUMBER INPUT KW F ELEMENTS WATTAGE F FUSES F THERM STATS PHASE 1 PHASE 3 PHASE 1 PHASE 3 PHASE 1 PHASE 1 PHASE 3
ME85-12 12.4 4 3100 8260 39 52 34 45 26 17
ME85-18 18 4 4500 8287 57 75 50 65 38 25
ME85-24 24 4 6000 82115 76 100 66 87 50 35
ME105-12 12.4 4 3100 8260 39 52 34 45 26 17
ME105-18 18 4 4500 8287 57 75 50 65 38 25
ME105-24 24 4 6000 82115 76 100 66 87 50 35
Commercial water heaters
from Rheem-Ruud

Commercial water heaters
from Rheem-Ruud
Rheem Water Heating • 101 Bell Road, Montgomery, AL 36117-4305
800-621-5622 • [email protected] • www.rheem.com
Rheem Canada Ltd./Ltée • Water Heater Division • 128 Barton Street West, Hamilton, Ontario L8N 3P3
Not all models are available in Canada.
Printed in .S.A 05/07 WP RR-2778 Rev. 3
LIMITED WARRANTY
This product features a ten-year limited warranty against tank leaks.
Please refer to Commercial Warranty Information brochure for complete
warranty information.
CERTIFICATI NS AND RATINGS
EFFICIENCY
These models have been tested according to D E test procedures, and
exceed the minimum energy factor requirements of current ASHRAE
Standards (Part of the Federally mandated Energy Policy Act (EPact)).
Also exceeds energy efficiency codes of all states including California
Energy Commission (CEC).
SAFETY AND C NSTRUCTI N
These products are design certified by Underwriters Laboratories (UL) to
meet UL standard 1453 as electric storage tank water heaters. All models
are North Carolina and Massachusetts Code compliant. Certified for a 150
PSI Maximum Working Pressure.
In keeping with its policy of continuous progress and product improvement,
Rheem-Ruud reserves the right to make changes without notice.
