Rhino Winch CD-K1750-1500 User manual

1500kg Hoist
Before installing and using the product, operators and participants should carefully read and fully
understand the instructions.
Operators must strictly abide by the rules of safety operation.
V3.1

1500kg Hoist
© Rhino Winch Co
02 © Rhino Winch Co
Contents
02 Contents
03 Quick Start Guide
04 Operation
05 Maintainance
06 Caution
07 CE Certication

1500kg Hoist
© Rhino Winch Co © Rhino Winch Co 03
Quick Start Guide
01. Mounting Bracket
02. Gearbox
03. Cable
04. Motor
05. Control Box
06. Remote
06a. Emergency Stop Button
06b. Up/Down Buttons
07. Clevis Hook
08. Mounting Bar
09. Mounting Brackets
02
05
03
04
01
06
07
08
09
06a
06b

1500kg Hoist
© Rhino Winch Co
04 © Rhino Winch Co
Operation
01. Open box and remove all items;
Hoist with attached remote
Clevis hook
Mounting bar
2x Mounting brackets
4x screws
4x washers
02. Attach hook to the end of the cable
03. Mount onto desired area using the mounting plate
04. For top mounting;
• Remove the bolts from the thread of the top bars
• Place the mounting brackets on the outside of the hoist
• Replace the bolts and use the two extra bolts and washers for added security
• Repeat the process for the other side
• Remove the pins from the mounting bar
• Slide bar through the top holes of the mounting bracket and replace the pins to secure in
position.
05. Attach the object to be lifted to the hoist via the hook at the end of the cable
06. Using the remote, lift the object up/down
07. Use the emergency stop button for quick stop incase of emergency

1500kg Hoist
© Rhino Winch Co © Rhino Winch Co 05
Maintainance
Check the bolt and power cord of the hoist on a regular basis. Always clean any dust and oil from the
cable and the outside of the hoist. Check the grease regularly and replace every 6 months. Always check
for any wear in the cable before use and replace immediately if any signs of wear are visable.
Note: cable must be replaced with the original cable diameter and rotation
Model Usage Nominal
Volage
(V)
Power
(KW)
Capacity
(KG)
Speed
(M/Min)
Lifting
Height
(M)
Diameter
of wire
rope
(mm)
Net
Weight
(KG)
CD-K1
750-
1500
Single
rope
250V
50HZ
Single
phase
4.0KW 750 14 12 Oiled
anti-
rotation
wire
rope with
19x7
core
37
Double
rope
1500 7 6

1500kg Hoist
© Rhino Winch Co
06 © Rhino Winch Co
Caution
• The lifting capacity is limited. Do not overload or use it without knowing the weight as
overloading can cause damage to the hoist/cable.
• Do not pull the object being hoisted when the hoist is working as it will increase the load.
• Keep the working area of hoist clean and tidy. Do not let unauthorised people approach; do not
let anyone touch the cable and never stand under the running hoist.
• If you need to replace the cable; the type, specification and direction must be the same as
the previous one, and the rotate direction should not be changed.
• Always wear gloves when operating and be careful not to let the cable slip through your hands
as this may cause injury.
• After finishing hoisting, store cable on the drum and never use hands to guide it.
• The emergency stop button is equipped as a safety device. It can automatically cut off the
rising circuit when it reaches its limit. Please do not regard emergency stop button as a limit
switch.
• Do not use hoist to lift people.
• The hoist must have safety warnings or signs in order to instruct operators to use it correctly.
• Do not use hoist after drinking, taking any medication and/or falling ill.
• Do not work under the hoist when it is running.
• Please use supporting fixtures with hoist or this may result in injury.
• Do not remake welding hoist parts or you may reduce hoist security.
• Do not operate in the rain.

1500kg Hoist
© Rhino Winch Co © Rhino Winch Co 07
CE Certication
We hereby declare that the machine described below complies with the relevant basic safety and health
requirements of the EU Directives, both in its basic design and construction as well as in the version put
into circulation by us. This declaration shall cease to be valid if the machine is modied without our prior
approval.
The undersigned: Michael S McQuaide
as authorised by: Union Mart Ltd
Declares that
Description: Electric Hoist Winch
Identication code: 1500kg Rhino Hoist
Conforms to the following directives and standards:
• Machinery Directive 2006/42/EC
• RoHS Directive 2011/65/EU
--
• EN ISO 12100:2010
• EN 14492-1:2006+A1:2009/AC:2010
• EN 60204-32:2008
Notied body: Union Mart Ltd
The technical documentation is kept by: Union Mart Ltd
Date: 08/10/2019
Signed:
Michael S McQuaide
CEO
Name and address of the manufacturer:
Union Mart Ltd, Company No. 8384155.
Registered address: Unit 4, Nursling Industrial Estate, Mauretania Road, Nursling, Southampton, SO16
0YS, United Kingdom.
