Rhyas HAM4003 User manual

HOT AIR GUN
HAM4003
Manual
ORIGINAL INSTRUCTIONS

EN
2
Fig. A
Fig. B
1
4
5
3

EN
3
HOT AIR GUN
Thank you for buying this Rhyas product.
All our products are manufactured to the highest
standards of performance and safety. As part
of our brand commitment we provide excellent
customer service and a 12 month warranty.
We hope you will enjoy using this product for
many years to come.
The numbers in the following text correspond
with the pictures at page 2
Always read the instruction for electrical
products carefully before use. It will help
you understand your product more
easily and avoid unnecessary risks.
Keep this instruction manual in a safe
place for future use.
Contents
1. Machine data
2. Safety instructions
3. Using the appliance
4. Maintenance
1. Machine data
Technical specifications
Voltage 220-240 V~
Frequency 50 Hz
Power input 2000 W
Weight 0.62 kg
IP Class IP 20
Position I
Air flow 300 l/min
Air temperature 450 °C
Position II
Air flow 500 l/min
Air temperature 600 °C
Vibration level
The vibration emission level stated in this
instruction manual has been measured in
accordance with a standardised test given in
EN 60745; it may be used to compare one tool
with another and as a preliminary assessment of
exposure to vibration when using the tool for the
applications mentioned
- using the tool for different applications, or with
different or poorly maintainted accessories,
may significantly increase the exposure level
- the times when the tool is switched off or when
it is running but not actually doing the job, may
signifi cantly reduce the exposure level
Protect yourself against the effects of vibration by
maintaining the tool and its accessories, keeping
your hands warm, and organizing your work
patterns
Contents of packing
1 Hot air gun
1 Deflector nozzle
1 Fishtail nozzle
1 Instruction manual
1 Safety instructions
1 Warranty card
Product information
Fig. A
1. Switch
2. Ventilation slots
3. Nozzle outlet
2. Safety instructions
Explanation of the symbols
Denotes risk of personal injury, loss of
life or damage to the tool in case of non-
observance of the instructions in this
manual.
Indicates electrical shock hazard.
Additional safety instructions
When using electric tools, basic safety
precautions should always be followed to reduce
the risk of fire, electric shock and personal injury.
Read all these instructions before attempting to
operate this product and save these instructions.
Before using the appliance
• Check the following:
• Make sure the voltage of the hot air gun
corresponds with the power voltage;
• Are the mains lead and the mains plug in
a good state: strong, without ravels or
damages.
• Avoidtheuseoflongextensioncables;

EN
4
• Donotusetheapplianceundermoist
circumstances;
• Themetalmouthpiecegetshot.Watchout
and do not touch the metal mouthpiece;
• Preventdamageoftheheatingelement.Do
not lock or block the mouth piece;
• Donotleavetheappliancewhenswitchedon;
• Donotusetheappliancefordryinghairorfor
drying living human beings in general;
• Donotusetheapplianceinabath,above
water or in spaces where easy inflammable
liquids are used.
This appliance operates at a
temperature of 600 degrees without
visible signs of this temperature (no
flames), still there is a chance of fire
risk. Watch out for the hot air stream
from the mouth piece. This air stream
can cause burns.
When operating the appliance
• Ifyouaregoingtousethehotairgun,
vapours and gas can be released during
a short time. This can be harmful for your
health. Asthmatics can suffer hindrance of it;
• Beforeconnectingtheplugtothemains
voltage you have to check if the switch is in
position “0”;
• Keepthemainsleadalwaysawayfromthe
mouthpiece of the hot air gun;
• Keepchildrenandanimalsawayfromthe
appliance if you are using it.
Immediately switch off the appliance when:
• Plugand/orcablearedefectiveordamaged;
• Theswitchisdefective;
• Yousmellorseesmokecausedbyscorched
insulation from the hot air gun.
Electrical safety
When using electric machines always observe the
safety regulations applicable in your country to
reduce the risk of fire, electric shock and personal
injury. Read the following safety instructions and
also the enclosed safety instructions.
Always check that the power supply
corresponds to the voltage on the rating
plate.
Class II machine – Double insulation –
You don’t need any earthed plug
Replacing cables or plugs
Immediately throw away old cables or plugs
when they have been replaced by new ones. It is
dangerous to insert the plug of a loose cable in
the wall outlet.
Using extension cables
Only use an approved extension cable suitable
for the power input of the machine. The minimum
conductor size is 1.5 mm2. When using a cable
reel always unwind the reel completely.
3. Using the appliance
The Hot air gun can be used for:
• Plumbingworkliketubeconnections,solder,
bowing tubes;
• Removingpaint,varnishandlacquerwithout
firerisk;
• Quicklydryingofapplianceswhichhave
become wet;
• Dryingsurfacesforquickrepairing;
• Removingself-adhesivelabelsinacleanway
placing PVC labels;
• BlisteringafterstickingPVCmaterialscanbe
smoothed after heating;
• Easyremovingofvinylcarpeting:
• Formingallsyntheticswithalowtemperature
(450 degrees) among which polyethylene and
PVC;
• Formingallsyntheticswithahightemperature
(580 degrees) among which acryl and
plexiglass;
• Smeltingsynthetics,amongwhichmatters
and foils with PVC layer;
• Applyingheatshrinkingtubes;
• Shrinkwrappers;
• Thawingtubesandengines;
• Repairingfinishinglayers:emailofbathand
household appliances;
• Applyingepoxypowdercoverlayers;
• Repairingofski’s,surf-boardsandother
sports goods;
• Unscrewingtoofastfixedscrewsand
connections.
Operation
Fig. A
Youcanworkmanuallywiththishotairgunoryou
can put it in a vertical position.
• Checkifthemainsswitchisonposition“0”
before you connect the apparatus;

EN
5
• Keepthemainleadalwaysawayfromthehot
air stream and the mouth piece;
• Putthemainsswitchinposition‘IorII’tolet
your hot air gun operate:
“I” = 450 degrees, air flow 300 l/min.
“0” = Off
“II” = 600 degrees, air flow 500 l/min.
When the temperature is excess 600° C, the
heats switches it off automatically, however, the
heater continues to run. When the heater has
cooled to operating temperature, the heater is
switched on again.
Switching off:
Slide the switch to 0.
Tip: If you want to get the best result, test all
appliances on a little part of the workpiece.
Use of accessoires
Fig. B
Deflector nozzle (4)
Deflects air away from glass for example when
stripping paint in window frames or softening
putty.
Fishtail nozzle (5)
Distributes air equally over small areas
4. Maintenance
Always disconnect the apparatus before
carrying out inspection or cleaning.
Never use water or other liquids to clean
the electrical parts of the hot air gun.
• Neveruseeasyinflammableliquidsfor
cleaning the hot air gun, especially for the
mouthpiece.
• Regularmaintenanceofyourhotairgun
preventsunnecessaryproblems.Keepthe
ventilation slots of the hot air gun clean to
prevent overheating.
Troubleshooting
In case the hot air gun does not work well, we give
you subjoined some possible causes and their
solutions.
• Theenginegetsoverheated.
• The ventilation slots of the hot air gun are
dirty.
• Clean the ventilation slots.
• Thehotairgundoesnotstartwhenitis
switched on.
• Interruption in the electrical circuit.
• Check the mains lead and the mains plug.
• The switch is defective.
• Pull the mains lead out of the wall socket,
because there is a chance of fire risk !
Have the hot air gun repaired at your local
dealer.
• Theenginedoesnotwork,butitdoes
heat.
• Interruption in the electrical circuit.
• Pull the mains lead out of the wall socket,
because there is a chance of fire risk !
Have the hot air gun repaired at your local
dealer.
Faults
Should a fault occur, e.g. after wear of a part,
please contact the service address on the
warranty card. In the back of this manual you find
an exploded view showing the parts that can be
ordered.
Environment
To prevent damage during transport, the
appliance is delivered in a solid packaging which
consists largely of reusable material. Therefore
please make use of options for recycling the
packaging.
Faulty and/or discarded electrical or
electronic apparatus have to be
collected at the appropriate recycling
locations.
Guarantee
The guarantee conditions can be found on the
separately enclosed guarantee card.

EN
6
Spare parts list
Position Description No.
2 - 7 Motor complete 408800
8 - 10 Heating element complete 408801
11 Switch 408802

EN
7

EN
8

EN
9

EN
10
GENERAL SAFETY INSTRUCTIONS
Warning!
Read all instructions. Failure to follow all instructions listed
below may result in electric shock, fire and/or serious injury.
The term "power tool” in all of the warnings listed below
refers to your mains operated (corded) power tool or battery
operated (cordless) power tool. Save these instructions.
1) Work area
a. Keep work area clean and well lit. Cluttered and dark
areas invite accidents.
b. Do not operate power tools in explosive atmospheres,
such as in the presence of flammable liquids, gasses
or dust. Power tools create sparks which may ignite the
dust of fumes.
c. Keep children and bystanders away while operating a
power tool. Distractions can cause you to lose control.
2) Electrical safety
a. Power tool plugs must match the outlet. Never modify
the plug in any way. Do not use any adapter plugs which
earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces
such as pipes, radiators, ranges and refrigerators. There
is an increased risk of electric shock if your body is
earthed or grounded.
c. Do not expose power tools to rain or wet conditions.
Water entering a power tool will increase the risk of
electric shock.
d. Do not abuse the cord. Never use the cord for carrying,
pulling or unplugging the power tool. Keep cord away
from heat, oil, sharp edges or moving parts. Damaged or
entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable for
outdoor use reduces the risk of electric shock. Always
use tool in conjunction with a residual circuit breaker
device.
3) Personal safety
a. Stay alert, watch what you are doing and use common
sense when operating a power tool. Do not use a power
tool while you are tired or under the influence of drugs,
alcohol or medication. A moment of inattention while
operating power tools may result in serious personal
injury.
b. Use safety equipment.Always wear eye protection.
Safety equipment such as dust mask, non-skid
safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c. Avoid accidental starting. Ensure the switch is in the off
position before plugging in. Carrying power tools with
your finger on the switch or plugging in power tools that
have the switch on invites accidents.
d. Remove any adjusting key or wrench before turning
the power tool on. A wrench or a key left attached to a
rotating part of the power tool may result in personal
injury.
e. Do not overreach. Keep proper footing and balance at
all times. This enables better control of the power tool in
unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery.
Keep your hair, clothing and gloves away from moving
parts. Loose clothes, jewellery or long hair can be
caught in moving parts.
g. If devices are provided for the connection of dust
extraction and collection facilities, ensure these are
connected and properly used. Use of these devices can
reduce dust related hazards.
h. Use clamps or a vice to hold work. It’s safer than using
your hand and it frees both hands to operate tool.
4) Power tool use and care
a. Do not force the power tool. Use the correct power
tool for your application. The correct power tool will
do the job better and safer at the rate for which it was
designed.
b. Do not use the power tool if the switch does not turn it
on and off. Any power tool that cannot be controlled with
the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source before
making any adjustments, changing accessories, or
storing power tools. Such preventive safety measures
reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and
do not allow persons unfamiliar with the power tool or
these instructions to operate the power tool. Power tools
are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding
of moving parts, breakage of parts and any other
condition that may affect the power tools operation.
If damaged, have the power tool repaired before use.
Many accidents are caused by poorly maintained power
tools.
f. Keep cutting tools sharp and clean. Properly maintained
cutting tools with sharp cutting edges are less likely to
bind and are easier to control.
g. Use the power tool, accessories and tool bits etc., in
accordance with these instructions and in the manner
intended for the particular type of power tool, taking
into account the working conditions and the work to be
performed. Use of the power tool for operations different
from intended could result in hazardous situation.

(EN) We declare under our sole responsibility that this product is in conformity with directive 2011/65/EU
of the European parliament and of the council of 9 June on the restriction of the use of certain
hazardous substances in electrical and electronic equipment is in conformity and accordance with the
following standards and regulations:
EN
11
EN60335-1, EN60335-2-45, EN55014-1, EN55014-2, EN61000-3-2,
EN61000-3-3, EN62233
2006/42/EC, 2006/95/EC, 2004/108/EC, 2011/65/EU, 2002/95/EC
Zwolle, 01-05-2014 W. Dekens
CEO Mactool Industrial BV
It is our policy to continuously improve our products and we therefore reserve the right to change the product specification
without prior notice.
Mactool Industrial BV • Lingenstraat 6 • 8028 PM • Zwolle The Netherlands
DECLARATION OF CONFORMITY
HAM4003
h. Damaged switches must be replaced at a customer
service repair centre. Do not use power tools that
cannot be switched on and off.
i. Do not leave power tools unattended while they are
switched on. Always switch off the tool and wait until it
has come to a full standstill before leaving.
j. If the mains cable has been damaged, it must be
replaced with a special mains cable. These can be
obtained from the manufacturer or the manufacturer’s
customer service department. The mains cable
may only be replaced by the manufacturer, the
manufacturer’s customer service department or equally
qualified persons.
5) Battery tool use and care
a. Ensure the switch is in the off position before inserting
battery pack. Inserting the battery pack into power tools
that have the switch on invites accidents.
b. Recharge only with the charger specified by the
manufacturer. A charger that is suitable for one type of
battery pack may create a risk of fire when used with
another battery pack.
c. Use power tools only with specifically designated
battery packs. Use of any other battery packs may
create a risk of injury and fire.
d. When battery pack is not in use, keep it away from other
metal objects like paper clips, coins, keys, nails, screws,
or other small metal objects that can make a connection
from one terminal to another. Shorting the battery
terminals together may cause burns of a fire.
e. Under abusive conditions, liquid may be ejected from
the battery; avoid contact. If contact accidentally occurs,
flush with water. If liquid contacts eyes, additionally
seek medical help. Liquid ejected from the battery may
cause irritations or burns.
6) Service
a. Please use a qualified expert who uses original
replacement parts to repair your power tool. This will
ensure proper functioning of the power tool.
b. Caution! The use of any accessories or additional tools
other than those recommended in this manual may
lead to an increased risk of injury. Only use original
replacement parts.

1406-05
