1400RV0
14 U.S. GALLON/53 LITER
PROFESSIONAL WET/DRY VAC
FOR QUESTIONS OR INFORMATION CONTACT US AT
1-800-4-RIDGID (1-800-474-3443) from the US and Canada
01-800-701-9811 from Mexico
www.ridgidvacs.com
Part No. SP6939 Printed in Mexico
OWNER’S MANUAL
SAVE THIS MANUAL FOR FUTURE REFERENCE
Thank you for buying a RIDGID product. • Español - página 21
• Français - page 41
WARNING:
To reduce the risk of injury, the user must read and understand the owner’s manual
before using this product.
!
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 1

2
IMPORTANT SAFETY INSTRUCTIONS
Safety is a combination of using common
sense, staying alert, and knowing how your
Wet/Dry vacuum cleaner (“Vac”) works.
Safety Signal Words
DANGER: Indicates a hazardous
situation which, if not avoided, will result
in death or serious injury.
WARNING: Indicates a hazardous
situation which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a hazardous
situation which, if not avoided, could
result in minor or moderate injury.
When using your Vac, always follow basic
safety precautions including the following:
WARNING
- To reduce the risk of fire, electric
shock, or injury:
• Read and understand this manual and
all labels on the Vac before operating.
• Use only as described in this manual.
• Do not leave Vac running while
unattended - you may fail to notice
important signs indicating abnormal
operation such as loss of suction,
debris/liquid exiting exhaust, or
abnormal motor noises. Immediately
stop using Vac if you notice these
signs.
• Do not leave Vac when plugged in.
Unplug from outlet when not in use and
before servicing.
• Sparks inside the motor can ignite
flammable vapors or dust. To reduce
the risk of fire or explosion, do not use
near combustible liquids, gases, or
!
!
!
!
dusts, such as gasoline or other fuels,
lighter fluid, cleaners, oil-based paints,
natural gas, coal dust, magnesium
dust, grain dust, aluminum dust, or gun
powder.
• Do not vacuum anything that is burning
or smoking, such as cigarettes,
matches, or hot ashes.
• Do not vacuum drywall dust, cold
fireplace ash, or other fine dusts with
standard filter. These may pass
through the filter and be exhausted
back into the air. Use a fine dust filter
instead.
• To reduce the risk of inhaling toxic
vapors, do not vacuum or use near
toxic or hazardous materials.
• To reduce the risk of electric shock,
do not expose to rain or allow liquid to
enter motor compartment. Store
indoors.
• This Wet/Dry Vac is not intended for
use by persons (including children) with
reduced physical, sensory, or mental
capabilities, or lack of experience and
knowledge, unless they have been
given supervision or instruction
concerning use of the appliance by a
person responsible for their safety.
• Do not allow to be used as a toy.
Close attention is necessary when
used by or near children.
• Do not use with a torn filter or without
filter installed except when vacuuming
liquids as described in this manual.
Dry debris ingested by the impeller
may damage the motor or be
exhausted into the air.
Table of Contents
Introduction . . . . . . . . . . . . . . . . . . . . . . 4
Unpacking and Checking Carton Contents. . 4
Tools Required . . . . . . . . . . . . . . . . . . 4
Carton Contents List . . . . . . . . . . . . . 4
Drum/Caddy Assembly . . . . . . . . . . . . . 6
Wet/Dry Vac Assembly . . . . . . . . . . . . . 8
Operation. . . . . . . . . . . . . . . . . . . . . . . . 9
Vacuuming Dry Materials . . . . . . . . . 10
Vacuuming Liquids . . . . . . . . . . . . . . 10
Emptying the Drum . . . . . . . . . . . . . 10
Moving the Wet/Dry Vac. . . . . . . . . . 10
Blowing Feature . . . . . . . . . . . . . . . . 11
Accessory and Hose Storage . . . . . . . 12
Cord Wrap . . . . . . . . . . . . . . . . . . . . 12
Maintenance . . . . . . . . . . . . . . . . . . . . 13
Repair Parts. . . . . . . . . . . . . . . . . . . . . 16
Servicing of Double Insulated
Wet/Dry Vacs . . . . . . . . . . . . . . . . 16
Warranty . . . . . . . . . . . . . . . . . . . . . . . 20
Section Page Section Page
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 2

3
• To reduce the risk of personal injury or
damage to Vac, use only Ridgid
recommended accessories.
• When using as a blower:
- Direct air discharge only at work
area.
- Do not direct air at bystanders.
- Keep children away when blowing.
- Do not use blower for any job except
blowing dirt and debris.
- Do not use as a sprayer.
• To reduce the risk of eye injury, wear
safety eyewear. The operation of any
utility Vac or blower can result in foreign
objects being blown into the eyes, which
can result in severe eye damage.
• Turn off Vac before unplugging.
• To reduce the risk of injury from
accidental starting, unplug power cord
before changing or cleaning filter.
• Do not unplug by pulling on cord.
To unplug, grasp the plug, not the cord.
• Do not use with damaged cord, plug or
other parts. If your Vac is not working
as it should, has missing parts, has
been dropped, damaged, left outdoors,
or dropped into water, call customer
service.
• Do not pull or carry by cord, use cord
as handle, close a door on cord, or pull
cord around sharp edges or corners.
Do not run Vac over cord. Keep cord
away from heated surfaces.
• Do not handle plug, switch, or the Vac
with wet hands.
• Use only extension cords that are rated
for outdoor use. Extension cords in
poor condition or too small in wire size
can pose fire and shock hazards.
To reduce the risk of these hazards,
be sure the cord is in good condition
and that liquid does not contact the
connection. Do not use an extension
cord with conductors smaller than
16 gauge (AWG) in size. To reduce
power loss, use a 14 gauge extension
cord if 25 to 50 ft. long and 12 gauge
for 50 ft. or longer.
• This Vac is double-insulated,
eliminating the need for a separate
grounding system. Use only identical
replacement parts. Read the
instructions for Servicing Double-
Insulated Wet/Dry Vacs.
• Do not put any object into ventilation
openings. Do not vacuum with any
ventilation openings blocked; keep free
of dust, lint, hair or anything that may
reduce air flow.
• Keep hair, loose clothing, fingers, and
all parts of body away from openings
and moving parts.
• To reduce the risk of falls, use extra
care when cleaning on stairs.
• To reduce the risk of back injury or
falls, do not lift a Vac that is heavy with
liquid or debris. Partially empty by
scooping debris or draining liquid.
Observe the following warnings that
appear on the motor housing of your Vac:
WARNING: For your own safety,
read and understand owner’s
manual. Do not run unattended.
Do not pick up hot ashes, coals,
toxic, flammable or other hazardous
materials. Do not use around
explosive liquids or vapors.
WARNING: To reduce the risk of
electric shock - do not expose to
rain - store indoors.
DOUBLE INSULATED
GROUNDING NOT REQUIRED.
WHEN SERVICING USE ONLY
IDENTICAL REPLACEMENT PARTS.
!
!
SAVE THIS MANUAL
CAUTION:
• To reduce the risk of hearing damage,
wear ear protectors when using for
extended time or in a noisy area.
• For dusty operations, wear dust mask.
• Static shocks are common when the
relative humidity of the air is low.
Vacuuming fine debris with your Vac can
deposit static charge on the hose or
Vac. To reduce the frequency of static
shocks in your home or when using this
Vac, add moisture to the air with a
humidifier.
!
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 3

4
Introduction
This Wet/Dry Vac is intended for house-
hold use. It may be used for vacuuming
wet or dry media and may be used as a
blower.
Refer to the assembly sketch for
positioning of parts.
Remove contents of carton.
Check each item against the Carton
Contents List. Call 1-800-4-RIDGID
(1-800-474-3443) from the US and
Canada, 01-800-701-9811 from Mexico,
or E-mail us at [email protected]
if any parts are damaged or missing.
Unpacking and Checking Carton Contents
Phillips Screwdriver
Tools Required
MalletHammer
Carton Contents List
Key Description Qty
A Wet/Dry Vac Assembly.................1
B* Qwik Lock™ Filter........................1
C* Filter Cage ...................................1
D* Float .............................................1
E Pro-Hose......................................1
F Utility Nozzle ................................1
G Wet Nozzle...................................1
H Car Nozzle ...................................1
I Crevice Tool .................................1
J Extension Wands .........................2
K Owner’s Manual...........................1
* The filter comes preassembled to the
power head.
A
B
C
D
F
G
I
J
H
E
K
Read this owner’s manual to familiarize
yourself with the product features and to
understand the specific usage of your
new Vac.
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 4

Unpacking and Checking Carton
Contents (continued)
O
Q
R
M
N
P
5
Key Description Qty
Carton -
Containing the following parts:
M Accessory Bag .............................1
N 8” Wheel.......................................2
O Metal Handle................................1
P Axle ..............................................1
Q Caddy, Right ................................1
R Caddy, Left...................................1
Key Description Qty
Bag of Loose Parts -
Containing the following parts:
S 2” Caster ......................................2
T 1/2” Cap Nut ................................2
U Wheel Caps .................................2
V Screw, Type AB #10 x 1-3/4 ........4
S
U
T
V
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 5

3. Installing Cap Nut
a. Place cap nut on end of axle.
b. Tap gently with hammer until fully
seated.
c. Place wheel on the axle with smooth
portion of wheel facing outward.
NOTE: Smooth side of the
wheel to the outside.
Caddy Left Drain
Axle
w/Wheel
Caddy
Right
Open
End
Cap
Nut
Drum/Caddy Assembly
Caddy
Right
Drain Caddy
Left
Right
Caddy
Assembly
Left Caddy
Assembly
Drain
#10 x 1-3/4"
Screw (4)
If any parts are missing or damaged
contact Customer Service.
Do not assemble until you have all the
parts.
1. Insert caddy left and caddy right into
the bottom of drum as shown. Light
taps with a mallet or hammer may be
needed to fully seat both caddies.
2. Install (4) #10 x 1-3/4” screws into
matching holes on both right and left
side of caddy, securing them to the
bottom of the drum. Tighten screws
until just snug. Do not over tighten as
this may tend to deform the caddies.
6
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 6

7
Drum/Caddy Assembly (continued)
Installing Handle
Press and hold release buttons while
installing handle into handle receptacles
in drum (See illustration).
NOTE: An audible snap of release
buttons indicates successful engagement
of handle.
Removing Handle
Press and hold release buttons as
shown. While firmly pushing in release
buttons, pull handle upwards to remove
(see illustration).
4. Slide open end of axle through caddy
left making sure the leg slot lines up
with the cradle hole. Slide all the way
through the caddy right. Light taps with
a mallet may be required to fully insert
axle.
5. Install second wheel onto axle with
smooth portion of wheel facing
outward.
6. Install the second cap nut. Tap gently
until cap nut is firmly seated
7. Using a rubber mallet or hammer,
gently tap the wheel cap onto the right
wheel until the wheel cap is firmly
seated onto the wheel. This is required
on both left and right sides.
8. Insert the caster stem into the socket
of the caster foot as shown. (Front
caster only).
9. Push on the caster until the ball on the
caster stem is inserted all the way into
the socket. You will be able to hear the
ball snap into the socket and the caster
will swivel easily when positioning is
correct.
Mallet
Wheel
Cap
Socket
Caster Stem
Caster Ball
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 7

Wet/Dry Vac Assembly
1. Position the power head assembly on
the drum/caddy assembly as shown
(assembled earlier).
2. Rotate both latches down and press
until you hear them snap over the
flanges on the drum.
Drum
Latch
Drum
Latch
Drum
Flange
Latch
Drum
Powerhead
Assembly
Insert Hose
Insert the push button end of the pro-
hose into the inlet of the Vac. The hose
should snap into place.
To remove the hose from the Vac, press
the release button in the hose assembly
and pull the hose out of the Vac inlet,
as shown.
Release
Button
Press
and
Pull
Accessory
Bag Snaps
Accessory
Bag Straps (4)
Handle
Installing Accessory Bag
Install accessory bag by wrapping the
four accessory bag straps around the
metal handle.
Secure accessory bag by snapping each
of the four snaps.
Drum/Caddy Assembly (continued)
8
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 8

9
Operation
To reduce the risk of electric shock,
this Vac has a polarized plug (one blade
is wider than the other). This plug will fit
in a polarized outlet only one way.
If the plug does not fit fully in the outlet,
reverse the plug. If it still does not fit,
contact a qualified electrician to install the
proper outlet. Do not change the plug in
any way.
After you plug the power cord into the
outlet, turn the unit on by pushing the
switch from position "O" to position "l".
The symbols used on the switch actuator
are international "On & Off" symbols:
=OFF =ON
Familiarize yourself with the accessories
included with the Vac. Each accessory may
be used in various ways for vacuuming
and blowing debris. Here is a list of the
accessories and their uses.
Utility Nozzle - General purpose nozzle for
most vacuuming applications.
Wet Nozzle - Used for wet pickup on
smooth surfaces to pick up liquid and dry
the surface in one stroke.
Car Nozzle - Dry pickup nozzle for car
interiors and most upholstery cleaning.
Extension Wands - These wands can be
connected together and provides
additional length for more reach.
Pro-Hose - Provides transfer of vacuum
or blowing capability to work site. Provides
the means of attaching extension wands
and nozzles.
Crevice Tool - Use to pick up debris in
hard to reach locations.
WARNING: To reduce the risk of fire, explosion, or damage to Vac:
• Do not leave Vac running while unattended - you may fail to notice important signs
indicating abnormal operation such as loss of suction, debris/liquid exiting the
exhaust, or abnormal motor noises. Immediately stop using Vac if you notice these
signs.
• Do not leave Vac plugged in when not in use.
• Do not continue running when float has cut off suction.
• Sparks inside the motor can ignite airborne flammables. Do not operate Vac near
flammable liquids or in areas with flammable gases, vapors, or explosive/airborne
dust. Flammable liquids, gases, and vapors include: lighter fluid, solvent-type
cleaners, oil-based paints, gasoline, alcohol, and aerosol sprays. Explosive dusts
include: coal, magnesium, aluminum, grain, and gun powder.
• Do not vacuum up explosive dusts, flammable liquids, or hot ashes.
WARNING: To reduce the risk of electric shock or injury:
• Do not expose to rain or allow liquid to enter motor compartment. Store indoors.
• Do not handle plug, switch, or Vac with wet hands.
• Unplug Vac before servicing. If your Vac is not working as it should, has missing
parts, has been dropped, damaged, left outdoors, or dropped into water, return it to an
independent service center or call customer service.
• When using an extension cord, use only outdoor-rated cords that are in good
condition. Do not allow the connection to come into contact with liquid.
!
!
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 9

1. The Vac comes equipped with a drain
for easy emptying of liquids. Simply
unscrew the drain cap and lift the
opposite side slightly to empty the
drum.
2. Another option is to remove the
powerhead assembly.
3. Lay powerhead assembly aside on
a clean area while emptying drum.
4. Dump the drum contents into the
proper waste disposal container.
Moving the Wet/Dry Vac
Should it become necessary to pick
the Vac up to move it, the handle on
the sides of the dust drum are used to
lift. To maneuver the Vac, the push/pull
handle in the rear of the unit should be
used.
WARNING: To reduce the risk of
back injury or falls, do not lift a Vac
heavy with liquid or debris. Scoop
or drain enough contents out to
make the Vac light enough to lift
comfortably.
Emptying the Drum
!
Operation (continued)
Vacuuming Dry Materials
1. The filter must always be in correct
position to reduce the risk of leaks and
possible damage to Vac.
2. Your Wet/Dry Vac comes with the
VF5000 Filter installed. When using
your Vac to pick up very fine dust, it will
be necessary for you to empty the
drum and clean the filter at more
frequent intervals to maintain peak Vac
performance.
NOTE: A dry filter is necessary to pick up
dry material. If you use your Vac to pick
up dust when the filter is wet, the filter will
clog quickly and be very difficult to clean.
Allow filter to dry out before storing.
Vacuuming Liquids
IMPORTANT:
1. When picking up small amounts of
liquid the filter may be left in place.
2. When picking up large amounts of
liquid we recommend that the filter be
removed. If the filter is not removed, it
will become saturated and misting may
appear in the exhaust.
3. After using the Vac to pick up liquids, the
filter must be dried to reduce the risk of
possible mildew and damage to the filter.
4. When the liquid in the drum reaches a
predetermined level, the float
mechanism will rise automatically to cut
off air-flow. When this happens, turn off
the Vac, unplug the power cord, and
empty the drum. You will know that the
float has risen because Vac airflow
ceases and the motor noise will become
higher in pitch, due to increased motor
speed.
WARNING: Do not operate
without filter cage and float, as they
prevent liquid from entering the
impeller and damaging the motor.
!
10
IMPORTANT: To reduce the risk of
damage to the Vac do not run motor with
float in raised position.
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:39 AM Page 10

11
WARNING: Always wear safety
eyewear complying with ANSI Z87.1
(or in Canada, CSA Z94.3) before
using as a blower.
!
1. Locate blowing port of your Vac.
2. Insert the locking end of the pro-hose
into the blowing port of the Vac.
The hose should snap into place.
To remove the hose from the Vac,
press the release button in the hose
assembly and pull the hose out of the
Vac inlet.
3. (Optional) Attach extension wand to
opposite end of hose.
4. Turn Vac on and you are ready to use
your Vac as a blower.
CAUTION: Wear a dust mask if
blowing creates dust which might
be inhaled.
CAUTION: To reduce the risk of
hearing damage, wear ear protectors
when using the Vac/Blower for
extended time or in a noisy area.
WARNING: To reduce the risk of
injury to bystanders, keep them
clear of blowing debris.
!
!
!
Pro-Hose
Blowing
Port
Extension
Wand
(Optional) Swivel
End of
Hose
Operation (continued)
Blowing Feature
Your Vac features a blowing port. It can
blow sawdust and other debris. Follow
the steps below to use your Vac as a
blower.
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 11

12
Push/Pull Handle
Cord Wrap
Power
Cord
Accessory
Bag
Your accessories may be stored in the
accessory bag, or in the two locations on
the caddy right/left. Either the hose or the
wands may be stored in the two areas
marked Hose Storage.
The hose may be stored by wrapping it
around the unit and plugging the open
end into one of the storage locations on
the caddy assembly. Alternatively, the
wands may also be stored in this location
by plugging either of the ends of the
wands onto the storage receivers located
on the caddy.
Hose Storage
Area
HOSE
STORAGE
HOSE
STORAGE
Cord Wrap
When vacuuming is complete, unplug the
cord and wrap it around the power
assembly as shown. The cord should wrap
under the pull handle (above the inlet) and
around and under the cord wrap of the
motor cover.
Accessory and Hose Storage
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 12

13
Maintenance
WARNING: To reduce the risk of
injury from accidental starting,
unplug power cord before changing
or cleaning filter.
Filter
!
1400RV Professional Wet/Dry Vac is
supplied with RIDGID’s best Qwik Lock™
Fine Dust Filter. Replacement Qwik
Lock™ Fine Dust Filters are available
where you purchased your Vac. Ask for
the RIDGID Qwik Lock™ Fine Dust Filter
VF5000.
NOTE: The filter is made of high quality
paper designed to stop very small
particles of dust. The filter can be used
for wet or dry pick up. Handle the filter
carefully when removing to clean or
installing it. Creases in the filter pleats
may occur from installation but not affect
the performance of the filter.
Filter Removal and Installation
Filter Removal:
1. Hold the filter tabs of the Qwik Lock™
filter in each hand.
2. With one thumb on the Qwik Lock™
stud, which protrudes through the
integrated filter plate, lift up on the filter
tabs while pushing down on the stud.
3. This action will cause the filter to
release from the filter cage. Slide filter
off cage.
Filter Installation:
1. Carefully slide the Qwik Lock™ filter
over the filter cage and press down on
the outside edge of the filter until the
rubber gasket on the bottom of the filter
seats securely around the base of the
filter cage and against the lid.
2. Align the small center hole in the top of
the filter over the Qwik Lock™ stud on
the filter cage. Press firmly on top of
the filter near the stud to allow the filter
to snap over the ball on the end of the
stud. The filter is now attached.
Filter
Cage
Qwik
Lock™
Stud
Filter
Tabs (2)
Integrated Filter
Plate with Center
Hole
PUSH
DOWN
PULL
UP
Rubber
Gasket at
Bottom of
Filter
(cutaway
view)
Lid
NOTE: Failure to properly seat the
bottom gasket could result in debris
bypassing the filter.
IMPORTANT: To avoid damage to the
blower wheel and motor, always reinstall
the filter before using the Vac for dry
material pick-up.
WARNING: Do not operate with-
out filter cage and float, as they
prevent liquid from entering the
impeller and damaging the motor.
!
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 13

14
Cleaning and Disinfecting the
Wet/Dry Vac
To keep your Wet/Dry Vac looking its
best, clean the outside with a cloth
dampened with warm water and mild
soap.
To clean the drum:
1. Dump debris out.
2. Wash drum thoroughly with warm
water and mild soap.
3. Wipe out with dry cloth.
Before prolonged storage or as needed
(i.e.; waste water pick up) the drum
should be disinfected.
To disinfect the drum:
1. Pour 1 gallon of water and 1 teaspoon
chlorine bleach into the drum.
2. Let solution stand for 20 minutes,
carefully swishing every few minutes,
making sure to wet all inside surfaces
of the drum.
3. Empty drum after 20 minutes. Rinse
with water until bleach smell is gone.
Allow drum to dry completely before
sealing the motor on the drum.
Cord Maintenance
When vacuuming is complete, unplug the
cord and wrap it around the motor cover.
If the power cord is damaged, it must be
replaced by the manufacturer or their
service agent or by similarly qualified
personnel to reduce the risk of accident.
Maintenance (continued)
Cleaning a Dry Filter
NOTE: For best cleaning results due to
accumulated dust, clean the filter in an
open area. Cleaning SHOULD be done
outdoors and not in the living quarters.
1. Remove filter from Vac. Gently tap filter
against the inside wall of your dust
drum. The debris will loosen and fall.
2. For thorough cleaning of dry filter with
fine dust (no debris), run water through
it as described under "Cleaning a Wet
Filter".
Cleaning a Wet Filter
After filter is removed, run water through
the filter from a hose or spigot. Take care
that water pressure from the hose is not
strong enough to damage filter. Allow filter
to dry out before storing.
IMPORTANT: After cleaning, check the filter
for tears or small holes. Do not use a filter
with holes or tears in it. Even a small hole
can cause a lot of dust to come out of your
Vac. If your filter is worn or damaged,
replace it immediately.
Allow the filter to dry before reinstalling
and storing the Vac.
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 14

15
Maintenance (continued)
Storage
Before storing your Vac, the drum should
be emptied and cleaned. The cord should
be wrapped around the unit and the hose
should be stored as described in this
manual. Accessories should be kept in
the same area as the Vac so they can be
readily available. The Vac should be
stored indoors.
Casters and Wheels
Should your cart squeak or become hard
to roll, you should place two or three
drops of general purpose oil on each
wheel at the axle. If your casters are
noisy, you may put a drop of oil on the
roller shaft to make them quieter.
Frame and Handles
Your metal handle is painted to prevent
rust, however, liquids and corrosive
debris should be wiped off with a soft
cloth should they come in contact with
the handle.
WARNING: to assure product
SAFETY and RELIABILITY, any other
maintenance, repairs or adjustments
should be performed by Authorized
service centers, always using
RIDGID replacement parts.
!
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 15

Key
No. Part No. Description
1 830564-4 Actuator, Switch
2 813213 Switch, Toggle
3 834287-2 Power Head Assembly
4 826387 Drum Latch
5 509488 Float
6 823201-3 Filter Cage
7 VF5000 Filter
8 VT2509 Utility Nozzle
9 VT2503 Car Nozzle
10 VT2510 Wet Nozzle
11 VT2502 Crevice Tool
12 831337-9 Pro-Hose
13 VT2508 Extension Wand
14 SP6939 Owner’s Manual
Repair Parts
14 Gallon Professional Wet/Dry Vac
Model Number 1400RV0
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
†
†
†
†
†
†
† These replacement parts may be available where you purchased your Vac.
WARNING
SERVICING OF DOUBLE-INSULATED WET/DRY VAC
In a double-insulated Wet/Dry Vac, two systems of insulation are provided
instead of grounding. No grounding means is provided on a double-insulated
appliance, nor should a means for grounding be added. Servicing a double-
insulated Wet/Dry Vac requires extreme care and knowledge of the system,
and should be done only by qualified service personnel. Replacement parts
for a double-insulated Wet/Dry Vac must be identical to the parts they replace.
Your double-insulated Wet/Dry Vac is marked with the words "DOUBLE
INSULATED" and the symbol (square within a square) may also be
marked on the appliance.
To reduce the risk of injury from electrical shock, unplug power cord before
servicing the electrical parts of the Wet/Dry Vac.
!
16
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 16

14 Gallon Professional Wet/Dry Vac
Model Number 1400RV0
RIDGID parts are available on-line at www.ridgidparts.com
4
1
3
2
5
7
6
14
8
9
12
10
11
13
Repair Parts (continued)
17
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 17

Key
No. Part No. Description
1 830686 Handle
2 830570-3 Dust Drum Assembly
3 73185 Drain Cap
4 830611 Wheel Cap
5 813836-1 Cap Nut 1/2”
6 830682 8” Wheel Assembly
(Includes Keys 4 and 5)
7 831024 Shaft
8 830576 Caddy, Right
9 830577 Caddy, Left
10 73102 Caster
11 830597-2 Accessory Bag
12 820563-12 Screw Type “AB” #10 x 1-3/4
13 509748-1 Bag of Loose Parts (Not Illustrated)
(Includes Keys 4, 5, 10, and 12)
18
Parts List for Wet/Dry Vac Cart
RIDGID parts are available on-line at www.ridgidparts.com
Always order by Part Number - Not by Key Number
Repair Parts (continued)
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 18

4
1
44
3
2
5
7
5
2
6
48
48
41
41
9
0
90
Repair Parts (continued)
19
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 19

Part No. SP6939 Form No. SP6939-1 Printed in Mexico 01/15
• What is covered
RIDGID®Wet/Dry Vacs are warranted to be free of defects in workmanship and material.
• How long coverage lasts
This warranty lasts for the lifetime of the RIDGID®Wet/Dry Vac.
• How to obtain service
To obtain the benefit of this warranty, deliver via prepaid transportation the complete product to
RIDGE TOOL COMPANY, Elyria, Ohio, or any authorized RIDGID®INDEPENDENT SERVICE
CENTER. Pipe wrenches and other hand tools should be returned to the place of purchase.
• What we will do to correct problems
Warranted Wet/Dry Vacs will be repaired or replaced, at Ridge Tool Company's option, and returned
at no charge; or, if after three attempts to repair or replace during the warranty period the Wet/Dry
Vac is still defective, you can elect to receive a full refund of your purchase price.
• What is not covered
Failures due to misuse, abuse or normal wear and tear are not covered by this warranty. RIDGE
TOOL COMPANY SHALL NOT BE RESPONSIBLE FOR ANY INCIDENTAL OR
CONSEQUENTIAL DAMAGES.
• How local laws relate to the warranty
Some states do not allow the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you. This warranty gives you specific rights, and you
may also have other rights which vary from state to state, province to province, or country to
country.
• No other express warranty applies
This FULL LIFETIME WARRANTY is the sole and exclusive warranty for RIDGID®Wet/Dry Vacs.
No employee, agent, dealer, or other person is authorized to alter this warranty or make any other
warranty on behalf of Ridge Tool Company.
FOR QUESTIONS OR INFORMATION CONTACT US AT
1-800-4-RIDGID (1-800-474-3443) from the US and Canada
01-800-701-9811 from Mexico
www.ridgidvacs.com
Please have your Model Number and Serial Number on hand when calling.
Stock No. 1400RV
Model No. 1400RV0
Model and serial number may be found on the back of power head assembly.
You should record both model and serial numbers in a safe place for future use.
c 2015 Emerson
SP6939-1 16 GALLON ESF1_SP6939-1 1/16/15 9:40 AM Page 20
