Ridgid Rwcs50t Service manual

SPECIFICATIONS

POWER SUPPLY

REQUIREMENTS 120 V, 60 Hz

MOTOR Single Phase, Dielectric Oil Filled

HORSEPOWER

1/2 HP

LIQUID TEMPERATURE 40° F - 120° F

CIRCUIT REQUIREMENTS 15 A (minimum)

DIMENSIONS

16-5/8 in. high x 9-5/8 in. base

ON LEVEL (FACTORY SET)

Approximately 19 in.

OFF LEVEL (FACTORY SET) Approximately 10.5 in.

610001W-005 C 09/19

CONSTRUCTION

MOTOR HOUSING

Cast Iron

VOLUTE

Cast Iron

IMPELLER Glass Reinforced Thermoplastic

SHAFT Steel

DISCHARGE 2 in. NPT

Sewage Pumps

PERFORMANCE (Gal/hr)

Model HP Discharge Head (Lift Distance)

0 ft 5 ft 10 ft 15 ft

RWCS50T 1/2 10000 9900 8100 3600

Intended for Indoor Use Only

Operating Instructions and Parts Manual RWCS50T

Please read and save these instructions. Read carefully before attempting to assemble, install,

operate or maintain the product described. Protect yourself and others by observing all safety

information. Failure to comply with instructions could result in personal injury and/or property

damage! Retain instructions for future reference.

INSTALLATION MANUAL

2Intended for Indoor Use Only

SAFETY SIGNAL WORDS

This manual contains information that is very important

to know and understand. This information is provided for

SAFETY and to PREVENT EQUIPMENT PROBLEMS. To

help recognize this information, observe all safety information

labeled danger, warning, caution, and notice.

SEWAGE PUMP DESCRIPTION

Sewage pumps are pumps used to remove waste water that

contains solids up to 2 inches in diameter. The most common

application is for draining bathroom waste water to a sewer or

septic line.

Intended for indoor use only. Installation of this pump outdoors,

unprotected from the weather, may cause hazardous conditions

and will void warranty. If using outdoors, protect pump from

direct weather elements such as sun, rain, sleet, snow, and

extreme temperature changes. Water inside the pump may

freeze, limiting its performance and damaging the pump and

pipes.

MAKE SURE THERE IS A PROPERLY GROUNDED RECEPTACLE

AVAILABLE. This pump is supplied with a grounding conductor

and grounding-type attachment plug. To reduce the risk of electric

shock, be certain that it is connected only to a properly grounded,

grounding-type receptacle.

S’ASSURER QU’UNE PRISE DE MISE À LA TERRE EST DISPONIBLE.

Cette pompe est fournie avec un conducteur et une ﬁche de mise à

la terre. Pour réduire le risque de choc électrique, s’assurer qu’elle

est branchée seulement à une prise de courant correctement mise

à la terre.

FOR ADDED SAFETY the receptacle must be protected with a ground

fault circuit interrupter (GFCI). All wiring must be performed by a

qualiﬁed licensed electrician and comply with the National Electric

Code and all applicable local codes and ordinances.

POUR PLUS DE SÉCURITÉ, la prise de courant doit être protégée par

un disjoncteur de fuite à la terre. Tout le câblage doit être effectué

par un électricien qualiﬁé et être conforme au Code électrique

national et à tous les codes et règlements locaux applicables.

NEVER REMOVE THE GROUND PRONG from the plug or bypass the

grounding wires.

NE JAMAIS RETIRER LE CONNECTEUR DE MISE À LA TERRE de la prise

ou contourner les ﬁls de mise à la terre.

MAKE SURE THE POWER SUPPLY HAS A FUSE OR CIRCUIT BREAKER

rated to handle the current (amps) noted on the pump nameplate

or cord tag.

S’ASSURER QUE L’ALIMENTATION ÉLECTRIQUE EST MUNIE D’UN

FUSIBLE OU D’UN DISJONCTEUR d’une valeur nominale appropriée

pour supporter l’intensité du courant (ampérage) indiquée sur la

plaque signalétique ou l’étiquette du cordon de la pompe.

IMPORTANT SAFETY INFORMATION

CONSIGNES DE SÉCURITÉ

IMPORTANTES

WARNING INDICATES A POTENTIALLY HAZARDOUS SITUATION

WHICH, IF NOT AVOIDED, COULD RESULT IN DEATH OR

SERIOUS INJURY.

LA MENTION AVERTISSEMENT INDIQUE UNE SITUATION

POTENTIELLEMENT DANGEREUSE QUI, SI ELLE N’EST PAS

ÉVITÉE, RISQUE D’ENTRAÎNER DES LÉSIONS CORPORELLES

GRAVES OU MÊME LA MORT.

RISK OF ELECTRIC SHOCK. TO REDUCE THIS RISK,

OBSERVE THE FOLLOWING WARNINGS:

RISQUE DE CHOC ÉLECTRIQUE. POUR RÉDUIRE CE

RISQUE, TENIR COMPTE DES AVERTISSEMENTS

SUIVANTS

UNPACKING

Inspect this unit before it is used. Occasionally, products

are damaged during shipment. If the pump or components

are damaged, return the unit to the place of purchase for

replacement, or call Customer Support (800-237-0987).

INSTALLATION MANUAL

ALWAYS DISCONNECT THE PUMP from power supply before installing,

servicing or making any adjustments.

TOUJOURS METTRE LA POMPE HORS TENSION avant de procéder à

l’installation, à l’entretien ou à des réglages.

DO NOT WALK on the ﬂoor when water is present until all power is

turned off. If the electric panel is in the basement, call an electrician.

NE PAS MARCHER sur un sol mouillé avant que l’alimentation

générale ne soit coupée. Si le tableau électrique est en sous-sol,

appeler un électricien.

NEVER HANDLE A PUMP or motor with wet hands or when standing

on a wet or damp ﬂoor while the pump is plugged into the power

supply.

NE JAMAIS MANIPULER UNE POMPE ou un moteur de pompe avec

les mains mouillées ou debout dans l’eau ou sur une surface

humide.

RISK OF ELECTRIC SHOCK. This pump has not been investigated for

use in swimming pool and marine areas.

RISQUE DE CHOC ÉLECTRIQUE. Cette pompe n’a pas fait l’objet

de vériﬁcation pour une utilisation dans les piscines et les aires

marines.

DO NOT USE TO PUMP FLAMMABLE OR EXPLOSIVE FLUIDS such as

gasoline, fuel oil, kerosene, etc. Do not use in a ﬂammable and/or

explosive atmosphere. Pump should only be used to pump clear

water. Personal injury and/or property damage will result and void

warranty.

NE PAS UTILISER POUR POMPER DES FLUIDES INFLAMMABLES OU

EXPLOSIFS tels que l’essence, le mazout, le kérosène, etc. Ne

pas utiliser dans un environnement inﬂammable et/ou explosif.

La pompe ne doit être utilisée que pour pomper de l’eau claire.

Des blessures corporelles et/ou des dégâts matériels pourraient

en résulter.

PUMPS ARE NOT DESIGNED TO TRANSFER WATER INTENDED FOR

DRINKING. Do not use the pump for moving water that will be

used for potable/drinking water. Pump should only be used in

applications for which it is designed.

LES POMPES NE SONT PAS CONÇUES POUR L’ACHEMINEMENT

D’EAU DESTINÉE À LA CONSOMMATION. Ne pas utiliser la pompe

pour transporter de l’eau qui sera utilisée comme de l’eau

potable/destinée à la consommation. La pompe doit être utilisée

uniquement dans les applications pour lesquelles elle est conçue.

DO NOT USE AN EXTENSION CORD OR SURGE PROTECTOR. Extension

cords and/or surge protectors could present a safety hazard if not

sized properly, become damaged or the connection falls into the

sump. If receptacle is not within reach of the pump’s power cord,

contact a qualiﬁed licensed electrician to install a new receptacle.

NE PAS UTILISER DE RALLONGE NI DE PROTECTEUR DE SURTENSION.

Les rallonges et/ou les protecteurs de surtension peuvent présenter

un danger pour la sécurité s’ils ne sont pas correctement calibrés,

s’ils sont endommagés ou si le raccordement tombe dans le

puisard. Si la prise n’est pas à portée du cordon d’alimentation

de la pompe, contacter un électricien qualiﬁé pour installer une

nouvelle prise.

CAUTION INDICATES A POTENTIALLY HAZARDOUS SITUATION

WHICH, IF NOT AVOIDED, MAY RESULT IN MINOR OR

MODERATE INJURY.

MISE EN GARDE

LA MENTION MISE EN GARDE INDIQUE UNE SITUATION

POTENTIELLEMENT DANGEREUSE QUI, SI ELLE N’EST PAS

ÉVITÉE, POURRAIT ENTRAÎNER DES BLESSURES MINEURES

OU MODÉRÉES.

TO REDUCE THE RISK OF HAZARDS THAT CAN CAUSE

INJURY OR PROPERTY DAMAGE, OBSERVE THE FOLLOWING

WARNINGS:

POUR RÉDUIRE LE RISQUE DE DANGERS POUVANT CAUSER

DES BLESSURES OU DES DÉGÂTS MATÉRIELS, RESPECTER

LES MISES EN GARDE SUIVANTES :

IT IS THE INSTALLER’S RESPONSIBILITY TO MAKE SURE THE

PUMPS AUTOMATIC SWITCH IS ABLE TO OPERATE WITHOUT ANY

OBSTRUCTIONS WITHIN THE BASIN. It is recommended that the

installer test and observe the pump’s operation for several cycles

after installation.

IL EST DE LA RESPONSABILITÉ DE L’INSTALLATEUR DE S’ASSURER QUE

L’INTERRUPTEUR AUTOMATIQUE DE POMPE PEUT FONCTIONNER SANS

AUCUN BLOCAGE À L’INTÉRIEUR DU SYSTÈME. Il est recommandé

que l’installateur teste et observe le fonctionnement de la pompe

pendant plusieurs cycles après l’installation.

INSTALLATION MANUAL

IT IS REQUIRED TO USE RIGID PIPING AND FITTINGS to secure the

pump in the basin and reduce pump movement. Pump movement

can prevent the switch from operating correctly. Do not use ﬂexible

hosing.

IL EST NÉCESSAIRE D’UTILISER DES TUYAUX ET DES RACCORDS

RIGIDES pour ﬁxer la pompe dans le système et réduire les

mouvements de la pompe. Les mouvements de la pompe peuvent

empêcher l’interrupteur de fonctionner correctement. Ne pas

utiliser de tuyaux ﬂexibles.

IT IS REQUIRED TO USE A CHECK VALVE with this pump to prevent the

back-ﬂow of water after each pump cycle.

Cette pompe NÉCESSITE L’UTILISATION D’UNE VANNE DE CONTRÔLE

pour empêcher le reﬂux d’eau souterraine claire après chaque

cycle de pompage.

DO NOT INSTALL OR OPERATE THE PUMP IF IT HAS BEEN DAMAGED

IN ANY WAY.

NE PAS INSTALLER OU FAIRE FONCTIONNER LA POMPE SI ELLE A ÉTÉ

ENDOMMAGÉE DE QUELQUE MANIÈRE QUE CE SOIT.

DO NOT LIFT OR CARRY THE PUMP BY THE POWER CORD. Use the

pump’s handle or lift ring.

NE PAS SOULEVER OU PORTER LA POMPE PAR LE CORDON

D’ALIMENTATION. Utiliser la poignée ou la bague de levage de la

pompe.

AN INDEPENDENT HIGH WATER ALARM OR BACK UP PUMP SHOULD BE

USED when risk of property damage from high water levels exists.

UNE ALARME AUTONOME DE? NIVEAU D’EAU ÉLEVÉ OU UNE POMPE DE

SAUVEGARDE DOIVENT ÊTRE UTILISÉES en cas de risque de dégâts

matériels causés par des niveaux d’eau élevés.

REPLACE THE TETHER SWTICH EVERY TWO (2) YEARS. This required

maintenance will reduce the risk of improper pump operation,

switch failure and/or ﬂooding.

REMPLACER LE COMMUTATEUR TOUS LES DEUX (2) ANS.Cet entretien

réduira le risque d’utilisation incorrecte de la pompe, de défaillance

de l’interrupteur ou d’inondation.

This product can expose you to chemicals, including DEHP,

which is known to the State of California to cause cancer, birth

defects and reproductive harm. For more information, go to

www.P65Warnings.ca.gov.

Ce produit peut vous exposer à des produits chimiques,

notamment du DOP, reconnus par l’État de Californie comme

étant cancérigènes et à l’origine d’anomalies congénitales et de

problèmes de l’appareil reproductif. Pour plus de renseignements,

visiter le site www.P65Warnings.ca.gov.

TETHER FLOAT SWTICH This ﬂoat should not be adjusted. Changing

the length of the tether switch will effect on and off water levels, run

time, and may result in the pump running continuously.

L’INTERRUPTEUR DU FLOTTEUR À AMARRE Ce ﬂotteur ne devrait pas

être ajusté. Si vous modiﬁez la longueur de l’interrupteur d’attache,

les niveaux d’eau et la durée de fonctionnement seront activés et

désactivés. La pompe pourrait fonctionner en permanence.

INSTALLATION MANUAL

1. Check Valve 7. Tether Switch

2. Union 8. GFCI Outlet

3. Discharge Pipe 9. Piggyback Plug

4. Inlet Pipe 10. Pump Power Supply Cord

5. Basin 11. Vent Pipe

6. Pump 12. Gasket/Basin Lid

TYPICAL SEWAGE INSTALLATION

1. This installation must be in accordance with the National

Electric Code and all applicable local codes and

ordinances.

2. Use a basin (5) that is large enough to accommodate the

pump. The basin diameter should be a minimum of 18

inches and the depth a minimum of 24 inches.

3. Clean the basin of all debris.

4. Set the pump (6) on a solid, level surface. Do not place

pump directly on clay, earth, gravel, or sand. A brick or

block may be installed under the pump to provide a solid

base.

5. Position pump (6) in the basin (5) so the tether switch (7) is

away from incoming water. Verify the tether ﬂoat switch has

at least 1 inch clearance to the side wall of the basin and is

free of any possible obstructions.

6. Install discharge plumbing according to local, regional and

state codes. Do not reduce the discharge pipe (3) size

below that which is provided on the pump (6).

7. A union (2) should be installed above the basin to allow

easy removal of the pump (6) for cleaning and service.

8. Install a check valve (1) (required) to prevent back-ﬂow.

It should be installed above the union.

9. A gate valve or ball valve should be installed above the

check valve if required by local, regional or state codes.

10. Connect remaining discharge pipe. Keep sections as short

as possible with a minimum number of turns.

11. A vent pipe (11) is required. It removes gases and odors

and should be installed as required by local, regional or

state codes.

12. Secure power supply cord (8) to discharge pipe (3) using

cable or zip ties to prevent possible switch entanglement.

13. Connect tether switch (7) piggyback cord to a ground fault

circuit interrupter (GFCI) outlet (9) (required) then connect

the pump power supply cord (8) into the piggyback cord.

14. Fill the basin with water. The pump will start when the

water level has reached the switch-on level. Verify the

pump is operating normally.

15. Install a basin cover and gasket (10) to prevent debris from

falling into the basin, prevent personal injury, and to contain

gases and odors.

INSTALLATION MANUAL

TROUBLESHOOTING WARNINGS

ALWAYS DISCONNECT THE PUMP FROM POWER SUPPLY before

installing or servicing.

TOUJOURS METTRE LA POMPE HORS TENSION avant de procéder à

l’installation, à l’entretien.

LET PUMP COOL FOR A MINIMUM OF 2 HOURS BEFORE ATTEMPTING TO

SERVICE. Submersible pumps contain oil may become pressurized

and hot under normal operating conditions.

LAISSER REFROIDIR LA POMPE PENDANT AU MOINS 2 HEURES AVANT

D’ESSAYER DE LA RÉPARER. Les pompes submersibles contiennent

de l’huile qui devient pressurisée et chaude dans des conditions

normales de fonctionnement.

1. Submersible pump models have permanently lubricated

bearings and require no additional lubrication.

2. Submersible pumps contain dielectric oil for cooling.

Dielectric oil can be harmful to the environment. Follow

state environmental laws when disposing of oil.

3. The pump motor is equipped with automatic resetting

thermal protector and may restart unexpectedly. Protector

tripping is an indication of motor overloading as a result of

operating the pump at low heads, excessively high or low

voltage, inadequate wiring, incorrect motor conditions, or

that the motor is at the end of its product life.

TROUBLESHOOTING

Symptoms Possible Cause(s) Suggested Remedies

Pump will not

start or run

1. Water level too low

2. Blown fuse or tripped circuit breaker

3. Low supply voltage

4. Motor

5. Switch

6. Inlet clogged

7. Switch obstruction

8. GFCI

1. Water must be at the appropriate level to activate switch

2. If blown, determine cause and then either replace with proper

sized fuse or reset breaker

3. Contact an electrician

4. Replace pump

5. Replace switch

6. Remove debris

7. Remove obstruction to verify free motion of switch

8. Reset GFCI outlet

Pump starts and

stops too often

1. Back-flow of water from discharge

pipe

2. Switch

3. Check valve not functioning properly

or leaking

1. Install check valve

2. Replace switch

3. Remove and examine check valve for proper installation and free

operation. Replace check valve if necessary.

Pump shuts off

and turns on

independently

of switch (trips

thermal overload

protection)

1. Switch

2. Switch obstruction

3. Obstruction in discharge pipe

4. Low supply voltage

1. Replace tether switch

2. Remove obstruction to verify free motion of switch

3. Remove obstruction in discharge piping

4. Contact an electrician.

INSTALLATION MANUAL

TROUBLESHOOTING (CONTINUED)

Symptoms Possible Cause(s) Suggested Remedies

Pump operates

noisily or vibrates

excessively

1. Worn bearings

2. Impeller broken

3. Piping attachments to building

structure too rigid or too loose

1. Replace pump

2. Replace pump

3. Install rubber coupling (available at local hardware stores) to isolate

pump vibration from discharge plumbing

Pump will not

shut off

1. Switch

2. Switch obstructions

3. Restricted discharge (obstruction in

piping)

4. Excessive inflow or pump not

properly sized for application

1. Replace switch

2. Remove obstruction to verify free motion of switch

3. Remove obstruction from discharge piping

4. Recheck all sizing calculations to determine proper pump size

Pump operates

but delivers little

or no water

1. Low supply voltage

2. Inlet clogged

3. Broken impeller

4. Pump not properly sized for

application

5. Check valve stuck closed or

installed backwards

6. Shut off valve closed

1. Contact an electrician

2. Remove debris

3. Replace pump

4. Recheck all sizing calculations to determine proper pump size

5. Remove and examine check valve for proper installation and free

operation

6. Open valve

Pump trips GFCI 1. Bad GFCI

2. Bad pump

1. Contact an electrician to verify GFCI operation

2. Replace pump

ROUTINE MAINTENANCE

The pump should be inspected monthly for pump movement or buildup of debris on the switch or ﬂoat Reposition pump if it has

moved. Remove any debris that could interfere with the operation of the switch. Lack of proper routine maintenance will void war-

ranty.

• Make sure the pump is plugged in to a working ground fault circuit interrupter (GFCI) outlet and the cord is in good shape. In

damp areas, GFCI breakers may trip, effectively shutting off the pump. Check in on your sewage pump and reset the GFCI if

necessary.

• Ensure the pump is standing upright. Vibrations during operation can cause it to move or tilt onto one side. This can jam the

tether ﬂoat so it can’t activate the pump.

• Flush toilet or run sink to make sure the pump starts automatically and the water drains quickly once the pump is on. If the

pump doesn’t start, have it serviced or replaced.

• Replace the tether switch every two (2) years. This maintence will reduce the risk of improper pump operation, switch failure

and/or ﬂooding.

INSTALLATION MANUAL

WARRANTY & SERVICE PARTS SHEET - REPLACEMENT PARTS

REPAIR KITS

MODEL: ALL MODELS

REF. NO. DESCRIPTION PART NUMBER

1TETHER SWITCH 56835-WYN1

10 FT. POWER CORD

31006-WYN2

INSTALLATION MANUAL

FOR REPLACEMENT

PARTS OR CUSTOMER SUPPORT,

CALL 1-877-9RIDGID

Please provide following information:

- Model number

- Serial number on cord tag (not to be removed)

- Part description and number as shown in parts list

LIMITED WARRANTY

For three years for RWCS50T model from the date of purchase, from an authorized dealer, RIDGID Water Systems will repair or replace, at its option for the original

purchaser, any part or parts of its Sewage or Efﬂuent Pumps or Water Pumps (“Product”) found upon examination by RIDGID Water Systems to be defective in

materials or workmanship. Please call RIDGID Water Systems (1-877-9RIDGID) for warranty instructions. Be prepared to provide the model number and the serial

number when exercising this warranty. All transportation charges on Products or parts submitted for repair or replacement must be paid by purchaser. This Limited

Warranty is not transferrable.This Limited Warranty does not cover Products which have been damaged as a result of accident, abuse, misuse, neglect, improper

installation, improper maintenance, or failure to operate in accordance with RIDGID’s written instructions.

This Limited Warranty does not cover Products which have been damaged as a result of accident, abuse, misuse, neglect, improper installation, improper

maintenance, or failure to operate in accordance with RIDGID Water Systems’ written instructions.

THIS WARRANTY IS IN LIEU OF ANY AND ALL OTHER WARRANTIES, OBLIGATIONS OR AGREEMENTS, EXPRESSED OR IMPLIED, INCLUDING ANY IMPLIED

WARRANTY OF MERCHANTABILITY OR FITNESS FOR ANY PARTICULAR PURPOSE, AND ANY RIGHTS OR REMEDIES AGAINST ANY PERSON OR ENTITY UNDER THE

UNIFORM COMMERCIAL CODE OR OTHERWISE WITH RESPECT TO THE SALE OF THE PRODUCT. THE REMEDIES AND OBLIGATIONS STATED IN THIS WARRANTY

ARE THE SOLE AND EXCLUSIVE REMEDIES OF AND OBLIGATIONS TO THE OWNER FOR ANY AND ALL MATTERS ARISING WITH RESPECT TO OR IN ANY WAY

CONNECTED WITH THE PRODUCT, REGARDLESS OF THE SOURCE OR PROVIDER OF SUCH GOODS. IN NO EVENT, WHETHER AS A RESULT OF BREACH OF CONTRACT,

WARRANTY TORT (INCLUDING NEGLIGENCE) OR OTHERWISE, SHALL RIDGID WATER SYSTEMS OR ANY AFFILIATE BE LIABLE FOR ANY SPECIAL, INCIDENTAL OR

CONSEQUENTIAL DAMAGES.

You MUST retain your purchase receipt along with this form. In the event you need to exercise a warranty claim, you MUST send a copy of the purchase receipt along
