RIKA Memo User manual

Operating Manual
MEMO

2
TABLE OF CONTENT
1. PREFACE 3
Explanations to symbols...........................................................................................................................................................................3
Spare part overview exploded diagram .....................................................................................................................................................4
Spare part overview article numbers.........................................................................................................................................................6
Dimensions ..............................................................................................................................................................................................7
Technical data...........................................................................................................................................................................................7
Amount of fuel .........................................................................................................................................................................................7
Packaging .................................................................................................................................................................................................7
Electrical connection ................................................................................................................................................................................7
2. IMPORTANT INFORMATION 8
General warning and safety information ..................................................................................................................................................8
Safety distances ........................................................................................................................................................................................8
Prior to set up...........................................................................................................................................................................................9
e correct chimney connection...............................................................................................................................................................9
3. BRIEF INFORMATION ON FUEL - PELLETS 10
What are pellets?....................................................................................................................................................................................10
Wood pellet specification according to ENplus – A1.............................................................................................................................10
Pellet storage ..........................................................................................................................................................................................10
4. TECHNOLOGY AND SAFETY FUNCTIONS 11
Operating comfort..................................................................................................................................................................................11
Top efficiency - lowest emissions............................................................................................................................................................11
Overheating............................................................................................................................................................................................11
Low-temperature shutdown...................................................................................................................................................................11
Electrical excess current protection.........................................................................................................................................................11
Component monitoring .........................................................................................................................................................................11
Power failure (during heating)................................................................................................................................................................11
Power failure (during the initial stage)....................................................................................................................................................11
5. INSTALLING THE STOVE 12
General information...............................................................................................................................................................................12
Connection to the chimney ....................................................................................................................................................................12
Connecting to a steel chimney ..............................................................................................................................................................12
Combustion air.......................................................................................................................................................................................12
Feeding in external combustion air.........................................................................................................................................................12
6. ASSEMBLY/DISMANTLING STONE AND OPTIONS 13
Disassembly of the front side casing.......................................................................................................................................................13
7. INTERNAL CONTROLS 14
Basics......................................................................................................................................................................................................14
Operation ...............................................................................................................................................................................................14
EASY MODE - simple heating operation ...........................................................................................................................................14
EASY OFF - inactive state ....................................................................................................................................................................14
Start - scavenge - tip - ignition ..............................................................................................................................................................14
Stopping during ignit or startphase........................................................................................................................................................15
EASY 40 – operation .............................................................................................................................................................................15
Cleaning and tipping during operation ..................................................................................................................................................15
EASY 40 – switch off.............................................................................................................................................................................15
Extended heating operation - HEAT MODE - comfort funktions ......................................................................................................16
Menu structure and main menu level .....................................................................................................................................................17
Main menu time - time adjustment .......................................................................................................................................................18
Main menu setup - additional functions ................................................................................................................................................20
Main menu info - additional information ..............................................................................................................................................22
8. COMFORT OPTIONS 24
RIKA room sensor/RIKA radio room sensor.........................................................................................................................................24
RIKA phone option – GSM ..................................................................................................................................................................24

|
3
EN
2
1. PREFACE
Explanations to symbols
...important
note #8
...hex #8
(M5 winding) 3
...allen key #3
(M4 winding)
...useful
tip #10
...hex #10
(M6 winding) ...manually
RIKA interface for various options.........................................................................................................................................................24
External room thermostat ......................................................................................................................................................................24
External connection cable bridge ...........................................................................................................................................................24
9. MODES 25
Pellet operation Heat/Easy/Automatic/Room .......................................................................................................................................25
Fuel addition pellet operation.................................................................................................................................................................25
Emergency - electrical heating up. without ignition...............................................................................................................................25
10. MENU OVERVIEW V1.40 26
11. WARNINGS AND ERROR MESSAGES 28
12. CLEANING AND MAINTENANCE 29
Basic information ...................................................................................................................................................................................29
Open the combustion chamber door ......................................................................................................................................................29
Cleaning the fire trough .........................................................................................................................................................................29
Ampty the ash drawer ............................................................................................................................................................................29
Cleaning flue pipes .................................................................................................................................................................................30
Clean flue gas collecting channel............................................................................................................................................................31
Clean flue gas fan housing......................................................................................................................................................................31
Cleaning the flame temperature sensor .................................................................................................................................................31
Combustion air - intake .........................................................................................................................................................................31
Cleaning the pellet container..................................................................................................................................................................31
Cleaning the door glass ..........................................................................................................................................................................31
Bearings .................................................................................................................................................................................................31
Checking door seal .................................................................................................................................................................................31
Checking chimneay connection..............................................................................................................................................................31
13. PROBLEMS - POSSIBLE SOLUTIONS 32
Problem 1 ...............................................................................................................................................................................................32
Problem 2 ...............................................................................................................................................................................................32
Problem 3 ...............................................................................................................................................................................................32
14. INSTRUCTIONS FOR COMMISSIONING PROTOCOL 33
15. GUARANTEE 35

4
Spare part overview exploded diagram

|
5
EN
4

6
Spare part overview article numbers
# Art.Nr.: Description
1 B15245 heat protection compl.
2 Z31459 sensor clamp
3 B16521 Control panel
4 L00426 Flue plate
4*** L02585 Flue plate
5 B15782 container compl.
6 N111515 flame sensor
6*** B16114 Temperature sensor
*** B16053 sensor tube
*** L01441 Pressure bracket
7 N107887 fuse holder
8 N111586 safety temperature limiter
9 Z32147 ignition cartridge
10 B12301 screw
11 B15773 auger motor 220V/50Hz
11*** N111820 Screw motor, stepless
12 B15781 HP bracket
13 B15587 fan compl.
14** Z32344 combustion chamber door compl.
B15249 combustion chamber door compl. until Snr.
1301733
15 Z32340 door glas
16 Z34857 Locking bolt
L02220 lock tongue
B15313 door handle complete until Snr 1301733
N111576 Switch cabinet key
17 L00437 glass holder
18 B15244 combustion chamber lid compl.
18*** B16321 Combustion chamber cover metallic grey
18*** B16052 Combustion chamber cover black
19 N100485 Round sealing strip D12
20 N103693 culimeta flat packing black 8x2
21 Z30493 door handle chrome
22 Z35183 Sintered bearing Di10
23* Z35182 Plastic bearing
24 B16270 main board
24*** B15856 Motherboard C2 (for control panel)
25 N111825 door contact switch
26 N111597 capacitor
27 B16155 Induced draft fan housing
28 N111581 induced draught fan motor
29 N108315 O-ring D76/4.5
30 Z32422 cleaning opening metallic
31 N100055 hexagon socket screw
32 B15243 combustion chamber front compl.
33 B14478 Hinge BA1
34 N106591 cage nut electro-galvanised, cage NR M8
35 Z32345 fire trough
36 Z18502 pipe adapter
37 B15800 Cabletree
37*** Z34546 Cabletree
50 L01018 cover left compl.
51 B16020 convection fin compl.
52 L01021 container lid
53a L01016 rear wall top
53b L01025 rear wall bottom
*** LB00620 rear wall metallic
*** LB00621 rear wall black
54 L01017 cover right compl.
55 LB00441 casing right, cast grey
58 Z18278 air intake
59 Z32424 casing front/bottom, silver
# Art.Nr.: Description
62 Z35705 casing front/top silver
65 LB00442 casing left cpl., cast grey
L00797 motor plate
*** B16030 additional board
**
up to serial number 1301733 the firebox
door completely (B15249) must be supplied
as a spare part when replacing the firebox
door. In addition (111576) is required when a
Türtasuch the cabinet key.
*** from serial number 1328866

|
7
EN
6
Dimensions
B
H
T R-S
R-H
F-S
F-H
R-
F-
Technical data
Dimensions
height [mm] 978
width [mm] 490
corpus depth [mm] 544
Weight
weight without shell [kg] 95
weight with shell [kg] 110
Flue pipe connection
R - Ø flue pipe outlet [mm] 100
RO - H original angle pipe connection height [cm] -
RO - T1 original angle pipe total depth [cm] -
RO - T2 original angle pipe distance to rear wall [cm] -
RO - T3 deapth from rear wall to middle of flue
pipe [cm] -
RO - S original angle pipe side distance [cm] -
R - H rear connection height [cm] 15
R - S rear connection side distance [cm] 17
Fresh air connection
F - Ø diameter [mm] 50
F - H connection height [cm] 12
F - S side distance [cm] 20
Convection air connection
K - Ø diameter [mm] -
K - H connection height [cm] -
K - S side distance [cm] -
Amount of fuel
nominal load part load
Amount of fuel ~2,2kg* ~0,6kg*
Burn time at full pellet
hopper ca. 11h ca. 28h
*Practical values may vary depending on pellet quality.
Technical data
heating power range [kW] 2,4 - 9
room heating capacity (depending on house
insulation) [m³] 50 - 240
fuel consumption [kg/h] bis 2,2
pellet container capacity [kg] 21
electric supply [V]/[Hz] 230/50
average electrical input [W] ~ 20
fuse [A] 2,5 AT
Efficiency [%] 92,1
CO2 [%] 11,1
CO-emission on 13% OO [mg/mN3] 34
dust emission [mg/mN3] 22
exhaust [g/s] 6,45
exhaust temperature [°C] 144
chimney draft requirement [Pa] 0
Note
Pellet consumption depends on the size of the pellets. The larger the pellet,
the slower the feed and vice versa
The owner of small firing systems or the person authorised for the small
firing system is to keep the technical documentation and is to submit it to the
authorities or the chimney sweep on request.
Note
Please observe the national and European standards as well as local
regulations concerning the installation and operation of firing installations!
Packaging
Your first impression is important to us!!
The packaging of your new stove provides excellent protection against damage.
However damage to the stove and accessories may still occur during transport.
Note
Therefore please check your stove on receipt for damage and completeness!
Report any deficiencies to your dealer immediately! Pay particular attention
during unpacking that the stone panels remain intact. Scratches to the
material can easily occur. Stone panels are excluded from the warrant
The packaging of your new stove is environmentally neutral to a great extent
Tip
The wood used in the packaging has not been surface treated and may
therefore be burnt in your stove. The cardboard and film (PE) can be disposed
of via the municipal waste collection for recycling
Electrical connection
The stove is supplied with an approx. 2m long connecting cable with a Euro-plug.
This cable is to be connected to a 230Volt/50Hz socket. The average electrical
power consumption is some 20 Watt in heating operation. And approx. 150
Watt during automatic ignition. The connection cable must be laid so that there
is no contact to any sharp edges or hot surfaces of the stove.

8
2. IMPORTANT INFORMATION
General warning and safety information
Observance of the introductory general warning information is imperative.
QRead the entire manual thoroughly before installing and putting the stove into
service. Observe the national provisions and laws as well as the regulations
and rules applicable locally.
QRIKA stoves should only be installed in rooms with normal humidity (dry
areas according to VDE 0100 Part 200). The furnaces are not splash water
protected and may not be installed in wet areas.
QOnly approved transport equipment with sufficient load carrying capacity
may be used with your heating appliance.
QYour heating appliance is not suitable for use as a ladder or stationary
scaffolding.
QThe burning of fuel releases heat energy that lead to extensive heating of
the stove surfaces, doors, door and operating handles, glass, flue pipes
and possibly the front wall. Refrain from touching these parts without
appropriate protective clothing or equipment e.g. heat-resistant gloves or
means of operation (operating handle).
QMake your children aware of this particular danger and keep them away from
the stove during heating.
QOnly burn approved heating materials
QThe combustion or introduction of highly flammable or explosive materials
such as empty spray cans etc. in the combustion chamber and storing them
near the stove is strictly prohibited due to the danger of explosion.
QNo light or inflammable clothing is to be worn when post-heating.
QPlacing non-heat resistant objects on the stove or near it is prohibited.
QDo not place clothing on the stove to dry.
QStands for drying clothes etc. must be placed at a sufficient distance to the
stove – ACUTE DANGER OF FIRE!
QWhen your stove is burning, the use of highly inflammable and explosive
materials in the same or adjacent rooms is prohibited
Note
Waste and liquids may not be burnt in the stove!
Note
To prevent your stove from overheating of the internal components,
do never cover the convection fins!
Safety distances
Note
1. To non-combustible objects
a > 40 cm b > 10 cm
2. To combustible objects and reinforced concrete load-bearing walls
a > 80 cm b > 20 cm
Tip
please observe a minimum distance of 20 cm behind and sideways the stove
for maintenance.

|
9
EN
8
Prior to set up
Floor bearing capacity
Ensure that the substructure is capable of bearing the weight of the stove prior
to set-up.
Note
No modifications may be made to the firing installation. This also leads to loss
of warranty and guarantee.
Floor protection
A base is required (glass, sheet steel or ceramic) if the floor is combustible
(wood, carpet, etc.).
Flue pipe connection
QFlue pipes pose a particular source of hazard regarding gas leaks and
fire. Get the advice of an authorised specialist company for the layout and
assembly.
QPlease observe the corresponding installation guidelines for walls panelled
with wood when connecting your flue pipes to the stove,
QObserve the formation of flue gas (atmospheric inversion) and draughts
when the weather is unfavourable.
QInfeed of too little combustion air can lead to smoke in the rooms or to flue
gas leaks. Hazardous deposits in the stove and chimney may also occur.
QIf flue gas escapes, let the fire burn out and check whether all the air inlet
openings are free and the flue gas pipes and the stove pipe are clean. If in
doubt notify the master chimney sweep since draught malfunctions may be
connected to your chimney.
QOnly use suitable tools from our range of accessories when handling embers
and make sure that no embers fall out of the combustion chamber onto
inflammable material.
QUse the heat-resistant gloves supplied to open the doors of your stove.
The correct chimney connection
There are several ways to connect your stove to the chimney, eg:
*1
*2
*3
*1
*2
*3
1) wind break, 2) chimney, 3) inspection opening
For the selection of the connection and to ensure a proper connection between
the stove and chimney, please read the guide „INSTALLING THE STOVE“ or ask
your local chimney sweep.
Stoves type 1 (BA 1):
QSuitable for multiple occupancy. (note the different country regulations)
Note
on ROOM-AIR DEPENDENT and
ROOM-AIR INDEPENDENT OPERATION:
Your stove has been tested as a room-air dependent stove according to EN
14785 and does not conform in Germany to the requirements for room-
air independent operation. In combination with room-air installations (e.g.
controlled ventilation and venting systems (extractors etc.) it must be ensured
that the stove and the room air system are monitored and safeguarded
mutually (e.g. via a differential pressure controller etc.). The combustion air
infeed of approx. 40 m3/h must be ensured. Please observe the respective
local regulations and rules in consultation with your master chimney sweep

10
3. BRIEF INFORMATION ON FUEL - PELLETS
What are pellets?
Wood pellets are a standardised fuel. Every manufacturer must adhere to certain
conditions in order to enable flawless, energy-efficient heating. Pellets are made
from wooden waste, from sawmills and planning workshops, as well as from
residue from forestry operations. These “starting products” are crushed, dried,
and pressed into Pellet “Fuel” without any bonding agent.
ENplus – Pellets
This new pellets are a standard sets new benchmarks in the European pellet
market. The traceability of pellets is ensured thanks to the use of identification
numbers. The pellet manufacturers’ production facilities and manufacturing
processes are reviewed every year. A quality assurance system ensures
the pellets comply with the requirements of the new standard and that the
conditions for trouble-free heating are guaranteed
Wood pellet specification according to ENplus –
A1
parameter measure ENplus-A1
diameter mm 6 (±1)2)
length mm 3,15 bis 403)
buld density kg/m³ ≥600
calorific value MJ/kg ≥16,5
water content Ma.-% ≤10
fine fraction (<3,15mm) Ma.-% ≤ 1
mechanical rigidity Ma.-% ≥97,54)
ash content Ma.-%1) ≤0,7
ash softening temperature (DT) °C ≥1200
chlorine content Ma.-% 1) ≤0,02
sulphur content Ma.-% 1) ≤0,03
nitrogen content Ma.-% 1) ≤0,3
copper content mg/kg 1) ≤10
chrome content mg/kg 1) ≤10
arsenic content mg/kg 1) ≤1
cadmium content mg/kg 1) ≤0,5
mercury content mg/kg 1) ≤0,1
lead content mg/kg 1) ≤10
nickel content mg/kg 1) ≤10
zinc content mg/kg 1) ≤100
1) in an anhydrous state
2) diameter must be specified
3) a maximum of 1% of the pellets may be longer than 40 mm,
max. length is 45 mm
4) the limit value of ≥97,7 Ma.-% applies when conducting measurements with a
lignotester (internal control)
Note
Please ask your pellet stove dealer for tested fuel and a list of monitored fuel
manufacturers.
Using poor quality or prohibited pellet fuel will have a negative effect on the
function of your pellet stove and can also lead to the warranty becoming null
and void, as well as the product liability connected with this. Observe waste
incineration legislation!
Only burn pellets that have been inspected according to ÖNORM, DIN Plus
or ENplus-A1.
Pellet storage
In order to guarantee problem free burning of the wooden pellets, it is imperative
necessary to store the fuel as dry as possible and free from impurities.
Pellets should not be kept in sacks outdoors or stored in a manner where
they are exposed to the environment. This can lead to blockages in the screw
conveyor
Note
“screw stoppers” are excluded from the warranty.
Note
Your pellet stove is only approved for the burning of wood or pellets of
tested quality. Burning straw, maize, woodchips etc. is not permitted! Non-
observance of these regulations makes void all warranty and guarantee
claims and may impair the safety of the unit!
