Rikomagic MK802 III User manual

RikomagicMK802IIIUserManual
Page0



Andriod4.1 Dual-core Mini PC









Shenzhen Rikomagic Tech Corp.,Ltd

RikomagicMK802IIIUserManual
Page1
Table of Contents
Declaration......................................................................................................................... 2
1.Connector ....................................................................................................................... 2
2. Device connection Instruction........................................................................................ 3
3. Boot state....................................................................................................................... 4
4. Main Screen Introduction............................................................................................... 5
4.1 Move/Delete desktop icon...................................................................................... 5
4.2 Function column..................................................................................................... 7
4.3 Status bar............................................................................................................... 8
4.4 Application.............................................................................................................. 8
5. Settings ........................................................................................................................ 10
5.1 WIFI Setting ......................................................................................................... 10
5.2 Ethernet Setting ................................................................................................... 10
5.3 PPPOE Setting .....................................................................................................11
5.4 USB.......................................................................................................................11
5.5 Sound....................................................................................................................11
5.6 Display ..................................................................................................................11
5.7 Screen.................................................................................................................. 12
5.8 Storage................................................................................................................. 12
5.9 Apps ..................................................................................................................... 12
5.10 Security .............................................................................................................. 12
5.11 Language & input ............................................................................................... 12
5.12 Backup & reset................................................................................................... 13
5.13 Date & time ........................................................................................................ 13
5.14 Developer options .............................................................................................. 13
5.15 About device ...................................................................................................... 13
6. Browse /Copy Files...................................................................................................... 13
7. Install/Uninstall Apps.................................................................................................... 14
7.1 Online installation................................................................................................. 14
7.2 Local installation .................................................................................................. 15
7.3 Uninstall Apps ...................................................................................................... 15
8. Airplay/DLNA................................................................................................................ 15
9. Web Browsing.............................................................................................................. 16
10. Local audio & video playback .................................................................................... 16
11. Use soft keyboard ...................................................................................................... 17
12. Switch input methods................................................................................................. 17
Question & Answer .......................................................................................................... 18
Specifications................................................................................................................... 19






RikomagicMK802IIIUserManual
Page2
Declaration
The user manual includes all the information of safe and correct operation
instruction. To avoid accident and product damaged, please make sure go through
all the content carefully before using the product.
Please keep the product away from high temperature, humid and dusty
environment.
Do not drop or crash the product.
Do not cut off the device when it is formatting, or upgrading, otherwise it will cause
operation system error.
Do not dismantle the device. Do not clean it by alcohol, thinner and Benzene.
We keep the right to upgrade and modify the product.
Disclaimer: we only take the responsibility to provide the warranty and after service.
The users have to take care of their data in the device by themselves. We do not
responsible for any data or related lost.
The product is not water-proof.
All the pictures in the instruction are just for reference.
1.Connector


RikomagicMK802IIIUserManual
Page3

Micro-USB Power: Connect with TV USB port for charge the unit.
USB 2.0 HOST: Connect with other USB device.
HDMI: High Definition Multimedia Interface Output
T-Flash: Support expanded 2GB-32GB TF card
2. Device connection Instruction
a) Take out the device insert into your TV HDMI port(if there is no enough space
around HDMI interface for MK802III, please use HDMI adapter connect), setup the
TV data receive mode to HDMI port(Refer to TV set user manual).
b) Power supply connection: take out Micro USB cable, connect it with the player′s
Micro USB2 port, then connect USB2 with TV′s USB port(notice: if there is no
USB2.0 port in your TV or you need connect external HDD box, please connect
power adapter directly)
c) This product suggest using 2.4G wireless keyboard or mouse. Plug 2.4G receiver
on USB Host connector. Or plug on USB OTG port by port converter. If only mouse
plugged, the device will provide soft keyboard in operation system. If the device
detected the physical keyboard, the soft keyboard will be hidden by OS
automatically.
d) Mouse left button for “ok”, right button for “return”, rolling for page up and page
down, Hold left button to pull icon or copy & paste file. Hold middle button for
Properties.

RikomagicMK802IIIUserManual
Page4
3. Boot state
After connect with power adapter for about 10 seconds, the boot screen would appear.

Then access to Rikomagic boot logo;


RikomagicMK802IIIUserManual
Page5

For about 30 seconds, device would access to main screen;

4. Main Screen Introduction
4.1 Move/Delete desktop icon
Long-press any icon in the main interface, you could put it in any position as you like, at
the same time you could put the other apps shortcut to the main interface.

RikomagicMK802IIIUserManual
Page6

Long press the icon and move it to the right above “×”and loosen, then you could delete it

Move your cursor to any space and drag towards left or right for page rolling.
Also you can use the mouse wheel for rolling page.

RikomagicMK802IIIUserManual
Page7

4.2 Function column

Return button: click to return to the upper level directory;
Homepage button: click it anytime to return to homepage;
Program button: Click to check all the running program;
Volume decrease button: Click to decrease volume;
Volume increase button: Click to increase volume;
Properties button: when in different apps, it shows different contents. It′s equivalent
toWindowspropertiesbutton;



RikomagicMK802IIIUserManual
Page8

Search button: Located in the top left corner of the main interface, click the icon to
input the website to search the web page;
Program tools button: Located in the right top corner of the desktop, click on the icon
can see installed apps software;

4.3 Status bar
The right button corner is status bar. It shows the status of T-Flash Card, USB connection,
Time, Wifi and Download…and so on.

Click status bar, the hide menu would bound up:

4.4 Application
Click to show up all the installed program and setup tools icon.

RikomagicMK802IIIUserManual
Page9

if the first desktop page file with icon, then pull or rolling mouse will move it to second
desktop page；
You could launch these program or set up directly, or hold this icon and throw them to
desktop to make shortcut；
Click then hold any button to make shortcut on desktop;


RikomagicMK802IIIUserManual
Page10
5. Settings
In the system user can setup according to their own requirements, such as network
connection, language, input methods, Video output resolution, Sound output and check
storage space.
It is in tool bar. Click to show it up below options:

5.1 WIFI Setting
When opened WIFI Player would search available wireless router signals within 20
meters, user just choose a router and input correct password then could browse internet;
if the router without password, player would connect it directly.
5.2 Ethernet Setting
If there is no wireless and have to use cable to access internet. But first, you should buy a
USB2.0 LAN Adapter and plug it on USB Host or OTG ports.（Notice: The USB2.0 LAN

RikomagicMK802IIIUserManual
Page11
Adapter supported is limited, please reference related type.）
Connect RJ45 LAN Cable, click “setting” “More” “Ethernet” tick “Use Ethernet”
5.3 PPPOE Setting
If your family or office network need dial-up, then click PPPOE Settings and input account
and password.
Connect RJ45 LAN cable, Click “Setting “More” “PPPOE Settings” input account
and password.
5.4 USB
This function user could exchange data between player and computer.
Specific operation steps：
1. Equipment connection: Use Micro USB to USB connect computer and Player，then
connect the player and TV with HDMI cable；
1. Settings: After device access to the main screen，click Settings USB Connect to
PC, press confirm. After the device go to USB mode, press Turn on USB storage. Now
your computer could find the device, after 5 seconds you could operate freely.
5.5 Sound
This is for Sound settings;
Volume: Click to setup volume level for music, video and games or other media;
Touch sounds: Click to open or close Touch sounds;
Screen lock sound: Click to open or close screen lock sound;
5.6 Display
Font size: Click to setup system font size according to their preference;

RikomagicMK802IIIUserManual
Page12
5.7 Screen
This is for Screen settings:
1. Screen Scale: Used to adjust the part of the game screen size
2. Output Interface: Default HDMI
3. HDMI mode: User could set appropriate output resolution according to their television
5.8 Storage
In this option, user could view local storage space and external storage space, besides,
user could uninstall or format storage equipment.
Notice: System divided the whole storage into seven area, only two areas visible, the
other five areas are taken up by Android system not visible. All the free space are the two
visible areas(0.98GB INTERNAL STORAGE + 1.60GB NAND FLASH=2.58GB)
5.9 Apps
In this option, user could view installed and running apps, at same time could check DDR
parameters.
5.10 Security
User can set password according to their needs
5.11 Language & input
1. User can set the language for system menus according to their Country or
preference(60 languages supported)
2. System default support Chinese and English, user need manual installing other input

RikomagicMK802IIIUserManual
Page13
methods.
3. User could set keyboard and mouse cursor speed and simulated mouse step length at
here.
5.12 Backup & reset
Backup: when you have very important files or apps, you′d better choose backup in case
files lost.
Reset: when choose this option, and confirm, system will erase user′s settings and all the
apps missing, and apply default configuration immediately (Not suggest);
5.13 Date & time
Because the machine don′t support built-in battery, so manual set date and time can′t be
saved, user can use automatic date & time, so when the device connected with internet,
date and time would update automatically;
5.14 Developer options
USB debugging: when connected with PC exchange data need open this option;
5.15 About device
This option show current system information display;
6. Browse /Copy Files
1. Open Explorer on the table

RikomagicMK802IIIUserManual
Page14

Internal Flash: Device internal storage space
SD Card: When insert TF card, fronts brighten
USB: When plug-in USB device (HDD, U-disk), fronts brighten
Network Places: In the same LAN, could access to other computer.
File Copy
In the Explorer long-press a file or folder will pop-up a menu, including: Copy, Delete,
Move, Paste, Rename options, if not execute operation, could directly click cancel.
7. Install/Uninstall Apps
MK802III support many commonly used third-party apps. You could install or uninstall
apps freely, there are two methods available install Apps:
7.1 Online installation
User could login built-in Google Play store download Apps (User need have an Gmail
account), user also could login Android market download Apps or other market. After
download system would prompt you install the Apps.

RikomagicMK802IIIUserManual
Page15
7.2 Local installation
User also could download Apps from computer, then copy to U disk or TF card, insert the
U disk or TF card to your device, then install from APKInstall or access to Explore find out
the Apps then install.
7.3 Uninstall Apps
Click SettingsApps, click an Apps you want to Uninstall, it would pop up a Uninstall
window, then click Uninstall. If you don′t want to uninstall just exit.



8. Airplay/DLNA
Airplay: By Airplay function, you can take iPhone, iPad music, video and images through
wireless transmission to the MK802 III equipment, and finally appear in the big screen;
DLNA : DLNA can through the specific applications let you share music, video and
images with smart cell phones and tablet PC. There are many Apps could realize DLNA
function, such as Air Play Free, Air Play DMR, Google TV Remote, Media Remote, iMedia
Share Lite, SoftMedia Player Tridl and so on.

RikomagicMK802IIIUserManual
Page16
9. Web Browsing
When connected Internet, you could use the following android built-in browser, or install
other browser

Considering android habit, new opened page will show on the webpage upper in the form
of tag, you can click “+” add new webpage, or click “-“ close opened webpage.
10. Local audio & video playback
User can through file manager browse external TF card, USB flash drive and HDD box
and playback the inside music, video, picture and files.

RikomagicMK802IIIUserManual
Page17

11. Use soft keyboard
The equipment support if only connected mouse, it would appear soft keyboard, if the
equipment detected you have inserted into physical keyboard, the soft keyboard will be
hidden.

12. Switch input methods
When you click any input box, you can setup your preference input methods, please click
desktop keyboard icon at the right-bottom status bar;

RikomagicMK802IIIUserManual
Page18
All the installed methods will display as below picture, and you can choose one of you
prefer:


Question & Answer
Screen flicker or unstable working: please check if the HDMI cable has been
connected tightly.
Cannot start device: please download FW file from Rikomagic official website:
www.rikomagic.com to refresh the device FW. Make sure all the important data has
been backup before process it. If the issue still cannot be solved, please contact the
distributor which you bought from.
Keep restarting system automatically: please check if the device get enough power
supply. Sometimes, external HDD cause power shortage. Please plug additional
power supply for external HDD or other external devices.
Cannot find file in SD card or open drive: Please check all the connection of the device.
And make sure you have tick of SD and USB Host in “Setting”






RikomagicMK802IIIUserManual
Page19
Specifications
Model# MK802 III
CPU RK3066 Dual Core
GPU Quad- Core 2D/ 3D/ OpenGL ES2.0(AMD Z430)/ OpenVG1.1
OS Android 4.1
Main Frequency Cortex-A9，Up to 1.6GHZ
RAM 1G DDR3
Memory 4GB/8GB
Expand Micro
SD T-Flash(Maximum support 32GB)
Browser Browse webpage
Video Format WMV/ASF/MP4/3GP/3G2M4V/AVI/MJPEG/RV10/DivX/VC-1/MPEG-2/
MPEG-4/H.263/H.264/1280*720P HD 30 fps, 1080P/720*480 D1 30fps
Audio Format MP3/WMA/APE/FLAC/AAC/OGG/AC3/WAV
Music Can be connected to the Internet, listen to music online
Picture format Max.8000x8000 JPEG BMP GIF PNG
WiFi 802.11 b/g/n
Flash Supports flash 11.1
Ports HDMI(male),Micro SD slot, USB host, USB power port; LED(Blue)
Accessory HDMI cable, USB power cable, manual, USB power adapter(optional)
Unit Size (mm) 90mm*40mm*13mm
ADD: 2F,Liangshi Building,Qi'an Road 6#,Shajing street, Bao'an,Shenzhen,
China, 518125
Tel: [phone]
Fax: [phone]
Sales E-mail: [e-mail]
Customer service E-mail: servi[email protected]
Official website: www.rikomagic.com
