Rime Lite SWING II User manual
1
USER GUIDE
Swing II ( Wireless Remote control and Flash Triggering System)
pr
Please read this manual before using SWING II, and keep it for future reference.
2
INTRODUCTION
Thank you for choosing Rimelite
New remote control system ‘SWING’ II provides an easy and compotable user interface.
It has the latest 2.4 Ghz high frequency transmission Module which provides reliability and availability in using any harsh environment.
16 Group channel and 6 individual channel, one transmitter can control totally 96 strobes.
Rime Lite telecommunications
Web: www.rimelite.com
Facebook: rimelites
Twitter: @rimelites
Headquarters: Hyundae Photonics B/D, 118-16, Chimsan-Dong, Buk-Gu, Daegu, South Korea.
Tel: 82–53–359–1445 / Fax: 82–53–359-0333
INTELLECTUAL PROPERTY
All intellectual property, owned by or which is otherwise the property of Rime Lite or its respective suppliers relating to Rime Lite Softbox, including but
not limited to, accessories, parts, or software, is proprietary to Rime Lite. No title to or ownership in the intellectual property is transferred to you. All
applicable rights of the intellectual Property shall remain with Rime Lite and its suppliers.
3
Unpacking
Your package contains the following items.
Swing II Transmitter AA battery Swing II Receiver
4
User manual
Swing II ( Wireless Remote control and Flash Triggering System)
The Swing II is the latest among Swing System family. Its inherited the sleek design, stable operation and high reliability.
The new Swing II comes with wireless control of the power setting of your flash. It allows user to control the flash
power output (On/Off, Increase/Reduce Power) up to 96 strobes wirelessly.
Swing II Transmitter Swing II Receiver
2.4 Ghz frequency. 2.4 Ghz
Sleek Design. 6 Groups Setting with 16
Channels per group
Use only 1 AA Battery (1.5V). Strobe No. Display in the LED
counter
Maximum Range: up to 180m. Individually set by User
Effective Range: 80m.
Effective Sync Speed: up to 1/250s
5
Cursor
Description
Cursor
Description
①
Strobe ID Display(LED)
⑥
Strobe Mains Power On/Off
②
The Selection button of Strobe ID
⑦
Test Button
③
Group Channel
⑧
Group Channel
④
Individual Strobe Channel
⑨
The battery cover
⑤
Strobe Power Up/Down
6
Operation Instruction for SWING-II
How to adjust the power Up/Down
1. Press one of Strobe individual button demanded to adjust the
power for 3 sec.
2. Selected button’s Red LED is flecking for 4 sec.
3. It is ready to adjust the Power Up/ Down with pressing +, -
button.(A-III)
For example) if a user would like to set the power of Strobe which has
individual No: 4, first, press the button No:4 (A-I) for 3 sec, and then
adjust the power with +,- button (A-III) while the button’s LED is
flecking.
Without any adjustment for 4sec, this mode is left automatically.
Strobe mains power On/Off individually.
1. Press one of Strobe individual button shortly demanded to turn
the power On/Off (A-I)
The whole Strobes mains power On/Off.
1. Press On/Off button
2. All Strobes power will be turn On/Off if strobes have the same
group channel.
The set up Group channel.
1. It has 16 Group Channels to avoid the bad connection.
2. Transmitter and Receiver’s Group channel should have the same
Group channel.
.
Notice) if there are many wireless devices( 2.4Ghz) and the bad connection,
Please, try to change the group channel of Transmitter&Receiver
주변에
.
Individual Strobe
No: Mains Power On
/ Off (click shortly)
* selected strobe is
turned the power
on/off
The display shows
the set individual
strobe No.
Power Up/Down
button
The blue LED,
Turned On Blue LED
shows the normal
operation of
Receiver.
Individual channel (6
channel)
Each group channel
has 6 individual
channel..
Test Button
Transmitter
Receiver
Battery cover (AA
size)
Group Channel
The whole strobes
Mains Power
On / Off
If Swing has the
normal operation,
please, check
Transmitter and
Receiver group
channel they set
the same channel
before using it.
.
10
Rime Lite is free of defects in material and workmanship for a period of twenty four (24) months from the
original date of purchase by the consumer.
If during the period of warranty this product proves defective under normal use and service, you should return
the product to the retailer from whom it was originally purchased, or to any Rime Lite authorized dealer or
authorized service center, if outside the time limit for returns imposed by the retailer.
-Warranty Conditions
1. The warranty is only valid presentation of the proof purchase consisting of original invoice or sales slip
confirmation, indicating the date of purchase, retailer’s name, model and serial number. Rime Lite
deserve the right to refuse warranty service if this information has been removed or changed after the
original purchased of the product from the retailer.
2. Rime Lite sole’s obligations are to the repair of the defective part, or at its discretion, replacement of the
product (service exchange unit)
3. Warranty repair must be carried out by an authorized Rime Lite dealer/ service center. No reimbursement
will be made for repairs carried out by non-Rime Lite, and warranty coverage will not be valid for any
repairs or damage caused by such repairs.
4. Repair or replacement under the term of this warranty does not give right to extension to or a new
starting of the period of warranty. Repair or direct replacement under the terms of this warranty may be
fulfilled with functionally equivalent service exchange units.
5. The warranty is not applicable in cases other than defects in material and workmanship. The warranty
does not cover the following:
A. Periodic checks, maintenance, repair, and replacement of parts due to normal wear and tear.
B. Abuse or misuse, including but not solely limited to the failure to use this product for its normal
purpose in accordance with Rime Lite’s instructions for usage and maintenance.
C. Failure of or damage to the product arising from incorrect installation or use inconsistent with
technical or safety standards, or failure to comply with product manual instructions.
