ring Range Extender Operating and safety instructions

1
Range Extender

Home security
beyond the front door
Ring Video Doorbells
began a Ring of Security
around your entire property.
Ring Protect is the security
system that takes the Ring
of Security a step further
giving you another level
of protection for your
property.
Now, you can arm and
disarm your system, prevent
crime and protect your
home - all from your phone,
tablet or PC.
2

Contents
1. Diagram
2. In-app Setup
3. Connecting the Device
4. Physical Installation
5. Troubleshooting
3

4
1.
Say hello
to your
Ring
Range
Extender.

5
LED
Ring
Diagram

6
2.
Set up
your Ring
Range
Extender
in the Ring
app.

Prepare to add the
range extender
In the Ring app, choose Set
Up a Device.
Choose the Ring Range
Extender, then tap Add
Device.
7

8
3.
Connect
your Ring
Range
Extender
to your
base
station.

Plug the range
extender into
a wall outlet
This turns on the device.
Your base station will find it.
9

Scan the QR Code or
enter the S2 PIN
The QR Code and PIN can
be found on the back of
your device, on the box, or
on the card in this box.
10

Track the connection
progress
Your extender will try to
connect to your base
station. The extender’s LED
ring will show the progress.
Here are some common
LED patterns:
11
Blue Blink
(30 sec)
Blue Solid
(5 sec)
Blue Blink
(5x, quick)
Blue Blink
(1x)
Blue Blink
(10x, quick)
Waiting to
connect
Connected
Couldn’t
add to base
station
Repeating
network
message
Factory
Reset

12
4.
Install
your Ring
Range
Extender
where
you’d like.

Place your detector
(but don’t install it yet)
Move the range extender in
between the base station
and a device that’s hard to
reach. The System Check
may give you ideas about
devices that might need a
boost.
13

14
