ring RX144 User manual

Pre upotrebe ovog proizvoda pažljivo
pročitajte sva uputstva. Sačuvajte ovo
uputstvo za upotrebu za budu buduću
referencu.
!
MANUAL / ENG
MOTORIZED TREADMILL
MODEL: RX144

2
Safety precautions
Warning: Now here we suggest that you should consult with your physician or health
professional before starting your workout, especially for the age up to 35 old or once-
health problem people. We take no responsible for any troubles or hurts if you don’t
following our specification. Treadmill will be carefully assembled and covered the motor
shield, then connect to the power.
Attention:
1. Ensuring the safety clamps were attached to the clothing or belts before using the treadmill.
2. Please do not insert any items to any part of the equipment, which would damage the equipment.
3. Position the treadmill on a clear, level surface. Do not place the treadmill on thick carpet as it
may interfere with proper ventilation. Do not place the treadmill near water or outdoors.
4. Never start the treadmill while you are standing on the walking belt. After turning the power on
and adjusting the speed control, there may be a pause before the walking belt begins to move,
always stand on the foot rails on the sides of the frame until the belt is moving.
5. Wear appropriate clothing when exercising on the treadmill. Do not wear long, loose fitting
clothing that may be caught in the treadmill. Always wear running or aerobic shoes with rubber
soles.
6. Keep the children and pets away from the treadmill while starting workout.
7. Don’t exercise in 40-Mints after dinner.
8. The equipment is suitable for adults, Juveniles need be accompanied with adults while workout.
9. You must hold on to the handrails until you become comfortable and familiar with the treadmill
at your first start the workout.
10. Treadmill is indoor-using equipment, not outdoor-using for avoiding damage. Keep the store-
place clean and flat, drying. Prohibiting the other purpose using, only for workout.
11. Please purchase the power-line to the distributor or contact with our company directly, for the
power-line only equip to the treadmill.
12. If the treadmill should suddenly increase in speed due to an electronics failure or the speed
being inadvertently increased, the treadmill will come to a sudden stop when the pull pin is
disengaged from the console.
13. Do not connect line to the middle of cable; do not lengthen cable or change the cable plug; do
not put any heavy thing on cable or put the cable near the heat source; forbid using socket with
several holes, these may cause fire or people may be hurt by the power.。
14. Cut off the power when the equipment is not used. When the power is cut off , do not pull the
power line to keep thee wire unbroken.Insert the plug to the socket with the safety ground circuit,
for the power-line is professional equipment .You must contact with the professional people directly
while the line is damaged.
15. This Treadmill only for home-using.
16.Safety area behind the treadmill：1000*2000MM

3
Assembly Instructions
When you open the carton, and you will find the below parts in the carton
PART LIST：
FIXING TOOLS:
5# Allen Wrench 5mm 1pc,
Wrench with screw driver S=13/14/15 1PC
Notice: Do not get through power before complete assembly
NO DES. Specification Nos. NO DES Specification Nos
1
Main frame
1
47
Wrench with screw driver
1
45
5#Allen wrench
5mm
1
46 Silicone oil
1
55
Bolt
M8*45 2 34 Left base cover
1
50
Bolt
M8*16 6 35 Right base cover 1
51
Lock washer 8
8
74
MP3 wire option
1
67
Bolt
4.2*19
2
44
Safety key
1

4
STEP 1 ：
STEP 2 ：
STEP 3
1. Open the carton, take out
the above spare parts, put the
Main Frame on the level
ground.
1. Hold on the Computer frame
and use the 5# Allen wrench(45),
bolt(50) and lock washer（51）,
fix the computer frame onto the
right and left upright.
NOTICE:Do not press the wire
inside the upright tube when
folding the computer. Keep
holding the computer to avoid
falling down.
1. Push up the Computer and
L&R uprights.
Notice: Support the upright
with hand to avoid falling
down to have any hurt.

5
STEP 4:
STEP 5:
STEP 6:
1.Use 5# Allen wrench，firstly
lock upright onto base frame by
bolt (55) and lock washer
（51）, then lock upright onto
base frame by bolt (50
) and
lock washer (51).
Left the same as right, see left
picture.
Notice: Support the upright
with hand to avoid falling
down to have any hurt.
Put the safety key (44) on the
computer.
1. Use the wrench with screw
driver and bolt(67) to lock the
left base cover(34) onto base
frame.
2. The right side is same as the
left side.
NOTE: the base cover need
to buckle into the upright
tube!
ATTENTION
：
Please confirm complete assembly
as the require above and lock all the
bolt. Do the following operation after
checking everything is OK. Before
you use the treadmill, please read
the instruction carefully.

6
Folding Instruction
Pulling up:
Pulling down:
Support place A with hand , kick the
place of air pressure bar, then the base
frame will fall down automatically
(Please keep anybody and any pet
away the machine when falling
down).
Pull up the base frame at position
( A) till hearing the sound that the
air pressure bar (B) is locked into
the round tube.

7
Technical Parameter
Grounding Methods
This product must be grounded. If it should malfunction or breakdown, grounding
provides
a path of least resistance for electric current to reduce the risk of electric shock. This
product is equipped with a cord having an equipment-grounding conductor and a
grounding plug. The plug must be plugged into an appropriate outlet that is properly
installed and grounded in accordance with all local codes and ordinances.
DANGER –Improper connection of the equipment-grounding conductor can result
in
a risk of electric shock. Check with a qualified electrician or serviceman if you are in
doubt
as to whether the product is properly grounded. Do not modify the plug provided with the
product –if it will not fit the outlet, have a proper outlet installed by a qualified electrician.
This product is for use on a nominal 220-240/100-120 volt(please choose the correct voltage)
circuit and has a grounding plug that looks like the plug illustrated in sketch A in following
figure. Make that the product is connected to an outlet having the same configuration as
the plug. No adapter should be used with this product.( The below picture is just for
reference，the actual plug and jack is depends on import country)
BUILT UP
SIZE(mm) 1490*760*1260mm POWER
As the rating label
showing
FOLDABLE
SIZE(mm) 870*760*1300mm Maximum output
power
As the rating label
showing
RUNNING
SURFACE
SIZE(mm)
450*1200mm SPEED RANGE 1-16KM/H
NET WEIGHT 52kg
MAX
AFFORDABLE
WEIGHT
110kg
4 LED WINDOW
WITH WHITE
BACK LIGHT
Speed, Time, Incline, Distance, Calories, Pulse

8
Operation Guide
DISPLAY WINDOW：
1. LCD WINDOW DISPLAY:
SPEED: Show speed
TIME: Show time
DISTANCE.: Show distance
CALORIE.: Show calories
PULSE: Show heart beat
PROGRAM/INCLINE: Show program/ Incline, When the PROGRAM character is lit the
corresponding window show program, When the INCLINE character is
lit the corresponding window show incline,
The middle window:Switched the DISPLAY-ALT，the window display TIME, DIST., SPEED,
CAL., PULSE.
2,KEY FUNCTION
“START” button: Press this button to start the machine, the machine will run at the lowest speed
or at the speed of default program after 3 seconds time count down;
“STOP” button: When the treadmill is running, Press this button once to slow down treadmill and
stop into PAUSE state. All data will remain. In this PAUSE state, If you press the this button twice,
the machine will stop completely and all the data will reset. But in this PAUSE state, if you press
START button, the treadmill will start running and continue the data of PAUSE state
“PROGRAM” button: Press this button to choose program from manual mode - P01-P15，U01-
U03，FAT;
“MODE” button：When machine in standby state, press this button to choose the mode: manual
mode, time count down mode, distance count down mode, calories count down mode. When
machine in FAT mode, the choose sequence is “Sex” “Age” “Height” “Weight”.
“DISPLAY-ALT” button：Press this button the window display TIME, DIST., SPEED, CAL.,PULSE.

9
“SPEED+/-”: Adjust the speed. Press the button to adjust the speed when running, or adjust the
data when stop.
SPEED（6,10）：Adjust the speed quickly
“INCLINE+/-”: Adjust the incline. Press the button to adjust the incline when running, or adjust the
data when stop.
“INCLINE（3,5）”：Adjust the incline quickly.
Button on left handle bar: Adjust incline;
Button on right handle bar: Adjust speed;
Notice: When any button is pressed, it will be accompanied by a prompt tone. When
the button is adjusted for parameter overrun, it will be accompanied by a long tone
prompt. There is no beep when the button is pressed Invalid.
3. MAIN FUNCTION
Open the power switch, the screen window will light up, the machine will enter into standby state.
3.1. START-UP QUICKLY (MANUAL):
Put safety key, press ‘ START’ button, the treadmill will run at the lowest speed in 3 seconds, press
SPEED+/-to adjust the speed. Press INCLINE+/-to adjust the incline. Press the ‘ STOP’ button or
take out the safety key directly to stop the treadmill.
3.2. COUNT DOWN MODE:
Press the ‘ MODE’ button, you can choose time countdown mode, distance count down mode,
calories countdown mode, and the screen window will show the default data and glitter. At the same
time, press SPEED+/-and INCLINE+/-to set the data. Press ‘ START ’ button, the machine will run
at the lowest speed, you can press SPEED+/-to change the speed, press INCLINE+/-to change
the incline. When it counts down to 0, the machine will stop smoothly. Certainly, you can press
‘ STOP’ button or take out the safety key from the computer to stop the machine.
3.3. INNER INSTALL PROGRAM:
Press ‘PROG’ button to choose the inner install program from P1----P15. When set the program,
the time window will show default data and glitter, press SPEED+/- or INCLINE+/-button to set the
running time. Each program has been divided into 16 section, Each exercise time=the setting
time/16. Press ‘START’, the machine will run at the first section speed and incline date. When the
section is over, it will enter into next section automatically, the speed and incline will change as next
section data. When finish one program, the machine will stop smoothly. During the running, you
can change the speed and incline by the SPEED+/-and INCLINE+/- or Left/right Handrail Button.
When the program enter next section will come back to the default date. And you can press ‘STOP’
or take out the safety key to stop the machine whenever.

10
At the end of the program mode the treadmill will flash with 15 beeps, after which
all data will be cleared to 0 and come into standby status.
4. HEART BEAT TEST:
When holding the hand pulse by two hands, the pulse window will show your heart beat after 5
seconds. In order to get the heart beat more correct, please test when the machine stop, and
holding the hand pulse more than 30 seconds. The heart beat data is just for reference, can not be
as the medical data.
5. BODY FAT TEST
When the treadmill standby, press ‘ PROGRAM’ button till ‘ FAT’ show in the window. ‘FAT’ is body
fat test mode. Press ‘ MODE’ to choose parameter ‘ SEX / AGE / HEIGHT / WEIGHT’, The middle
window will show “M/F”, “WEIGHT”, “HEIGHT”, “AGE". When set each parameter, press
SPEED+/-(INCLINE+/-) to adjust the data, press ‘MODE’ button to finish, the middle window will
show “---” enter into ready to go condition. Hold the handle pulse with two hands, it will show your
BMI data after 5 seconds.
5.1 Data display and set range
5.2 BMI reference
6.SLEEP FUNCTION:
Stopped for more than 10 minutes without any operation, the system completed all showed off
into the body of sleep state. Press any key to wake up.
Parameter
Type
default Setting range mark
SEX
（
M/F
）
0
（
MALE
）
0—1
0= MALE 1= FEMALE
AGE
25
10—99
HEIGHT
170 CM
100—240 CM
WEIGHT
70KG
20—160KG
（
BMI
）
<19
Under weight
19--26 Normal weight
26--30
Over weigh
>30 Obesity

11
7.SAFETY LOCK FUNCTION:
Pull out the safety pulling rope, then the treadmill will stop immediately. The middle window
display“OFF”. All normal operation must under safety key locked condition.
8. USER DEFINED PROGRAM
There are three program U1, U2, U3 for user defined.
Press “PROGRAM” continuously under standby mode until window display U1-U3,press “MODE”
to start setting first segment, setup speed and incline by pressing ‘SPEED + -’、’ SPEED
（6,10）’、’’INCLINE + -’’、’’INCLINE（3,5）’’, .press “MODE” finish first segment setting and
enter second one, until finish all 16 segments. The data will be permanently saved until user reset
next time.
The U1 is usually with default speed 1KM/H, incline 0. The U2 is usually with default speed 2KM/H,
incline 0. The U3 is usually with default speed 3KM/H, incline 0.
9. RUNNING DATA DISPLAY AND SETTING RANGE
10. PROGRAM TABLE
TIME
PROGRAM
Setting time/16= interval running time
1 2 3 4 5 6 7 8 9
1
0
1
1
1
2
1
3
1
4
15 16
P01
SPEED
2
3
3
4
4
5
5
3
4
5
4
4
3
3
5
3
INCLINE
1
1
2
2
3
3
2
2
1
2
2
1
3
2
2
2
P02
SPEED
2
4
4
5
6
6
6
4
5
6
4
4
2
5
4
2
INCLINE
1
2
2
2
3
2
2
2
2
2
3
3
4
3
2
2
P03
SPEED
2
4
4
6
7
7
7
4
7
7
4
4
4
5
3
2
INCLINE
2
3
3
2
3
3
2
2
2
2
4
4
6
3
2
2
P04
SPEED
3
5
5
6
5
7
7
8
8
5
9
5
6
4
4
3
INCLINE
2
3
3
2
3
3
2
2
2
2
4
4
6
3
2
2
P05
SPEED
2
4
4
5
7
5
6
7
8
8
5
4
6
5
4
2
INCLINE
3
3
3
4
5
5
4
4
4
4
5
5
3
2
2
2
P06
SPEED
2
4
4
4
8
8
6
7
8
8
6
4
5
4
3
2
INCLINE
3
5
5
5
4
3
3
3
3
4
4
4
3
4
3
2
P07
SPEED
2333345345336533
RANGE
DISPLAY
MODE
DEFAULT
PROGRAM
DEFAULT
SETTING
DEFAULT
SPEED 1-16 -------- -------- 1-16KM
INCLINE
0-15%
0—15%
TIME
0:00—99:59
30:00
30:00
5:00---99:00
DISTANCE 0.00KM—99.99KM 1.00KM -------- 1.0KM—99.9KM
CALORIES
0Kcl—999Kcl
50Kcl
--------
10Kcl—990Kcl

12
INCLINE
4444666778896544
P08
SPEED
2
3
3
6
4
6
7
4
6
7
4
4
3
4
4
2
INCLINE
4
5
5
5
6
7
8
9
9
9
10
10
12
8
6
3
P09
SPEED
2
4
4
7
7
8
4
8
9
9
4
4
6
3
3
2
INCLINE
5
5
5
6
4
4
6
6
5
5
8
8
9
7
4
2
P10
SPEED
2
4
5
6
4
6
8
8
6
6
5
4
4
4
3
3
INCLINE
5
6
6
6
8
8
4
4
4
5
5
8
10
8
6
3
P11
SPEED
2
5
8
10
10
10
7
7
10
10
5
5
5
5
4
3
INCLINE
4
5
3
2
2
2
2
2
2
4
5
6
5
5
2
0
P12
SPEED
3
4
9
9
5
8
5
9
7
5
5
7
5
7
6
3
INCLINE
1
2
3
2
5
0
0
2
3
5
7
3
6
5
3
3
P13
SPEED
3 6 7 5 7 5 5 7 9 5 8 5 9 9 4 3
INCLINE
3 3 5 6 3 7 5 3 2 0 0 5 2 3 2 1
P14
SPEED
2
2
4
5
4
3
2
1
2
3
4
5
4
3
2
1
INCLINE
4
4
4
4
6
6
6
7
7
8
8
9
6
5
4
4
P15
SPEED
2
4
6
8
4
4
2
2
2
4
6
8
4
4
2
2
INCLINE
3
3
3
4
5
5
4
4
4
4
5
5
3
2
2
2
EXERCISE INSTRUCTIONS
Warm up stage：
If you are over 35 years old, or not very healthy, also it’s your first time exercise, please consult
with your doctor or professional person.
Before you use the motorized treadmill, please learn how to control the machine, know well how to
start, stop, adjust the speed and so on, don’t stand on the machine at this time. After that, you can
use the machine. Stand on anti-slip pad both sides and handle the handle bar with your both hands.
Keep the machine at the low speed about 1.6~3.2 km/h, then test the running machine by one foot,
after get used to the speed, then you can run on the machine and you can add the speed between
3 and 5 km/h. Keep the speed about 10 minutes, then stop the machine.
Exercise stage：
Learn how to adjust the speed and incline before using. Walk about 1 km at stable velocity and
write down the time, it will take you about 15-25 minutes. If walk at 4.8 km/h, it will take you about
12 minutes in 1 km. If you feel comfortable at the stable velocity, you can add the speed and incline,
after 30 minutes, you can have good exercise. At this stage, you can not add the speed or incline
too much at one time, it can keep you feel comfortable.
Exercise intensity：
Warm up at the speed 4.8 km/h in 2 minutes, then add the speed to 5.3 km/h and keep walking in
2 minutes, then add to 5.8km/h and walk in 2 minutes. After that, add up 0.3 km/h in each 2 minutes,
until rapid breath but not feel comfortable
Calorie burning---the best effective way
Warm-up for 5mints by the velocity:4-4.8KM/H, then slowly increase the speed by

13
0.3KM/H/2Mints ,until up to the stable speed which you feel is comfortable for 45Mints.For
improving the intensity of movement, you can maintain the speed during 1H of TV program, then
increase the speed by 0.3KM/H each Advertisement interval time, after that return to the original
speed . You can acquaint the best efficiency of workout for calorie burning during the advertisement
time and subsequent heart frequency increasing time. Finally , you should slow down the speed
step by step for 4Mints.
Exercise frequency：
The cycle time: 3-5times/Week, 15-60mints/Times.Make up the schedule of workout scientific, not
only for your hobby.
You can control the running intensity through adjusting the velocity and incline of treadmill. We
suggest that you don’t set the incline at first; improve the incline is the effective way to strengthen
the exercise’s intensity.
Consult with your physician or health professional before starting your workout. The professional
people can help you make up the suitable exercise time-chart according to your age and health
condition, determine the velocity of movement, the intensity of exercise. Please stop at once, If
you feel chest tightness, chest pain, irregular heart beat, breath difficulty, dizziness or other
discomfort during exercise. You should consult with your physician or health professional as keep
going.
You can choose the normal walking speed or the jogging speed ,if you always take workout with
treadmill.
Speed 1-3.0KM/H not well physical
Speed 3.0-4.5KM/H less movement and workout
Speed 4.5-6.0KM/H normal walking
Speed 6.0-7.5KM/H Fast walking
Speed 7.5-9.0KM/H Jogging
Speed 9.0-12.0KM/H intermediate speed walking
Speed 12.0-14.5M/H well experiences of running
Speed 14.5-16.0KM/H excellent runner
Attention: The velocity of movement ≤6KM/H , the normal walking; The velocity of movement
≥8.0KM/H ,the good runner.

14
WARM UP INSTRUCTION
Before exercise, it is better to do stretching
exercises . Warm muscles stretch more easily, so
the first of 5 ~ 10 minutes to warm up. Then in
accordance with the following methods to stop
and do stretching exercises - do five times, each
leg every time 10 seconds or more time to do it
again after the end of the exercise.
1. Down the stretch: knees slightly curved, the
body bent forward slowly, so that the back and
shoulders relaxed, hands try to touch your toes.
Maintain 10 to 15 seconds, then relax. Repeat
three times to do (see Figure l).
2. Hamstring stretch: sitting on the clean seat, put
one leg straight. Inward close to the other leg to
make it close to the inside leg straight. hand try to
touch the toes. Maintain 10 to 15 seconds, then
relax. Repeat for each leg do three times (see
Figure 2).
3. Legs and feet tendon stretch: two on the Rotary
wall or tree stand, one foot in the post. Keep legs
straight and heel to tilt the direction of the wall or
tree. Maintain 10 to 15 seconds, then relax.
Repeat for each leg do three times
(see Figure 3).
4 .Quadriceps stretch: the left hand wall or table
to master balance, and then stretched his right
hand back to seize the right foot to the buttocks
with slowly pull until you feel the front thigh
muscles tense. Maintain 10 to 15 seconds, then
relax. Repeat for each leg to do three times (see
Figure 4).
5. Sartorius muscle (inner thigh muscles) stretch: Foot In contrast, the knee outward to sit down.
The hands grasp the feet to the groin pull. Maintain 10 to 15 seconds, then relax. Repeat three
times(see Figure 5).

15
RUNNING BELT ADJUSTMENT
Warning: ALWAYS UNPLUG THE TREADMILL FROM THE ELECTRICAL OUTLET BEFORE CLEANING OR
SERVICING THE UNIT.
Clean: General cleaning or the unit will greatly prolong the treadmill.
Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking
belt and also the side rails. This reduces the build up of foreign material underneath the walking belt by wearing the
clean running shoes.
Warning: Always unplug the treadmill from the electrical outlet before removing the motor cover. At
least once a year remove the motor cover and vacuum under the motor cover.
RUNNING BELT AND DECK LUBRICATION
This treadmill is equipped with a pre-lubricated, low maintenance deck system. The belt/ deck friction may
play a major role in the function and life of your treadmill, thus requiring periodic lubrication. We recommend a
periodic inspection of the deck. You need contact with our service center if you find the damage of the deck.
We recommend lubrication of the deck according to the following timetable:
Light user (less than 3 hours/ week) annually
Medium user (3-5 hours/ week) every six months
Heavy user (more than 5 hours/ week) every three months
We recommend that you buy the lubrication from our distributor or directly to our company.
Attention: Any repair need the professional technician.

16
CENTER THE RUNNING BELT
1. We suggest that you should cut off the power for 10Mints after keep running 2HS ,so that it’s
good for maintain the treadmill.
2. For avoiding the slipping during running , the belt not too loose; for avoiding the more abrasion
between the roller and belt and maintain the machine’s good running ,the belt not too tight. You
can adjust the distance between plates and belt , the belt be away from the plates about 50-
75mm on both sides ,if the best not too tight and loose.
●Place treadmill on a level surface. Run
Treadmill at approximately 6-8KM/H, checking
the running condition.
If the belt has drifted to the right, pull out of the
save clock and switch, turn the right adjusting
bolt 1/4 turn clockwise, then start running until
centering the belt. PIC A
If the belt has drifted to the left ,pull out of the
safety clock and switch, turn the left adjusting
bolt 1/4 turn clockwise ,then start running until
centering the belt .PIC B
Timely adjust the tightness of the belt ,for the
looseness after a period of time running. Pull
out of the safety clock and switch , turn the left
and right adjusting bolt 1/4 turn clockwise ,then
re-start running, confirm the belt-tightness until
the belt be right tightness. PIC C

17
Exploded Parts Diagram

18
Part list
NO. DESCRIPTION SPECS. QTY NO. DESCRIPTION SPECS. QTY
1
Main frame
1
44
Safety key
1
2 Base frame 1 45 5#Allen wrench 5 mm 1
3 Left upright tube
1
1
46 Silicone oil 1
4 Right upright tube 1 47 Wrench with screw driver S=13、14、15 1
5 Computer bracket 1 48 Magnetic ring 2
6 Incline bracket 1 49 Brown single wire 1
7
Running board
1
50
Bolt
M8*16
12
8
Running belt
1
51
Lock washer
8
14
9 Front roller 1 52 Bolt M8*25 3
10 Rear roller 1 53 Bolt M8*42 1
11 Cylinder 1 54 Bolt M8*40 4
12
DC motor
1
55
Bolt
M8*45
2
13
Control board
1
56
Bolt
M10*55
2
14
Overload protector
1
57
Lock washer
10
6
15 Switch 1 58 Bolt M6*55 1
16 Power wire 1 59 Bolt M6*65 2
17 Computer bottom wire 1 60 Lock washer 6 3
18
Ring protect wire B
2
61
Bolt
M6*30
4
19 Computer top wire 1 62 Bolt M6*37 4
20 Side rail 2 63 Lock nut M6 8
21 Right back end cap 1 64 Lock nut M8 6
22 Left back end cap 1 65 Lock washer C level 8 2
23
Wheel
2
66
Standard spring washer
8
2
24
Display board
1
67
Screw
ST 4.2*19
2
25
Running board strengthen
tube
2 68 Screw ST 4.2*25 4
26 Strengthen tube cushion 4 69 Screw ST 4.2*12 18
27
Distance sleeve
8
70
Screw
ST 4.2*19
4
28 Cushion 4 71 Screw ST 4.2*13 4
29 Power wire buckle 1 72 Screw ST 4.2*45 2
30
Barb cushion


Barb cushion


Barb cushion

2 73 Screw ST 4.2*25 4
31 Isolation nylon pad 4 74 Screw ST 4.2*40 2
32 Moving wheel 2 75 Bolt M5*8 1
33 Foot pad 4 76 Standard spring washer 5 1
34 Left base cover
1
77
Lock washer 5 1
35 Right base cover 1 78 Display panel cover 1
36 Motor top cover 1 79 Computer leather sticker 1
37 Motor bottom cover 1 80 Computer Acrylic sticker 1
38
Computer top cover
1
81
Motor belt
1
39 Computer bottom cover 1 82 Incline motor 1
40 Inclined tube plug 2 83 Lock nut M10 6
41 Foam 2 84 Bolt M10*45 4
42
Speed +/-
1
85
Inductor
1
43
Incline +/-
1
86
Filter
1

19
TROUBLE SHOOTING GUIDE
CODE REASON SOLUTION
E01
1.message wire is broken or not
connected well
1
．
Check if the computer and bottom control
board wire connect well;
2．Check if IC on bottom control board is
loosen, reset the IC
E02
1. Burst clash
1. Check if the power voltage is 50% lower
than the normal voltage, please us
e the
normal voltage to test;
2.
check if the control board is burnt with
irregular smell, replace a control board;
3. Check if the motor wire is well connected,
reconnect it.
E03
no sensor signal
1. Check if the signal light on control board is
light on, if the signal light is burnt out, change
a signal light.
2.
Check if the plug of sensor is well
connected
3. Check if the magnetic sensor is broken or
well connected, reconnect it or replace a
magnetic sensor.
E05
Current overload protecting
1. Over rated loaded or the motor is stuck,
cause excessive current, machine will start
self-
protecting system. Adjust the machine
and restart;
2. Check if the motor has noise from motor or
if the motor / bottom control board were burnt
out, if burnt out, change motor and bottom
control;
3. Check if the power voltage is wrong, use
right voltage to test again.
Show ”----”
1. The safety key is not at the
appointed site
2. The safety key is not connected
well or broken
1. Check if the safety key is at the appointed
site.
2. Check if the safety key s
ensor board is
connected well
3. Replace the safety key sensor board inside
computer
If the motor doesn’t rotate after press “START” button. The wire that control the motor might have
something wrong. Such as the protective tube on control board is damaged or fall off,. Or the motor
wire isn’t connected well.Or the IGBT on control board is burnt out Check if the motor wire is
connected well and re-connect well.Check if the protective tube is OK, re-set it or change one. Use
multimeter to test if the IGBT is burnt out,and change an IGBT or control board.
E07/E08
EEPROM damaged
Change a control board

Read all instruction carefully before use
this product.Retain thisowner’smanual
for the future’sreference
!
UPUTSTVO ZA UPOTREBU / SRB
TRAKA ZA TRČANJE SA MOTOROM
MODEL: RX144
