Ringway PDP300 User manual

1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings,install in accordance with the manufacturer s instructions.
8) Do not install near any heat sources such as radiators, heat registers,stoves,or other apparatus (including am
plifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug.A polarized plug hase two blades
with one wider than the other.A grounding type plug has two blades and a third grounding prong.The wide blade
or the third prong are provided for your safety,if the provided plug does not fit into your outlet.consult an elec
trician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs.convenience receptacles,and
the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the cart,stand,tripod,bracket,or table specified by the manufacturer,or sold with the
apparatus.When a cart is used,use caution when moving the cart/apparatus combination to avoid injury from
tip-over (Figure 1).
13) Unplug this apparatus during lightning storms or when unused for a long periods fo time.
14) Refer all servicing to qualified service personnel.Servicing is required when the apparatus has been dam
aged in any way,such as power-supply cord or plug is damaged,liquid has been spilled or objects have fallen
into the apparatus,the apparatus has been exposed to rain or moisture,does not operate normally,or has been
dropped.
WARNING:To reduce the risk of fire or electric shock,do not expose this apparatus to rain or
moisture.
CAUTION:Apparatus shall not be exposed to dripping or splashing and no objects filled with
liquids,such as vases,shall be placed on the apparatus.
(Figure 1)
Thank you for purchasing this digital instrument.For perfect operation andsecurity,please
read the manual carefully and keep it for future reference.
Precaution
Safety Precautions
Important Safety Instructions
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
The lightning flash with arrowhead symbol within an equilateral triangle is in
tended to alert the user to the presence of uninsulated dangerous voltage
within the product s enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance(servicing) instructions in
the literature accompanying the product.

Your digital piano is a high-quality digital piano with 88 standard touch
sensitivity keyboard and combines the most advanced PCM tone generation
technology. Your instrument has 137 voices, and 109 accompaniment
styles.The record function real time to playback the play which you
recorded.In order to obtain maximum performance and enjoyment, please
read this manual thoroughly while trying out the various features described.
Thanks for using our digital piano
DIGITAL PIANO

2
4
4
4
4
4
4
5
5
5
6
6
6
7
8
8
9
9
10
13
14
14
15
17
18
19
19
20
21
22
23
24
Contents
Panel Control
Play the Piano
1.Turn on the Power
2.Demo
3.Set the Volume
4.Using Headphone
5.Using External Sound System
6.Midi Connection
7.The Pedals
8.Select Voice
9.Touch Effect
10.One Touch Setting
11.Select Dual Voice Mode
12.Select Split Mode
13.Reverb
14.Chorus
Auto Accompaniment
1.Selecting Style
2.Auto Accompaniment Chord
3.Kb.Vol
4.Tempo/Tap Control
5.The Metronome
6.Accompaniment Control
Registration Memory
Recording Functions
Appendix
1.Voice List
2.Style List
3.Percussion List
4.Midi Implementation Chart
5.Specifications
6.Assembly Instructions
..........................................................................
..........................................................................
..........................................................
................................................................................
.................................................................
............................................................
......................................
.............................................................
........................................................................
......................................................................
.....................................................................
.........................................................
...............................................
...........................................................
.............................................................................
.............................................................................
.............................................................
.................................................................
.........................................
.............................................................................
.........................................................
................................................................
................................................
.............................................................
.............................................................
.................................................................................
...........................................................................
...........................................................................
............................................
..................................................................
4
1
DIGITAL PIANO
.................................................................
.....................................................

MIDI OUT PEDAL LINE OUT
MIDI IN LINE IN PHONE DC 12V
Rear Panel
Top Panel
2216 17
18 19 20
3
4
56
77
8
99
1010
1111
1212
1515
1414
1313
Panel Control
MULTI DISPLAY
MASTER VOLUME
RECORD PLAY REVERB CHORUS DEMO
ACCOMP
TRACK-1
RIGHT
TRACK-2
LEFT TRACK-3 TRACK-4
VOICE/STYLE
12345
67890
DUAL TOUCH TRANS. MODE
KB.VOL TEMPO/TAP METRON O.T.S
D A T A
K.MODE
OVERALL
STORE M1 M2 M3 M4
SYNC START/STOP
INTRO/ENDING FILLIN ACC.VOL
MEMORY
ACCOMPANIMENT CONTROL
POWER
ON
OFF
41 VIOLIN 42 VIOLA 43 CELLO 44 CONTRABASS 45 TREMOLO STRINGS 46 PIZZICATOSTRINGS 47 ORCHESTRAL HARP 48 TIMPANI 49 STRINGS ENSEMBLE 1 50 STRINGS ENSEMBLE 2 51 SYNTH STRINGS1 52 SYNTH STRINGS 2 53 CHOIR AAHS 54 VOICE OoHS 55 SYNTH VOICE 56 ORCHESTRA HIT 57 TRUMPET 58 TROMBONE 59 TUBA 60 MUTED TRUMPET
61 FRENCH HORN 62 BRASS SECTION 63 SYNTH BRASS 1 64 SYNTH BRASS 2 65 SOPRANO SAX 66 ALTOSAX 67 TENOR SAX 68 BARITONE SAX 69 OBOE 70 ENGLISH HORN 71 BASSOON 72 CLARINET 73 PICCOLO 74 FLUTE 75 RECORDER 76 PANFLUTE 77 BLOWN BOTTLE 78 SHAKUHACHI 79 WHISTLE 80 OCARINA
81 LEAD 1(SQUARE) 82 LEAD 2(SAWTOOH) 83 LEAD 3(CALLIOPE) 84 LEAD 4(CHIFF) 85 LEAD 5(CHARANG) 86 LEAD 6(VOICE) 87 LEAD 7(FIFTH) 88 LEAD 8(BASS+LEAD) 89 PAD1(NEWAGE) 90 PAD2(WARM) 91 PAD3(POLYSYNTH) 92 PAD4(CHOIR) 93 PAD5(BOWED) 94 PAD6(METALLIC) 95 PAD7(HALO) 96 PAD8(SWEEP) 97 FX 1(RAIN) 98 FX 2(SOUNDRACK) 99 FX 3(CRYSTAL) 100 FX 4(ATMOSPHERE)
101 FX 5(BRIGHTNESS) 102 FX 6(GOBLINS) 103 FX 7(ECHOES) 104 FX 8(SCI-FI) 105 SITAR 106 BANJO 107 SHAMISEN 108 KOTO 109 KALIMBA 110 BAGPIPE 111 FIDDLE 112 SHANAI 113 TINKLEBELL 114 AGOGO 115 STEELDRUMS 116 WOODBLOCK 117 TAIKODRUM 118 MELODICTOM 119 SYNTHDRUM 120 REVERSE CYMBAL
121 GUITAR FRETNOISE 122 BREATH NOISE 123 SEASHORE 124 BIRD TWEET 125 TELEPHONE RING 126 HELICOPTER 127 APPLAUSE 128 GUNSHOT 129 STANDARD 130 ROOM 131 POWER 132 ELECTRONIC 133 SYNTH 134 JAZZ 135 BRUSH 136 CLASSIC
40 SYNTH BASS 2 26 ACOUSTIC GUITAR(STEEL) 27 ELECTRIC GUITAR(JAZZ) 28 ELECTRIC GUITAR(CLEAN) 29 ELECTRIC GUITAR(MUTED) 30 OVERDRIVEN GUITAR 31 DISTORTION GUITAR 32 GUITARHARMONICS 33 ACOUSTIC BASS 34 FINGER BASS 35 PICK BASS 36 FRETLESS BASS 37 SLAP BASS 1 38 SLAP BASS 2 39 SYNTH BASS 1 21 REED ORGAN 22 ACCORDION 23 HARMONICA 24 TANGO ACCORDION 25 ACOUSTIC GUITAR(NYLON)
20 CHURCH ORGAN 14 XYLOPHONE 15 TUBULAR BELLS 16 DULCIMER 17 DRAWBAR ORGAN 18 PERCUSSIVE ORGAN 19 ROCK ORGAN 13 MARIMBA 01 ACOUSTIC GRAND PIANO 02 BRIGHT ACOUSTIC PIANO 03 ELECTRIC GRAND PIANO 04 HONKY-TONK PIANO 05 ELECTRIC PIANO 1 06 ELECTRIC PIANO 2 07 HARPSICHORD 08 CLAVI 09 CELESTA 10 GLOCKENSPIEL 11MUSIC BOX 12 VIBRAPHONE
VOICES
PCM PCM
STYLES
01 8BEATMODERN 02 MERSEYBEAT 03 SURF POP 04 8BEAT 05 60'SROCK 06 HEAVYROCK 07 ROCKSHUFFLE 08 80'SROCK 09 16BEAT1 10 16BEAT2 11POPSHUFFLE 12 GUITARPOP 13 JAZZROCK 14 SWING FUNK 15 POPROCK 16 PIANOBALLAD 17 LOVESONG 18 6/8MODERN 19 6/8SLOWROCK 20 SHOWBALLAD
39 NEWYORK DISCO 21 POPBALLAD 22 16BEATBALLAD 23 RAP (EMINEM) 24 DANCEPOP 25 HOUSE 26 SWINGHOUSE 27 CLUBDANCE 28 CLUBLATIN 29 GARAGE 30 TECHNO 31 DANCE 8BEAT 32 HIPHOP 33 CHILL OUT 34 70'SDISCO 35 LATINDISCO 36 DISCO 37 DISCOPARTY 38 DISCOFEVER 40 BIGBANDFAST
41 BIGBANDMID 42 BIGBANDBALLD 43 JAZZCLUB 44 SWING 45 JAZZBALLAD 46 DIXIELAND 47 RAGTIME 48 STRIDEPIANO 49 MODERN JAZZ 50 SOUL 51 DETROITPOP 52 RHYTHM&BLUES 53 6/8SOUL 54 TWIST 55 ROCK&ROLL 56 BOOGIEWOOGIE 57 6/8BLUES 58 3/4GOSPEL 59 GOSPELSHUFFLE 60 COUNTRY8BEAT
61 COUNTRYPOP 62 COUNTRYSWING 63 COUNTRY2STEP 64 COUNTRYBALLAD 65 BLUEGRASS 66 COUNTRY WALTZ 67 MERENGUE 68 BOSSANOVA 69 POPBOSSA 70 MAMBO 71 SALSA 72 BEGUINE 73 REGGAE 74 SWINGYREGGAE 75 DANCEBAND 76 ENGLISHWALTZ 77 FOXTROT 78 QUICKFOXTROT 79 QUICKSTEP 80 TANGO
84 CHACHA 85 JIVE 86 RHUMBA 87 VIENNESEWALTZ 88 2/4MARCH 89 6/8MARCH 90 2/4POLKA 81 HABENERA TANGO 82 PASODOBLE 83 SAMBA 1 91 6/8POLKA 92 TARANTELLA 93 SIRTAKI 94 SCOTTISHREEL 95 HAWAIIAN 96 MARIACHI 97 SWINGWALTZ 98 JAZZWALTZ 99 WALTZ 100 FRENCHWZ
NUMBER
MIN MAX
137 EFFECT
101 LEVADA
102 PAGODE
103 RASTA PE
104 SAMBA 2
105 SAMBA 3
106 SAMBA REGGAE
107 VANEIRAO
108 XOTE 1
109 XOTE 2
G.PIANO VIBRAPHONE C.ORGAN ACCORDION STRINGS1
E.PIANO MARIMBA P.ORGAN GUITAR STRINGS2
VIOLIN CHOIRAAHS BRASS FLUTE CLARINET
CELLO ORCHESTRA HIT TRUMPET SAXOPHONE DRUMS
MULTI DISPLAY
MASTER VOLUME
RECORD PLAY REVERB CHORUS DEMO
ACCOMP
TRACK-1
RIGHT
TRACK-2
LEFT TRACK-3 TRACK-4
VOICE/STYLE
12345
67890
DUAL TOUCH TRANS. MODE
KB.VOL TEMPO/TAP METRON O.T.S
D A T A
K.MODE
OVERALL
STORE M1 M2 M3
M4
SYNC START/STOP
INTRO/ENDING FILLIN ACC.VOL
MEMORY
ACCOMPANIMENT CONTROL
NUMBER
MIN MAX
G.PIANO VIBRAPHONE C.ORGAN ACCORDION STRINGS1
E.PIANO MARIMBA P.ORGAN GUITAR STRINGS2
VIOLIN CHOIR AAHS BRASS FLUTE CLARINET
CELLO ORCHESTRA HIT
TRUMPET SAXOPHONE DRUMS
4
2
DIGITAL PIANO
1
21 22

Top Panel Controls
1. Power Button
2. Multi Display
3. Master Volume Control
4. Control
Sync Button
Start/Stop Button
Intro/Ending Button
Fill In Button
Acc.Vol Button
5. Memory Control
Store Button
M1-M4 Button
6.K.Mode Control
Dual Button
Touch Button
Trans. Button
Mode Button
7.Overall Control
Kb.Vol Button
Tempo/Tap Button
Metron Button
O.T.S Button
8. Data Buttons
9. Voice/Style Button
10.Number Button
11.Voice Control
12.Accompent Control
Accomp Button
Track-1(Right) Button
Track-2(Left) Button
Track-3 Button
Track-4 Button
13.Record Button
14.Play Button
15.Reverb Button
16.Chorus Button
17.Demo Button
Rear Panel Control
18.Midi In Jack/Midi Out Jack
19.Pedal Jack
20.Line Out Jack/Line In Jack
21.Phone Jacks
22.DC 12V jack
4
3
DIGITAL PIANO

1.Turn on the Power
Turn on the power by pressing the POWER switch before playing. The pannel LCD
will light.
Play the Piano
ON
OFF
POWER MULTI DISPLAY
2.Demo
The digital piano has 10 demo songs, press [DEMO] to start. LCD shows: Demo 1 .
All demonstrations will be played in sequence repeatedly. You can select one of the
demonstration by using [+/-] buttons.
CHORUS DEMO
TRACK-3 TRACK-4
MASTER VOLUMEMASTER VOLUME
MINMIN MAXMAX
PHONES
3.Set the Volume
Initially set the MASTER VOLUME at the middle between the"MIN" and "MAX" .
You can adjust the volume to accommodate your playing.
4. Using Headphone
For private practicing and playing without disturbing others.
Connect a set of stereo headphones to the phones jack. Sound
from the built-in speaker system is automatically cut off
when you insert a headphone plug into this jack.
5. Using External Sound System
The Line Out jack can be used to deliver the output of the piano to a keyboard
amplifier, stereo sound system, mixing console or tape recorder and used the
Line In jack you can also play the piano through an external amplifier/speaker
system.
LINE OUT
Stereo
System
LINE IN
Stereo
System
4
4
DIGITAL PIANO

6. Midi Connections
The Midi IN connector receives the Midi data from an
external Midi device which can be used to control the
instrument. The Midi OUT connector transmits Midi
data generated by the instrument to other Midi devices.
MIDI IN MIDI OUT
7. The Pedals
A footswitch can be plugged into the rear-panel PEDAL jack. It is similar to real
piano function. The Sustain Pedal functions as a damper pedal controlling sustain.
Press the pedal to sustain notes after the keys are released.
8.Select Voice
When [voice/style] button is unlighted, You can press [0-9] buttons to select 20
voices as follows, press any of 0-9 buttons, side A voice is selected, then press the
same button again, side B voice is selected.
Press [number] button, the indicator is lighted, then you can use [0-9] buttons to
select 01-137 voices. When selecting voice 100-137 , holding the [1] button till
the 1_ is displayed, you can enter the tens and ones digits.
VOICE/STYLE
123
678
NUMBER
G.PIANO VIBRAPHONE C.ORGAN
E.PIANO MARIMBA P.ORGAN
VIOLIN CHOIR AAHS BRASS
CELLO ORCHESTRA HIT
TRUMPET
45
9 0
ACCORDION STRINGS1
GUITAR STRINGS2
FLUTE CLARINET
SAXOPHONE DRUMS
PEDAL
4
5
DIGITAL PIANO

9.Touch Effect
Press [TOUCH] button to turn touch sensitivity ON or OFF as required. When touch
sensitivity is ON. The sensitivity value [1-3] will appear on the Message Display
Area. You can select sensitivity value by [+] or [-] when value [1-3] are shown.
When touch is set to off, the same volume is produced no matter how strongly or
softly you play the keyboard. You can press [TOUCH] for few seconds. LCD will
show this volume value and you can adjust it by [+] or [-].
TOUCH TRANS.
11.Select Dual Voice Mode
Press [DUAL] button to select layer voice mode, two voices will sound simulta-
neously when you play keyboards.
Press [DUAL] button , use the number [0]-[9] or [+]/[-] to select the second voice.
DUAL TOUCH
10.One Touch Setting (O.TS)
Each style has its own panel settings to accommodate with. These settings can be
recall by press [O.T.S] button.
Press [O.T.S]button, turn ON/OFF the O.T.S mode.
TEMPO/TAP METRON O.T.S
TOUCH TRANS.
4
6
DIGITAL PIANO

.Select a Split Voice
Press [MODE] button until the Split function is turned on ,the split voice will
appear in the message display . Use [0-9] to select the left voice.
TRANS.
TRANS.
MODE
MODE
.Changing the Split Point
Select chord mode first use [mode] button, LCD shows C . Then Press
[MODE] button about 3 seconds later. You can play any keys to change the split
point.
12. Select Split Mode
Press [MODE] button to select split mode, S will appear on the MULTI DISPLAY.
Your keyboard will be split into two sections which means different voices can be
played with the left and right hands at the same time.
TRANS. MODE
4
7
DIGITAL PIANO

14. Chorus
Press [CHORUS] button to turn chorus effect ON or OFF as required. When chorus
effect is ON, it will make sound rich "fat" as if several parts are being played
simultaneously.
You can select chorus type by [+] or [-] when these type are shown in LCD.
You can also press [CHORUS] for few seconds, LCD will show chorus level.
You can adjust the level by [+]/ [-] or number keys.
REVERB CHORUS DEMO
13. Reverb
Press [REVERB] button to turn reverb effect ON or OFF as required. When reverb
effect is ON, it will make sound to produce warm ambience like hall or club depend
on the reverb type.
You can select reverb type by [+] or [-] when these type are shown in LCD.
You can also press [REVERB] for few seconds, LCD will show reverb level. you
can adjust the level by [+]/ [-] or number keys.
REVERB CHORUS DEMO
4
8
DIGITAL PIANO

Auto Accompaniment
Your instrument has 109 accompaniment styles which can be used to provide
fully-orchestrated Auto Accompaniment.
When the Auto Accompaniment function is turned ON, this instrument create
fully-orchestrated rhythm, bass and chord accompaniment base on chords you
play with the left hand in the Auto Accompaniment section of the keyboard
(i.e. all keys to the left of the Auto Accompaniment split point). The right-hand
section of the keyboard is available for normal playing.
The default Auto Accompaniment split
#
point is the F2 (34) key. The Auto
Accompaniment section of the keyboard
consists of all keys to its left .
Auto Accompaniment Normal
Left hand fingering
specifies the auto
accompaniment chords.
The right hand plays normally
Auto Accompaniment
1. Selecting a Style
Press [voice/style] button , the indicator is lighted, then you can use [+]/[-]or[0]-[9]
buttons to select 01-109 styles.
When selecting style 100-109, holding the [1] button till the 1- displayed,
then you can enter the tens and ones digits.(Reference:P20 Style List)
VOICE/STYLE
123
678
NUMBER
G.PIANO VIBRAPHONE C.ORGAN
E.PIANO MARIMBA P.ORGAN
VIOLIN CHOIR AAHS BRASS
CELLO ORCHESTRA HIT
TRUMPET
45
9 0
ACCORDION STRINGS1
GUITAR STRINGS2
FLUTE CLARINET
SAXOPHONE DRUMS
.Transpose
Transpose function make it possible to shift the pitch of this instrument up or down
in semitone intervals up to a maximum of 12 semitones.
Press [TRANS] button, use [+/-] keys to set the transpose value.
TOUCH TRANS. MODE
4
9
DIGITAL PIANO

.Changing the Chord Point
Press [MODE] button to select normal , then press [MODE] button about 3
seconds later, play any keys to change the chord point.
2. Auto Accompaniment Chord
Press [MODE] button to select chord mode. The letter C will appear on the
MULTIDISPLAY.
Turn on this mode. The specified left-hand section of the keyboard becomes the
Auto Accompaniment section, and chords played in this section are automatically
detected and used as a basis for fully automatic accompaniment with the selected style.
TRANS. MODE
TRANS. MODE
4
10
DIGITAL PIANO

.Single Mode
Single Mode fingering makes it simple to produce beautifully orchestrated
accompaniment using major , seventh , minor and minor-seventh chords by pressing
a minimum number of keys in the Auto Accompaniment section of the keyboard .
The accompaniment produced is perfectly matched to the currently selected
accompaniment style.
.Major Chords:
If you press a C key in the left-hand section of the
keyboard, for example, a C-major accompaniment will
be played. Press another key in the left hand section of
the keyboard to select a new chord. The key you press
will always determine the "root" of the chord played
(i.e. C for a C chord).
CC
CmCm
C7C7
Cm7Cm7
Minor Chords
Simultaneously press the root key and a black key
to its left.
Seventh Chords:
Simultaneously press the root key and a white key
to its left.
Minor-Seventh Chords:
Simultaneously press the root key and both a white and
black key to its left.
4
11
DIGITAL PIANO

C CM CM
CM CMadd CM
C Caug Cm
Cm6Cm7 Cm7
Cmadd9Cm9 Cm11
CmM7CmM9Cdim
Cdim7 C7C7sus4
C7 C C7
C7 C7 C7
CM7aug C7aug Csus4
C1+2+5
Example for c chords
67
9
7
7
9
B9 B13
69
B 5
11
11 13
#
#
# 9
The chord fingerings listed are all in root position, but other inversions can be use
with the following exceptions:6, m6, sus4, aug, dim7, 6(9), m7(11), 1+2+5.
.Fingered Mode
Fingered Mode is ideal if you already know how to play chords on a keyboard,
since it allows you to supply your own chords for the Auto Accompaniment feature.
The instrument will recognize the following chord type:
4
12
DIGITAL PIANO
Name
[M]
[6]
[M7]
[Madd9]
[M9]
[6 9]
[aug]
[m]
[m6]
[m7]
[m7b5]
[madd9]
[m9]
[m11]
[mM7]
[mM9]
[dim]
[dim7]
[7sus4]
[7 9]
[7 13]
[7b9]
[7b13]
[7#9]
[M7aug]
[7aug]
[sus4]
[1+2+5]
Normal Voicing
1-3-5
1-(3)-5-6
1-3-(5)-7or1-(3)-5-7
#
1-(2)-3-4- 5-7 or
#
1-2-3-4- (5)-7
1-2-3-5
1-2-3-(5)-7
1-2-3-(5)-6
Chord(C)
C
C6
CM7
CMadd9
CM9
C6 9
Caug
Cm
Cm6
Cm7
b
Cm7 5
Cmadd9
Cm9
Cm11
CmM7
CmM9
Cdim
Cdim7
C7sus4
C7 9
C7 13
b
C7 9
b
C7 13
#
C79
CM7aug
C7aug
Csus4
C1+2+5
Display
C
C6
CM7
C(9)
CM7(9)
C6(9)
Caug
Cm
Cm6
Cm7
b
Cm7 5
Cm(9)
Cm7(9)
Cm7(11)
CmM7
CmM7(9)
Cdim
Cdim7
C7sus4
C7(9)
C7(13)
b
C7( 9)
b
C7(13 )
#
C7(9)
CM7aug
C7aug
Csus4
C
#
1-3- 5
b
1- 3-5
b
1- 3-5-6
bb
1- 3-(5)- 7
bbb
1- 3- 5- 7
b
1-2- 3-5
bb
1-2- 3-(5)- 7
bb
1-(2)- 3-4-5-( 7)
b
1- 3-(5)-7
b
1-2- 3-(5)-7
bb
1- 3- 5
bb
1- 3- 5-6
b
1-3-(5)- 7 or
b
1-(3)-5- 7
b
1-4-(5)- 7
b
1-2-3-(5)- 7
#b
1-(2)- 3- 4-5- 7 or
#b
1-2-3- 4-(5)- 7
b
1-3-(5)-6- 7
bb
1- 2-3-(5)- 7
bb
1- 3-5- 6 - 7
#b
1- 2-3-(5)- 7
#
1-(3)- 5-7
#b
1-3- 5- 7
1-4-5
1-2-5
[M7#11] #
CM7 11 # CM7( 11)
[7]
[7#11] #
C7 11 # C7( 11)
C7 C7

3.Kb.Vol
This function can adjust three volume settings: main voice volume,split voice volume,
and dual voice volume.
Main voice volume(R): In normal mode, you can press [KB.Vol] button to select
R and use [+/-] buttons to adjust the whole keyboard volume.
Split voice volume (L): In split mode, you can press [KB.Vol] button to select
L or R and use [+/-] buttons to adjust left hand and right hand volume.
Dual voice volume: In dual voice mode, you can press [KB.Vol] button to select
D and use [+/-] buttons to adjust dual voice volume.
KB.VOL TEMPO/TAP METRON
.Twin
Press [MODE] button to select Twin , letter T will appear in LCD. In this
mode, the keyboard will be separated into two play areas.
Right: from C3 to C7 Left: from A2 to B6
TOUCH TRANS. MODE
4
13
DIGITAL PIANO
KB.VOL TEMPO/TAP METRON
KB.VOL TEMPO/TAP METRON
In Twin mode.You can press[KB.VOL]button to select R and use[+/-]buttons to
adjust keyboard volume.
KB.VOL TEMPO/TAP METRON

.Tap
This useful feature lets you tap out the tempo for a song or an accompaniment
style. Simply tap the [TEMPO/TAP] button at the desired speed, and the tempo of
the song or the accompaniment style changes to match your tapping.
When the auto-rhythm isn't playing, it will be start automatically after your tapping.
.Number Select
When you input value using number button, you can get 100 or 200 by keeping
to press [1] or [2] for few seconds.
KB.VOL TEMPO/TAP METRON
5. The Metronome Button
The metronome provides a click sound, giving you an accurate tempo guide when
you practise, letting you hear and check how a specific tempo sounds.
The metronome starts by pressing the [METRONOME] button. Adjust the metr-
onome beat type by [+] or [-] when the metronome type is shown in LCD. Beat
types include: 1/4,2/4,3/4,3/8,4/4,6/4,6/8,9/8. To stop the metronome, press the
[METRONOME] button again.
When the auto-rhythm or songs starts, you can also use metronome function. At
this moment, the metronome will run as the beat type and tempo of certain rhythm
or songs.
To adjust the metronome tempo, please see TEMPO.
KB.VOL TEMPO/TAP METRON
4
14
DIGITAL PIANO
4. Tempo/Tap Control
.Set the Tempo
Push [TEMPO/TAP],you can use the [+] and [-] buttons to set the desired tempo.
Also the LCD of [NUM] is flash, it indicate that you can input tempo value by
number button.
The available tempo range is from 20 to 280 beats per minute. Each accompani-
ment style has a different "default" tempo which is automatically set whenever a
new style is selected (but it not used "default" when a new style is selected while
the accompaniment is playing).

2).Synchro Start
Press the [SYN] button, then the accompaniment will start when you play the first
chord on the AUTO ACCOMPANIMENT section of the keyboard.
SYNC START/STOP
INTRO/ENDING FILLIN ACC.VOL
ACCOMPANIMENT CONTROL
3).Starting the Accompaniment with an Introduction
Any of your instrument accompaniment patterns can be started with an appropriate
introduction by pressing the [INTRO/ENDING] button directly.
If you press the [SYNC] button and then press the [INTRO/ENDING] button,
the accompaniment will start from the introduction as soon as a chord is detected
in the AUTO ACCOMPANIMENT section of the keyboard.
SYNC START/STOP
INTRO/ENDING FILLIN ACC.VOL
ACCOMPANIMENT CONTROL
4
15
DIGITAL PIANO
6. Accompaniment Control
1).Straight Start
The [START/STOP] button starts the selected accompaniment style immediately.
Selecting the CHORD mode before starting the accompaniment. The accompani-
ment will start with the rhythm sound only when the [START/STOP] button is
pressed, then the bass and chord parts will playing as soon as the first note or
chord is played on the Auto Accompaniment section of the keyboard.
A different accompaniment style can be selected at any time while the accompa-
niment is playing. SYNC START/STOP
INTRO/ENDING FILLIN ACC.VOL
ACCOMPANIMENT CONTROL

5).Stopping the Accompaniment
An accompaniment progress can be stopped immediately by pressing the
[START/STOP] button and also can be stopped with an appropriate ending
by pressing the [INTRO/ENDING] button.
SYNC START/STOP
INTRO/ENDING FILLIN ACC.VOL
ACCOMPANIMENT CONTROL
6). Accompaniment Volume
The [ACC.VOL] buttons can be used to adjust the volume of the selected accom-
paniment.
.Press the [ACC.VOL] buttons
Press the [ACC.VOL] buttons, The current accompaniment volume value will
appear on .
.Set the Volume
Use [+/-] buttons to set the desired volume. The volume range is from 0 (no
sound) to 31(Max volume). Default 28
SYNC START/STOP
INTRO/ENDING FILLIN ACC.VOL
ACCOMPANIMENT CONTROL
4
16
DIGITAL PIANO
4).Adding Fill-In
Press [FILL IN] button at any time while the accompaniment is playing to add a
one-measure fill-in.
If you press the [SYNC] button and then the [FILL IN] button, the accompaniment
will start from the fill-in as soon as a chord is detected in the AUTO
ACCOMPANIMENT section of the keyboard.
SYNC START/STOP
INTRO/ENDING FILLIN ACC.VOL
ACCOMPANIMENT CONTROL

Registration Memory
Your instrument registration memory can be used to store four sets of voice and
auto accompaniment settings that can be recalled during you playing at the touch
of one single button.
1. Memorizing the Settings
The panel settings listed above can be stored to any one of the 4 registration
memory buttons by pressing the [STORE] button, then press [M1] , [M2] , [M3]
or [M4] button, please note that anytime you store to a REGISTRATION MEMORY
button, all settings previously stored in that button will be erased and replaced by
the new settings.
STORE M1 M2
MEMORY
M3 M4
2. Recalling the Settings
The settings stored to a REGISTRATION MEMORY button can be recalled simply
by pressing the appropriate button. The stored status example: Voice, Style, Tempo,
Acc.vol, Mode and so on will be restore on the LCD.
STORE M1 M2
MEMORY
M3 M4
3. Reset the Settings
The factory setting can be reseted by pressing [+] and [-] buttons, when you turn
on the instrument. The user songs will be also deleted.
4
17
DIGITAL PIANO
