Ringway TB688 User manual

Precaution
Safety Precautions
Important Safety Instructions
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION
The lightning iconinside a triangleis intended toalert the userto the presence
of exposed dangerousvoltages within theproduct s enclosure, that could cause
electric shock.
The lightning iconinside a triangleis intended toalert the userto read important
operating and maintenance(servicing)instructions within theliterature accompanying
this product.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any ventilation openings, install in accordance with the manufacturer's instructions.
8) Do not near any heat sources such as radiators, heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9) Do not the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding type plug has two blades and a third grounding prong. The
wide blade or the third prong are provided for your safety, if the provided plug does not fit into your outlet.
consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched particularly at plugs, convenience receptacles,
and the point where they exit from the apparatus.
11) Only use attachments/accessories specified by the manufacturer.
12) Use only with the , stand, tripod, bracket, or table specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when moving the cart/apparatus combination to avoid injury
from (Figure 1).
13) Unplug this during lightning storms or when unused for a long periods fo time.
14) Refer all servicing to qualified service personnel. Servicing is required when the has been
damaged in any way, such as power-supply cord, or plug is damaged, liquid has been spilled or objects
have fallen into the , the has been exposed to rain or moisture, does not operate
normally, or has been dropped.
WARNING: To reduce the risk of fire or electric shock, do not expose this to rain or moisture.
CAUTION: E must not be exposed to or splashing and also no objects filled with
liquids, such as vases,
Always make sure all batteries are .
Always replace at the same time.
Remove the batteries from the instrument if it is not to be used for a long time.
place
bypass
trolley
tipping over
equipment
equipment
equipment equipment
equipment
quipment liquid dripping
or beverages may be placed.
all of the batteries
inserted the correct way around to match the +/- polarity markings
Do not combine old and new batteries, also do not mix battery
types, as this can cause overheating, or fire, or battery fluid leakage.
(Figure 1)
Thank you forpurchasing this digitalTB688. For perfect operation and security,
please read themanual carefully andkeep it for future reference.

Thanks For Using Our Electronic Keyboard
Your instrument is a high-quality electronic keyboard with 61 standard
touch sensitive keys, and which employs the most advanced PCM tone generation
technology, as well as a high quality DSP (Digital Signal Processor). It has 203
accompaniment styles which can be used to provide fully-orchestrated auto
accompaniment. The multi-functional LCD (Multi Display) provides easy to
understand information regarding your keyboard's various settings.
We recommend that you read through the manual carefully, so you can
get the best performance and maximum enjoyment from your new electronic
keyboard.

Contents
1
3
3
3
3
4
4
4
5
5
6
6
7
14
14
14
15
16
16
17
18
19
20
21
23
23
24
27
29
30
Panel Control
Basic Operation
Turn On the Power
Phones/Line Out Jack
Line In Jack
Pedal Jack
Mic Jack
USB To Host Jack
Adjust the Main Volume
Demo Songs
Play the Electronic Keyboard
Select a Voice
Overall Control
Auto Accompaniment
Selecting a Style
Turn Chord On/Off
Full keyboard
Accompaniment Control
Metronome
Overall Control
Registration Memory
Record and Play
Chord Dictionary
Teaching Function
Appendix
Percussion Voice List
Voice List
Style List
Troubleshooting Hints
Specifications

1.POWER[POWER ON/OFF]
2.MASTER VOLUME
3.[REVERB] Button
4.[CHORUS] Button
5.[APREG.] Button
6.[TRANS./TUNE] Button
7.[TEMPO/TAP] Button
8.[MIXER] Button
9.ACCOMPANMENT CONTROL
[SYNCHRO] Button
[START/STOP] Button
[INTRO/ENDING] Button
[FILL IN] Button
10. [KBD.MODE] Button
11. [PEDAL] Button
12. [TOUCH] Button
13. [O.T.S] Button
14. [GRAND PIANO] Button
15.REGESTRATION MEMORY
[STORE/BANK] Button
[M1]-[M4]Button
16.[METRONOME] Button
17.MULTI LCD DISPLAY
18. + - Buttons
0 - 9 Number Buttons
19.[VOICE/STYLE ]Button
20.[DUAL] Button
21.[DEMO/LEARN] Button
22.[RECORD] Button
23.[PLAY] Button
Rear Panel Controls
24.Pitch Bend
25.DC 12V In Jack
26.Phones/Line Out Jack
27.Line In Jack
28.Pedal Jack
29.Mic Jack
30.USB To Host
Top Panel Controls
Panel Controls
1

START/
STOP
INTRO/
ENDING FILL INSYNCHRO
ON OFF
POWER
TB688TB688
01-13 8Beat
14-26 16Beat
27-36 Ballad
37-51 Dance
52-61 Disco
62-76 Swing&Jazz
77-93 R&B
94-105 Country
106-123 Latin
124-156 Ballroom
157-178 Traditional
179-187 Waltz
188-192 Piano
193-203 Sino
129-154 Piano
155-171 Chromatic Perc.
172-193 Organ
194-213 Guitar
214-235 Bass
236-254 Strings
255-271 Ensemble
272-295 Brass
296-313 Reed
314-333 Pipe
334-344 Synth Lead
345-352 Synth Pad
353-363 Synth Effects
364-375 Ethnic
376-399 Percussive
400-448 Sound Effects
449-467 Ethnic
468-479 Percussive
01-08 Piano
09-16 Chromatic Perc.
17-24 Organ
25-32 Guitar
33-40 Bass
41-48 Strings
49-56 Ensemble
57-64 Brass
65-72 Reed
73-80 Pipe
81-88 Synth Lead
89-96 Synth Pad
97-104 Synth Effects
105-112 Ethnic
113-120 Percussive
121-128 Sound Effects
RECORD PLAY
VOICE/STYLE
DUAL
TRANS./
TUNE
TEMPO/
TAP
STORE/
BANK
M1 M2 M3 M4
DEMO/LEARN
GRAND PIANO METRONOME
CHROUS
ARPEG.
VOICEVOICE
STYLESTYLE
REVERB
MIXER
MIN MAX
MAIN VOLUME
GM Voice XM Voice
1 2 3
4 5 6
7 8 9
- 0 +
4
3
24
25 26 27 28 29
PITCH BEND
30
1 2 3
4 5 6
7 8 9
- 0 +
4
3
START/
STOP
INTRO/
ENDING FILL INSYNCHRO
ON OFF
POWER
TB688TB688 RECORD PLAY
VOICE/STYLE
DUAL
TRANS./
TUNE
TEMPO/
TAP
STORE/
BANK
M1 M2 M3 M4
DEMO/LEARN
GRAND PIANO METRONOME
CHROUS
ARPEG.
REVERB
MIXER
MIN MAX
MAIN VOLUME
LINE IN PEDAL MIC USB TO HOST
PHONES/
LINE OUT
DC 12V
Panel Controls
2
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE VOICE DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE VOICE DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
KBD.MODE
KBD.MODE

Basic Operation
Turn On the Power
1. Ensure the keyboard is turned off when connecting
and disconnecting the power, and turn the volume switch
to reach the minimum level.
2. Connect the adaptor into the AC wall outlet and the cord into the unit,
then turn the power on.
NOTE:
When the keyboard is not in use or in the time of thunderstorm, please disconnect the
power for safety purpose.
PHONES/LINE OUT
Plug a set of stereo headphone into the [PHONES/LINE OUT] jack, and the internal
speaker system is automatically shut off when the headphone is plugged.
The [PHONES/LINE OUT] jack can be used to deliver the output of the piano to a
keyboard amplifier, stereo sound system, mixing console or tape recorder.
Phones/Line Out jack
Line In jack
The audio output from other sound system connected to the LINE IN jack on the rear
panel can be mixed with the sound of the unit. This function is convenient when you want
to play along with a favourite song.
3

Line In
Stereo
System
PEDALPEDAL
A foot switch can be plugged into the rear-panel [PEDAL] jack. The Pedal is a damper
pedal controlling sustain function. Press the pedal you can sustain the notes after the keys
are released.
Pedal Jack
MIC
A Micphone can be plugged into the rear-pannel [MIC] jack .
Mic Jack
USB To Host Jack
Connect PC or other USB to host devices that support USB audio with a standard
USB cable. For devices with USB cable, after the driver is installed and initialization
is finished, you can choose USB audio device in the device menu of the software to
transfer midi data.
USB TO HOST
Basic Operation
4

There are 5 preset demo songs and 100 learning songs that you can play individually.
Here's how you can select and play the demo songs .
1. Press [DEMO/LEARN] button and the LCD display :
play the demo songs in sequence.
d0 .Then your instrument
will
Demo Songs
MAIN VOLUME
MIN MAX
Adjust the Main Volume
Use [MAIN VOLUME] control to adjust the volume to
your desired level.
2. Use the [+] [-] button or number button to select a demo song. Press the [TEMPO/TAP]
button and then press [+] [-] button to change the tempo.
3.Press [DEMO/LEARN] button again to stop playing.
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
KBD.MODE
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
RECORD PLAY
DEMO/LEARN
Basic Operation
5

Play the Electronic Keyboard
Your instrument has 479 voices that you can select and play.
Select a Voice
. Press the [VOICE/STYLE] button to let the cursor point to "VOICE". The voice number
will appear on the LCD display.
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
.Select a Main Voice Number
VOICE/STYLE
DUAL
.Select a Split Voice Number
Use the [+] / [-] buttons or the number buttons to select the required voice number
(01-479). Press the [+] button briefly to increment the value, or the [-] button to decrement. If
you hold the [+] or [-] button down , the value will increment or decrement continuously -
simply release the button when the desired value has been reached.
In Voice Mode the main voice number will appear on the LCD.
1~9 voice: press 01~09.
10~99 voice: press 10~99.
100~479 voice: hold the [1] button till the LCD displays: 1_ _ , then enter the tens digit
and single digits.
Your keyboard can be split into two sections which means different voices can be played
with the left and right hands at the same time.
Press [KBD.MODE] button so that the cursor points to SPLIT to turn Split mode
ON. The split voice number will appear on the MULTI DISPLAY. Use the [+] and [-] buttons
or the number buttons to select the desired split voice number (01 through 479). There is a
horizontal line behind the 33 when the LCD display the voice of left hand area.
If you want to change the voice of right hand area, press the [VOICE/STYLE] button,
then the horizontal line will disappear, you can use the [+] and [-] buttons or the number
6
buttons to select desired voice and the LCD will display the number of the right hand area.

CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
VOICE/STYLE
DUAL
Pedal
Press [PEDAL] button to turn on/off the function. Press the [PEDAL] button and then
press the pedal ,the cursor will point to [PEDAL].
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
1.Multi-function pedal
This function allows you to set the function of the pedal plugged into the pedal jack
on the back board.
Your instrument has 7 different pedal functions. Press the [PEDAL] button. Then
use [+] and [-] buttons to select your desired pedal function among PE1-PE7 .
7
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
Overall Control
Play the Electronic Keyboard

2.Detail Instructions
Sustain Pedal (Switch-type Pedal)
If your pedal is a switch-type pedal, connect the pedal to your piano, then the pedal is
ready to use. The default pedal function is PE1 , sustainer pedal function.
.
PE1------ It performs the same function as the damper pedal on an actual acoustic
piano, letting you sustain the sound of the voices even after releasing your fingers from
the keys.
PE2------It performs the same function as the soft pedal on an actual acoustic piano,
the volume of the whole keyboard will decrease when you play the TB688 keys and
depress the soft pedal.
PE3------If you play a note or chord on the keyboard and press the sostenuto pedal
whilst the notes are held, those notes will be sustained as long as the pedal is held, but
all subsequently played notes will not be sustained.
PE4------You can change the volume of the keyboard by the pedal.
PE5------This function is the same as the [START/STOP] button on the front panel.
Switches the rhythm on/off whenever you press the Left Foot-switch.
PE6------This function is the same as the [FILL 1] button on the front panel. Let you
add dynamic variations and breaks in the rhythm of the accompaniment.
PE7------Anytime you store to a REGISTRATION MEMORY button, all settings
previously stored in that button will be erased and replaced by the new settings.
PEDAL
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
Note: If PE4 is selected while you are using the sustain pedal, the pedal can
only be used to turn on or off the keyboard volume.
8
Volume Pedal(AD-type Pedal)
If your pedal is a volume pedal, you have to preset it.
Press the [REVERB], [TRANSPOSE] and [POWER ] button at the same time to enter
the Pedal Setting Mode. Press the [+] (or [-]) button before stepping the pedal. Then step the
pedal and press the [-] (or [+]) button.
Then the LCD will show two values between 0 and 255. Press the button
to save your redefined parameters.
Note: If your instrument is restored, it will restore the current setting.
[STORE/BANK]
Play the Electronic Keyboard

POWER
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
KBD.MODE
STORE/BANK
PITCH BEND
The PITCH BEND wheel is located on the left side of your keyboard
that can be used to tune the pitch of the keyboard. Push the wheel upward,
the keyboard pitch will be increased and pull wheel downward will decreased
the keyboard pitch.
Push the wheel to the top position for about 2 seconds, LCD will display
the pitch range (pitch sensitivity). You can use the [+] and [-] or the number
[0]-[9] buttons or the digital dial to set the pitch sensitivity: 1~ 12 semitones.
When the power is turned ON, the preset sensitivity is +/- 2 semitones.
PITCH BEND
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
TRANS./
TUNE
REVERB
PEDAL
ON OFF
9
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH
Touch
Press [TOUCH] button, you can turn ON/OFF the touch function. When the Touch
function is ON, the volume will be varied according to how hard you play on the keyboard.
O.T.S
Play the Electronic Keyboard

KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
Trans/Tune
Hold down LCD will display the value of Reverb depth then
you can use [+]/[-] buttons or number button to set the value:00-63(default:18).
the [REVERB] button
Press the [REVERB] button and then use the [+][-]buttons to select the Reverb types
(10).
Reverb
Press the [Trans/Tune] button until the LCD display , it possible to shift the
pitch of this instrument up or down in semitone intervals up to a maximum of 12 semitones
( total one octave).
his function makes
it possible to tune the pitch of your instrument to match other instruments. Tune can be
accomplished over 50 cents range (that's 100 cents total, or one semitone) in 128
(-64~63) steps (approximately 0.8 cents per step).
Press the [Trans/Tune] button until the LCD display , t
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
TRANS./
TUNE
REVERB
TRANS./
TUNE
REVERB
10
Press the [CHORUS] button and then use the [+]/[-]buttons to select the Chorus
types (8).
the [CHORUS] buttonHold down LCD will display the value of Chorus depth,
then you can use [+]/[-] buttons or number button to set the value:00-63(default:18).
Chorus
Play the Electronic Keyboard

KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
Arpeggio
R
An Arpeggio, also called broken chord , is a group of notes played in sequence from
the lowest to the highest note or from the highest to the lowest note. It is a musical technique
usually used in practicing songs. An arpeggio may be a melody part of songs and may be
written with a squiggly vertical line in front of the chord. Arpeggio is divided into the Tonic
Triad, Diminished Seventh Chords and Dominant Seventh Chord.
Press the [ARPEGGIO] button and the LCD will show P1 , indicating the Arpeggio
function is enabled. When P1 is selected, hold one key or several keys and you will hear
the note played from the lowest to the highest. When P2 is selected, hold one key or
several keys and you will hear the note played from the highest to the lowest.
epeatedly press the [ARPEGGIO] button to turn off the Arpeggio function.
Mixer
This function can set Accompaniment Volume, Main Volume, Split Volume, Dual
Volume and Metronome Volume.
TEMPO/
TAP
CHORUS
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
MIXER
ARPEG.
11
Press the [MIXER] button repeatedly to select , then use
buttons to set the Accompaniment Volume. Range: 00~15. Default: 12
[+]/[-] buttons
or number
Accompaniment Volume
Play the Electronic Keyboard

KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
Dual Volume
Press the [MIXER] button repeatedly to select , then use
to set the Dual Volume. Range: 00~127. Default: 75.
[+]/[-] buttons
or number buttons
Press the [MIXER] button repeatedly to select , then use
to set the Split Volume. Range: 00~127. Default: 127.
[+]/[-] buttons
or number buttons
S. Volume
Press the [MIXER] button repeatedly to select , then use
to set the Main Volume. Range: 00~127. Default: 127.
[+]/[-] buttons
or number buttons
M. Volume
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
MIXER
ARPEG.
MIXER
ARPEG.
MIXER
ARPEG.
12
Play the Electronic Keyboard

Grand Piano
GRAND PIANO
Dual
Press the [GRAND PIANO] button. This convenient function allows you to instantly
call up the Grand Piano voice.
Metronome Volume
Press the [MIXER] button repeatedly to select , then use
to set the Metronome Volume. Range: 00~127. Default: 127.
[+]/[-] buttons
or number buttons
This function is capable of enhancing the delicacy of your music by playing two voices
of musical instruments simultaneously; new combinations of voices and music could be
created then.
Press [+]/[-] buttons or number button to select your desired voice.
Press [DUAL] button again to turn off the dual voice
When the cursor is stop flashing, you can select the main voices. .
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
MIXER
ARPEG.
VOICE/STYLE
DUAL
MIXERARPEG.
13
Play the Electronic Keyboard

Press the [VOICE/STYLE] button to let the Active Input Arrow point to string STYLE .
The style number will appear on the MULTI DISPLAY. You can use the [+] and [-] buttons
or the number buttons to select the required style number(00 through 203).
You can use [+]/[-] buttons or number buttons to select the desired style.
1~9 style: press 01~09.
10~99 style: press 10~99.
100~203 style: hold the [1] button till the LCD displays: 1_ , then enter the tens digit
and single digits.
The keyboard has a total of 203 accompaniment styles which can be used to provide
Fully-orchestrated Auto Accompaniment. When the Auto Accompaniment function is
turned on, , bass and chord accompaniment
Auto Accompaniment section of the
keyboard (i.e. all keys to the left of the Auto Accompaniment split point). The right-hand
section of the keyboard is available for normal playing.
The default Auto Accompaniment split point is the key. The Auto Accompaniment section
of the keyboard consists of all keys to its left.
this instrument creates fully-orchestrated rhythm
based on chord s that you play with the left hand, in the
F 2
Turn Chord On/Off
Press the [KBD.MODE] button repeatedly to select CHORD and its Active
Input Arrow lights. The specified left-hand section of the keyboard becomes the Auto
Accompaniment section,and chords played in this section are automatically detected
and used as a basis for fully automatic accompaniment with the selected style.
Auto Accompaniment
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
VOICE/STYLE
DUAL
14
Selecting a Style

Full Keyboard
This function detects chord in entire key range. Chords are detected in a way similar to
fingered, even if you split the notes between your left and right hands.
For example: playing a bass note with your left hand and a chord with you right, or by
playing a chord with your left hand and a melody note with your right.
Press [FULL KEYBOARD] button to enter the Full Keyboard mode. FULL
KEYBOARD signal appears in the display.
Press [SYNCHRO] button to enter the sync start waiting mode, play the keyboard to start the
accompaniment.
Press [KBD.MODE] repeatedly to turn off the full keyboard function and the cusior will
disappear.
Auto Accompaniment
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
KBD.MODE
CHORD
SPLIT
FULL KEYBOARD
CHORD DICTIONARY
STYLE
VOICE
DEMO/LEARN
PEDAL DUAL TOUCH REC. PLAY O.T.S
PEDAL TOUCH O.T.S
15

START/
STOP
INTRO/
ENDING
SYNCHRO
START/
STOP
INTRO/
ENDING
SYNCHRO
START/
STOP
INTRO/
ENDING
FILL IN
SYNCHRO
The [START/STOP] button starts the selected accompaniment style immediately.
Selecting the Chord mode(Reference:Turn chord on/off P.14) .
The left hand
section of the keyboard becomes the Auto Accompaniment section, and chords
played in this section are automatically detected and used as a basis for fully
automatic accompaniment with the selected style.
Accompaniment Control
Any of your instrument accompaniment patterns can be started with an appropriate
introduction by pressing the [INTRO/ENDING] button directly.
If you press the [SYNCHRO] button and then the [INTRO/ENDING] button, the
accompaniment will start from the introduction as soon as a chord is detected in the AUTO
ACCOMPANIMENT section of the keyboard.
Metronome
Press the [FILL IN] button at any time while the accompaniment is playing to add a
one-measure fill-in.
If you hold the [FILL IN] button , the fill-in pattern will repeat until the button is
released , then the MAIN section will play from the beginning of the next measure.
Press the [SYNCHRO] button, then the accompaniment will start when you
play the first chord on the AUTO ACCOMPANIMENT section of the keyboard.
The metronome sound may be alternately turned on and turned off by pressing
the [METRONOME] button.
Time signature: 2/2,1/4, 2/4, 3/4, 4/4, 5/4,6/4, 3/8, 6/8, 7/8,9/8,12/8. 4/4
Hold the [METRONOME] button to enter the page for selecting the time signature.
Then use the [+] /[-] buttons to select your desired time signature.
(Default: )
Auto Accompaniment
START/
STOP
INTRO/
ENDING
SYNCHRO
16
FILL IN
FILL IN
