COMMERCIAL & COMMON FLUE SYSTEM
DD1 Flue Adaptor
INSTALLATION INSTRUCTIONS
For Use With Rinnai DD1
Commercial Water Heaters
& Commercial / Common
Flue Components
This appliance shall be installed in accordance with:
• Manufacturer’s Installation Instructions
• Rinnai Commercial Common Flue System, Operating and Installation Manual (supplied separately)
• Current AS/NZS 3000, AS/NZS 3500 & AS/NZS 5601
• Local Regulations and Municipal Building Codes including local OH&S requirements
This appliance must be installed, maintained and removed by an Authorised Person.
For continued safety of this appliance it must be installed operated and maintained
in accordance with the manufacturers instructions.

Rinnai Australia 2 DD1FADAPT
Assembly & Installation
REGULATIONS
This appliance must be installed in accordance with:
• Rinnai Commercial Common Flue System, Operating and Installation Manual (supplied separately)
• Current AS/NZS 3000, AS/NZS 3500 and AS/NZS 5601
• Rinnai Installation Instructions
• Local regulations and municipal building codes including local OH&S requirements
Installation, Service and Removal MUST BE by an Authorised Person only.
BEFORE ASSEMBLY
Review and understand the content of the “Rinnai Commercial Common Flue System, Operating and Installation
Manual” as it contains important information toensure safe and reliable operation of the applianceand flue system.
FLUE ADAPTER ASSEMBLY
Step 1. Fit Flue Insert Terminal (DDINSTERM) A. into the flue terminal spigot of the water heater B.
Step 2. Fit adaptor box C. and bracket D. and screw into place as shown with screws provided.
A
C
Installed
Side View
D
B

Rinnai Australia 3 DD1FADAPT
Assembly & Installation
CONDENSATE DRAIN ASSEMBLY
Step 1. Rinnai supplies a condensate tube E. that is pre-installed under the lower left front of the adaptor boxC.
Step 2. Installer is to provide, install and fix condensate drain components G. and H. to the condensate tube E.
in accordance with AS/NZS 5601.
C
Example of a typical
condensate drain
tube installation
Discharge the drain in accordance with AS/NZS 5601
and any other local requirements
G
H
E
G
H
E

Part No.15401092 4 E&TD 12-021 DD1FADAPT Issue 1 16/04/2013
