Rinnai Brivis DGH Manual Controller Manual

Brivis DGH Manual Controller IM - Issue 2 May 2020
Digital Room Thermostat
Operating & Installation Manual
1. DESCRIPTION
The Brivis Digital Room Thermostat is an easy to operate manual thermostat.
2. MAIN FEATURES
Power Source: 2 x 1.5V AA Battery
Battery Life: 1 year (typical operation)
Protection Class: IP30
Switch Function / Capacity: 36V AC or DC, 1.0 Amp maximum
Temperature Set-point Range: 5°C to 35°C
Temperature Display Range: -9°C to 50°C
Temperature Control Accuracy: 1°C
Returned Temperature: 1°C
Storage Temperature Range: -20°C to 70°C
Dimensions: 100mm (L) x 85mm (W) x 25mm (H)
Weight: 180 grams (excluding batteries)
3. SPECIFICATIONS (ELECTRICAL DATA)
1. 0 to 36Vac 50/60Hz or DC
2. 0.05 to 1.0 Amps (load per terminal)
3. 1.0 Amps Maximum Total (all terminals)
1. Start-up
Fit the battery, press , the LCD flashes with the set temperature, then displays the working mode icon and
environment temperature (factory default set temperature is 18°C).
2. Power-o󰀨
Pressing powers the thermostat on / off. Whilst off the current environment temperature remains on display.
3. Backlight
Press , or , to enable the backlight. The backlight will go off several seconds after last button press.
ON / OFF
Backlight Temperature Adjustment
Reset
(on back)
Power Indicator
Heating mode
Temperature Indicator
Battery Indicator
Status Indicator
by

Brivis DGH Manual Controller IM - Issue 2 May 2020
Rinnai Australia Pty Ltd
ABN 74 005 138 769 | AU24752
100 Atlantic Drive, Keysborough, Victoria 3173
P.O. Box 460, Braeside, Victoria 3195
Tel: [phone] Fax: [phone]
National Help Line
Tel: [phone]* Fax: [phone]
Monday to Friday, 8.00 am to 5.00 pm EST.
*Cost of a local call higher from mobile or public phones.
For further information visit www.rinnai.com.au
or email [email protected]
4. Setting Temperature
Press or to set the temperature.
5. Working status
This symbol indicates that the thermostat is heating.
6. Restore factory defaults
Press the [RESET] button on the back of the thermostat to restore factory defaults.
7. Low battery indicator
When the low battery indicator flashes replace the batteries immediately.
4. WIRING & INSTALLATION
InstallationWiring
(1) Fix the back board onto a wall
(2) Insert batteries into the thermostat
(3) Attach the thermostat to the backboard
3 Volt Power
Reset
Thermostat Connection Point
Back Board
Remove back board
& fit battery as shown
