INSTRUCTION MANUAL
PARTICLE SENSOR
KS-19F

i
Organization of this manual
This manual describes the features and operation principles of the light scattering
type liquid-borne particle sensor KS-19F. For information regarding the operation
of other equipment in the case of incorporating the KS-19F into a measurement
system with other equipment, always make sure to refer to the documentation of
the other equipment. The following pages contain important information on safety.
Be sure to read this part.
This manual contains the following sections.
Outline
Provides an outline of the unit and descriptions of measurement system
conguration examples.
Panel Explanation
Briey identies and explains all parts of the unit.
Preparations
Describes how to make sampling tube, purge gas, and sample uid con-
nections and how to set the unit up for use.
Measurement
Describes the basic steps for measurement, and gives information on error
messages.
Function for cancelling erroneous count
Describes the function for cancelling erroneous count.
Maintenance
Describes steps to perform after measurement, including how to clean the
piping.

ii
Troubleshooting
Describes countermeasures to take when the CELL indicator, the LIQUID
LEAK indicator and the LASER indicator are lit, and ash.
Specications
Lists the technical specications of the unit.
This product may cause interference if used in residential
areas. Such use must be avoided unless the user takes
special measures to reduce electromagnetic emissions to
prevent interference to the reception of radio and television
broadcasts.

iii
FOR SAFETY
In this manual, important safety instructions are specially marked as shown
below. To prevent the risk of death or injury to persons and severe damage
to the unit or peripheral equipment, make sure that all instructions are fully
understood and observed.
Caution
WARNING
Important
Disregarding instructions
printed here incurs the risk of
death or severe injury to per-
sons.
Disregarding instructions
printed here incurs the risk of
injury to persons and/or dam-
age to peripheral equipment.
Disregarding instructions
printed here incurs the risk of
damage to the unit.
Mentioned about the tips to
use this unit properly. (This
messages do not have to do
with safety.)
Note

iv
WARNING
Types of sample uids and cleaning uids
The unit is designed for measuring the particle number concentration in
liquid. The particle count is determined for various sizes.
Never use the unit with the liquid types listed below, to prevent false mea-
surement and the possibility of accidents and damage to the unit.
- Explosive liquid or mixtures containing explosive uid
- Liquid with a temperature of less than +15°C or more than +35°C
- Liquid with a pressure of more than 300 kPa (gauge pressure)
When using different types of sample uid where mixing can lead to reactions
such as thermal build-up, hardening, or particle generation, always perform
thorough cleaning to ensure complete replacement.

v
WARNING
Sample uid danger prevention
When toxic sample uid comes into contact with any part of the human body
or when toxic gases generated by the sample uid are breathed, there is a
danger of severe injury or death.
When sample uid comes into contact with other objects in the vicinity, there
is a risk of re, explosion, corrosion, deformation or other effects. Observe the
following points closely to prevent leakage and adherence of sample uid.
• In case of accidental contact with any potentially harmful uid, immediately
wash the affected part with plenty of water and contact a physician.
•Do not pass sample uids which can cause corrosion of uid-contacting
parts (PFA and sapphire) through the system.
•Observe the following points when setting up or dismantling a measure-
ment system.
- Check for any possible risks or toxicity of the intended sample uid.
- Take any required steps to prevent sample uid leaks, spray, or ex-
posure of the body to sample uid.
- Always use protective measures such as wearing dual gloves when
connecting or disconnecting tubes and connectors. Dispose of gloves
which have come into contact with uid in such a way that the gloves
do not come into contact with persons or equipment.
- Do not exert strong force or bending stress on tube joints to prevent
leaks.
- As far as possible, tubes and other piping parts should be built up as
a xed installation.
- Do not start to pass sample uid through the system before all con-
nections have been checked.
- This unit incorporates a leak sensor or other safety device, but to
verify safety you should always perform a thorough leak check before
starting operation. To ensure that the leak sensor operates properly,
the unit must be placed on a horizontal surface (inclination within 2
degrees; see page 2).

vi
•The pressure of sample uid passed through the unit may not exceed 300 kPa
(gauge pressure). Ensure that the supply system (sampler, sample uid lines
etc.) has sufcient pressure resistance.
•When using sample uid which may generate harmful gases, provide
adequate ventilation as prescribed by applicable laws and regulations.
• Before and after measurement, clean the entire sample uid system
thoroughly to remove any remnants. Otherwise unwanted effects such as
thermal build-up, hardening, particle accumulation etc. can occur. This is
especially important to prevent the possibility of serious accidents when
using the unit to measure different types of sample uids.
• After use, perform purging while observing any precautions regarding
the mixing of uids. As the last step, purge with pure water and verify
neutrality (pH7). Then ll the unit with ethyl alcohol and seal it.
• Dispose of waste sample uid only as prescribed by applicable laws and
regulations.
• Never mix waste sample uid with other substances unless absolute safety
has been established.
• Always follow the sequence: purging, measurement, exchange, measure-
ment
When using uids of different properties, always thoroughly purge
the uid system, and verify complete exchange before starting the
next measurement. This is to prevent unwanted effects such as sudden
thermal build-up, hardening, particle accumulation etc. that can be
caused by mixing. If this precaution is not properly observed, there
is a risk of a serious accident.

vii
• Pay attention to measurement, exchange, purging sequence
Some uids may be subject to emulsication, temperature rise, or other
effects when mixed with water. In some combinations, hardening or
precipitation may also occur. Before introducing sample uid, make
sure that there is no possibility of a chemical reaction.
Some possibly hazardous combinations and their effects are listed
below. (This list is not comprehensive. There may be other hazardous
combinations as well.)
• Water and sulfuric acid
A high-temperature reaction will occur.
• Oxidizing substances and reducing substances
Example: nitric acid and isopropyl alcohol
A violent reaction (explosion etc.) will occur.
• Acidic and alkaline substances
Example: introducing ammonia water after nitric acid is pro-
hibited
Damage and stress due to neutralization heat and reaction
heat may occur.
Always purge with pure water in between.
• Water and oil, water and organic solvent, or oil and organic
solvent
Emulsication may occur.
Purge with plenty of ethyl alcohol (followed by n-hexane
if required).
[Note]
The above information has been compiled by Rion to the best
of our knowledge, but it does not cover all possible cases or
applications. Be aware that other risks or dangers may exist
depending on usage conditions.

viii
WARNING
The unit uses a laser source
This unit is designated as a class 1 laser product
according to IEC 60825-1 (2014). The internal
particle detector mechanism uses a laser, but it is
fully shielded so that the beam cannot exit from the
enclosure. The identication label shown at right
is afxed to the top of the unit.
Laser Precautions
The particle detector mechanism in
this unit uses a laser classied as a
class 4 laser product according to IEC
60825-1 (2014). The laser source beam
and scattered light can cause blindness
if viewed directly, and can cause skin
injuries if the skin is exposed directly
to the beam and scattered light.
Never open the cover, because this involves the risk of exposure to the laser
beam.
The warning label shown at right is afxed to the top of the unit.
Caution
Use of controls or adjustments or performance of procedures other than those
specied herein may result in hazardous radiation exposure.
CLASS 4 LASER RADIATION WHEN
OPEN AVOID EYE OR SKIN EXPOSURE
TO DIRECT OR SCATTERED RADIATION
(800mW CW SOLID-STATE LASER 532nm)

ix
Warning Labels
The following types of warning labels are used with this unit.
Transport label
Instructs the user to purge the sample
uid system with pure water and ll
it with ethyl alcohol for maintenance
or servicing. When sending the units,
please follow any related laws and
regulations, and the instructions of
your shipping carrier.
The label is afxed to the rear of the
unit.
Warning label regarding inlet and outlet, and sample
uid pressure
Instructs the user not to exert strong
force on the inlet and outlet.
Warns the user that sample fluid
pressure must not exceed 300 kPa
(gauge pressure).
The label is afxed to the rear of the
unit.
Installation warning label
Instructs the user that the unit must
be installed horizontally (inclination
angle within 2 degrees), to ensure that
the leak sensor operates properly.
The label is afxed to the top of the unit.

x
Caution label for remove the sample uid and clean
the system after measurement
Instructs the user that the sample uid
should be removed after measurement
and replaced by a suitable uid that
serves to clean the system and does
not cause corrosion.
The label is afxed to the rear of the
unit.
Caution label for prevention of contamination using
the purge gas
Instructs the user that the unit must be
cleaned with the purge gas when the
unit is not installed in a clean room.
The label is afxed to the top of the unit.

xi
Laser product warning label
This unit is designated as a class 1 laser product
according to IEC 60825-1 (2014). The internal
particle detector mechanism uses a laser, but it is
fully shielded so that the beam cannot exit from
the enclosure.
The label is afxed to the top of the unit.
Laser product description label
The particle detector mechanism in
this unit uses a laser classified as a
class 4 laser product according to IEC
60825-1 (2014). The laser source beam
and scattered light can cause blindness
if viewed directly, and can cause skin
injuries if the skin is exposed directly
to the beam and scattered light.
Never open the cover, because this involves the risk of exposure to the laser
beam.
The label is afxed to the top of the unit.
Transport label
To assure continued operating accu-
racy, carefully protect the unit from
shocks and vibrations during transport
and installation.
The label is afxed to the top of the
unit.
CLASS 4 LASER RADIATION WHEN
OPEN AVOID EYE OR SKIN EXPOSURE
TO DIRECT OR SCATTERED RADIATION
(800mW CW SOLID-STATE LASER 532nm)

xii
Precautions
• Operate the unit only as described in this manual.
• The uid-contacting parts of this product are made of sapphire and PFA,
which provides high resistance against corrosion by hydrouoric acid.
However, gradual corrosion may occur in some cases. If hydrouoric acid
was left in the unit for a long time, replacement of uid-contacting parts
may become necessary.
• In order to ensure long life of this product, the sample uid should be
removed as soon as possible after measurement and replaced by a suitable
uid that serves to clean the system and does not cause corrosion (such
as pure water, alcohol, or similar). When doing this, care must be taken
to avoid adverse reactions due to unsuitable uid combinations.
• Depending on conditions such as the liquid type, concentration, and tem-
perature, the sample uid may gradually corrode the uid-contacting parts,
leading to leaks. It is therefore essential to carry out regular inspections.
• Store the unit in locations within the prescribed temperatures and humid-
ity ranges (-10°C to +50°C, 90% RH and less).
• Use the unit in locations within the prescribed temperatures and humidity
ranges (+15°C to +35°C, 80% RH and less).
If the temperature of the sample uid is lower than the environmental
temperature, condensation may occur. Take suitable countermeasures
such as using purge gas (refer to the section “Precautions against con-
densation” on page 10).
• Do not use or store the unit in locations which
- may be subject to condensation by sudden changes in temperature, or
- may be subject to splashes of water or other uids, or
- may be subject to direct sunlight, or
- may be subject to air with high salt or sulfur content, to corrosive
chemicals, or to gases, or
- may be unstable or inclined, or
- may be subject vibrations or shock.
• If the unit is used in a manner not specified by the manufacturer, the
protection provided by the unit may be impaired.

xiii
• If sample uid has accidentally entered other part of the unit, there may
be a risk of re. Disconnect the connection cable immediately from the
CONTROLLER connector of the unit.
• If the unit operates abnormally, disconnect the connection cable from the
CONTROLLER connector of the unit.
• Before using the unit, make sure that all cord, cable and tube connections are
correctly and safely established. Do not subject the cords, cables and tubes to
excessive bending or other force. When disconnecting the cords, cables and
tubes, disconnect while holding onto the end of the plug, connector or tube.
• Be aware of the possibility of leaks from uid system parts such as
tubes, connectors, and the syringe of the syringe sampler. These parts
are consumables and must be regularly replaced.
• Excessive electrical noise or voltage uctuations can cause a malfunction
or a failure.
• Do not disassemble the unit or attempt internal alterations. If a malfunction
should happen to occur, do not try to solve the problem on your own, but
rather note the condition of the unit clearly and contact the supplier.
• The end plugs are required to seal the unit when storing or returning it for
maintenance or servicing. Store the plugs in a safe location for later use.
• The sample uid system of the unit must always be lled with uid (during
measurement, storage, and transport). If the sample uid system dries up,
ow cell problems (see page 7) can occur.
• When the unit is not installed in a clean room environment, airborne
contamination that entered in the case may adversely affect the measurement
or may cause the malfunction of the unit. To prevent this, please clean
the unit with the purge gas during installation.
• Before returning the unit for maintenance or servicing, thoroughly purge
the piping with pure water. Then ll the piping with clean ethyl alcohol
and install the end plugs. In addition, use the special packaging box so as
to prevent the unit from being subjected to vibrations and shock. When
sending the units, please follow any related laws and regulations, and the
instructions of your shipping carrier.
• When disposing of the unit, be sure to observe all applicable legal regulations
and guidelines in your country and community.

xiv

xv
Contents
FOR SAFETY............................................................................... iii
Outline............................................................................................1
Light source service life.............................................................1
Particle size detection ................................................................2
Leak detection ...........................................................................2
Measurement system conguration examples.............................3
Panel Explanation............................................................................6
Front panel.................................................................................6
Rear panel..................................................................................8
Preparations ....................................................................................9
Place of Installation ...................................................................9
Connection to controller KE-40B1........................................... 11
Sampling tubes ........................................................................12
Connecting the sampling tubes ................................................12
Removing the sampling tubes ..................................................14
Extending the sampling tube ................................................... 16
Purge gas .................................................................................18
Before supplying the sample uid ............................................20
Sample uid ow rate adjustment ............................................21
Dissolved air in sample uid ...................................................21
Particle size setting range .......................................................22
LIQUID LEAK ALARM terminals ........................................23
Turning the system on..............................................................24
Measurement.................................................................................25
Measurement ...........................................................................25
Error message ..........................................................................25
Automatic recovery of abnormal internal processing ...............27
Function for cancelling erroneous count........................................28
Function for cancelling erroneous count ..................................28

xvi
Maintenance..................................................................................31
Steps after use..........................................................................31
Cleaning the piping..................................................................31
Cleaning main unit ..................................................................33
Laser service life detection .....................................................33
Cooling fan .............................................................................33
Replacement of consumables ..................................................33
Periodic maintenance ..............................................................34
Transport .................................................................................34
Troubleshooting ............................................................................37
When CELL indicator is lit in red ...........................................37
When LIQUID LEAK indicator is lit in red ............................37
When LASER indicator is lit in red .........................................37
When LASER indicator ashes in red .....................................37
When LASER indicator ashes in green..................................37
Specications ................................................................................38

1
Outline
The KS-19F is a sensor which uses the light scattering method for measuring
the particle number concentration in liquid. The particle count is determined
for various sizes. Sample uid contacting parts are made of sapphire and PFA,
allowing direct measurement of hydrouoric acid.
By connecting the KS-19F to the optional controller KE-40B1, a liquid-borne
particle counter system with up to ten size ranges can be created.
Using the KE-40B1, it is also possible to freely specify the size ranges 0.03
μm to 0.13 μm for particle detection. The factory default setting is four chan-
nels (≥0.03 μm, ≥0.06 μm, ≥0.1 μm, ≥0.13 μm).
The ow rate is 10 mL per minute, and counting efciency is 5%. The effec-
tive ow rate at which particles are detected and measured is the ow rate
multiplied by the counting efciency, i.e. 0.5 mL per minute.
The KS-19F does not have measurement controls or a display for measure-
ment results. It is designed to be used under control of a separate controller
KE-40B1 which also supplies power to the KS-19F.
The KS-19F incorporates a leak sensor. If a leak is detected, an alarm output
can be activated.
As the KS-19F does not incorporate a ow control circuit for the sample
uid, the ow rate of the sample uid must be controlled by external means.
Light source service life
The KS-19F uses a diode pumped solid state laser as a light source.
The life expectancy of a laser diode for pumping is shorter than that of other
semiconductors. When the laser diode nears the end of its service life, the
optical power falls below the rated level. There are considerable differences
in service life between individual diodes.
The KS-19F detects when the laser diode no longer provides the required
output. In such a case, the LASER indicator of the KS-19F and the [LASER]
icon of connected controller KE-40B1 display ash in green, which indicates
that the laser diode must be replaced.

2
Outline
Particle size detection
The KS-19F is calibrated at the factory, using particles of known diameter
and refractive index (monodisperse polystyrene latex spheres with a refractive
index of 1.6) in pure water. As the amount of scattered light by such particles
is used as reference to determine the particle size, the measured size corre-
sponds to the light scattering size of polystyrene latex particles.
Leak detection
The KS-19F incorporates a leak sensor. If a leak is detected, the LIQUID
LEAK indicator lights up in red and the LIQUID LEAK ALARM terminals
become OPEN.
To ensure that the leak sensor operates properly, the KS-19F must be placed
on a horizontal surface (inclination within 2 degrees). For proper activation
of the leak sensor, the leak sample uid must be held at the bottom of the
KS-19F.
Caution
If a leak is detected, stop the sample uid
supply to the KS-19F and disconnect the
connection cable from the CONTROLLER
connector of the KS-19F. When any sample
uid has accumulated in the KS-19F, contact
your supplier.
(inclination within 2 degrees)
OK Incorrect
Incorrect
PARTICLE MONITOR
LIQUID LEAK
CELL
LASER
POWER
LASER OFF
PARTICLE MONITOR
LIQUID LEAK
CELL
LASER
POWER
LASER OFF
PARTICLE MONITOR
LIQUID LEAK
CELL
LASER
POWER
LASER OFF
