RITE-HITE TS-2000 Operating instructions

Model: TS-2000
Manual Part #: 54450042
Publication: AMEN00110 2017-07-26
TS-2000 Trailer Stand
Installation/Owner's Manual
This manual covers units: May 7, 2015 to Date
Language: English (Hazards: English, French)
The English version of this manual shall prevail over any
error in, or conflicting interpretation of, any translations.
NOTICE TO USER. . . . . . . . . . . . . . . . . . .2
SAFETY . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Safety Identications . . . . . . . . . . . . . . . . .2
INSTALLATION (OPTIONAL)
Transport Wheel Assembly (OPTIONAL) . . .3
OPERATION
Position TS-2000 . . . . . . . . . . . . . . . . . . . .4
Remove TS-2000 . . . . . . . . . . . . . . . . . . . .4
MAINTENANCE . . . . . . . . . . . . . . . . . . . .5
PARTS . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
WARRANTY. . . . . . . . . . . . . . . . . . . . . . . .8

TS-2000 Trailer Stand Installation/Owner’s Manual Rite-Hite®
2 Publication: AMEN00110 2017-07-26
NOTICE TO USER
Thank you for purchasing the TS-2000 Trailer Stand.
This heavy duty trailer stand provides additional safety
to a parked trailer resting on its landing gear.
Capacity: 100,000 lbs [45400 kg]
Read, understand and save this manual prior to
installation or operation of this equipment.
For best results, have this product serviced by your
authorized Rite-Hite®Representative.
SAFETY
Safety Identifications
DANGER
Indicates a hazardous situation which, if not
avoided, will result in death or serious injury.
Indique une situation dangereuse qui, si elle n’est
pas évitée, peut entraîner la mort ou de graves
blessures.
WARNING / AVERTISSEMENT
Indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
Indique une situation dangereuse qui, si elle n’est
pas évitée, peut entraîner la mort ou des
blessures graves.
CAUTION / ATTENTION
Indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
Indique une situation dangereuse qui, si elle n’est
pas évitée, peut entraîner des blessures légères à
modérées.
NOTICE
Indicates a situation which can cause damage to the
equipment, personal property and/or the environment,
or cause the equipment to operate improperly.
NOTE:A note is used to inform you of important
installation, operation, or maintenance information.

Rite-Hite®Installation/Owner’s Manual TS-2000 Trailer Stand
Publication: AMEN00110 2017-07-26 3
INSTALLATION (OPTIONAL)
Transport Wheel Assembly (OPTIONAL)
Verify you received all components before installation.
Notify your authorized Rite-Hite®Representative if parts
are missing or damaged.
1 Transport wheel support weldment (yellow)
1 10in solid rubber wheel
1 1in wheel axle bolt and nylock nut
2 3/8in U-bolts with lock nuts
Tools Required:
• 1 9/16in wrench
• 2 large channel lock pliers or vice grips
For easier assembly, tip trailer stand over
(front of stand on pavement).
NOTE:2 people are required to tip trailer stand
over and bring it back to vertical position.
A
B
1. Install wheel into weldment by inserting wheel into
slot in weldment and sliding axle bolt through holes
provided.
• Tighten axle bolt securely. Engage bolt into nylon
portion of nut (A).
• DO NOT over-tighten or restrict wheel rotation.
2. Remove nuts from U-Bolts and slide U-Bolts from
weldment.
3. Slide weldment into position under trailer stand axle
until holes for U-Bolts align with axle.
• Install U-Bolts around trailer stand axle and down
through weldment holes.
• Install the nylon lock nuts onto the U-Bolts.
• Tighten the nuts securely and evenly (B).
Figure 1
Figure 2

TS-2000 Trailer Stand Installation/Owner’s Manual Rite-Hite®
4 Publication: AMEN00110 2017-07-26
OPERATION
!WARNING / AVERTISSEMENT
DO NOT put arms or hands between the trailer and
the TS-2000-Trailer Stand.
Ne mettez pas de bras ou les mains entre la
remorque et le TS-2000-Trailer Stand.
A B
C
Position TS-2000
1. Confirm vehicle restraint and/or wheel chocks are
securely in position.
2. Adjust height of landing gear, if necessary.
Trailer must be horizontal.
3. Roll trailer stand into position (A). It must fit
underneath the nose of the trailer without any
interference. If necessary turn height adjustment
crank counter clockwise to decrease the height. The
top plate of the trailer stand should be flush with
trailer front wall.
4. With the TS-2000 in this position, turn height
adjustment crank clockwise so that it is closely
against the underside of the trailer’s nose (B). Rotate
height adjustment crank to closest position backward
where it is pointed downward. It is acceptable to have
a gap of up to 1in [25 mm] between top of trailer
stand and bottom of trailer.
5. Drop looped chain over height adjustment crank of
trailer stand to secure position (C).
Remove TS-2000
1. Tractor should stand-by to be coupled with trailer.
2. Confirm vehicle restraint and/or wheel chocks are
securely in position.
3. Check height of landing gear. It should firmly touch
the ground.
4. Lift chain off height adjustment crank and allow it to
rest on rotating shaft.
5. Turn height adjustment crank counter clockwise to
crank down the TS-2000 to allow trailer stand to roll out.
NOTE:If trailer stand is tight, remove weight from
trailer stand by cranking up legs of trailer so trailer
stand can be removed smoothly (without jerking).
6. Remove trailer stand.
7. Allow tractor to connect with trailer.
8. Disengage any vehicle restraints or wheel chocks.
9. Clean and store the TS-2000.
Figure 3

Rite-Hite®Installation/Owner’s Manual TS-2000 Trailer Stand
Publication: AMEN00110 2017-07-26 5
MAINTENANCE
Before each use:
INSPECT REMEDY
Bent parts (eg. handles, top cover, or height adjustment crank) Replace broken or bent parts.
Welds for breaks
Chain is attached
Trailer stand is able to move and operate freely. Lubricate the wheels.
If there is binding in main structure, contact your
authorized Rite-Hite service representative to
disassemble top section and determine cause.

TS-2000 Trailer Stand Installation/Owner’s Manual Rite-Hite®
6 Publication: AMEN00110 2017-07-26
1
2
3
4
5
9
8
19
22
26
25
27
7
28
18
23
24
2120
11 12
14
13
15
16
18
17
10
PARTS
Exploded View

Rite-Hite®Installation/Owner’s Manual TS-2000 Trailer Stand
Publication: AMEN00110 2017-07-26 7
PARTS Continued
# DESCRIPTION PART #
1SEAT, ASSY,HNDLD, TS2000,36” 68400001
SEAT, ASSY,HNDLD, TS2000,38.5” 68400002
SEAT, ASSY,HNDLD, TS2000,42.5” 68400003
2 HANDLE,BAR W/GRIPS,TS2000 51850054
3 GRIP,HANDLE,VINYL,1-1/4ODX4-1/2" 55150278
4 LABEL,PRODUCT,TS2000 53850675
5 LABEL,ROTATION,CAPACITY,TS2000 53850676
LABEL,ROTATION,CAPACITY,TS,CE 53850690
7 CHAIN,ASSY,TS2000 16600068
8 CRANK,WLDMNT,TS2000,8.5” 19600003
CRANK,WLDMNT,TS2000,10.5” 19600004
CRANK,WLDMNT,TS2000,13.5” 19600005
9 HOUSING,RISER,WLDMNT,LWER,TS 52930032
HOUSING,RISER,WLDMNT,LWER,TS,CE 52930033
10 SPACER,1-34ODX1IDX5/32 70450171
11 GEAR,PINION,BEVELED,2.75 51230002
12 GEAR,PINION,BEVELED,4.5 51230003
13 SMALL GEAR SPRING PIN 64010012
14 PIN,DOWEL,3/8X2,STL 64040037
15 BRG,THRUST,1.253 ID X 1.872 OD 12500050
16 SPACER,DRIVE,RISER,TS2000 70450172
17 SCR,HHMS,3/8-16X6.5,GR5,ZNC 67880145
18 NUT,HEX,NYL LOCK,3/8-16,ZNC 55630005
19 CHASSIS,WLDMNT,W/SHAFT,TS2000 51550279
20 PIN,COTTER,3/16X1-1/4 64030009
21 WSHR,FLAT,1-1/8X1-3/4X1/8,ZNC 74170030
22 WHEEL,RIM/TIRE,16ODX4WX1" BORE 75550016
23 BLT,U,3/8,1X1-3/4,SS 67880146
24 NUT,HEX,1-8,GR8,ZNC 55670016
25 SCR,HHMS,1-8,4-1/2,GR5,ZNC 67920012
26 WHEEL,RIM/TIRE,10ODX4WX1" BORE 75550018
27 COMPLETE TRANSPORT WHEEL (UNASSEMBLED) 75550017
28 AXLE ONLY, UNFINISHED 118600001
