RiverGrille TF2201802-RG Quick reference guide

Page 1 of 30 20160927-Ver.1
Oil-less Fryer & Roaster
Model number: TF2201802-RG
ASSEMBLY & OPERATING INSTRUCTIONS
Tools required (not included):
Phillips screwdriver / Adjustable wrench
For Outdoor Use Only
To installer or person assembling this appliance: Leave this manual with this
appliance for future reference.
This instruction manual contains important information necessary for the
proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using
the appliance.
Follow all warnings and instructions when using the appliance.
Keep this manual for further reference.
Please keep this instruction manual for future reference
Customer Service: [phone], 8:00am to 5:00pm, Monday to Friday,
Pacific Standard Time
(Made in China)
(Tank Not Included)

Page 2 of 30 20160927-Ver.1
SAFETY SYMBOLS:
The symbols and boxes shown below explain what each heading means. Read and follow all of
the messages found throughout the manual.
DANGER: Indicates an imminent hazardous situation which if not avoided will result
in death or serious injury.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation, which, if not avoided, may
result in minor or moderate injury.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the appliance and immediately call
your gas supplier or fire department.
Failure to follow these instructions could result in fire or explosion which
could cause property damage, personal injury or death.
DANGER
1. Never operate this appliance unattended.
2. Never operate this appliance within 10 ft (3.05 m) of any structure,
combustible material or other gas cylinder.
3. Never operate this appliance within 25 ft (7.5 m) of any flammable liquid.
4. If a fire should occur, keep away from the appliance and immediately call
your fire department. Do not attempt to extinguish an oil or grease fire
with water.
Failure to follow these instructions could result in fire or explosion which
could cause property damage, personal injury or death.
WARNING
1. Do not store or use gasoline or other flammable liquids or vapors in the
vicinity of this or any other appliance.
2. An LP cylinder not connected for use shall not be stored in the vicinity of
this or any other appliance.

Page 3 of 30 20160927-Ver.1
DANGER
(a) Do not store a spare LP gas cylinder under or near this appliance;
(b) Never fill the cylinder beyond 80 percent full;
(c) If the information in (a) and (b) is not followed exactly, a fire causing death or serious
injury may occur.
WARNING
Do not attempt to repair or alter the hose/valve/regulator for any “assumed” defect. Any
modification to this assembly will void your warranty and create the risk of a gas leak
and fire. Use only authorized replacement parts supplied by manufacturer.
CAUTION
For residential use only. Do not use for commercial cooking.
PROP 65 WARNING
Chemicals known to the state of California to cause cancer, birth defects or other
reproductive harm are created by the combustion of propane.
WARNING
This appliance is for OUTDOOR USE ONLY. DO NOT use in building, garage, shed,
breezeway, or any other enclosed area.
This appliance is not intended to be installed in or on a boat. This appliance is not
intended to be installed in or on recreational vehicles.
This appliance shall not be used on or under any apartment or condominium balcony or
deck.
If stored indoors, detach and leave cylinder outdoors.
DO NOT leave appliance unattended. Keep children and pets away from the appliance at
all times.
The use of alcohol, prescription or non-prescription drugs may impair the user’s ability to
properly assemble or safely operate the appliance.
DO NOT put the appliance in storage or travel mode immediately after use. Allow to cool
completely to touch before moving/storing. Failure to do so could result in fire, which could
cause property damage, personal injury or death.
Always keep the fuel supply hose away from any heated surface.
This appliance is not intended for commercial use. It is for household use only. DO NOT
use this appliance for other than its intended purpose.
This appliance is not intended for and should never be used as a heater.
Never use natural gas in a unit designed for liquid propane gas.

Page 4 of 30 20160927-Ver.1
Leak tests must be conducted prior to each use.
Appliance is hot when in use.
To avoid burns:
DO NOT attempt to move the appliance.
Wear protective gloves or oven mitts.
DO NOT touch any hot surfaces.
DO NOT wear loose clothing or allow hair to come in contact with appliance.
This appliance will be hot during and after use. Use insulated oven mitts or gloves for
protection from hot surfaces or splatter from cooking liquids.
When cooking with oil or grease, have a type BC or ABC fire extinguisher readily available.
In the event of an oil or grease fire do not attempt to extinguisher with water. Immediately
call the FIRE DEPARTMENT. A type BC or ABC fire extinguisher may, in some
circumstances contain fire.
When cooking, the appliance must be on a level, stable noncombustible surface in an area
clear of combustible material. An asphalt surface may not be acceptable for this purpose.
Use your appliance OUTDOORS in a well ventilated space away from dwellings or other
buildings to prevent dangers associated with gas accumulation and toxic vapors. The
appliance should be situated at least 10 feet (3.05m) from buildings. Not adhering to these
clearances will prevent proper ventilation and may increase the risk of a fire and/or
property damage, which could also result in personal injury.
Maintain a minimum clearance of 10 feet (3.05m) between all sides of the appliance, deck
railings, walls or other combustible material. The outdoor cooking gas appliance shall not
be used under overhead combustible construction. DO NOT obstruct the flow of
combustion/ventilation air.

Page 5 of 30 20160927-Ver.1
WARNING
Never move the appliance when in use.
Never operate appliance with LP cylinder out of correct position specified in assembly
instructions.
Always close LP cylinder valve and remove coupling nut before moving LP cylinder from
specified operating position.
Avoid bumping of or impact with the appliance to prevent spillage or splashing of hot
grease.
Grease collected in grease tray is hot. Do not remove the grease tray from the appliance
until it is cool to touch.
Keep appliance area clear and free from combustible materials, gasoline and other
flammable vapors and liquids.
Keep LP cylinder at a minimum distance of 24 inches (61cm) away from appliance at all
times.
CAUTION
Open lid during lighting.
Putting out grease fires by closing the lid is not possible. This appliance is well
ventilated for safety reasons.
Do not use water on a grease fire. Personal injury may result. If a grease fire
develops, turn knob and LP cylinder off.
Do not leave appliance unattended while burning off food residue. If appliance has
not been regularly cleaned, a grease fire can occur that may damage the product.

Page 6 of 30 20160927-Ver.1
USE AND INSTALLATION OF LP GAS CYLINDER (PROPANE TANK)
BEFORE INSTALLING:
The installation must conform with local codes or, in the absence of local codes, with either the
National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code,
CSA B149.1, or Propane Storage and Handling Code, B149.2, or the Standard for Recreational
Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as
applicable.
BEFORE EVERY USE:
Be sure to inspect the hose for leaks, cuts, wear, abrasion, or damage of any sort before using
this appliance. If any damage is apparent, the hose must be replaced with a new hose specified
by the manufacturer before further use.
LP GAS CYLINDER
The LP (liquid propane) cylinder specifically designed to be used with this unit MUST have a 20
lb. (9.1kg) capacity with a Q.C.C. Type 1 cylinder valve and an overfilling protection device
(OPD). Only use LP cylinders with this type of valve.
LP cylinder valve requirement:
Purchase LP cylinders only with these required measurements:
12” (30.5cm) (diameter) x 18” (45.7cm) (tall) with 20lb. (9.1kg)
capacity maximum.
Q.C.C. Type 1 outlet compatible with regulator or appliance.
Safety relief valve.
UL-listed Overfill Protection Device (OPD). This OPD safety
feature is identified by a unique triangular hand wheel. Use only
tanks equipped with this type of valve.
LP cylinder must be arranged for vapor
withdrawal.
The LP cylinder must be constructed and marked
in accordance with the Specifications for LP-Gas
Cylinders of the U.S. Department of
Transportation (D.O.T.) or the National Standard of
Canada CAN/CSA – B339, Cylinder, Spheres and
Tubes for Transportation of Dangerous Goods;
and Commission of Dangerous Goods; as
applicable.
The LP cylinder must include a collar to protect
the cylinder valve.
If the outdoor cooking gas appliance is not in use, the gas must be turned off at the supply
cylinder(s).
The LP cylinder must be stored outdoors out of the reach of children and MUST NOT be
stored in a building, garage, shed, breezeway, or any other enclosed space.
Storage of an outdoor cooking gas appliance indoors is permissible ONLY if the cylinder is
disconnected and removed from the outdoor cooking gas appliance.
The cylinder should ALWAYS be put in an upright position.
LP Cylinder Valve

Page 7 of 30 20160927-Ver.1
DANGER
DO NOT connect this appliance to an existing #510 POL cylinder valve with Left hand
threads. The Type 1 valve can be identified with the large external threads on the valve
outlet.
DO NOT connect to a propane cylinder exceeding its capacity.
DO NOT connect to a cylinder that uses any other type of valve connection device.
Never store a spare LP gas cylinder under or near your grill. This could cause pressure to
be expelled through the vapor relief valve resulting in fire, explosion, or severe personal
injury, including death.
Keep the ventilation opening(s) of the LP gas cylinder enclosure free and clear from
obstructions and debris.
DO NOT insert any foreign objects into the valve outlet. Damage to the valve outlet could
result. A damaged valve outlet can cause a leak, possibly resulting in explosions, fire,
severe bodily harm, or death.
WARNING
FOR FILLING THE LP GAS CYLINDER
Allow only qualified LP gas dealers to properly fill or repair your LP cylinder.
DO NOT allow the cylinder to be filled beyond 80% capacity. Over-filled tanks can create a
dangerous condition. Over-filled tanks can build up pressure and cause the relief valve to
expel propane gas vapors. The vapor is combustible and if it comes in contact with a spark
source or flame an explosion causing severe burns, bodily harm, or death could occur.
Always use a safety cap when the grill is not connected to a cylinder.
If you exchange a cylinder with a qualified exchange program, be sure the cylinder has a
Type 1 valve and an over-fill prevention device (OPD).

Page 8 of 30 20160927-Ver.1
CONNECTION PROCEDURES
1. Make sure the cylinder valve is closed (turn
valve clockwise until tight).
2. Check the cylinder valve to insure it has the
proper external male threads.
3. Make sure all burner valves are turned OFF.
4. Inspect valve connections, port, and regulator
assembly. Look for any damage or debris.
Remove any debris. Inspect the hose for
damage. Never attempt to use damaged or
obstructed equipment. Contact your local LP
gas dealer for repair.
5. When connecting the regulator assembly to the valve, hand tighten the quick coupling nut
clockwise to a complete stop. Do not use a wrench to tighten. Use of a wrench may damage
the quick coupling nut and result in a hazardous condition.
6. Open the cylinder valve fully (counterclockwise). Use a soapy water solution to check all
connections for leaks (a Leak Test) before attempting to light the appliance (see P.20-21). If
a leak is found, turn the cylinder valve off and do not use the appliance until your LP gas
dealer can make repairs.
TO DISCONNECT LP CYLINDER:
1. Turn the burner valve off.
2. Turn the cylinder valve off fully (turn clockwise to stop).
3. Detach the regulator assembly from the cylinder valve by turning the quick coupling nut
counterclockwise.
CAUTION
When installing LP cylinders, the pressure regulator and hose supplied by the
manufacturer MUST be used with the appropriate cylinder. Replacement regulators
and hoses need to be specified by the manufacturer of this appliance.
Place the dust cap on the cylinder valve outlet whenever the cylinder is not in use. Only
install the type of dust cap on the cylinder valve outlet that is provided with the cylinder.
Other types of caps or plugs may result in leakage of propane.
Cylinder Valve/Knob

Page 9 of 30 20160927-Ver.1
PRODUCT DIAGRAM

Page 10 of 30 20160927-Ver.1
COMPONENT LIST
1. Lid Assembly 2. Body Assembly 3. Match Hole Cover
Qty: 1pc Qty: 1pc Qty: 4pcs
4. Lid Handle, Silver 5. Rear Leg 6. Basket
Qty: 1pc Qty: 2pcs Qty: 1pc
7. Grease Tray 8. Front Left Leg 9. Front Right Leg
Qty: 1pc Qty: 1pc Qty: 1pc
10. Control Panel And Regulator
Assembly
11. Flame Tamer 12. Grease Collector
Qty: 1pc Qty: 4pcs Qty: 1pc

Page 11 of 30 20160927-Ver.1
13. Meat Thermometer 14. Lifting Hook 15. Fryer Handle, Black
Qty: 1pc Qty: 1pc Qty: 2pcs
REPLACEMENT PART LIST (I)

Page 12 of 30 20160927-Ver.1
REPLACEMENT PART LIST (II)
Part
Number Part Name Part Number Part Name
1 Lid Assembly 1a Upper Hinge
1b lid 2 Body Assembly
2a Lower Hinge 2b Main Body
2c Heat Shield 2d Burner
2e Ignition Electrode & Wire 2f Fire Box
3 Match Hole Cover 4 Lid Handle, Silver
5 Rear Leg 6 Basket
7 Grease Tray 8 Front Left Leg
9 Front Right Leg 10 Control Panel And Regulator
Assembly
10a Orifice Nut 10b Orifice Bracket
10c Control Panel 10d Knob Bezel
10e Control Knob 10f Regulator & Valve Assembly
10g Hook 11 Flame Tamer
12 Grease Collector 13 Meat Thermometer
14 Lifting Hook 15 Fryer Handle, Black
HARDWARE LIST
Item No. Item name Diagram Qty / pcs
A M6x8 mm Bolt 24
B M6 Step Bolt 4
C Hinge Pin 2
D Cotter Pin 2
E Heat Insulation Washer 4

Page 13 of 30 20160927-Ver.1
ASSEMBLY PROCEDURES
Step 1. Attach the Rear Leg (5), Front Left Leg (8) and Front Right Leg (9) to
the Body Assembly (2) by using 12 pcs M6x8mm Bolt (A).
Step 2. Attach the Control Panel And Regulator Assembly (10) to the front
legs by using 4 pcs M6x8mm Bolt (A) as shown.

Page 14 of 30 20160927-Ver.1
Step 3. Attach the Orifice Bracket to the bottom of body assembly by using 2
pcs M6x8mm Bolt (A) as shown. Make sure that the valve outlet (orifice) is
inserted STRAIGHTLY into the burner port.
Step 4. Insert the terminal of ignition wire into the connector of burner valve.
Correct Position Incorrect Position

Page 15 of 30 20160927-Ver.1
Step 5. Attach the Match Hole Covers (3) to the body assembly by using 4 pcs
M6 Step Bolt (B).
Make sure that the covers can swing smoothly.
Step 6. Attach the Fryer Handle, Black (15) to the body assembly by using 4 pcs
M6x8mm Bolt (A).

Page 16 of 30 20160927-Ver.1
Step 7. Attach the Lid Assembly (1) to the body assembly by using 2 pcs Hinge
Pin (C) and 2 pcs Cotter Pin (D).
Step 8. Attach the Lid Handle, Silver (4) to the lid by using 2 pcs M6x8mm Bolt
(A) and 4 pcs Heat Insulation Washer (E).

Page 17 of 30 20160927-Ver.1
Step 9. Insert the Grease Tray (7) into the sliding slots at the bottom of the body
assembly as shown. Suggest using a disposable aluminum tray as a liner.
Step 10. Position the Grease Collector (12) into the fryer body and make sure
that it is fixed by 4 guiding pins in the fryer body as shown
Tip: Grease tray sized to hold
a disposable aluminum tray.

Page 18 of 30 20160927-Ver.1
Step 11. Place the Flame Tamer (11) into the guiding pins on the grease
collector as shown.
Step 12. Place the Basket (6) into the fryer body (on the grease collector) as
shown.

Page 19 of 30 20160927-Ver.1
Step 13. Your unit is fully assembled! Make sure to read and follow the Instruction
Manual before using this appliance.
When transporting or storing the appliance without tank attached, hook the
regulator onto the handle to prevent damage to regulator.

Page 20 of 30 20160927-Ver.1
LEAK TEST
GENERAL
Although all gas connections on the appliance are leak tested at the factory prior to shipment, a
complete gas tightness check must be performed at the installation site due to possible
mishandling in shipment, or excessive pressure unknowingly being applied to the unit.
Periodically check the entire system for leaks following the procedures listed below. Before using
your appliance you must check for leaks.
BEFORE TESTING
Make sure that all packing material is removed from the appliance.
Make a soap solution of one part liquid detergent and one part water. You will need a spray
bottle, brush, or rag to apply the solution to the fittings. For the initial leak test, make sure the LP
cylinder is full.
WARNING
DO NOT SMOKE WHILE CONDUCTING LEAK TEST.
NEVER PERFORM LEAK TEST WITH AN OPEN FLAME.
If it is evident that there is excessive abrasion, wear or the hose is cut, it must be
replaced prior to the appliance being put into operation. The replacement hose must
be specified by the manufacturer.
TO TEST
1. Make sure the control valve is in the OFF
position then turn on the gas supply.
2. Check all connections from the gas
cylinder, LP gas regulator and supply valve
up to and including all connections to the
pipe that go to the burner. The following are
the points where the soap-water mixture is
to be applied. Soap bubbles will appear if a
leak is present.
A. Supply tank (cylinder) weld.
B. Tank valve to cylinder.
C. Tank valve knob.
D. Regulator coupling nut to tank valve.
E. Regulator to regulator coupling nut.
F. Regulator connections to gas supply
hoses.
G. The full length of gas supply hose.
H. Burner valve stem cap.
I. Hose connection to burner valve.
j. The full length of corrugated tube.
