Riverlea CEDAR SHED NOTTINGHAM User manual

CEDARSHED INSTRUCTIONS
NOTTINGHAM - COLOURSTEEL ROOF
Base size: 3600mm x 1500mm deep

NOTTINGHAM
• Baery Drill
• Riveter
• Hammer
• Tape Measure
• Ladder
• Skillsaw
• Level
• Screwdriver - Flat
• 3/8 Hex Drive bit
• 8mm Hex Drive bit
• Drill Bit 3.2mm
• Read all instrucons carefully.
• Idenfy all parts and check quanes against checklist.
• Do not aempt to build your shed in high winds.
• Beware of sharp edges.
• Protect your eyes and ears.
• Use electric tools with care. Use a Safety Trip Switch.
• It is easier and quicker if this shed is erected by two people.
• Your shed must be level. Achieve this by either levelling the
ground or by using blocks.
Tools Required:
Select your site:
Safety:
Before you start:

NOTTINGHAM PARTS LIST
Descripon Size Qty
PACK ONE - SHED
Standard Door 895 x 1780 1
Front Wall Panel 300 x 2177 1
Front Wall Panel 1200 x 2177 2
Back Wall Panels 1200 x 1937 3
Side Raking Wall Panels (1L, 1R) 1410 x 2152 2
Cedar Corner Clashings - Front 65 x 17 x 2152 2
Cedar Corner Clashings - Back 65 x 17 x 1962 2
15 x 17 Std Cedarbead 15 x 17 x 1937 2
30 x 17 Long Cedarbead 30 x 17 x 1937 1
15 x 17 Long Cedarbead 15 x 17 x 2152 4
Bargeboards 90 x 17 x 1850 2
Door Stop 45 x 45 x 900 1
Door Lintel 405 x 900 1
Silicone Tube 300g 1
Weatherstrip 50mm x 20m Roll 1
Seners 45 x 45 x 3600 2
Building Paper 1370 x 5400 1
Roong Sheets 875 x 1820 4
Roong Sheet—2 pan 390 x 1820 1
Purlins 70 x 45 x 3720 2
Spoung 3715mm 2
15mm Packer 15 x 45 x 1720 1
Hardware Pack
Tek Screws 14G x 75mm, CL4 60
Framing Nails 75 x 3.15mm 50
Bead Nails 50 x 2.5mm 75
Clouts (Cladding nails) 30 x 2.5mm 70
Colour Rivets 3.2 x 9.6mm 50
Roong Screws 50mm 36
Door Handle 1
Door Latch 1
Door Handle Screws 3/16 x 2.5” 2
Instrucons 1
PACK TWO - FLOOR (if required)
Floor Boards 150 x 25 x 1490 24
Floor Joists 70 x 45 x 3590 4
Floor Nails 50 x 2.5mm 200
Packed by: Date: / /
PG 2

NOTTINGHAM CONCRETE FLOOR - OPTION-
Step 1: Establish size of shed and excavate sucient area. Re-
member to allow for rear roof overhang up to 150mm, and
120mm on each end.
Step 2: Ensure that the base substrate is compacted rmly.
We suggest that the slab should be 80mm thick in the middle
and 100mm thick around the edges.
Step 3: Lay boxing to the required size, the raised slab
size should be 2685 x 1485mm and at least 30mm
above the ground line.
Step 4: Lay plasc sheeng if required. Plasc sheeng under slab
will prevent moisture coming through from underneath.
Step 5: Pour concrete and screed ush
Building a Raised Concrete Base
100mm
80mm
100mm
PG 3

NOTTINGHAM FLOOR - OPTIONAL
PG 4
Step 1: Lay out oor joists, spacing them evenly
as shown. Using 50mm ooring nails, nail a oor
board on each end, ensuring ends are ush with
joists. Make sure oor is level and joists are sup-
ported at 900mm centres.
Step 2: Lay out remaining oor boards. Measure
diagonals to ensure measurements are equal (i.e.
oor is square). Rip down last oor board to suit
gap, and nail o oor with 50mm ooring nails (8
nails per board).
Step 3: Nail plasc weather strip to edge of oor on
all four sides, with 30mm clouts, (approx 3-4 nails
per side) ensuring top edge is ush with top of oor.
This isn't required if shed is on a concrete base.
Step 4: Unpack panels and idenfy wall panels
and door posions as per plan on following page.
Select two panels that go either side of a corner
(i.e. end and standard panel) and stand together.

NOTTINGHAM WALL PLAN
15 x 17mm Std Cedar bead
30 x 17mm Std Cedar bead
Corner Clashing
45 x 15mm Packer
Tek Screws (To secure walls to the oor)
Please note: The walls are not screwed down to the oor unl all the walls
are erected, the roof is in place and the doors are about to be installed.
PG 5
NOTTINGHAM WALL PLAN
1410R 1410L
1200
1200
1200 1200 1200
NOTE: FRONT WALL IS THE HIGH WALL.

NOTTINGHAM WALLS
PG 6
Step 5: Screw wall panels together using 75mm
Tek screws (3 per short panel, 4 per long panel),
ensuring side raking wall panels are inside the
front and back wall panels as per wall plan.
Step 6: Silicone edge of weatherboards on standing
panel and nail on cedar beads with 5 x bead nails.
(Refer to wall plan for correct beads).
Make sure bead is properly sealed to avoid leaks.
Note: On standard panels only, top of bead is bev-
elled to allow for slope of roof.
Step 7: Silicone and nail remaining beads on each
panel. Screw panels together using 3 Tek Screws
per join and 4 on the longer joins on gable end
panels.
Step 8 Silicone and nail 15mm bead each side of
door way.

NOTTINGHAM TOP STIFFENER
NOTTINGHAM TOP LINTEL
PG 7
Step 9: Using 4 x 75mm tek screws screw
door lintel to studs. Ensure outside cedar
weatherboard on lintel is ush with weather-
boards each side .
Door lintel shown from inside
Door lintel shown from outside.
Step 10: Using 75mm framing nails, nail both top
plate seners into front and back wall panels
studs, as shown using 2 nails per stud. Ensure
ends are ush before nailing.
Note Front sener is bevelled to suit roof angle.
Step 11: Using 30mm clouts nail top cedar boards
to Seners (2-3 per board). Predrill holes to stop
boards from spling.

NOTTINGHAM CORNER CLASHINGS
NOTTINGHAM ROOF
PG 8
Step 12: Silicone and nail 15 x 17mm beads on all cor-
ners as shown using 5 x 50mm beading nails, per
bead.
Step 13: Silicone and nail corner clashings on all cor-
ners as shown using 5 x bead nails per clashing. Note
long clashings at the front, short clashings at the rear.
Ensure clashings are ush with the top of side panel
as shown.
Silicone both edges of clashing to ensure this doesn't
leak.
Step 14: Posion both purlins on roof as shown.
Top purlin and boom purlins should be against
top plate seners. Using 75mm framing nails,
nail purlins to end panels (2 nails per join)
Step 15: Using 1 x 75mm tek screw , screw
boom purlin to top plate centrally in shed.
Repeat with top purlin.

Step 16: Ensure shed is square, by measuring diagonals at top corner of wall panels.
Using 30mm clouts, nail building paper on to purlins.
Note: Temporary screw packaging mber to underside of Purlins to hold purlins straight
unl roof is screwed o
Step 17: Posion rst full sheet with rib ush
with ends of purlins and 200mm overhang at
front of shed.
Using a 50mm Roong Screw with Washer,
screw through the rib into the front purlin.
Note. Predrilling with a 3mm drill bit may
make this easier.
Step 18: Lay out remaining full roof sheets.
Rivet these sheets together, 2 rivets per join,
to make 1 large roof panel as shown in photo.
Tack remaining front corner and back corner
ensuring edge of sheet is ush with end of
purlins and front overhang is correct.
Ensure purlins are straight and screw through
each rib into the front and back purlins.
NOTTINGHAM ROOF
PG 9

NOTTINGHAM DOOR
Step 19: Fit door stop in door way. Check all wall
panels are straight and panels either side of door
stop are ght against door stop. Screw panels to
oor using 1 x 75mm tek screw per panel. Screw
near the panel joins, where possible.
Nail door stop to oor using 75mm framing nails.
Step 20: Fit Door in posion as shown.
Step 21: Using 3 x 50mm Framing screws, screw door stud
to panel ensuring height is correct.
Check that door opens and closes correctly and height is
correct.
Fit handle as shown. Aach with 2 x handle screws, pushing
screws into back of plasc handle to create a thread. Aach
and ghten latch to square sha.
Using 5 x 50mm beading nails, nail 20mm packer onto side
of door opening as shown in Wall plan on pg. 5.
PG 10

NOTTINGHAM BARGE
PG 11
Step 22: Aach barges with 2 x 50mm
bead nails into each purlin.
Remember to remove all drill lings from your colour steel roof.
Your shed is now complete. You may protect Cedar by staining cedar weatherboards if
required.
Step 23: Aach spoung channels to
front and rear of roof, leaving ap-
proximately 5mm at each end for
water to run o. One rivet through
both end ribs, then every second rib
between.

CEDAR SHED WARRANTY
GUARANTEE TO CUSTOMER
Congratulaons on purchasing a quality New Zealand made Cedar Shed manufactured by Riverlea Group Limited. With proper care and aenon this
product will oer you many years of use.
WARRANTY ON METAL CLADDING
Your new shed is guaranteed for the benet of the original purchaser, against defecve material or faulty workmanship for een years from date of
purchase. Riverlea Group Limited will, at its discreon, replace or repair any faulty or defecve materials within this me on condion that due care
and maintenance has been carried out as detailed below.
TERMS AND CONDITIONS
This warranty does not cover Cedar sheds with steel roong if it is installed outside the inland corrosion zone or areas where the
corrosion rate is more than 200g/m2 (as published by BRANZ)
1. The warranty does not cover damage or failure due to improper assembly.
2. This warranty does not cover damage through force majeure or other cause beyond the control of Riverlea Group Limited.
3. This warranty is void if maintenance as detailed below and in the assembly manual has not been adhered to.
4. This warranty does not cover natural variaons, expansion, contracons as can be reasonably expected from a mber product.
Painng or coang of your Cedar Shed with a dark colour will cause increased mber temperature and movement which will render this warranty
null and void.
Beyond the exclusions above, Riverlea Group Limited will repair or replace the damaged or faulty product. The balance of the original warranty will
cover any repaired or replaced material. Riverlea Group Limited will not be liable for any consequenal loss or damage, labour or transport costs.
All claims must be made within 21 days of discovery.
MAINTENANCE
The following are the minimum maintenance requirements for Cedar Sheds manufactured by Riverlea Group Limited. Please refer to your assembly
manual for more details.
Immediately coat all cedar walling cladding with “Endurance Cedar Wall Protector”. Cedar walls are to be regularly recoated according to applicaon
instrucons on the product packaging.
Immediately coat all cedar shingle roong with “Endurance Cedar Shingle Protector” Cedar shingles are to be regularly recoated
according to applicaon instrucons on the product packaging.
All steel roong is to be kept clean and free of debris and washed annually with a hose and so brush.
Timber oors, where supplied are to be kept out of direct water contact or runo
The above guidelines will guarantee you a superior Cedar Shed that will oer you many years of outstanding usefulness.
Please visit www.duratuf.co.nz/warranty to validate the Warranty on your shed.
Click on the Warranty Registraon Link and complete all details.
If you are unable to access the computer, please phone us on 0800 438 274 and one of the customer services team will help you to acvate the
warranty on your garden shed.
Many thanks, from the Team at Riverlea Group.
