Roadmaster RAC10 User manual

RAC10 12 Volt DC
Air Compressor
Read First!
Dear Customer,
CONGRATULATIONS. The RAC10 12 Volt DC Air Compressor, when used
as described, will give you years of dependable service in your car, truck,
RV, or mini-van. We have taken numerous measures in quality control to
ensure that your product arrives in top condition, and will perform to your
satisfaction. In the rare event that your RAC10 12 Volt DC Air Compressor
contains a damaged or missing item, does not perform as specified,
requires warranty service, or you have a installation problem,
DO NOT
RETURN THIS PRODUCT TO THE STORE .Please call our TOLL-FREE
number US (800-445-1797) and ask to speak with a member of our
technical service team, or submit your questions by e-mail to
[email protected] and a member of our technical
service team will respond by e-mail to your questions. Our in-house
technical service team will expedite delivery of your part, advise you on
installation, or help troubleshoot a problem with you. If your product needs
warranty service, our technical service team representative will help you
obtain the fastest remedy possible under the warranty.
• Molded Heavy-Duty Plastic Housing
• 24" Reinforced Rubber Hose with Braided Nylon Covering
• 10 foot Power Cable with Cigarette Lighter Plug
• Air Pressure Gauge
• Operates with 12 Volt DC
• Dimesions 8.8" (L) X 5.9" (W) X 3.13" (H)
22.54 cm (L) x 16.51 cm (W) x 8.89 cm (H)
Specifications
Features & Functions
Limited Warranty
1-800-445-1797
PLEASE DO NOT RETURN PRODUCT TO STORE.
Visit us on the WEB
WWW.ROADMASTERUSA.COM
For Information and Technical Assistance, Call Toll-Free in U.S.A. and Canada.
Give Us A Call, We'll Help You Install!Give Us A Call, We'll Help You Install!
After 6 minutes of continuous
use, shut compressor off and
let cool for 30 minutes.
Make sure to read manufacturer
inflation recommendations prior
to inflating their products.
Make sure to read manufacturer
inflation recommendations prior
to inflating their products.
Valve Stem
Adaptors
Locking Air Nozzle
Locking
Air Nozzle
Accessories Compartment
With Supplied Adaptors.
Cigarette Lighter Plug
in stored position
ON/OFF Switch
Air Pressure Gauge
To Operate:
1. The locking nozzle on the end of the air hose
can be attached to most valve stems or to any
of the 3 adaptors supplied.
2. For use with a valve stem, place the locking
air nozzle over the end of the valve stem, make
sure the valve stem is fully inserted, then move
the lever on the locking air nozzle to the locked
position.
2a. For use with one of the supplied adaptors,
fully insert the threaded end of the adaptor into
the locking air nozzle, then move the lever on
the locking air nozzle to the locked position.
3. Turn on the RAC10 air compressor unit with
the switch located on the top of the RAC10.
4. Hold the air hose in place and watch the air
pressure gauge on the top of the RAC10. When
the desired air pressure based on
manufacturer’s recommended specification is
reached, turn off the compressor.
5. Disconnect the air hose from the item that
has been inflated.
6. Wrap power cord and air hose around the
RAC10.
7. Store air compressor in safe place. Keep
away from children.
TOP VIEW BOTTOM VIEW
Locking
Air Nozzle
in Stored
Position
Use the adaptors to inflate
air mattresses, sports balls
and toys.
Ventilation Slots
We recommend when operating the
RAC10, that your vehicle's engine be
running to prevent a drain of power from
the vehicle's battery. Never operate any
vehicle in a closed, non-vented area.
ROADMASTER (USA) CORP.®products are designed and manufactured to provide a high level of trouble-free performance.
ROADMASTER (USA) CORP.®warrants, to the original purchaser, that its products are free from defects in material and
workmanship for 30 days from the date of original purchase. As part of our commitment to product excellence,
ROADMASTER (USA) CORP.®and/or its affiliates routinely improve the designs, materials or production methods of its
existing products. Because it is impractical to publicize all changes in every product, we reserve the right to make such
changes without notice.
CONDITIONS OF WARRANTY:
If during the 30 day warranty period your new product is found to be defective, ROADMASTER (USA) CORP.®will repair
such defect, or replace the product, without charge for parts or labor subject to the following conditions:
1. All repairs must be performed by ROADMASTER (USA) CORP.®and/or its affiliates in Eatontown, New Jersey.
2. The equipment must not have been altered or been damaged through negligence, accident, or improper operation.
3.
The replacement of parts are exempted from this warranty when replacement is necessary due to normal wear and tear.
4. All warranty claims must be accompanied by a copy of the sales receipt or bill of sale.
5. Repair or replacement parts supplied by ROADMASTER (USA) CORP.®under this warranty are protected only for the
unexpired portion of the original warranty.
6. In the case of car stereos, this warranty does not extend to the elimination of car static or motor noise; correction of
antenna problems; costs incurred for the removal or reinstallation of the product; damage to tapes, speakers, accessories or
car electrical systems.
7. ROADMASTER (USA) CORP. will not be responsible for any charge incurred for installation.
OWNER'S RESPONSIBILITIES:
ROADMASTER (USA) CORP.®will make every effort to provide warranty service within a reasonable period of time.
SHOULD YOU HAVE ANY QUESTIONS ABOUT SERVICE RECEIVED, OR IF YOU WOULD LIKE ASSISTANCE IN
OBTAINING SERVICE, PLEASE CALL toll-free 1-800-445-1797, 8:30am - 4:30pm EST.
In order to provide you with the proper warranty service, we request that you adhere to the following procedure:
1. Include a copy of your sales receipt or bill of sale with your unit when it is returned for warranty service.
2. If it is necessary to return your product for service, please return it securely packed, preferably in the original shipping
carton, and freight and insurance prepaid to the following address: ROADMASTER (USA) CORP.®, Service Department, 41
James Way, Eatontown, New Jersey 07724.
3. Please include a detailed explanation of the problem you are having.
4. If your product is found by ROADMASTER (USA) CORP.®to have a defect in material or workmanship, within the warranty
period, it will be repaired or replaced at no charge and returned to you prepaid. Where permitted by Iaw ROADMASTER
(USA) CORP.’S liability shall be limited to that set forth in this warranty. This warranty shall be the exclusive remedy of the
purchaser.
ROADMASTER (USA) CORP.®makes no other warranty of any kind, expressed or implied; and all implied warranties, are
hereby disclaimed by ROADMASTER (USA) CORP.®and excluded from this warranty, ROADMASTER (USA) CORP.®, its
affiliates, the manufacturer, distributor and seller shall not be liable for any injury, loss or damage, incidental or consequential,
arising out of the use or intended use of the product.
©2005 ROADMASTER (USA) CORP.® , All designs, logos and images are the exclusive property of
ROADMASTER (USA) CORP.® and/or it’s affiliates. All rights reserved. 081505 Printed in China 00000
