Craftsman 919.184160 User manual

OWNERS
MANUAL
IMPORTANT:
Read the Safety Guidelines and
All Instructions Carefully Before
Operating.
MODEL NO.
919.184160
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
SINGLE STAGE
AIR COMPRESSOR
ASSEMBLY
OPERATION
MAINTENANCE
REPAIR PARTS
Record in the spaces provided.
(1) The model number which can be found
on the label on the front of the air tank
saddle.
(2) The code number which can be found
on the foil label on the side of the air
tank.
(3) The Manufacturer's Number (ASME
Code Compressors only) is located on
the metal data plate which is welded
onto the side of the air tank. (This data
plate is painted the same color as the
tank.)
(4) The Motor Manufacturer's name which
is located on the motor label.
(5) The Motor Mfg. number - also located
on the motor label.
Retain these numbers for future refer-
ence.
Model No._________________________
Code No._________________________
D20410 Rev. 2 12/11/00

2 — Eng
D20410
Page
SAFETYGUIDELINES ........................................................................... 2
WARNING CHART................................................................................. 3-5
SPECIFICATION CHART ...................................................................... 6
GLOSSARY ............................................................................................ 6
ACCESSORIESFOR USE WITH
SEARSAIRCOMPRESSORS .......................................................... 6
GENERALINFORMATION .................................................................... 7
DESCRIPTION OF OPERATION ........................................................... 7
INSTALLATIONAND BREAK-IN PROCEDURES ................................. 7-9
LocationofAir Compressor .............................................................. 7
Piping ............................................................................................... 8
Lubrication and Oil ........................................................................... 8
WiringInstructions ............................................................................ 8
WiringDiagram ................................................................................. 8
Break-In Procedures ......................................................................... 9
OPERATINGPROCEDURES ................................................................. 9
MAINTENANCE ..................................................................................... 9-11
AirCompressor ................................................................................ 9
Air Filter - Inspection and Replacement ............................................ 9
Oil - Checking and Changing ............................................................ 10
Air Tank - Draining Water .................................................................. 10
Check Valve - Inspection and Replacement ..................................... 10
Safety Valve Inspection .................................................................... 10
Motor ................................................................................................ 10
Belt - Replacement .......................................................................... 10
Pulley and Flywheel - Alignment ....................................................... 11
TROUBLESHOOTINGGUIDE ............................................................. 11-12
AIRCOMPRESSORDIAGRAM ............................................................. 14
Parts List .......................................................................................... 15
COMPRESSORPUMP DIAGRAM ........................................................ 16
Parts List .......................................................................................... 17
HOW TO ORDER REPAIR PARTS ............................................. Back Cover
WARRANTY ............................................................................... Back Cover
CAUTION indicates a potentially hazardous situation
which, if not avoided, may result in minor or moder-
ate injury.
This manual contains information that is important for you to know and understand. This information relates to
protecting YOUR SAFETY and PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information,
we use the symbols to the right. Please read the manual and pay attention to these sections.
DANGERindicatesanimminentlyhazardoussituation
which, if not avoided, will result in death or serious
injury.
CAUTION used without the safety alert symbol indi-
cates a potentially hazardous situation which, if not
avoided, may result in property damage.
WARNINGindicatesapotentiallyhazardoussituation
which, if notavoided, could result in deathor serious
injury.
SAFETY GUIDELINES - DEFINITIONS
TABLE OF CONTENTS

3 — Eng D20410
HAZARD
IMPORTANT SAFETY INSTRUCTIONS
RISK OF BURSTING
IT IS NORMAL FOR ELECTRICAL CONTACTS WITHIN THE
MOTOR AND PRESSURE SWITCH TO SPARK.
IF ELECTRICAL SPARKS FROM COMPRESSOR COME INTO
CONTACT WITH FLAMMABLE VAPORS, THEY MAY IGNITE,
CAUSING FIRE OR EXPLOSION.
RESTRICTING ANY OF THE COMPRESSOR VENTILATION
OPENINGS WILL CAUSE SERIOUS OVERHEATING AND
COULD CAUSE FIRE.
UNATTENDED OPERATION OF THIS PRODUCT COULD
RESULT IN PERSONAL INJURY OR PROPERTY DAMAGE.
ALWAYS OPERATE THE COMPRESSOR IN A WELL VENTI-
LATED AREA FREE OF COMBUSTIBLE MATERIALS,
GASOLINE OR SOLVENT VAPORS.
IF SPRAYING FLAMMABLE MATERIALS, LOCATE COMPRES-
SOR AT LEAST 20 FEET AWAY FROM SPRAY AREA. AN
ADDITIONAL LENGTH OF HOSE MAY BE REQUIRED.
STORE FLAMMABLE MATERIALS IN A SECURE LOCATION
AWAY FROM COMPRESSOR.
NEVER PLACE OBJECTS AGAINST OR ON TOP OF COM-
PRESSOR. OPERATE COMPRESSOR IN AN OPEN AREA AT
LEAST 12 INCHES AWAY FROM ANY WALL OR OBSTRUC-
TION THAT WOULD RESTRICT THE FLOW OF FRESH AIR TO
THE VENTILATION OPENINGS.
OPERATE COMPRESSOR IN A CLEAN, DRY, WELL VENTI-
LATED AREA. DO NOT OPERATE UNIT INDOORS OR IN ANY
CONFINED AREA.
ALWAYS REMAIN IN ATTENDANCE WITH THE PRODUCT
WHEN IT IS OPERATING.
SAVE THESE INSTRUCTIONS
IMPROPER OPERATION OR MAINTENANCE OF THIS PRODUCT COULD RESULT IN SERIOUS INJURY AND PROPERTY
DAMAGE. READ AND UNDERSTAND ALL WARNINGS AND OPERATING INSTRUCTIONS BEFORE USING THIS EQUIPMENT.
RISK OF EXPLOSION OR FIRE
AIR TANK: THE FOLLOWING CONDITIONS COULD LEAD TO A WEAKENING OF THE TANK, AND RESULT IN A
VIOLENT TANK EXPLOSION AND COULD CAUSE PROPERTY DAMAGE OR SERIOUS INJURY.
DRAIN TANK DAILY OR AFTER EACH USE. IF TANK DEVEL-
OPS A LEAK, REPLACE IT IMMEDIATELY WITH A NEW TANK OR
REPLACE THE ENTIRE COMPRESSOR.
NEVER DRILL INTO, WELD, OR MAKE ANY MODIFICATIONS
TO THE TANK OR ITS ATTACHMENTS.
THE TANK IS DESIGNED TO WITHSTAND SPECIFIC OPERATING
PRESSURES. NEVER MAKE ADJUSTMENTS OR PARTS
SUBSTITUTIONS TO ALTER THE FACTORY SET OPERATING
PRESSURES.
FOR ESSENTIAL CONTROL OF AIR PRESSURE, YOU MUST
INSTALL A PRESSURE REGULATOR AND PRESSURE GAUGE
TO THE AIR OUTLET OF YOUR COMPRESSOR. FOLLOW THE
EQUIPMENT MANUFACTURERS RECOMMENDATION AND
NEVER EXCEED THE MAXIMUM ALLOWABLE PRESSURE
RATING OF ATTACHMENTS. NEVER USE COMPRESSOR TO
INFLATE SMALL LOW-PRESSURE OBJECTS SUCH AS
CHILDREN’S TOYS, FOOTBALLS, BASKETBALLS. ETC.
1. FAILURE TO PROPERLY DRAIN CONDENSED WATER
FROM THE TANK, CAUSING RUST AND THINNING OF THE
STEEL TANK.
2. MODIFICATIONS OR ATTEMPTED REPAIRS TO THE TANK.
3. UNAUTHORIZED MODIFICATIONS TO THE UNLOADER
VALVE, SAFETY VALVE, OR ANY OTHER COMPONENTS
WHICH CONTROL TANK PRESSURE.
4. EXCESSIVE VIBRATION CAN WEAKEN THE AIR TANK
AND CAUSE RUPTURE OR EXPLOSION.
ATTACHMENTS & ACCESSORIES:
EXCEEDING THE PRESSURE RATING OF AIR TOOLS, SPRAY
GUNS, AIR OPERATED ACCESSORIES, TIRES AND OTHER
INFLATABLES CAN CAUSE THEM TO EXPLODE OR FLY
APART, AND COULD RESULT IN SERIOUS INJURY.
WHAT CAN HAPPEN HOW TO PREVENT IT
WHAT CAN HAPPEN HOW TO PREVENT IT

4 — Eng
D20410
HAZARD
WHAT CAN HAPPEN HOW TO PREVENT IT
RISK FROM FLYING OBJECTS
THE COMPRESSED AIR STREAM CAN CAUSE SOFT TISSUE
DAMAGE TO EXPOSED SKIN AND CAN PROPEL DIRT, CHIPS,
LOOSE PARTICLES AND SMALL OBJECTS AT HIGH SPEED,
RESULTING IN PROPERTY DAMAGE OR PERSONAL INJURY.
ALWAYS WEAR ANSI Z87.1 APPROVED SAFETY GLASSES
WITH SIDE SHIELDS WHEN USING THE COMPRESSOR.
NEVER POINT ANY NOZZLE OR SPRAYER TOWARD ANY
PART OF THE BODY OR AT OTHER PEOPLE OR ANIMALS.
ALWAYS TURN THE COMPRESSOR OFF AND BLEED PRES-
SURE FROM THE AIR HOSE AND TANK BEFORE ATTEMPTING
MAINTENANCE, ATTACHING TOOLS OR ACCESSORIES.
THE COMPRESSED AIR FROM YOUR COMPRESSOR IS NOT
SAFE FOR BREATHING! THE AIR STREAM MAY CONTAIN
CARBON MONOXIDE, TOXIC VAPORS OR SOLID PARTICLES
FROM THE TANK.
SPRAYED MATERIALS SUCH AS PAINT, PAINT SOLVENTS,
PAINT REMOVER, INSECTICIDES, WEED KILLERS, CONTAIN
HARMFUL VAPORS AND POISONS.
ALWAYS OPERATE AIR COMPRESSOR OUTSIDE IN A CLEAN,
WELL VENTILATED AREA. AVOID ENCLOSED AREAS SUCH AS
GARAGES, BASEMENTS, STORAGE SHEDS, WHICH LACK A
STEADY EXCHANGE OF AIR. KEEP CHILDREN, PETS AND
OTHERS AWAY FROM AREA OF OPERATION.
NEVER INHALE AIR FROM THE COMPRESSOR EITHER
DIRECTLY OR FROM A BREATHING DEVICE CONNECTED TO
THE COMPRESSOR.
WORK IN AN AREA WITH GOOD CROSS-VENTILATION. READ
AND FOLLOW THE SAFETY INSTRUCTIONS PROVIDED ON
THE LABEL OR SAFETY DATA SHEETS FOR THE MATERIAL
YOU ARE SPRAYING. USE A NIOSH/MSHA APPROVED
RESPIRATOR DESIGNED FOR USE WITH YOUR SPECIFIC
APPLICATION.
WHAT CAN HAPPEN HOW TO PREVENT IT
RISK TO BREATHING
YOUR AIR COMPRESSOR IS POWERED BY ELECTRICITY.
LIKE ANY OTHER ELECTRICALLY POWERED DEVICE, IF IT IS
NOT USED PROPERLY IT MAY CAUSE ELECTRIC SHOCK.
REPAIRS ATTEMPTED BY UNQUALIFIED PERSONNEL CAN
RESULT IN SERIOUS INJURY OR DEATH BY ELECTROCU-
TION.
ELECTRICAL GROUNDING: FAILURE TO PROVIDE ADEQUATE
GROUNDING TO THIS PRODUCT COULD RESULT IN SERIOUS
INJURY OR DEATH FROM ELECTROCUTION. SEE GROUND-
ING INSTRUCTIONS.
NEVER OPERATE THE COMPRESSOR OUTDOORS WHEN IT IS
RAINING OR IN WET CONDITIONS.
NEVER OPERATE COMPRESSOR WITH COVER COMPONENTS
REMOVED OR DAMAGED.
ANY ELECTRICAL WIRING OR REPAIRS REQUIRED ON THIS
PRODUCT SHOULD BE PERFORMED BY AUTHORIZED
SERVICE CENTER PERSONNEL IN ACCORDANCE WITH
NATIONAL AND LOCAL ELECTRICAL CODES.
MAKE CERTAIN THAT THE ELECTRICAL CIRCUIT TO WHICH
THE COMPRESSOR IS CONNECTED PROVIDES PROPER
ELECTRICAL GROUNDING, CORRECT VOLTAGE AND
ADEQUATE FUSE PROTECTION.
WHAT CAN HAPPEN HOW TO PREVENT IT
RISK OF ELECTRICAL SHOCK

5 — Eng D20410
MOVING PARTS SUCH AS THE PULLEY, FLYWHEEL AND BELT
CAN CAUSE SERIOUS INJURY IF THEY COME INTO CONTACT
WITH YOU OR YOUR CLOTHING.
ATTEMPTING TO OPERATE COMPRESSOR WITH DAMAGED
OR MISSING PARTS OR ATTEMPTING TO REPAIR COM-
PRESSOR WITH PROTECTIVE SHROUDS REMOVED CAN
EXPOSE YOU TO MOVING PARTS AND CAN RESULT IN
SERIOUS INJURY.
NEVER OPERATE THE COMPRESSOR WITH GUARDS OR
COVERS WHICH ARE DAMAGED OR REMOVED.
ANY REPAIRS REQUIRED ON THIS PRODUCT SHOULD BE
PERFORMED BY AUTHORIZED SERVICE CENTER PERSON-
NEL.
HAZARD
RISK FROM MOVING PARTS
WHAT CAN HAPPEN HOW TO PREVENT IT
TOUCHING EXPOSED METAL SUCH AS THE COMPRESSOR
HEAD OR OUTLET TUBES, CAN RESULT IN SERIOUS BURNS.
NEVER TOUCH ANY EXPOSED METAL PARTS ON COMPRES-
SOR DURING OR IMMEDIATELY AFTER OPERATION. COM-
PRESSOR WILL REMAIN HOT FOR SEVERAL MINUTES AFTER
OPERATION.
DO NOT REACH AROUND PROTECTIVE SHROUDS OR ATTEMPT
MAINTENANCE UNTIL UNIT HAS BEEN ALLOWED TO COOL.
WHAT CAN HAPPEN HOW TO PREVENT IT
A PORTABLE COMPRESSOR CAN FALL FROM A TABLE,
WORKBENCH OR ROOF CAUSING DAMAGE TO THE COM-
PRESSOR AND COULD RESULT IN SERIOUS INJURY OR
DEATH TO THE OPERATOR.
ALWAYS OPERATE COMPRESSOR IN A STABLE SECURE
POSITION TO PREVENT ACCIDENTAL MOVEMENT OF THE
UNIT. NEVER OPERATE COMPRESSOR ON A ROOF OR
OTHER ELEVATED POSITION. USE ADDITIONAL AIR HOSE
TO REACH HIGH LOCATIONS.
WHAT CAN HAPPEN HOW TO PREVENT IT
OIL CAN LEAK OR SPILL AND COULD RESULT IN FIRE OR
BREATHING HAZARD, SERIOUS INJURY OR DEATH CAN
RESULT. OIL LEAKS WILL DAMAGE CARPET, PAINT OR OTHER
SURFACES IN VEHICLES OR TRAILERS.
WHAT CAN HAPPEN HOW TO PREVENT IT
ALWAYS PLACE COMPRESSOR ON A PROTECTIVE MAT WHEN
TRANSPORTING TO PROTECT AGAINST DAMAGE TO VEHICLE
FROM LEAKS. REMOVE COMPRESSOR FROM VEHICLE
IMMEDIATELY UPON ARRIVAL AT YOUR DESTINATION.
RISK OF PROPERTY DAMAGE WHEN TRANSPORTING
COMPRESSOR
(Fire, Inhalation, Damage to Vehicle Surfaces)
RISK OF BURNS
ESW-99 — 9/26/99
RISK OF FALLING

6 — Eng
D20410
Model No.
Max. Developed HP
Displacement CFM at Max. Pressure
Bore
Stroke
Voltage - Single Phase
MinimumBranchCircuitRequirement
*Fuse Type
Amperage at Max. Pressure
Air Tank Capacity - Gallons
ApproximateCut-inPressure
ApproximateCut-outPressure
SCFM@ 90 psig
SCFM@ 40 psig
UL Listed
919.184160
6.5
15
2 7/8
2"
220
20 amp
Fusetron Type "T"
15
60 gal ASME
100
125
10.5
13.0
Yes
*A circuit breaker is preferred. Use only a fuse or circuit breaker that is the same rating as the branch
circuit the air compressor is operated on.
CFM: Cubic feet per minute.
SCFM:Standardcubicfeetper minute; a unit of measure
of air delivery.
PSIG: Pounds per square inch gauge; a unit of measure
of pressure.
ASME:AmericanSocietyofMechanicalEngineers;made,
tested, inspected and registered to meet the standards
of the ASME.
UL Listed: Underwriters Laboratories; samples of com-
pressoroutfits taken from production were submitted to
UL and found to comply with their requirements for
design and performance.
Cut-Out Pressure: When you turn on your air compres-
sorand it begins to run, air pressure in theairtankbegins
to build. It builds to a certain high pressure before the
motor automatically shuts off - protecting your air tank
frompressurehigher than its capacity. The high pressure
at which the motor shuts off is called "cut-out pressure."
Cut-InPressure:Whilethemotoris off, air tank pressure
drops as you continue to use your accessory. When the
tank pressure drops to a certain low level the motor will
re-start automatically. The low pressure at which the
motorautomaticallyre-startsis called "cut-in pressure."
To Lock-Out Power: Place a lock on the line power
switch so no one else can turn on the power.
The following accessories are available through the current Power and Hand Tool Catalog or full-line Sears stores.
• SPRAY GUNS
• BLOW GUNS
• AIR CAULKING GUNS
• AIR POWERED WASHER GUNS
• SAND BLASTERS
• AIR BRUSHES
• IN LINE FILTERS
• TIRE AIR CHUCKS
• PAINT TANKS
• AIR TANKS
• INFLATOR KITS
• QUICK CONNECTOR SETS
(various sizes)
• AIR PRESSURE REGULATORS
• OIL FOG LUBRICATORS
• AIR TOOLS
Sanders
Drills
Impact Wrenches
Hammers
• AIR HOSE:
1/4", 3/8" OR 1/2" I.D.
in various lengths
SPECIFICATION CHART
GLOSSARY
ACCESSORIES FOR USE WITH SEAR AIR COMPRESSORS

7 — Eng D20410
Youhavepurchased an air compressor unit consisting of
a two cylinder, single stage air compressor pump, an
ASMEair tank, associatedcontrolsandinstruments. This
air compressor must be permanently mounted in place.
Your air compressor can be used for operating paint
spray guns, air tools, caulking guns, grease guns, air
brushes, sandblasters, inflating tires and plastic toys,
spraying weed killers, insecticides, etc. An air pressure
regulator is usually necessary for most of these applica-
tions. Regulators can be purchased from most Sears
storesor through the current Sears Power andHandTool
Catalog.
Separateair transformers whichcombinethe functions of
airregulationand/ormoistureanddirtremovalshouldbe
used where applicable.
Some form of piping or shut-off valve must be installed
beforeoperatingtheaircompressor.A1/2"NPTshut-off
globe valve should be installed at the air compressor
tank. Do not use a ball valve.
Location of the Air Compressor
Operate the air compressor in a clean, dry and well
ventilated area. The air intake filter must be kept clear of
obstructions which could reduce air delivery of the air
compressor. The air compressor should be located at
least12" away from wallsorother obstructions that could
interfere with the flow of air through the fan bladed
flywheel. The air compressor crankcase and head are
designed with fins to provide proper cooling. If the
humidity is high, a Sears air filter can be installed to
remove excessive moisture.
The air compressor should be as near to air outlets as
possiblein order to avoid longpipelines.Do not place the
air compressor where heat is excessive.
Pressure Switch: The pressure switch automatically
starts
the motor when the air tank pressure drops below the
factoryset"cut-in"pressure.Itstopsthemotorwhenthe
air tank pressure reaches the factory set "cut-out"
pressure.
Pressure Release Valve: The pressure release valve is
designed to automatically release compressed air from
the compressor head and the outlet tube when the air
compressor reaches "cut-out" pressure or is shut off. If
the air is not released, the motor will try to start but will
be unable to. The pressure release valve allows the
motortorestartfreely.Whenthemotorstopsrunning,air
will be heard escaping for a few seconds. No air should
be heard leaking when the motor is running.
SafetyValve: If the pressure switch does not shut off the
aircompressoratornear its cut-out pressure setting, the
safety valve will protect against high pressure by "pop-
ping out" at its factory set pressure (slightly higher than
the pressure switch cut-out setting).
Air Compressor Pump: To compress air, the pistons
move up and down in the cylinders. On the downstroke,
airisdrawn in through the air intakefilterandthenthrough
the air intake valves. The exhaust valve remains closed.
On the upstroke of the piston, air is compressed. The
intake valves close and compressed air is forced out
through the exhaust valves, through the outlet tube,
through the check valve and into the air tank. Working air
is not available until the compressor has raised air tank
pressure above that required at the air outlet.
Check Valve: When the air compressor is operating, the
check valve is "open," allowing compressed air to enter
the air tank. When the air compressor reaches "cut-out"
pressure, the check valve "closes," allowing air pressure
to remain inside the air tank. If the air is not unloaded, the
motor will try to start, but will be unable to. The check
valve allows the motor to re-start freely.
GENERAL INFORMATION
DESCRIPTION OF OPERATION
INSTALLATION AND BREAK-IN PROCEDURES

8 — Eng
D20410
EXCESSIVE VIBRATION MAY WEAKEN THE
AIR TANK AND CAUSE AN EXPLOSION.
THE OUTFIT MUST BE MOUNTED AS
DESCRIBED AND ILLUSTRATED BELOW.
Piping
Plastic or PVC pipe is not designed for use
with compressed air. Regardless of its
indicated pressure rating, plastic pipe can
burst from air pressure. Use only metal pipe
for air distribution lines.
If a pipe line is necessary, use pipe that is the same size
as the air tank valve. Piping that is too small will restrict
the flow of air. If piping is over 100 feet long, use the next
larger size. Bury underground lines below the frost line
and avoid pockets where condensation can gather and
freeze. Apply pressure before underground lines are
covered to make sure all pipe joints are free of leaks.
Lubrication and Oil
Compressors are shipped without oil. Do not attempt to
operate this air compressor without first adding oil to the
crankcase.
Place unit on a level surface. Remove oil fill plug and
slowly add a special compressor oil such as Sears 9-
16426orSAE-20-20W SF motor oil until itisevenwiththe
1. The air compressor must be bolted to the floor.
Bolting holes are provided in the base feet.
2. Mountthe air compressor onasolid level foundation
with no strain to the air tank feet. Solid shims may
be used if necessary.
top of the oil fill hole. (It must not be allowed to be lower
than3/8"- 6 threads down - from the top.) Whenfillingthe
crankcase,the oil flows very slowly. If theoilis added too
quickly, it will overflow and appear to be full. (Crankcase
oil capacity is 16 fluid ounces.) Under winter-type condi-
tions use SAE 10W oil. (Multi-viscosity oil - 10W30 - will
leave carbon deposits on critical components reducing
performance and compressor life.) Replace oil fill plug.
Wiring Instructions
IMPROPER GROUNDING CAN RESULT IN
ELECTRICAL SHOCK. WIRING OF THE
PRESSURE SWITCH, ELECTRIC MOTOR
AND MANUAL ON/OFF SWITCH SHOULD
BE DONE BY A LICENSED ELECTRICIAN
IN ACCORDANCE WITH NATIONAL AND
LOCAL CODES AND ORDINANCES.
Toprevent addedcurrentdraw and motoroverheatingwe
recommendtheuse of 12 gauge (AWG) wire, notexceed-
inga 70 foot length. The wire must be ratedataminimum
temperature of 75oC.
Whenconnecting wires, make sure that: (1)theelectrical
box is large enough; (2) service is of adequate amperage
rating; (3) the supply line has the same electrical charac-
teristics (voltage, cycles and phase) as the motor; (4) the
line wire is the proper size and (5) no other equipment is
operated from the same line. Various national and local
codes and standards have been set up covering electri-
calapparatusand wiring. These should be consulted and
observed. Our recommended wire sizes may be smaller
than the minimum set up by local ordinances. If so, the
larger size wire should be used to prevent excessive line
voltage drop. For wiring instructions, see the diagram
inside the pressure switch cover.
Electrical wiring must be located away from hot surfaces
such as the compressor head, compressor cylinder or
compressor outlet tube.

9 — Eng D20410
Break-In Procedures
Serious damage may result if the following
break-in instructions are not closely fol-
lowed.
This procedure is required only once; before the air
compressor is put into service. Some form of piping or
shut-off valve must be installed before beginning the
break-in procedure. A 1/2" NPT shut-off globe valve
should be installed at the air compressor tank. Do not
use a ball valve.
1. Recheck compressor wiring. Make sure wires are
secureatallterminalconnections.Freeall contacts
of loose wire cuttings, etc.
2. Check oil level in the crankcase before operation.
The oil level should be even with the top of the fill
hole and must not be allowed to be lower than 3/8"
(six threads down) from the top at any time. Add oil
if level is low.
3. Opentheshut-offvalvefully,topermitairtoescape
and to prevent pressure build-up in the air tank.
4. Turn ON the air compressor.
5. Run the air compressor for 30 minutes to seal the
rings and lubricate all internal surfaces.
6. Checkallairlinefittingsandconnections/pipingfor
air leaks by applying a soap solution. Correct as
necessary. Even minor leaks can cause this air
compressor to overwork, resulting in premature
break-downor inadequate performance.
7. Check for excessive vibration and noise. Adjust air
compressor belt guard as necessary to eliminate
chatter. Re-adjust or shim the air compressor feet,
if necessary for proper level.
8. Close the shut-off valve and let the air compressor
pumpuptocut-out pressure. Turn the air compres-
sor off and check oil level. Add oil if necessary.
Connect the air hose to the air outlet adapter.
Your compressor is now ready for use.
1. Before attaching an air hose or accessory, make
sure the pressure switch OFF/AUTO lever is in the
"OFF" position.
2. Attach hose and accessory.
TOO MUCH AIR PRESSURE CAUSES A
HAZARDOUS RISK OF BURSTING. CHECK
THE MANUFACTURER'S MAXIMUM
PRESSURE RATING FOR AIR TOOLS AND
ACCESSORIES. THE REGULATOR OUTLET
PRESSURE MUST NEVER EXCEED THE
MAXIMUM PRESSURE RATING.
Serious damage may result if the following
break-in instructions are not closely fol-
lowed. Compressed air from the outfit may
contain water condensation and oil mist.
Do not spray unfiltered air at an item that
could be damaged. Some air operated tools
or devices may require filtered air. Read the
instructions for the air tool or device.
3. Turn the compressor on and allow tank pressure to
build. The motor will stop when tank pressure
reaches cut-out pressure.
Your outfit is ready for use.
Air Compressor
A clean air compressor runs cooler and provides longer
service. Clean or blow off fins and any other parts of the
aircompressorthat collect dust or dirt. Do not place rags,
containers or other material on or against the ventilation
openings in the belt guard. Adequate ventilation is nec-
essary to maintain proper air compressor operating
temperature.
Air Filter - Inspection and
Replacement
NOTE
Keep the air filter clean at all times. Do not
operate the compressor with the air filter
removed.
TOO MUCH AIR PRESSURE CAUSES A HAZARDOUS RISK OF BURSTING. CHECK THE
MANUFACTURER'S MAXIMUM PRESSURE RATING FOR AIR TOOLS AND ACCESSORIES. THE
REGULATOR OUTLET PRESSURE MUST NEVER EXCEED THE MAXIMUM PRESSURE RATING.UNIT
CYCLES AUTOMATICALLY WHEN POWER IS ON. WHEN DOING MAINTENANCE, YOU MAY BE
EXPOSED TO VOLTAGE SOURCES, COMPRESSED AIR OR MOVING PARTS. PERSONAL INJURIES
CAN OCCUR. BEFORE PERFORMING MAINTENANCE OR REPAIR, TURN OFF AND LOCK OUT
ELECTRIC POWER AND BLEED OFF AIR TANK PRESSURE. NEVER OPERATE THE COMPRESSOR
WITH THE BELT GUARD REMOVED.
OPERATING PROCEDURES
MAINTENANCE

10 — Eng
D20410
A dirty air filter will not allow the compressor to operate
at full capacity. Before you use the compressor, check
the air filter to be sure it is clean.
If it is dirty, remove the screws and filter retainer. Pull out
the filter, replace with new.
Oil - Checking and Changing
Overfilling with oil will cause premature
compressor failure. Do not overfill.
Checkoillevel in the crankcase daily. The oil level should
be even with the top of the fill hole and must not be
allowed to be lower than 3/8" from the top (6 threads) at
anytime.Itisrecommendedthat the oil be changed after
every100hoursofoperation.Todraintheoil,removethe
oildrainplugandcollecttheoilinasuitablecontainer.Be
sure to replace the plug securely before adding new oil.
Use a special compressor oil such as Sears 9-16426 or
SAE-20-20W SF motor oil. (Crankcase oil capacity is 16
fluid ounces.) Under extreme winter conditions use 10
weight oil.
Air Tank - Draining Water
WATER WILL CONDENSE IN THE AIR
TANK. IF NOT DRAINED, THE WATER WILL
CORRODE AND WEAKEN THE AIR TANK
CAUSING A RISK OF AIR TANK RUPTURE.
Watershould be drained from the air tank after each use.
Operate the unit to apply 15-20 PSIG and open the drain
cock. Continue operating unit until all moisture is re-
moved from the air tank. Close the drain cock tightly.
NOTE
If drain cock valve is clogged, release air
pressure in air tank. The drain cock valve
can then be removed, cleaned and rein-
stalled.
Check Valve - Inspection and
Replacement
Remove the check valve for inspection or replacement if
air tank pressure will not build up. Use the following
procedure to inspect, clean or replace the check valve.
1. Release air pressure from the air tank.
2. Loosen the top and bottom nuts and remove the
outlet tube.
3. Unscrew the check valve (turn counterclockwise)
using a 7/8" diameter 1/2" socket wrench.
4. Check that the valve disc moves freely inside the
check valve and that the spring holds the disc in the
upper, closed position. The check valve may be
cleaned with a solvent.
5. Apply sealant to the check valve threads.Reinstall
the check valve (turn clockwise). The valve stem
should still move freely do not over tighten.
6. Replace the outlet tube and tighten top and bottom
nuts.
Safety Valve - Inspection
IF THE SAFETY VALVE DOES NOT WORK
PROPERLY OVER-PRESSURIZATION MAY
OCCUR, CAUSING AIR TANK RUPTURE
OR EXPLOSION. OCCASIONALLY PULL
THE RING ON THE SAFETY VALVE TO
MAKE SURE THAT THE SAFETY VALVE
OPERATES FREELY. IF THE VALVE IS
STUCK OR DOES NOT OPERATE
SMOOTHLY, IT MUST BE REPLACED WITH
THE SAME TYPE OF VALVE.
Motor
The motor has a thermal overload protector. If the motor
overheatsforanyreason,theoverloadprotectorwillshut
off the motor. The motor must be allowed to cool down
before restarting. De-energize power supply. To restart,
depress the reset button located on the end of the motor
and energize the power supply.
NOTE
If the overload protector shuts the motor
off frequently, check for a possible voltage
problem. Low voltage can also be sus-
pected when:
1. the motor does not get up to full power
or speed;
2. fuses blow out when the motor is
started;
3. lights dim when motor is started and
remain dim while it is running.
Belt - Replacement
SERIOUSINJURY OR DAMAGEMAY OCCUR IFPARTS OF
THE BODY OR LOOSE ITEMS GET CAUGHT IN MOVING
PARTS. NEVER OPERATE THE COMPRESSOR WITH THE
BELT GUARD REMOVED. THE BELT GUARD SHOULD BE
REMOVED ONLY WHEN THE POWER TO THE COMPRES-
SOR IS DISCONNECTED.
The motor is mounted on an adjustable motor base.
To replace belt:
1. Turn off and lock out power source.
2. Remove screws from the back of the belt guard.
3. Loosen the four motor mounting screws.
4. Slide the motor toward the compressor pump.
5. Remove belt and replace.

11 — Eng D20410
NOTE
The belt should be centered over the
grooves on the flywheel and motor pulley.
6. Pushthemotor backintoregular position andtighten
boltssecurely.Propertensionisapproximately1/4"
belt deflection measured midway between the pul-
ley and flywheel when a 3 pound weight or equiva-
lent finger pressure is applied at this point. A loose
belt will squeal at compressor start-up.
7. Replace beltguard and screws.
Pulley and Flywheel - Alignment
Thecompressorflywheelandmotor pulley must be inline
(in the same plane) within 1/16" to assure belt retention
withinsheavegrooves.The motor mounting holes on the
saddle are skewed to square the motor with the com-
pressor mounting hole as the belt is tensioned. To check
alignment, disconnect electrical power and remove the
beltguard. Place a straightedgeagainsttheoutside of the
flywheel and measure the distance from it to the nearest
groove. Alignment is achieved when the other end of the
straightedge is within 1/16" of the measured dimension
at the pulley grooves. Squareness is achieved when the
pulley grooves are an equal distance from the straight-
edge on both sides of the motor shaft.
UNIT CYCLES AUTOMATICALLY WHEN POWER IS ON. WHEN DOING MAINTENANCE, YOU MAY BE
EXPOSED TO VOLTAGE SOURCES, COMPRESSED AIR OR MOVING PARTS. PERSONAL INJURIES
CAN OCCUR. BEFORE PERFORMING MAINTENANCE OR REPAIR, TURN OFF AND LOCK OUT
ELECTRIC POWER AND BLEED OFF AIR TANK PRESSURE. NEVER OPERATE THE COMPRESSOR
WITH THE BELT GUARD REMOVED.
PROBLEM CAUSE CORRECTION
Excessivetank pressure -safety
valve pops off.
Pressure switch does not shut off motor
whencompressor reaches"cut-out" pres-
sure.
Pressure switch must be replaced.
Tighten fittings where air can be heard escaping.
Check fittings under soapy water solution. DO NOT
OVER-TIGHTEN.
Tube or hose fittings are not tight enough.
Air leaks at fittings or hose.
Defective or dirty check valve.
Air leaks at check valve. Remove and clean or replace check valve. DO NOT
OVER-TIGHTEN.
Remove and replace the release valve.
Defective pressure switch release valve.
Air leaks at pressure switch re-
leasevalve.
Air leaks at air tank welds. Defective air tank. Air tank must be replaced.
Possible defect in safety valve.
Air leak from safety valve. Operate safety valve manually be pulling on ring. If
valve still leaks, it should be replaced.
Restrictedcheck valve. Remove and clean or replace.
Loose pulley. Tighten pulley set screw.
Low oil level. Maintain prescribed oil level.
Loose flywheel. Tighten screw.
Loose compressor bolts. Check bolts. Tighten as required.
Tighten belt as per instructions under Belt Replace-
mentabove.
Carbon build-up. Remove the head and valve plate. Clean the valve
plate and the top of the piston. (Be sure carbon does
notfall into the cylinder.) Reassemble to 25-30ft.lbs.
using new gasket and torque screws.
Loose belt.
TROUBLESHOOTING GUIDE
DO NOT DRILL INTO, WELD OR
OTHERWISE MODIFY AIR TANK. IT
WILL BE WEAKENED.

12 — Eng
D20410
PROBLEM CAUSE CORRECTION
Motor will not run. Motor overload protection switch has tripped. Let the motor cool off and reset switch by pressing
the red button located on the end of the motor.
Tank pressure exceeds pressure switch "cut-
in" pressure.
Motor will start automatically when tank pressure
drops below "cut-in" pressure of pressure switch.
Check valve stuck - fails to relieve head pres-
sure; motor cannot start.
Remove and clean or replace. (Do not overtighten.)
Loose electrical connections. Checkwiring connection inside pressure switchand
terminal box area.
Possible defective capacitor. Return to Sears Service Center for inspection or
replacementif necessary.
Possible defective motor. Have checked at a local Sears Service Center.
Fuse blown, circuit breaker tripped. 1. Check fuse box for blown fuse and replace if
necessary. Re-set circuit breaker. Do not use a
fuse or circuit breaker with higher rating than
that specified for your particular branch circuit.
2. Check for proper fuse; only "Fusetron" Type T
fusesare acceptable.
3. Check for low voltage conditions.
4. Remove check valve and clean or replace if it is
stuck open or closed.
5. Disconnectthe otherelectrical appliancesfrom
circuit or operate the compressor on its own
branch circuit.
Pressure release valve on pressure switch has
not unloaded head pressure.
Bleed the line by pushing the lever on the pressure
switch to the "OFF" position, opening the pressure
releasevalve. Ifthe valve still doesn't open, it mustbe
replaced.
Replace with new.
Dirty air filter.
Restricted air intake.
Compressor is not supply-
ing enough air to operate
accessories.
Prolonged excessive use of air. Decrease amount of air usage.
Compressoris not largeenough for airrequire-
ment.
Check the accessory air requirement. If it is higher
than the pressure supplied by your air compressor,
you need a larger compressor.
Restricted air intake filter. Replace air intake filter.
Loose belt. Adjust belt tension.
Hole in hose. Check and replace if required.
Check valve restricted. Remove and clean or replace.
Air leaks. Tighten fittings. (See Air Leaks Section of Trouble-
shooting Guide.)
Excessivebelt wear. Loose belt. Adjust tension.
Tight belt. Adjust tension.
Loose pulley. Checkfor wornkeyway orpulley bore.Also checkfor
bent motor shaft. Replace parts if necessary.
Loose belt. Adjust belt tension.
Squealing sound.
There is no oil in the compressor. Add oil.

13 — Eng D20410
REPAIR PARTS

14 — Eng
D20410
AIR COMPRESSOR DIAGRAM

15 — Eng D20410
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
19
20
21
22
23
24
25
26
27
29
30
31
32
34
35
36
37
38
39
40
41
42
43
KEY
NO. PARTNUMBER DESCRIPTION
SSF-953-ZN
CAC-22-2
SSF-8113-ZN
CAC-2-1
CAC-362-1
SSP-9401
SSP-7812
SSP-7811
SS-8553
C-BT-224
SS-391
Z-C-PU-2861
SUDL-65
CAC-4205
Z-MO-3022-1
CAC-1331
SSF-928
CAC-4336
SS-3222-CD
CAC-95
TIA-4150
GA-360-B
39124607
SSV-6-B
SS-1525-CD
D20343
SSF-8150
LA-2269-1
LA-3266
LA-3105
SS-2707
TA-4438
SSW-7367
SS-2110
CAC-437-2
AC-0720
SSF-3152
LA-3108
Z-D22624
LA-3027
Self Tapping Screw 10 x 5/8 (4 used)
Belt Guard
LockNut
Bracket
Belt Guard Closure
ConnectorBody
Nut-Sleeve Assembly 1/2" (2 used)
Nut Sleeve Assembly 1/4"
ConnectorBody
Poly-V Belt
SetScrew
MotorPulley
Key, Motor Shaft
MotorCord Assembly
Motor6.5 HP
Pressure Release Tube
Cap Screw 5/16"-18-1" (4 used)
PressureSwitch
PipePlug
Manifold
Safety Valve
Gauge
Screw (2 used)
Globe Valve
Isolator Washer (4 used)
PerformanceLabel
Locking Flange Nut (4 used)
MaintenanceLabel
WarningLabel
CraftsmanLabel
Drain Valve
Air Receiver - 60 gal.
Strain Relief
Nipple
Check Valve
OutletTube
Locking Cap Screw (4 used)
Warning - Hot Surface Label (2 used)
Compressor Pump Assembly (includes Key No. 43 thru 78, inclusive)
Drain Tank Label
PARTS LIST

16 — Eng
D20410
COMPRESSOR PUMP DIAGRAM
80
79

17 — Eng D20410
44
45
46
47
Z-48
Z-49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
74
75
76
77
78
79
80
KEY
NO. PARTNUMBER DESCRIPTION
PartsOrdering Information
Key No. 56, 57, 58 only available in Ring Kit KK-4313.
Key No. 19, pressure release valve and nut is available as part of Kit KK-5020.
Key No. 50, 51 and 53 only available in Valve Kit KK-4275.
Key No. 46, 49, 55, 67, 69, 77, and 78 are available in Gasket Kit K-0159.
+
*
+
+
+
*
*
*
*
*
SSF-935
AC-0322
AC-0333
SSF-955
CAC-4213
CAC-291-1
265-25
SSF-9821
CAC-294
265-196-1
Z-CAC-4212-1
Z-CAC-54-2
Z-CAC-56-1
Z-CAC-58
Z-CAC-57
CAC-55-1
Z-265-19
CAC-207
Z-265-410
SSF-927
AC-0205
SST-104
SSP-486
SSP-505
DAC-276
265-16-1
Z-D22270
SSF-925
SSN-1018
265-2
SSN-1014-ZN
SSF-3039-ZN
AC-0169
265-6
SSF-6627
AC-0330
NOT SHOWN
D20377
AC-0331
D20410
*
*
Screw #8-32 x 3/8" (2 used)
Filter Plate Assembly
FeltFilter
Screw 3/8"-16 x 1-1/2" (5 used - Torque 25 to 30 ft. lbs.)
Head Assembly (includes 2 ea. Key #50 & 4 ea. Key #51)
Head Gasket
Intake Flapper Valve
(2 used on head)
Screw, THD Forming 5-40x1/4 (8 used)
Restrictor Plate (2 used)
Flapper Valve with Corner Bevels
(2 used on valve plate)
Valve Plate Assembly (includes 4 ea. Key #51 & 2 ea. Key #52 & 53)
Valve Plate Gasket
Compression Ring (4 used)
Oil Ring (4 used)
Oil Ring Expander (2 used)
Piston
Piston Pin (2 used)
Piston Pin Plug (4 used)
Connecting Rod Assembly (2 used Includes two SSF-927 screws)
Screw 1/4"-20 x 1-1/8" (2 used)
Crankcase and Cylinder
Ball Bearing (2 used)
Pipe Plug, 3/8-18" NPT (2 used)
Oil Plug
Base
Base Gasket
Crankshaft
Screw 1/4 - 20 x 7/8" (8 used)
Wavy Spring Washer
Flywheel
Washer
Screw
Oil Seal
VentFilter
Stud 3/8" - 16 Taptite (1 used - Torque 25 to 30 ft. lbs.)
SolbergFilter
SpecificationLabel
SolbergFilterReplacement
OwnersManual
PARTS LIST

OWNERS
MANUAL
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
SINGLE STAGE
AIR COMPRESSOR
For the repair or replacement parts you need
Call 7 am - 7 pm, 7 days a week
1-800-366-PART
(1-800-366-7278)
For in-home major brand repair service
Call 24 hours a day, 7 days a week
1-800-4-REPAIR
(1-800-473-7247)
For the location of a
Sears Parts and Repair Center in your area
Call 24 hours a day, 7 days a week
1-800-488-1222
For information on purchasing a Sears
Maintenance Agreement or to inquire
about an existing Agreement
call 9 am - 5 pm, Monday-Saturday
1-800-827-6655
MODEL NO.
919.184160
When requesting service or ordering
parts, always provide the following
information:
• Model Number
• Part Number
• Part Description
• Name of Item
FULL ONE YEAR WARRANTY
AIR COMPRESSOR
If this air compressor fails due to a defect in
material or workmanship within one year
from the date of purchase, RETURN IT TO
THE NEAREST SEARS REPAIR CENTER
THROUGHOUT THE UNITED STATES
AND SEARS WILL REPAIR IT, FREE OF
CHARGE. IF PURCHASED FROM OR-
CHARD SUPPLY HARDWARE, RETURN
TO THE NEAREST ORCHARD STORE
AND ORCHARD WILL REPAIR IT, FREE
OF CHARGE.
Ifthis air compressor is usedfor commercial
or rental purposes, the warranty will apply
for ninety days from the date of purchase.
This warranty gives you specific legal rights
and you may have other rights which vary
from state to state.

MANUAL DEL
OPERADOR
IMPORTANTE:
Leer las pautas de seguridad y todas
las instrucciones cuidadosamente
antes de operar.
MODELO NO.
919.184160
Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.
COMPRESOR DE AIRE
DE UNA ETAPA
ENSAMBLAJE
OPERACIÓN
MANTENIMIENTO
REPUESTOS
Registrar el los espacios provistos.
(1) El número de modelo que puede
encontrarse en el rótulo en el frente de
la montura del tanque.
(2) El número de código que puede
encontrarseen elrótulo metálico enun
costado del tanque.
(3) El número del fabricante (sólo en
compresorescon elcódigo ASME) que
estáubicado en la placa de metal
soldada a un costado del tanque de
aire. (Esta placa de datos estápintada
del mismo color que el tanque).
(4) Elnombre delfabricante del motor que
se encuentra en la placa del motor.
(5) El número de motor del fabricante,
también estáubicado en el rótulo del
motor.
Guardarestosnúmerosparareferencia
futura.
Modelo No. ________________________
Código No. ________________________
D20410 Rev. 2 12/11/00

2 —SP
D20410
Página
PAUTAS DE SEGURIDAD ..................................................................... 2
TABLA DE ADVERTENCIAS .................................................................. 3-5
TABLA DE ESPECIFICACIONES .......................................................... 6
GLOSARIO ............................................................................................. 6
ACCESORIOS PARA USAY CON LOS COMPRESORES
DE AIRE DE SEARS ........................................................................ 6
INFORMACIÓNGENERAL .................................................................... 7
DESCRIPCIÓN DE LA OPERACIÓN ..................................................... 7
INSTALACIÓN Y PROCEDIMIENTOS PARA EL ASENTAMIENTO ..... 7-9
Ubicación del Compresor de Aire ..................................................... 7
Tuberías ........................................................................................... 8
Aceite y Lubricación ......................................................................... 8
Instrucciones para el Cableado ........................................................ 8
Diagrama de Cableado ..................................................................... 8
Procedimientosparael Asentamiento .............................................. 9
PROCEDIMIENTOSPARAOPERAR ..................................................... 9
MANTENIMIENTO ................................................................................ 9-11
Compresorde Aire ........................................................................... 9
Filtro de Aire - Inspección y Reemplazo ........................................... 9
Aceite - Inspección y Cambio .......................................................... 10
Tanque de Aire - Drenaje de Agua .................................................... 10
Válvula de Chequeo - Inspección y Reemplazo ............................... 10
Válvula de Seguridad - Inspección ................................................... 10
Motor ................................................................................................ 10
Correa-Reemplazo ......................................................................... 10
Polea del Motor y Polea Volante - Alineamiento ................................ 11
GUÍA PARA DIAGNÓSTICO DE PROBLEMAS ................................. 11-12
DIAGRAMA DEL COMPRESOR DE AIRE ............................................. 14
Lista de Repuestos .......................................................................... 15
DIAGRAMA DE LA BOMBA DEL COMPRESOR DE AIRE ................... 16
Lista de Repuestos .......................................................................... 17
CÓMOORDENAR REPUESTOS ............................................... Contratapa
GARANTÍA ................................................................................. Contratapa
PRECAUCION indica una situación potencialmente
peligrosa, la cual, si no es evitada, podría resultar en
lesionesmenores.
Este manual contiene información que es importante que usted conozca y comprenda. Dicha información se
relaciona con la protección de SU SEGURIDAD PERSONAL y LA PREVENCIÓN DE PROBLEMAS PARA SU
EQUIPO. A fin de ayudarlo a reconocer dicha información usamos los símbolos que se muestran a la derecha.
Sírvase leer este manual y prestar atención a
PELIGROindicauna situacióndeinminente riesgo, la
cual, si no evitada, causarála muerte o lesiones
serias.!
PRECAUCION usado sin el símbolo de seguridad de
alerta indica una situación potencialmente riesgosa la
que, si no es evitada, podría causar daños en la
propiedad.
ADVERTENCIA indica una situación potencialmente
riesgosa, que si no es evitada, podría resultar en la
muerte o lesiones serias.
DEFINICIONES DE NORMAS DE SEGURIDAD
PELIGRO PRECAUCION
ADVERTENCIA PRECAUCION
TABLA DE CONTENIDOS
