Robe ANOLIS Subdrive 4 User manual

1
Version 1.4

2
SubDrive 4
Table of contents
1. Introduction .................................................................................................................... 3
2. Safety information.......................................................................................................... 3
3. Fixture exterior view ...................................................................................................... 4
4. Mounting ......................................................................................................................... 5
5. SubDrive 4 menu ............................................................................................................ 8
5.1 Fixture Address ("A001") ........................................................................................... 8
5.2 Fixture information ("InFo") ........................................................................................ 8
5.3 Personality ("PErS") ................................................................................................... 9
5.4 Manual mode ("Man.C.").......................................................................................... 10
5.5 Test sequences ("tESt")............................................................................................ 10
5.6 Stand-alone setting ("St.AL") .................................................................................. 10
5.7 Special functions ("SPEC") ...................................................................................... 11
6. Technical specications .............................................................................................. 14

3
1. Introduction
The SubDrive 4 serves for power and control up to four ArcSource Submersible II LED modules.
2. Safety information
FOR YOUR OWN SAFETY, PLEASE READ THIS USER MANUAL CAREFULLY
BEFORE POWERING OR INSTALLING YOUR SUBDRIVE 4 !
Save it for future reference.
DANGEROUS VOLTAGE CONSTITUTING A RISK OF ELECTRIC SHOCK IS PRESENT WITHIN THIS UNIT!
The xture was designed for outdoor use and it is intended for professional application only. It is not for house-
hold use.
Make sure that the available voltage is not higher than stated on the xture.
Be careful when removing xture cover in order to get access to the control display and the xture is under
voltage. If you do not need to set the xture, always disconnect the xture from AC power before removing its
cover.
Do not install the xture near an open ame.
Refer servicing to qualied service personnel.
This xture falls under protection class I. Therefore this xture has to be connected to a mains socket outlet
with a protective earthing connection.
Do not connect this xture to a dimmer pack.
Keep combustible materials at least 10 cm away from the xture.
Do not cover the xture with cloth or other materials.
When choosing the installation spot, please make sure that the xture is not exposed to extreme heat or dust.
Only operate the xture after having checked that the housing is rmly closed and all screws are tightly fastened.
Operate the xture only after having familiarized with its functions. Do not permit operation by persons not
qualied for operating the xture.
Please consider that unauthorized modications on the xture are forbidden due to safety reasons!
Please use the original packaging if the xture is to be transported.
If this device will be operated in any way di󰀨erent to the one described in this manual, the product may suf-
fer damages and the guarantee becomes void. Furthermore, any other operation may lead to dangers like
short-circuit, burns, electric shock etc.
Immunity of the equipment is designed for electromagnetic environments E1, E2, E3 according to
the standard EN55103-2 ed.2 Electromagnetic compatibility. Product family standard for audio, video,
audiovisual and entertainment lighting control apparatus for professional use. Part 2: Immunity.
The installation company should check levels of possible interferences above the tested levels E1,E2,E3 given
by this standard (e.g. transmitters in surrounding area) before installing the equipment.
The product (covers and cables) must not be exposed to a high frequency electromagnetic eld higher than 3V/m.
Emission of the equipment complies with the standard EN55032 Electromagnetic compatibility of multimedia
equipment – Emission Requirements according to class B.

4
3. Fixture exterior view
.
1-Top cover 6- DMX In
2-Fastening screws 7- DMX Out
3- Antenna cover 8- LED Output 1
4-Gore valve 9- LED Output 2
5- Power In 10- LED Output 3
11- LED Output 4

5
4. Mounting
Fixture must be installed by a qualied electrician in accordance with all national
and local electrical and construction codes and regulations.
Maximum cable length between between the SubDrive 4 and the ArcSource
Submersible II depends on the operating mode:
Minimum mode: 100 m
Medium mode: 50 m
Maximum mode: 25 m
1. Unscrew four fastening screws (2) on the top cover (1) of the SubDrive 4 to get access to the PCB RB 3091
(14) with a display and connection blocks.
2. Fasten the SubDrive 4 on a non-ammable at surface via four mounting holes (12) of a diameter of 6 mm
in the housing.
3. Remove end caps (2) from cable glands before passing cables into the SubDrive 4.
Five cable glands M20x1.5 serve for cables of diameter of 7-13mm and two cable glands M12x1.5 serve for
cables of diameter of 3-7mm.
We recommend to apply an adequate layer of the paste LOCTITE 5331 on the plastic holder of each cable
gland before inserting it into the body of the gland.
Note: enclosed reducing seal (P/N 13051388) serves for cable of diameter of 4-8mm. Original seal has to be
removed from the cable gland before installing the reducing seal.
This device falls under protection class I. Therefore the SubDrive 4
has to be connected to a mains socket outlet with a protective earthing connection.
4. Connect the power cable to the terminal block (13) and rest of cables to the terminal blocks on the PCB
(14) according to the tables below, check their connection.
5. Fully tighten cable gland nuts and check that cables are properly fastened in the cable glands.
Note: To keep declared IP rating, every cable gland has to be covered with the end cap if this cable gland is
not used for cable passing.

6
Power connection
L N
EU Braun Blue Green/yellow
US Black White Green
DMX connection
D + D - 0V
Data + Data - Data ground (shielding)
ArcSource Submersible II connection
+DATA -
+24V
(red wire)
Communication
(orange wire
Ground
(blue wire)
6. Connect the xture to mains.
7. Set desired parameters in the xture menu ( DMX address, operating mode, etc) by means of display and
four control buttons.
8. Screw the top cover of the xture back. Check that all screws are rmly tightened.

7
RB 3091

8
5. SubDrive 4 menu
The 4-digit display with four buttons serves for setting the xture to desired operating mode ,setting DMX
address and mode, manual control etc.
The four control buttons on the front have the following functions:
ESCAPE button - leaves menu without saving changes.
ENTER button - enters menu, conrms adjusted values and leaves menu.
UP and DOWN buttons - allows you to move between menu items on the same level and set values.
Some menu items depend on selected DMX mode and ArcSource Submersible II variant (RGBW, RGBA,
SW, SC).
5.1 Fixture Address ("A001")
Use this menu to set the DMX address of the xture.
"E. dMX" --- Set DMX address. Select this submenu to set a DMX start address.
To set a DMX address.
1. Use the UP/DOWN buttons to nd “ E.dMX" item.
2. Press the ENTER button.
3. Use the UP/DOWN buttons to select desired start address.
4. Press the ENTER button to conrm the choice.
Note: After switching the xture on, the SubDrive 4 will automatically detect whether DMX 512 data is received
or not.
If there is no data received at the DMX input, the display will start to ash with actually set address.
"dM.Pr" --- DMX mode selection. Select this submenu to select desired DMX mode, for more information
please see DMX protocol.
5.2 Fixture information ("InFo")
Use this menu to read useful information about the xture and connected ArcSource Submersible II modules.
"P.O.tI" ---Power On time. Use the menu to read the number of operation hours of the SubDrive 4 and con-
nected ArcSource Submersible IIs.
"P.O.ti" --- Total Power On time. Use the menu to read a total number of operation hours.
"P.O.t.b." - the item shows total number of operation hours of the SubDrive 4 since
the SubDrive 4 has been fabricated.
"P.O.t.1." - the item shows a total number of operation hours of the ArcSource Submersible II
connected to the LED output 1 since this ArcSource Submersible II has been fabricated.
"P.O.t.2." - the item shows a total number of operation hours of the ArcSource Submersible II
connected to the LED output 2 since this ArcSource Submersible II has been fabricated.
"P.O.t.3." - the item shows a total number of operation hours of the ArcSource Submersible II
connected to the LED output 3 since this ArcSource Submersible II has been fabricated.
"P.O.t.4." - the item shows a total number of operation hours of the ArcSource Submersible II
connected to the LED output 4 since this ArcSource Submersible II has been fabricated.
"P.O.t.r." - Use the menu to read a total number of operation hours since counters were last reset.
"P.t.r.b." - the item shows a total number of operation hours of the SubDrive 4 since
the counter has been last reset.
"P.t.r.1." - the item shows a total number of operation hours of the ArcSource Submersible II
connected to the LED output 1 since the counter has been last reset.
"P.t.r.2." - the item shows a total number of operation hours of the ArcSource Submersible II
connected to the LED output 2 since the counter has been last reset.
"P.t.r.3." - the item shows a total number of operation hours of the ArcSource Submersible II
connected to the LED output 3 since the counter has been last reset.
"P.t.r.4." - the item shows a total number of operation hours of the ArcSource Submersible II
connected to the LED output 4 since the counter has been last reset.
Note: If DMX signal has been disconnected,
DMX address blinks.

9
In order to reset some counter to 0 you have to press and hold the UP and DOWN
buttons and at the same time press the ENTER button.
"dM In" ---DMX input values. Select this function to read DMX values of each channel received by the xture.
"tEMP" ---LED module temperature. Select this menu to read temperature of a connected LED module:
"Cur.t." --- the current temperature of the LED module.
"LEd1." - temperature in the ArcSource Submersible II connected to the LED output 1.
"LEd2." - temperature in the ArcSource Submersible II connected to the LED output 2.
"LEd3." - temperature in the ArcSource Submersible II connected to the LED output 3.
"LEd4." - temperature in the ArcSource Submersible II connected to the LED output 4.
"Hi.tE." --- the maximum temperature of the ArcSource Submersible II since the ArcSource Submersible
II has been fabricated.
"LEd1." - temperature in the ArcSource Submersible II connected to the LED output 1.
"LEd2." - temperature in the ArcSource Submersible II connected to the LED output 2.
"LEd3." - temperature in the ArcSource Submersible II connected to the LED output 3.
"LEd4." - temperature in the ArcSource Submersible II connected to the LED output 4.
"rSEt" --- the maximum temperature of the LED module since the counter was last reset.
"LEd1." - temperature in the ArcSource Submersible II connected to the LED output 1.
"LEd2." - temperature in the ArcSource Submersible II connected to the LED output 2.
"LEd3." - temperature in the ArcSource Submersible II connected to the LED output 3.
"LEd4." - temperature in the ArcSource Submersible II connected to the LED output 4.
In order to reset some counter to 0 you have to press and hold the UP and DOWN buttons
and at the same time press the ENTER button.
The notice "n A" means that no ArcSource Submersible II is connected to LED output.
The temperature can be displayed in either °C or °F - see option “tEM.U“ in the menu “PErS“.
"Ver.S." ---Software Versions. Select this function to read the software version of the SubDrive 4 and
connected ArcSource Submersible II modules.
"VEr.d" --- version of the SubDrive 4.
"VE.L.1" --- version of the ArcSource Submersible II connected to the LED output 1.
"VE.L.2" --- version of the ArcSource Submersible II connected to the LED output 2.
"VE.L.3" --- version of the ArcSource Submersible II connected to the LED output 3.
"VE.L.4" --- version of the ArcSource Submersible II connected to the LED output 4.
"VE.V.i" --- version of the wireless DMX module (if is installed).
5.3 Personality ("PErS")
Use this menu to modify the SubDrive 4 operating behaviour.
"dM.Pr." --- DMX mode. Select this menu item to set a desired DMX mode. Please refer to the DMX protocol
for detail description of each DMX mode.
"M. F.ti." --- Max. fade time. Select this menu item to set a desired max. fade time (0.1-25.5 sec.). This adjusted
fade time inuences fade of red, green, blue, white and dimmer during DMX operation:
If time between two receiving DMX values is > than fade time set in the item “M.F.ti.“, the entire adjusted fade
time will be used.
If time between two receiving DMX values is < than fade time set in the item “M.F.ti.“, the adjusted fade time
will be reduced to ll entire time between the two receiving DMX values.
e.g “M.F.ti.“ = 2sec. and xture has received Red=0 DMX, after 5 seconds will receive red=255 DMX. It means,
that red will go to full intensity during 2 seconds.
“M.F.ti.“ = 8 sec. and xture has received Red=0 DMX, after 5 seconds will receive red=255 DMX. It means,
that red will go to full intensity during 5 seconds. (Max, fade time is reduced from 8 sec. to 5 sec.).
Value "OFF" means, that this function is disabled.
"CAL.t" --- Calibrated colour temperature. The menu item inuences behaviour of the colour channels if
the channels are fully saturated (at RGBW or RGBA version). If the item is set to "Yes", the light output will be
calibrated white 5600K, if the item is set to "no", the light output will be uncalibrated white. The menu item does
not inuence DMX mode 4, 7 at RGBW or RGBA version.
"rGb.C." --- White counting. If this function is On, the white channel uses red, green and blue channels in a
proportion to the intensity of the white channel in order to maximize white output of the LED module.
If you wish to light only with white LEDs at white channel, switch this function to OFF.

10
"tEM.U" --- Temperature Unit. Use this menu item in order to display the ArcSource Submersible II temper-
ature in desired units: °C or °F.
"LoAd" --- Load. Use this menu to set a desired power to the connected ArcSource Submersible IIs. You can
set di󰀨erent power to each LED output (LEd1, LEd2,LEd3, LEd4).
"Min." - Minimum mode (35W).
"MEd." - Medium mode (70W).
"MAX." - Maximum mode (100W).
"In.Po." --- Init e󰀨ect positions. Use this menu to set e󰀨ects to desired positions to which they will move after
switching the xture on without receiving DMX signal.
"dF.SE" --- Default Setting .The menu item sets certain xture parameters to the default (factory) values:
"M. F.ti." = 0.1
"rGb.C." = On
"tEM.U" = °C
"LoAd" =MEd
5.4 Manual mode ("Man.C.")
Use this menu for control the xture without connected DMX console.
To control xture channels.
1. Use the UP/DOWN buttons to nd “ Man.C“ menu.
2. Press the ENTER button.
3. Use the UP/DOWN buttons to select desired e󰀨ect (channel).
List of control channels:
“rEdA.” - all red LEDs saturation
“GrE,A.“ - all green LEDs saturation
“bLu.A.“ - all blue LEDs saturation
“Vhi.A.“ - all white LEDs saturation
"AMb.A" - all amber LEDs saturation
“CtO“ - a colour temperature correction
“V.C.Vh“ - a virtual colour wheel
“Stro“- a strobe, shutter
“dim“- a dimmer
“din.F” a ne dimmer
4.Press the ENTER button and use the UP/DOWN buttons to set value , press the ENTER button to conrm it.
5.5 Test sequences ("tESt")
Use this menu to run test sequences without an external controller, which will show you some possibilities of
using the ArcSource Submersible II.
5.6 Stand-alone setting ("St.AL")
The xtures on a data link are not connected to the controller but can execute pre-set programs which can be
di󰀨erent for every xture.
"Auto" --- Automatic playback. This function allows you to select the program which will be played after
switching the xture on. Selected program will be played continuously in a loop.
1. Use the UP/DOWN buttons to nd “ St.AL" menu.
2. Press the ENTER button.
3. Use the UP/DOWN buttons to select item “Auto“ item.
4. Press the ENTER button.
5. Use the UP/DOWN buttons to select desired program (tESt, PrG.1, PrG2, PrG3). Option "OFF" disables
the function.
6. Press the ENTER button to conrm the choice.
"PLAy" --- Playing program. Use the menu to run desired program.
1. Use the UP/DOWN buttons to nd “PLAy“ menu.
2. Press the ENTER button.
3. Use the UP/DOWN buttons to select desired program (tESt, PrG.1, PrG2, PrG3).
4. Press the ENTER button. The selected program runs in a loop.

11
"Edit" --- Editing program. The xture o󰀨ers 3 freely editable programs (PrG.1-Prog.3) each up to 42 steps.
Every program step includes a fade time-the time taken by the step´s channel status to reach the desired level
and a step time-the total time occupied by the step in the program.
E.g. If fade time=5 second and step time =20 second, e󰀨ects will go to the desired position during 5 seconds
and after that they will stay in this position for 15 seconds before going to the next prog. step
1. Use the UP/DOWN buttons to nd “ St.AL“ menu and press the ENTER button.
2. Use the UP/DOWN buttons to select “Edit“ menu and press the ENTER button.
3. Use the UP/DOWN buttons to select a program you want to edit (PrG.1-PrG.3) and press ENTER button.
4. Use the UP/DOWN buttons to select a desired program step ("St.1" - "St. 42") and press ENTER button.
5. Use the UP/DOWN buttons to select a channel you want to edit and press the ENTER button.
List of editable items:
“P.End” - a total number of program steps (value 1-42). This value should be set before start
programming (e.g. if you want to create program with 10 steps, set P.End=10).
“rEd1” - a red LEDs saturation on output 1
“GrE.1“ - a green LEDs saturation on output 1
“bLu.1“ - a blue LEDs saturation on output 1
“Vhi.1“ - a white LEDs saturation on output 1
"AMb.1" - an amber LEDs saturation on output 1
:
“rEd4” - a red LEDs saturation on output 4
“GrE.4“ - a green LEDs saturation on output 4
“bLu.4“ - a blue LEDs saturation on output 4
“Vhi.4“ - a white LEDs saturation on output 4
"AMb.4" - an amber LEDs saturation on output 4
“CtO“ - a colour temperature correction (for all outputs)
“V.C.Vh“ - a virtual colour wheel (for all outputs)
“Stro“- a strobe, shutter (for all outputs)
“dinn“- a dimmer (for all outputs)
“din.F” a ne dimmer (for all outputs)
“F.tiM.“- a fade time, (0-25.5) seconds
“S.tiM.“ - step time, value (0-25.5) seconds
“CoPy“. – this item duplicates the current prog. step to the next prog. step. The item “P.End” is
increased automatically if you stay in a last program step.
6. Use the UP/DOWN buttons to set a DMX value of the channel and then press the ENTER button.
7. Use the UP/DOWN buttons to select next channel and press the ENTER button.
8. After having set all channels in the current program step, press the ESCAPE button to go by one menu level
back and select another program step.
5.7 Special functions ("SPEC")
"rdML" --- RDM Code. This menu item shows the rst part of the RDM identication code.
"rdMH" --- RDM Code. This menu item shows the second part of the RDM identication code.
"L. tyP." --- LED colour variant. This menu allows to set desired colour variant according to connected LED
module.
"rGbV" – RGBW variant.
"Si. Co."– Single colour variant.
"SM.Wh.– Smart white variant.
"rGbA" - RGBA variant.
Note: some menu items will be changed according to set colour variant!
uPd.b. --- Software update. The menu item allows you to update software in the Control unit and connected
ArcSource Submersible IIs via either serial or USB port of PC.
The following items are required in order to update software:
- PC running Windows or Linux or macOS
- DSU le
- Flash cable RS232/DMX, P/N13050624 (if you want to use a serial port of PC)
- Robe Universal Interface or Robe Universal interface WTX (if you want to use an USB port of PC)
After the software update the xture will be set to default values.

12
To update software in the xture.
1. DSU le is available from Robe web site at WWW.robe.cz.
File with extension zip is intended for Windows (used and tested from XP to W10 on 32/64bit systems).
File with extension tbz is intended for Linux (used and tested on Debian and Ubuntu 32/64bit).
File with extension dmg is intended for macOS (used and tested on OSX up to Sierra) XQuartz required,
install it from https://www.xquartz.org/
Save the download le to a folder on your computer.
In case that you use windows, extract les in the zip le (e.g. DSU_SubDrive_4.zip)
2. Disconnect the xture from DMX controller.
3. If you use the ash cable RS232/DMX, connect a serial port of your computer with DMX input of the xture
by means of the cable.
If you use the Robe Universal Interface, connect a USB port of your computer with the Robe Universal Interface
by means of the USB cable and DMX input of the xture with the DMX output of the Robe Universal Interface
via a DMX cable.
4. Switch the xture to the update mode (tab "SPEC" --> "uPd.b."--> "yES.").
Note: If you do not want to continue in the software update, you have to switch o󰀨 and on the xture
to escape from the updating mode.
We recommend to cancel all running programs on your computer before starting the software update.
5. Double-click the software uploader le (e.g. DSU_SubDrive_4.exe) in
the extracted les. The Software Uploader program will start running.
6. Select correct "COM " number if you use a Flash cable RS232/DMX or select " Robe Universal Interface "
if you use the Robe Universal Interface/Robe Universal Interface WTX and then click on the "Connect" button.
7. If the connection is OK, click the “Start Uploading" button to start software uploading. It will take several
minutes to perform software update.
If the option "Incremental Update" is not checked, all processors will be updated (including processors with
the same software version).
If you wish to update only processors with new version of software, check the “Incremental Update box“.
Avoid interrupting the process. Update status is displayed in the "Info Box" window.

13
When the update is nished, the line with the text “Fixture is successfully updated“ will appear in
this window.
In case upload process is interrupted (e.g. power loss), the xture stays in “Updating mode” and you will have
to repeat the software update again.
Another way, how to update software in the xtures (especially large installation of xtures) is to use the ROBE
Uploader. It is a software for automatized software update of Robe xtures. It takes advantage of RDM
support).
For more information please see https://www.robe.cz/robe-uploader/.

14
6. Technical specications
ELECTRICAL
Input Voltage: 100 - 277 V AC 50 / 60 Hz
Max. Power Consumption: 440W
Max. Output Power per Output
Maximum mode (1A): 100W
Medium mode (700mA): 70W
Minimum mode (350mA): 35W
Max. Output Current per Output
Maximum mode: 1000 mA
Medium mode: 700 mA
Minimum mode: 350 mA
LED Output Voltage: 24V DC
Fuse F1/F2/F3/F4: T4A/T4A/T4A/T4A
CONTROL
Display: 4 - Digit LED, 4 buttons
Wireless DMX (Option): Lumen Radio CRMX Technology
Interface Protocol: USITT DMX512, RDM
Control System: Third Party DMX Controllers
Operating Modes: DMX, Master/Slave, Stand-alone
DMX Modes:
RGBW/RGBA: 7 (2,3,4,9,12,16,3 channels)
SW: 4 (2,2,6,8 channels)
SC: 3 (1,3,4 channels)
Editable Programs: 3 (up to 42 steps each)
Settings/Addressing: Via RDM communicator or Robe Universal Interface (RUNIT)
PHYSICAL
Weight 7.5 kg | 16.53 lbs
Number of LED Output zones: 4
Max. Load Per Zone: 1x ArcSource Submersible II
Total Load: 4x ArcSource Submersible II
Max Cable Length:
100m (Minimum mode)
50m (Medium mode)
25m (Maximum mode)
LED Output Connection: Terminal Block
DMX Connection: Terminal Block
Power Connection: Terminal Block
Finish Options: Standard Colour - Graphite Black (RAL 9011), Silver (RAL 9006)
Cost Option: Custom RAL
Mounting Method: 4 Mounting Holes
Protection Factor: IP66 (CE)
Suitable For Wet Location (US)
IK Rating: IK10
Cooling System: Convection
Operating Temperature Range: -20 °C / +40 °C (-4 °F / +104 °F)
INCLUDED ITEMS
1 x SubDrive 4
1 x Reducing seal (P/N 13051388) for cable diameter of 4-8 mm.
1 x User manual

15
DiMENSIONS
mm [inch]
September 10, 2021
Copyright © 2021 Robe Lighting - All rights reserved
All Specications subject to change without notice
Made in CZECH REPUBLIC by ROBE LIGHTING s.r.o. Palackeho 416/20 CZ 75701 Valasske Mezirici

SubDrive 4 (RGBW, RGBA) - DMX chart, version 1.0
Red - all zones
0-255 Red LEDs saturation control (0-100%) (255=default) proportional
Green - all zones
0-255 Green LEDs saturation control (0-100%) (255=default) proportional
Blue - all zones
0-255
Blue LEDs saturation control (0-100%) (255=default)
proportional
White (Amber) - all zones
0-255
LEDs saturation control (0-100%) (255=default)
proportional
Red - zone 1
0-255
Red LEDs saturation control (0-100%) (255=default)
proportional
Green - zone 1
0-255 Green LEDs saturation control (0-100%) (255=default) proportional
Blue zone 1
0-255 Blue LEDs saturation control (0-100%) (255=default) proportional
White (Amber) - zone 1
0-255 LEDs saturation control (0-100%) (255=default) proportional
Red - zone 2
0-255 Red LEDs saturation control (0-100%) (255=default) proportional
Green - zone 2
0-255 Green LEDs saturation control (0-100%) (255=default) proportional
Blue - zone 2
0-255 Blue LEDs saturation control (0-100%) (255=default) proportional
White (Amber) - zone 2
0-255 LEDs saturation control (0-100%) (255=default) proportional
Red - zone 3
0-255 Red LEDs saturation control (0-100%) (255=default) proportional
Green - zone 3
0-255 Green LEDs saturation control (0-100%) (255=default) proportional
Blue - zone 3
0-255 Blue LEDs saturation control (0-100%) (255=default) proportional
White (Amber) - zone 3
0-255 LEDs saturation control (0-100%) (255=default) proportional
Red - zone 4
0-255 Red LEDs saturation control (0-100%) (255=default) proportional
Green - zone 4
0-255 Green LEDs saturation control (0-100%) (255=default) proportional
Blue - zone 4
0-255 Blue LEDs saturation control (0-100%) (255=default) proportional
White (Amber) - zone 4
0-255 LEDs saturation control (0-100%) (255=default) proportional
Green correction -all zones
1-127 Minus green - uncorrected white proportional
*
*
*
*
*
*
1
9
10
11
12
13
14
15
16
1 2 3
* 1 1
* * *
* * *
* * *
*
* 2 2
* 3 3
* * 4
Value Function Type of
control
*
*
*
4 5 7
1 * *
2 * *
Mode/Channel
6
*
3 * *
4 * *
* *
*
* 6 *
* *
6
7
8 *
* * *
* * *
* 3 *
* * ** * *
* * *
3
4
5
*
* 11 *
* 12 *
*
* * *
* * *
* * *
* * *
*
* * * 7 *
* 8 *
*
* *
* 10 *
* * *
* * *
9 *
* *
* 1 *
* 2 *
*
5
4 *
*
1
2
* * *
1

1 2 3
Value Function Type of
control
4 5 7
Mode/Channel
6
128 Uncorrected white (128=default) step
129-255 Uncorrected white - Plus green proportional
CTO - all zones
0 No function (0=default) step
1-255 Colour temperature correction proportional
Virtual Colour Wheel - all zones
0 No function (0=default) step
1-2 White 2700 K step
3 White 2700 K (tungsten emulation*) step
4-5 White 3200 K step
6 White 3200 K (tungsten emulation*) step
7-9 White 4200 K step
10-12 White 5600 K step
13-15 White 8000 K step
16 Blue (Blue=full, Red+Green+White=0) step
17-55 Red=0, Green->up,Blue =full, White=0 proportional
56 Light Blue (Red=0, Green=full, Blue =full, White=0) step
57 - 95 Red=0, Green=full, Blue->down, White/Amber=0 proportional
96 Green (Red=0, Green=full, Blue =0, White=0) step
97 – 134 Red->up, Green=full, Blue=0, White=0 proportional
135 Yellow (Red=full, Green=full, Blue=0, White=0) step
136 - 174 Red=full, Green->down, Blue=0, White=0 proportional
175 Red(Red=full, Green=0, Blue=0, White=0) step
176 -214 Red=full, Green=0, Blue->up, White=0 proportional
215 Magenta (Red=full, Green=0, Blue=full, White=0) step
216 - 246 Red -> down, Green=0, Blue=full, White=0 proportional
247 Blue (Red=0, Green=0, Blue=full, White=0) step
248-251 Rainbow effect( with fade time) from min.->max. speed proportional
252-255 Rainbow effect(without fade time)from min.->max.speed proportional
Shutter/Strobe - all zones
0-31 Shutter closed step
32-63 Shutter open (32=default) step
64-95 Strobe effect from slow--> fast proportional
96-127 Shutter open step
128-143 Opening pulses in sequences from slow--> fast proportional
144-159 Closing pulses in sequences from fast--> slow proportional
160-191 Shutter open step
192-223 Random strobe effect from slow --> fast proportional
224-255 Shutter open step
Dimmer coarse - all zones
0-255 Dimmer intensity from 0% to 100% (0=default) proportional
Dimmer fine -all zones
0-255 Dimmer intensity from min.—>max. (0=default) proportional
*Halogen lamp effect during dimming
Copyright © 2021 Robe Lighting s.r.o. - All rights reserved All Specifications subject to change without notice
*
*
*
*
*
*
1
* * * 5 * * 2
* * *
1 * *
* * *
2 * *
9 * *
6 * *
7 * *
8 * 3
*
*
*
*
2

SubDrive 4 (SW) - DMX chart, version 1.0
Warm white - all zones
0-255 Warm white LEDs saturation control (0-100%) (255=default) proportional
Cool white - all zones
0-255 Cool white LEDs saturation control (0-100%) (255=default) proportional
Warm white - zone 1
0-255 Warm white LEDs saturation control (0-100%) (255=default) proportional
Cool white - zone 1
0-255 Cool white LEDs saturation control (0-100%) (255=default) proportional
Warm white - zone 2
0-255 Warm white LEDs saturation control (0-100%) (255=default) proportional
Cool white - zone 2
0-255 Cool white LEDs saturation control (0-100%) (255=default) proportional
Warm white - zone 3
0-255 Warm white LEDs saturation control (0-100%) (255=default) proportional
Cool white - zone 3
0-255 Cool white LEDs saturation control (0-100%) (255=default) proportional
Warm white - zone 4
0-255 Warm white LEDs saturation control (0-100%) (255=default) proportional
Cool white - zone 4
0-255 Cool white LEDs saturation control (0-100%) (255=default) proportional
Virtual Colour Wheel - all zones
0No function (0=default) step
1-2 White 2800K step
3-4 White 3200K step
5-6 White 3800K step
7-8 White 4200K step
9-10 White 4600K step
11-12 White 5000K step
13-14 White 5600K step
15-16 White 6300K step
17-247 Warm white --> Cool white proportional
248-255 Reserved
Shutter/Strobe - all zones
0-31 Shutter closed step
32-63 Shutter open (32=default) step
64-95 Strobe effect from slow--> fast proportional
96-127 Shutter open step
128-143 Opening pulses in sequences from slow--> fast proportional
1
2
3
8
*
6
7
*
* 1 3
* * 4
* * *
* * *
* * *
* * *
4
5
* * *
* * *
* * *
* * *
1 * 1
Mode/Channel
2 * 2 *
4
*
Value Function Type of
control
1 2 3
1

Mode/Channel
4
Value Function Type of
control
1 2 3
144-159 Closing pulses in sequences from fast--> slow proportional
160-191 Shutter open step
192-223 Random strobe effect from slow --> fast proportional
224-255 Shutter open step
Dimmer coarse - all zones
0-255 Dimmer intensity from 0% to 100% (0=default) proportional
Dimmer fine - all zones
0-255 Dimmer intensity from min.—>max. (0=default) proportional
Copyright © 2021 Robe Lighting s.r.o. - All rights reserved
All Specifications subject to change without notice
*
*
* * 6
* 2 5
2

SubDrive 4 (SC) - DMX chart, version 1.0
Dimmer - zone 1
0-255 Dimmer intensity from 0% to 100% (0=default) proportional
Dimmer - zone 2
0-255 Dimmer intensity from 0% to 100% (0=default) proportional
Dimmer - zone 3
0-255 Dimmer intensity from 0% to 100% (0=default) proportional
Dimmer - zone 4
0-255 Dimmer intensity from 0% to 100% (0=default) proportional
Shutter/Strobe - all zones
0-31 Shutter closed step
32-63 Shutter open (32=default) step
64-95 Strobe effect from slow--> fast proportional
96-127 Shutter open step
128-143 Opening pulses in sequences from slow--> fast proportional
144-159 Closing pulses in sequences from fast--> slow proportional
160-191 Shutter open step
192-223 Random strobe effect from slow --> fast proportional
224-255 Shutter open step
Dimmer coarse - all zones
0-255 Dimmer intensity from 0% to 100% (0=default) proportional
Dimmer fine - all zones
0-255 Dimmer intensity from min.—>max. (0=default) proportional
Copyright © 2021 Robe Lighting s.r.o. - All rights reserved
All Specifications subject to change without notice
* * 1
Mode/Channel
Value Function Type of
control
1 2 3
* * 2
* * 4
* * 3
* 3 *
* 1 *
1 2 *
