209-1059 MLLWTR TRADITION SCONCE INSTALLATION INSTRUCTIONS
General Notes
1. Unpack the light xture. Check the box thoroughly
for all hardware and loose parts as follows:
A. Sconce Base B. Mounting Bracket C. Screw
D. Screw Cap E. Sconce Shade F. Mounting Ring
2. Rated for 100W bulb Type-A UL listed for damp
locations.
3. If you experience any problems with your Sconce
contact your dealer or Robern directly.
Robern • 701 N Wilson Ave • Bristol, PA 19007
800 877 2376 • FAX [phone]
A. Sconce Base
B. Mounting Bracket
C. Base Fastener
D. Screw Cap
E. Sconce Shade
F. Mounting Ring
Limited Warranty One Year Term
ROBERN warrants to the original purchaser that, it will, at its elec-
tion repair, replace, or make appropriate adjustment to products
made by this company shown to have signicant defects in mate-
rial or workmanship which are reported to ROBERN in writing
within one (1) year from the date of delivery. ROBERN is not
responsible for installation costs.
The warranty is void in the event the product is damaged in transit,
or if damage or failure is caused by abuse, misuse, abnormal
usage, faulty installation, damage in an accident, improper mainte-
nance, or any repairs other than those authorized by ROBERN.
At the expiration of the one year warranty period, ROBERN shall
be under no further obligation under any warranty, expressed or
implied, including the implied warranty of merchantability.
ROBERN shall not be liable for any consequential damages aris-
ing out of or in connection with the use or performance of its
products. Some states do not allow limitations on how long an
implied warranty lasts or do not allow the exclusion or limitation
of incidental or consequential damages, so the above limitation or
exclusion may not apply to you.
Any liability against ROBERN under any implied warranty, includ-
ing the warranty of merchantability, is expressly limited to the
terms of this warranty. Permission to return any merchandise
under this warranty must be authorized by ROBERN and returned
prepaid by the purchaser. Claims under this warranty should be
sent directly to your dealer.
Part List – MLLWTR SCONCE
1. Dimensions of Sconce
1. Overall size of the sconce is shown below, however,
sconces can be adjusted in height.
Model No. Overall
MLLWTR 8”W X 9”H
©2003 Robern
All rights reserved.
2. Selecting Location
A. Clearance from the cabinet must be determined.
B. When opening door of the cabinet, make sure it
will not hit the sconce.
8"
9"
CABFAX# 1059

Fig. A
Fig. B
F
E
A
Note: If your house has metal
electrical boxes, connect the
xture ground wire to the
green ground screw on the
crossbar. If you house is new
or has been rewired and
has plastic boxes, connect
the xture ground wire to the
house ground wire.
209-1059 MLLWTR Tradition Sconce
3. Installation
1. Attach crossbar (B) to the electrical box using the
screws supplied with the box. Sometimes it is
necessary to mount the crossbar at a slight upward
angle (use a washer or two under the lower screw) so
that the weight of the xture doesn’t make it appear
to “droop.” Make sure holes on crossbar (B) line up
with holes on Sconce Base. (A)
WALL MOUNT
ONL
Y
ITEM NO: sconce1-3
DATE: 09052002
A
B
C
D
2. Slip the wires into the electric box and make
connections per Electrical codes.
3. Screw provided base fasteners (C) into crossbar
(B) leaving enough room to allow screw to
pass through the xture base and protrude by
1/8” and 3/16” to allow screw cap (D) to t on end
of base fastener. (C)
4. Shade Installment
1. For proper shade installment,
follow Figure B illustration.
2. Make sure to attach shade before
installing bulb.
REV2 5/06/03
