Robertshaw RS5220C User manual

1
Thank you for purchasing a Robertshaw RS5220C programmable
thermostat. This user’s manual will guide you through the setup of the
RS5220 two stage thermostat. The thermostat should already be
mounted and correctly wired. The default settings will enable the
thermostat to operate efficiently. Before making any changes to the
schedule read the section on Default Settings.
Features
• Pop-Up Wizard
• Automatic changeover
• Circulating Fan
• Worry-Free memory retention
• Easy change battery
• Large back lit display
• Filter change reminder
• Low battery indicator
• Fahrenheit and Celsius displays
• EnergyStar™ compliant
• Dual power
• Adjustable 1st stage temperature differential: 0.5 °F to 3.0 °F (0.5 °C
to 1.5 °C)
• Accuracy within ±1 °F
• Universal staging on multi-stage units
• Automatic heating shutdown if temperature exceeds 99 °F (37 °C)
• Keypad security lockout
• 4 events per day for heating and cooling
• 5-2 day scheduling
• User settable Hi and Lo temperature limits
• Vacation setpoint override
RS5220C
352-00059-001 Rev B
USERS MANUAL

2
Application
The Robertshaw RS5220C thermostat is designed to control gas, electric,
oil, heat pump, and millivolt heating and electric cooling systems. The
RS5220C is a two stage thermostat.
The RS5220C thermostats use 5-2 programming. This means the 5
weekdays will operate on one schedule and the 2 weekend days will
operate on a second schedule
IMPORTANT SAFETY INFORMATION
WARNING:
• Always turn off power at main fuse or circuit breaker panel before
installing, removing, cleaning, or servicing thermostat.
• Read all the information in this manual before installing this
thermostat.
• This is a 24V AC low-voltage thermostat. Do not install on voltages
higher than 30V AC.
• All wiring must conform to local and national building and electrical
codes and ordinances.
• Do not short (jumper) across terminals on the gas valve or at the
system control to test installation. This will damage the thermostat
and void the warranty.
• Do not connect ground to any terminal in this unit.
• This thermostat is configured with automatic compressor protection
to prevent damage because of short cycling or extended power
outages. Short cycle protection provides a delay between heating
and cooling cycles on heat pumps.
Detailed mounting and wiring instructions are explained in the
Installation Manual.
Refer to the Pop-Up Wizard section in the installation manual for a
complete list of factory defaults and contractor settings.
Providing Power to the Thermostat
For wiring diagrams refer to the Installation Manual.
The thermostats will operate using 24V AC or two AA batteries. When
the two AA batteries are installed the thermostat will continue to run if
the 24V AC fails.

3
Installing or Changing the Batteries
To remove the battery compartment gently
squeeze the ribbed edges on both sides.
The battery compartment will pull down from
the thermostat body and will detach. Install
two AA batteries following the polarity as
shown inside the compartment. Place
compartment back into the thermostat.
When the batteries are low the thermostat
will enter a low battery mode.
Low battery mode has two levels.
• LEVEL 1: The low battery icon will be displayed. The
thermostat will continue to operate. Replace the
batteries as soon as possible
• LEVEL 2: The low battery icon will flash. If 24V AC is
present the thermostat will continue to operate if
the batteries are discharged or removed. If 24V AC
is not present the thermostat runs on batteries only
and THE SYSTEM WILL NOT OPERATE. Replace
batteries immediately.
Replace batteries if leaving thermostat unattended for more than
30 days.
The clock will continue to run for 10 minutes when the batteries
are removed.
Display Description
The thermostat display will show information that is being used during
operation or programming. This illustration shows all of the display’s
possibilities with an explanation.
2
1. Event Names (used for editing schedule).
2. Day is displayed on Idle screen. Also used to display day ranges
when editing the schedule (e.g., SAT SUN for weekend).
3. Used with clock to display hold duration (e.g., FOR 2h).
4. On when running a schedule.
5. Used with setpoint.
6. Used along with clock for service reminders (e.g., CHECK HP).
7. Used for time, current setpoint, and some configuration data (e.g.,
filter hours).
8. HVAC mode and status. Icons blink when active. A is for Auto, 2 is
for second stage, E is for emergency.
9. Indicates when security is active.
10. Low battery indicator.
11. Displayed when in vacation hold.
12. Used for ambient temperature and configuration data (e.g., first
stage differential, F or C, etc.).
13. Fan status (rotates when active).
14. Fan mode selected by pressing FAN button.
5
3
4
1
6
7
8
9
10
12 11
13
14

4
Schedule Settings – Defaults
This thermostat is preprogrammed with a schedule that is recommended
by EnergyStar™. The schedule is designed to lower energy costs
year-round.
The default schedule settings are:
Time Cooling °F Heating °F
Morn 6:00 am 78 70
Day 8:00 am 85 62
Eve 6:00 pm 78 70
Nite 10:00 pm 82 62
User Settings – Defaults
During any program changes the display returns back to the operating
display if a button has not been pushed in 10 seconds.
The temperature scale is set to Fahrenheit.
Night light is on.
The first stage differential is 1 °F.
The second stage differential is 2 °F.
The second stage delay is 20 minutes.
Auto changeover is enabled.
Auto changeover deadband is 3 °F.
Filter reminder length is off.
Temperature offset is 0 degrees.
The HI heat limit is 90 °F (32 °C).
The LO cool limit is 45 °F (7 °C)
The vacation temperature settings are set at: heating 60°F, cooling 85 °F.
The operation mode is OFF.
The fan setting is Auto.
The keypad has no password protection.
Refer to the pop up wizard section in the installation manual for a
complete list of factory defaults and contractor settings.
Emergency Heat
Your system may include Emergency Heat. The RS5220C thermostats
have an emergency heat capability for multi stage heat pump systems.
To determine if your system is capable of using emergency heat contact
your contractor. Use the button to enter the EMER mode. An E will
be displayed with the Heat symbol. This mode is used to bypass the
heat pump when it needs servicing or when it cannot keep up with the
heat demand.

5
Auto Changeover
Auto changeover is the ability of the thermostat to switch automatically
between heating settings and cooling settings. This is useful in Spring
and Fall when the days are warm and the nights are cool. In heat mode
if the room continues to warm beyond a set threshold the thermostat
switches to the cool mode and the associated cooling settings. The
reverse is also true.
As the room temperature changes, the thermostat will call for heating or
cooling as needed. To prevent the heating and cooling systems from
overriding each other, an auto changeover deadband is used.
The deadband is the minimum temperature swing before changing from
heating to cooling or vice versa. The larger the deadband the more the
room temperature will vary.
Operating the Thermostat
Any setting can be changed when it is flashing by pushing or
If a button is not pushed for 10 seconds the thermostat returns
to operation.
The following buttons can be accessed from the front panel.
START/STOP SCHEDULE: Switches between running a schedule and
manual (permanent override). Cancels a temporary override.
EDIT SCHEDULE: Use this button to start editing the schedule. Push
repeatedly to move through the selections.
VACATION: Used to set a temporary setpoint for a number of days.
SET TIME: Sequences through the hour, minute and day.
LIGHT BAR: Turns on the display back light for 10 seconds.
FAN: Turns fan to AUTOMATIC, CIRCULATE or ON.
UP ARROW: Raises the setpoint or increases flashing item.
DOWN ARROW: Lowers the setpoint or decreases flashing item.
HEAT/COOL: Toggles through OFF, HEATING, COOLING, and AUTO.
If configured as HP then emergency heat is also displayed.

6
Setting Time and Day
To adjust the time and day settings press the SET TIME button. The hour
will flash. If a button is not pushed in 10 seconds the thermostat returns
to operation. To change the settings:
1. Use the and buttons to change the flashing number.
2. Press the SET TIME button to move through hour, minutes and day
of week.
3. Make changes as needed. They will be saved automatically.
NOTE: The thermostat will not correct for Daylight Saving Time.
The thermostat will now function properly using the default schedule.
Changing the Schedule Settings
This thermostat can operate using a single setpoint by overriding the
schedules. If you will be using this thermostat for single setpoint
operation skip to Overriding the Schedule.
The chart below represents one day’s programming schedule. To make
programming your thermostat quicker and easier, recreate the table
for each day of the week on a separate piece of paper, and refer to it
while programming.
Press START/STOP SCHEDULE at any time to exit and save your settings.
Push START/STOP SCHEDULE. The display will show a day flashing at
the top. If a button is not pushed in 30 seconds the thermostat returns
to normal operation.
Use the or to change the hour of the start time if desired.
Push EDIT SCHEDULE to move to minutes.
Use the or to change the minutes of the start time if desired.
Push EDIT SCHEDULE to move to the heat or cool temperature setting.
Use the or to change the temperature setpoint.
Push EDIT SCHEDULE to move to the other setpoint.
Use or to change the temperature setpoint.
NOTE: Pressing will switch between cooling and heating setpoints.
Pressing Set Time button will switch back to the event time.
NOTE: The heating and cooling setpoints CANNOT be entered as
crossed. That is, the cooling setpoint CANNOT BE lower than
the heating setpoint.
Push EDIT SCHEDULE and repeat this process for the remaining
three settings.
Time Cool Heat
Morning
Day
Evening
Nite

7
After the weekend schedule is complete, the display will show the
weekend schedule. Continue the same steps to program the four
weekend setting
When finished press START/STOP SCHEDULE or wait 30 seconds and
the thermostat will return to operation.
Changing the User Settings
When and are pressed at the same time the thermostat will
display the current settings in order.
To change any setting:
When the setting is visible and flashing press the or
arrows to adjust the number on the screen.
To exit the changes and save:
Press START/STOP SCHEDULE. The thermostat will return
to operation.
SCAL = Scale in °F (Fahrenheit) or °C (Celsius).
CLOC = Set clock to 12 or 24 hour format.
LITE = Display backlight always on ”y” or off ”n”. Also called the
nightlight feature. If the thermostat has been wired with 24V AC
(R and C terminals) then this feature will be displayed and the
setting can be changed.

8
DIFF = The differential keeps the thermostat from turning on for small
changes in temperature. When in Fahrenheit the range is 0.5 to
3.0 Degrees. In Celsius the range is 0.5 to 1.5 Degrees. The
differential is factory set at 1.0 °F (0.5 °C). This means that
whenever the room temperature is more than 1 °F (0.5 °C)
different from the set temperature the system will turn on. If the
system is turning on too often, increase the differential setting.
Note that a larger differential will mean the room temperature
changes more before the system turns on.
DIF2 = Second Stage Differential = Operates with the first stage to
control a second heating/cooling system. This number will be
added to the first stage differential (See: Two Stage Systems).
If the first stage is running too often lower the settings. This will
turn the second stage on to help the first stage. If both stages
are coming on too often then increase this setting to delay the
second stage.
DLY2 = Second Stage Delay = This timer starts when the first stage turns
on. It resets when the first stage turns off. If this timer runs out
the second stage will turn on (See Two Stage Systems).
Auto changeover enable = Makes the auto changeover mode available.
When chosen, the thermostat can automatically switch between
heating and cooling. Note that the High and Low setpoint limits
are not enforced in auto changeover mode.

9
DEDB = Deadband for auto changeover = the number of degrees that the
room temperature can move away from the active setpoint until
heating or cooling is called for. The larger the deadband the
more the room temperature will vary. This can be from heat to
cool or cool to heat.
HI = High Heat Limit = This is the highest allowed heating setpoint. The
user will not be allowed to set a schedule setpoint or override
temperature higher than this value.
NOTE: High Heat Limit is not enforced in auto changover mode.
LO = Low Cool Limit = This is the lowest allowed cooling setpoint. The
user will not be allowed to set a schedule setpoint or override
temperature lower than this value.
NOTE: Low Cool Limit is not enforced in auto changover mode.
VAC HEAT = Vacation Heat Setpoint = This is the temperature setpoint
for the heating system when a vacation override has been
made active.
VAC COOL = Vacation Cool Setpoint = This is the temperature setpoint
for the cooling system when a vacation override has been
made active.

10
CHECK = Timer to remind the home owner to maintain the filter. Default
setting is off. The timer runs when the system is on. It can be
set at 0 (OFF) or up to 9900 hours. When the time expires
CHECK FLTR is displayed. Press the and buttons to
restart the filter timer.
CYCL = Cycle Timer allows a compressor to rest between cycles. Can be
set from 0 to 5 minutes in 1 min increments.
WARNING: A wrong short cycle setting can
damage your equipment. This should only
be changed by a trained HVAC professional.
CAL = Calibration offset. Changes the displayed temperature from the
actual temperature by +3 to -3 degrees in one degree increments.
Increasing the offset by +2 will cause the thermostat to display a
temperature that is 2 degrees higher than the actual room
temperature
Creating a Password – Protect the Settings
The buttons on the front of the thermostat can be locked with a password.
To create a password:
1. Press the and buttons at the same time and hold them in
for 5 seconds.
You will be asked for a 4 digit password.
2. Each digit is set using the and buttons. Press the to
move to the next digit. Press to move back.
3. The password is saved after 5 seconds.
All of the front buttons are now locked out until the password is entered.
Pressing any button will cause to flash.
To unlock the buttons:
1. Push and hold the and buttons for 5 seconds until the
request for password is displayed.

11
2. Enter the digits for the password by pressing the and
buttons. Press the to move to the next digit. Press to
move back.
3. When the correct password is set, wait for 5 seconds to unlock
the system.
4. If the wrong password is entered the display will flash ---- for 5
seconds then return to normal.
Once the security has been disabled, a password needs to be recreated
to protect the settings.
Two Stage Systems
A 2nd stage is a second or additional system
that will provide extra heating or cooling. When
a 2nd stage is operating the display will show
the number 2 by the heat/cool icons.
A temperature differential (default value is 2.0 °F or 1.0 °C) and time
delay (default value 20 minutes) control the 2nd stage cycle.
Operation of the 2nd stage begins when:
• The room temperature changes from the setpoint by the sum of the
1st and 2nd stage differential settings.
• The first stage has been on for the specified delay time, but the
heating/cooling demand has not yet been met.
Energy Efficient Recovery
With Energy Efficient Recovery, the thermostat “Looks Ahead” to the
next event and attempts to reach the next setpoint at the exact time of
the event. If you have two stages, the thermostat will use only the first
stage during this period. This is more efficient than waiting until the
next event and then turning on both first and second stages.
Backlit Display
This thermostat is equipped with a backlight to make viewing the display
easy. Press the button to activate the backlight. The backlight will
turn off after 10 seconds of inactivity. If the thermostat is wired to have
the backlight stay on all the time the night light can be turned on/off in
the settings menu.
Overriding the Schedule Settings
When the thermostat has been programmed, the settings and the
schedule are saved. The thermostat will run to the schedule unless an
override is entered.
Two methods of override are available.
Permanent Override
Press START/STOP SCHEDULE until the word SCHEDULE is not shown
on the display. A Permanent Override allows the thermostat to maintain
a setpoint indefinitely. To switch between Schedule and Permanent
Override, press START/STOP SCHEDULE button. Press or to
change the setpoint. The heat or cool mode should be selected.

12
Temporary Override
When the thermostat is running to a schedule, an override allows the
thermostat to function with a single setpoint for a time period.
A temporary override is entered as a setpoint for a number of hours.
1. Press or to display the flashing setpoint and the number
of hours.
2. Use and to change the setpoint.
3. Press SET TIME to move to the hours.
4. Use and to set the length of the override.
After 5 seconds the thermostat will start operation of the override. The
display will show room temperature, and the setpoint will alternate with
the number of hours remaining in the override.
The schedule will resume after the programmed override time expires.
Cancel the override by pressing START/STOP SCHEDULE.
Vacation Override
This override is programmed by pressing VACATION. The number of
days will flash.
Use and to change the number of days.
After 5 seconds the thermostat will begin operation of the vacation
override. The display will show room temperature and the setpoint will
alternate with the number of days remaining in the override.
Use and to change the setpoint. This will become the new
setpoint for future vacation overrides.
Cancel the override by pressing START/STOP SCHEDULE.
Determining Operating Setpoint
When the thermostat is using a schedule the temperature setpoint
originates from the schedule settings.
When one of the schedule overrides is active the setpoint has been
entered as part of the override.
Use the display to determine the origin of the current temperature setpoint.

13
Permanent Override – The day, time and “schedule” are not displayed.
Vacation Override – Vac and For are displayed. The clock shows days
of override. The display alternates days of override with setpoint.
Temporary Override – The display alternates hours of override with
setpoint.
Automatic Shut-Down
The thermostat will not display the room temperature if the temperature
goes higher than 99 °F (37 °C) or lower than 32 °F (0 °C).
The display will show HI or LO. The thermostat continues to control
heating and cooling and will resume the display of real time information
when the room temperature is back inside the display’s range.
Setting the Fan To ON, AUTO or CIRC
The fan has 3 settings: On, Auto, or Circ. Press the button to switch
among the three.
ON: The fan is on constantly. The room temperture, set points, and
status of the heating and cooling equipment has no effect on the
fan.
AUTO: When there is a call for heating or cooling the fan will turn on.
CIRC: The fan operates in a cycle of on for 10 minutes and off for 20
minutes. When there is a call for heating or cooling the cycle
stops and the fan responds to the call. The fan circulation cycle
resumes when the call for heating or cooling is satisfied.

14
Troubleshooting
If problems with thermostat cannot be resolved, call:
www.robertshawclimate.com
or
Technical Support: 844-362-4822
Problem Action
Thermostat does not turn on system. Check wiring.
(See Wiring Diagrams section.)
System turns on too often.
Increase temperature differential.
(See To Make Changes to the Settings
section.)
System fan does not operate properly.
Move fan option switch to either gas
or electric, to match system.
(See Setting the Fan to ON, AUTO, or
CIRC section.)
Thermostat does not display proper
room temperature.
Check F/C (Fahrenheit/Celsius) setting.
(See To Make Changes to the Settings
section.)
Display shows HI or LO and room
temperature is normal.
Call a licensed service person to
replace/repair.

15
Five Year Limited Warranty
Robertshaw Climatewarrants to the original contractor installer, or to the
original consumer user, each new Robertshaw thermostat to be free
from defects in materials and workmanship under normal use and
service for a period of Five (5) years from date of purchase. This
warranty and our liability does not apply to batteries or merchandise
that has been damaged by misuse, neglect, mishandling, alterations,
improper installation, or use in a way other than in accordance with
Robertshaw Climaterecommendations and instructions.
Robertshaw Climate agrees to repair or replace at its option any
thermostat under warranty provided it is returned within the warranty
period, postage prepaid, with proof of the date of purchase. Cost of
thermostat removal or reinstallation is not the responsibility of Robertshaw
Climate.
Repair or replacement as provided under this warranty is the exclusive
remedy of the consumer. Robertshaw Climate shall not be liable for any
incidental or consequential damages for breach of any express or
implied warranty on this product, or under any other theory of liability.
Except to the extent prohibited by applicable law, any implied warranty
of merchantability or fitness for a particular purpose on this product is
limited to the duration of this warranty.
Some states do not allow the exclusion or limitation of incidental or
consequential damages, or allow limitations on how long an implied
warranty lasts, so the above limitations or exclusions may not apply to
you. This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
For warranty returns, send thermostat, shipping prepaid to:
Robertshaw Climate
Warranty Claims Department
PO Box 3161
Grapevine, TX 76099

16
352-00059-001 Rev B

1
RS5220C
352-00059-001 Rev B
Merci pour votre achat du thermostat programmable Robertshaw de
série RS5220C. Ce manuel de l'utilisateur vous servira de guide pour le
réglage du RS5220C pour deux étages d'équipement.. Le thermostat
devrait déjà être monté et correctement câblé. Les réglages par défaut
permettront au thermostat de fonctionner efficacement. Avant de
changer le programme, lisez le chapitre sur les réglages par défaut.
Caractéristiques
• Guide intelligent
• Transition automatique
• Ventilateur de circulation
• Préservation de la mémoire sans tracas
• Remplacement facile de la pile
• Grand écran d'affichage rétroéclairé
• Rappel de changement de filtre
• Indicateur de décharge de la pile
• Affichage en Centigrade ou en Fahrenheit
• Conformité avec la norme EnergyStar™
• Alimentation double
• Différentiel de température de 1er étage (ou niveau de
fonctionnement) réglable : 0,5 °C à 1,5 °C (0.5 °F à 3 °F)
• Exact à ± 0,5 °C
• Étagement universel pour le matériel multi-étagé
• Arrêt automatique du chauffage si la température dépasse 37 °C
(99 °F)
• Verrouillage sécuritaire du clavier
• 4 événements par jour pour le chauffage et la climatisation
• Programmable 5 - 2 jours
• Limites de températures haute et basse réglables par l'utilisateur
• Neutralisation des valeurs de réglage pour les vacances
MANUEL DE L'UTILISATEUR

2
Application
Le thermostat RS5220C est conçue pour contrôler les systèmes de
chauffage au gaz, électriques, au pétrole, avec pompes à chaleur, le
chauffage au millivolt et les systèmes de climatisation électriques.
Le RS5220C est un thermostat pour deux étages d'équipement.
Les thermostats RS5220C utilisent une programmation 5-2. Ceci veut
dire que les 5 jours ouvrables de la semaine correspondent à une
programmation et que les 2 jours de fin de semaine ont une deuxième
programmation.
MISE EN GARDE ET CONSIGNES DE
SÉCURITÉ IMPORTANTES
• Coupez toujours l'alimentation électrique au niveau du fusible ou du
disjoncteur principal avant d'installer, de retirer, de nettoyer ou de
dépanner le thermostat.
• Lisez toute l'information de ce manuel avant d'installer ce thermostat.
• Il s'agit d'un thermostat de 24 V c.a. en basse tension. Ne l'installez
pas si la tension est supérieure à 30 V c.a.
• Tout le câblage doit se faire en conformité avec les règlements et codes
de construction et les règlements et codes électriques en vigueur.
• Ne court-circuitez pas (avec un cavalier) les bornes au niveau du
robinet de gaz ou du contrôle du système pour vérifier l'installation.
Ceci endommagera le thermostat et annulera la garantie.
• Ne mettez aucune des bornes de ce dispositif à la masse.
• Ce thermostat est configuré avec une protection automatique du
compresseur pour empêcher les dégâts en raison d'un cycle court
ou de coupures de courant prolongées. La protection contre les
cycles courts fournit un délai entre les cycles de chauffage et de
climatisation pour les pompes à chaleur.
Des instructions détaillées pour la pose et le câblage sont fournies dans
le manuel d'installation
Référez-vous à la section sur le guide intelligent dans le manuel
d'installation pour la liste complète des réglages d'usine et
d'entrepreneur.
Alimentation électrique du thermostat
Référez-vous au manuel d'installation pour les schémas de câblage.
Les thermostats fonctionneront sur 24V c.a. ou avec deux piles de
format AA. Si les deux piles AA sont installées, le thermostat continuera
de fonctionner même si l'alimentation en 24 V c.a. est coupée.

Installation ou remplacement des piles
Pour retirer le compartiment des piles resserrez
doucement les bords côtelés.
Le compartiment des piles s'abaissera du corps du
thermostat et s'en détachera. Placez-y deux piles
de type « AA » en respectant la polarité indiquée à
l'intérieur du compartiment. Remettez le
compartiment dans le thermostat.
Lorsque les piles seront presque déchargées, le thermostat se mettra en
mode de pile déchargée.
Ce mode a deux niveaux.
• NIVEAU 1 : L'icône de la pile déchargée est affichée.
Le thermostat continuera à fonctionner. Changez les
piles aussitôt que possible.
• NIVEAU 2 : L'icône de la pile déchargée clignote.
Avec une alimentation de 24 V c. a., le thermostat
continuera de fonctionner même si les piles sont
déchargées ou retirées. Sans alimentation de 24 V
c. a., le thermostat fonctionne seulement sur les
piles et LE SYSTÈME NE FONCTIONNERA PAS.
Changez immédiatement les piles.
Changez les piles si vous laissez le thermostat sans surveillance
pendant plus de 30 jours.
L'horloge continuera de fonctionner pendant 10 minutes une fois que les
piles sont retirées.
Description générale
L'affichage du thermostat indiquera l'information qui est utilisée lors du
fonctionnement ou de la programmation. Cette illustration indique toutes
les possibilités d'affichage avec une explication.
3

Programme - valeurs par défaut
Ce thermostat est préprogrammé avec un programme qui est
recommandé par EnergyStar™. Ce programme est conçu pour abaisser
les coûts énergétiques pendant toute l'année.
La programmation par défaut est la suivante :
Heure Climatisation °F Chauffage °F
Matin (Morn) 6:00 am 78 70
Jour (Day) 8:00 am 85 62
Soir (Eve) 6:00 pm 78 70
Nuit (Nite) 10:00 pm 82 62
Réglages programmables par l'utilisateur –
valeurs par défaut
Pendant tous les changements de programmation l'affichage retourne à
l'affichage du fonctionnement si aucune touche n'a été enfoncée dans
les 10 secondes.
La température est en Fahrenheit.
La lumière de nuit est allumée.
Le différentiel de premier étage est de 1 ºF.
Le différentiel de second étage est de 2 ºF.
Le délai de second étage de fonctionnement est de 20 minutes.
Le délai de troisième étage de fonctionnement est de 20 minutes.
Inversion Auto activée.
La zone morte de l'Inversion Auto est de 3 ºF.
Le rappel de la durée du filtre est éteint.
Le décalage de la température est de 0 degrés.
La limite haute (« HI ») pour le chauffage est à 32 ºC (90 ºF).
La limite basse (« LO ») de la climatisation est à 7 ºC (45 ºF).
Les valeurs de réglage de la température pour les vacances sont :
chauffage 62°F, climatisation 85°F.
Le mode de fonctionnement est ÉTEINT.
La valeur du ventilateur est Auto.
Le clavier n'a pas de protection par mot de passe.
Référez-vous à la section sur le guide intelligent dans le manuel
d'installation pour la liste complète des réglages d'usine et d'entrepreneur.
Chauffage d'urgence
Votre système peut comprendre un chauffage d'urgence (« Emergency
Heat »). Les thermostats RS5220C ont une capacité de chauffage
d'urgence pour les systèmes de thermopompes à plusieurs étages de
fonctionnement. Pour savoir si votre système est capable d'utiliser le
chauffage d'urgence, contactez votre entrepreneur. Utilisez la touche
pour accéder au mode d'URGENCE (EMER). Un E sera affiché avec
le symbole du chauffage. Ce mode est employé pour contourner la
pompe à chaleur quand elle a besoin d'entretien ou quand elle ne peut
pas répondre à la demande de chauffage.
4
