ROBINHOOD RHCD7W User manual

Installation and Operating Instructions Issue: 1
Description: ROBINHOOD CONDENSOR DRYER 7KG WHITE
Model Number: RHCD7W
Model pictured: RHCD7W
Actual unit may differ from image above

Contents
Congratulations!
Thank you for choosing one of our appliances. Before you use the appliance, we strongly recommend that you read
through the whole user manual which provides important safety instructions and description of the product and the
proper use of its functions.
To avoid the ever-present risks involved with using an electrical appliance it is vital that the oven is installed
correctly and that you read the safety instructions carefully to avoid misuse and hazards. It is important that you
retain these instructions and your proof of purchase along with any other important documents about this product
for future reference.
Due to continual product development, Robinhood reserves the right to alter specifications or appearances without
notice.
Important Safety Instructions……………………………………………………………………………………………………………………..1-2
Appliance Details……………………………………………………………………………………………………………………………………………3
Installation……………………………………………………………………………………………………………………………………………………..4
Operating Instructions………………………………………………………………………………………………………………………………5-14
Cleaning and Maintenance…………………………………………………………………………………………………………………… .15-16
Troubleshooting……………………………………………………………………………………………………………………………………………17
Warranty certificate (New Zealand) ………………………………………………………………………………………………………….18
Warranty certificate (Australia) ……………………..……………………………………………………………………………………………19
Disposal Information
Most of the packing materials are recyclable. Please dispose of these materials through your local recycling
depot or by placing them in appropriate collection containers.
If you wish to discard this product, please contact your local authorities and ask for the correct method of
disposal.

1
Important Safety Instructions
When using electrical appliances, in order to reduce the risk of fire, electric shock, and/or
injury to persons, basic safety precautions should always be followed, including
•This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for their
safety. Young children should be supervised to ensure that they do not play with the appliance.
•The tumble dryer is not to be used if industrial chemicals have been used for cleaning.
•The lint trap has to be cleaned frequently.
•The lint trap must to be allowed to accumulate around the tumble dryer.
•Adequate ventilation has to be provided to avoid the back flow of gases into the room from
appliance burning other fuels, including open fires.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol,
kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water
with an extra amount of detergent before being dried in the tumble dryer.
•Items such as foam rubber (latex foam), shower caps, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in the tumble dryer.
•Fabric softeners, or similar products, should be used as specified by the fabric softener
instructions.
•The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the
items are left at a temperature that ensures that the items will not be damaged.
•The exhaust air must not be discharged into a flue which is used for exhausting fumes from
appliances burning gas or other fuels.
•The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge
on the opposite to that of the tumble dryer, in such a way that a full opening of the tumble
dryer door is restricted.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
•Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in
a tumble dryer. The items become warm, causing an oxidation reaction in the oil. Oxidation
creates heat. If the heat cannot escape, the items can become hot enough to catch fire. Piling,
stacking or storing oil-affected items can prevent heat from escaping and so create a fire
hazard.
•If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated
by hair care products be placed in a tumble dryer they should first be washed in hot water with
extra detergent - this will reduce, but not eliminate, the hazard.
•The maximum mass of dry load is 7 Kg.
•WARNING: Never stop a tumble dryer before the end of the drying cycle unless all items
quickly removed and spread out so that the heat is dissipated.
•WARNING: The appliance must not be supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on and off by a utility.
•WARNING: This appliance is only to be serviced by a qualified person. There are no user-
serviceable parts inside.
Symbol
Meaning
Read operator’s manual
Warning: Risk of fire / flammable material

2
Important Safety Instructions
•In certain circumstances electrical appliances may be a danger hazard. Check the
conformity of voltage and power settings, which are specified on the information plate
attached to the appliance and/or packaging, with the usage conditions available.
•Do not place heavy objects in or on these appliances, or use for storage, or let children play or
swing from the door. Do not use the appliances until fully installed.
•The electrical connection must be accessible after installation. The appliance must be
electrically isolated before any maintenance can be performed. The appliance is not
intended to be operated by means of an external timer or separate remote control system.
•
Fabric softeners or similar products should not be used in a tumble dryer to eliminate
the effects of static electricity unless this practice is specifically recommended by the
manufacturer of the fabric softener or product.
•
Undergarments that contain metal reinforcements should not be placed in a tumble
dryer. Damage to the tumble dryer can result if metal reinforcements come loose
during drying. When available a drying rack could be used for such items.
•
Plastic articles such as shower caps or babies’ waterproof napkin covers should not be
placed in a tumble dryer.
•
Rubber-backed articles, clothes fitted with foam rubber pads, pillows, galoshes and
rubber-coated tennis shoes should not be placed in a tumble dryer.
•
Do not cover the air inlet or exhaust openings.
•
If appliance has ventilation openings in base, ensure carpet does not obstruct the
openings.
•
The appliance must not be installed behind a lockable door, a sliding door or a door with
a hinge on the opposite side to that of the tumble dryer in such a way that a full
opening of the tumble dryer door is restricted.
•Undergarments that contain metal reinforcements should not be placed in a tumble dryer.
Damage to the tumble dryer can result if metal reinforcements come loose during drying. When
available a drying rack could be used for such items.
•Do not cover the air inlet or exhaust openings.
•If appliance has ventilation openings in base, ensure carpet does not obstruct the openings.
•Do not operate the dryer without the filter door and filter base.
•Do not install the dryer in the humid and drenching environment.
•Save these instructions.
INDOOR USE ONLY - this appliance is not intended for outdoor use.

3
Appliance details
Model
RHCD7W
Maximum Drying Capacity
7 kg
Rated Voltage
220 –240 V
Rated Frequency
50 Hz
Rated Wattage
2000 W
Net Weight
41 kg
Dimension (WxDxH)
595 x 615 x 845 mm (without door frame)
595 x 660 x 845 mm (with door frame)
Accessories
The following parts are optional for specific models.
If your dryer has following parts, please wear gloves and install them following the instruction
below.

4
Installation Instructions
Transport
Move cautiously. Do not grasp any salient parts of machine. The dryer door cannot be used as the handle for
delivery.
Installation Position
1.
It is recommended that, for your convenience, the machine is positioned close
to your washing
machine.
2.
The tumble dryer must be installed in a clean place, where dirt does not build up. Air must be able
to circulate freely, all round the appliance. Do not obstruct the front air inlet or the air intake
grilles at the back of the machine.
3.
To keep vibration and noise to a minimum when the dryer is in use, it should be placed on a
firm and level surface.
4.
The feet must never be removed. Do not restrict the floor clearance through deep pile
carpets, strips ofwood or similar.This might cause heat built-upwhich would interfere with the
operation of the appliance.
Level Adjusting
Once in its permanent operating position,
check that the dryer is absolutely level with the aid of a spirit level. If it
is not, adjust the feet with a tool.
Power Supply Connection
1.
Make sure that the voltage of the power supply is the same as the electric specification
of the dryer.
2.
Donot connect the dryerwith the power connection board,the universal plug orsocket.

5
Operation Instructions
Quick Start
Before using, please make sure it's installed properly.
Drying
After Drying
Buzzer beep or “0:00” on display
•
If socket provided with on/off switch, please switch off the power.
Plug in
Load
Close door
On
Select
program
Select
function
or default
Start
Open the door
and take out
laundry
Pull out the
container
Pour out
condensate
water
Clean the
filter
Power off
Note!
Note!

6
Operation Instructions
Before Each Drying
Before the first cycle,the dust and grease may remain inthisdryerduringthe
period of manufacture
and transportation, to avoid contaminating your clothes,
please follow these steps:
•Put some clean rags into the drum.
•Plug the power.
•Select the “Quick” program, press “Start/Pause” button.
•
After finishing this program, please follow the “cleaning and
maintenance” to clean the lint filter
and air condenser.
1.
Before drying thoroughly spin the laundry in washing machine. High spin speed can reduce the drying
time and save energy consumption
.
2.
For uniform drying result, sort the laundry according to fabric type and drying program.
3.
Before drying, please close zips, hooks and eyelets, button up, tie fabric belts, etc.
4.
Do not over dry the clothes, because over dried clothes can easily get creases.
5.
Do not dry the articles containing rubber or similar elastic materials.
6.
The door can be opened only after the program of the drying machine finishes to prevent human skin
from being scalded by hot steam or over heated drying machine.
7.
Clean the lint filter and empty container after each use to avoid extension of drying time
and energy
consumption.
8.
Do not dry these clothes after dry-clean process.
The reference weight of dry clothes (each)
•
Never overload.
•
Not for textile with dropping water. The dryer could be damaged, even fire.
•
Not suitable for silk or woolen textiles.
Attention !
Note!

7
Operation Instructions
Please pay attention to use the drying machine if the materials of your clothes can not bedried by it or contain
the symbols as follows:
Operation Instructions

8
Operation Instructions
Control Panel
On / Off
Product is switched on or off.
Display
This display shows the setting, estimated
Remaining time and status message of
your dryer.
Start / Pause
Press the button to start or pause the drying
cycle.
Program
Different dryer cycle can be selected according
to the users needs to make the clothes have
more effective drying results.
Specialty function
These buttons are used for setting
additional functions.

9
Operation Instructions
Display Icon
Meaning
Filter
After the dryer stops, clean filter when icon lights up.
Tank
After the dryer stops, empty container when icon lights up.
Delay start
Timer
Child lock
Remaining time indicator/Error message
Cycle phase status
Clean filters (warning)
Empty water container (warning)
Dryness level (four settings)
Speed dry indicator
Signal indicator
Anti-crease mode
My cycle

10
Operation Instructions
Program selector
1.
Press the【On/Off 】button ,when the LED display screen brightens up, rotate the program knob to
select the desired program.
2.
Select the【Delay】,【Time】,【Intensity】,【Speed Dry】,【Signal】or
【
Anti-Crease
】
functions for additional option.
3. Press the【Start/Pause】button.
Program start
The drum will keep rotating after the program starts, the state light in the display area will flash in
sequence, the remaining time displayed will change automatically.
Program end
1.
The drum will stop running after the program ends, the buzzer will beep, the display will show
"", the last cycle phase status light will flash. The dryer will start 【Anti-crease】function if
user doesn’t remove the load in 1 minute. Please press【On/Off】key to cut off power and pull
the plug out.
2.
Deal with the problem according to“Malfunction display and solutions”, if there is aunexpected
stop during the drying procedure and the dryer show information.
Other Functions
•Instructions of the 【Delay】function
This function is used for delaying clothes drying time within 24 hours. The delay time means the program
will start after x hours. When the delay program starts, the
time starts to decrease on the display and the
delay icon blinks.
Steps in details
1.
Load your laundry and make sure the machine door is closed.
2.
Press the
【
On/Off
】
button, then to turn the program selector knob and select a
desired program.
3.
You can select the 【Anti-Crease】or 【Signal】functions according to your need.
4.
To press the 【Delay】key.
5.
Continue to press the 【Delay】to select the delay time.
6.
After the
【
Start/Pause
】
button is pushed, the dryer is at the run condition. The
dryingprocedurewillbe
automaticallyperformedwhenthedelaytimeisover.
7.
If you push the
【
Start/Pause
】
button again, the delay function will be paused.
8.
If you want to cancel the “Delay” function, please press the
【
On/Off
】
button.

11
Operation Instructions
•Instructions of the 【Time】function
When the warm or cool or refresh program is selected, the
【
Time
】
button can be
used to adjust the
drying time in 10 min.steps.
•Instructions of the 【Intensity】function
Used to adjust the dryness level of the laundry. The level has four grades .
The drying time
increases 3 minutes in every grade.
1.
The intensity function can be activated only before the programme start.
2.
Press the 【Intensity】button repeatedly to select the drying time.
3.
Except the 【Cotton Iron】【Quick】【Synthetic Iron】【Baby Care】【Warm】
【Cool】【Refresh】, all the other programs can be the【Intensity】function.
•Instructions of the 【Speed dry】
Useto curtail shorten the drying time, the【Cotton Extra】【Cotton Standard】【Mix】
【Jean】program can be set the function.
•Instructions of the【Signal】function
Setupthebuzzeron oroff.In the generalcondition,thebuzzeris on.Please press it if needed. When the
buzzer on:
1.
The dryer will give the leading sound if press the extra function buttons.
2.
If the dryer is running, rotate the function choosing knob, the dryer will remind the
operator it is an
invalid choose.
3.
When the drying programme is end, the buzzer will also remind the user
•Instructions of the【Anti-Crease】function
At the end of the drying cycle,the anti-crease operation time is 30 minutes (default ) or 120
minutes (selected).
The
【
Anti-Crease
】
light shall illuminate when the anti-crease function is selected. This
functionpreventsthe
laundry from creases. Thelaundry can be removed during the
anti-crease phase. Except
【
Cool
】
,
【
Refresh
】
and
【
Baby Care
】
, all the other programs
have this function.

12
Operation Instructions
•Instructions of the【My Cycle】function
Used to define and save your favorite programs that are used frequently.
1.
Use the program selector to select the required program and other drying functions.
2.
Press and hold the
【
Intensity
】
button for 3 seconds until the beep and the required
program has been
saved.
3.
Turn the program selector to the
【
My Cycle
】
position, you can start your favorite program. If you want to
change the
【
My Cycle
】
settings, repeat the steps 1 and 2.
•Instructions of the 【Child Lock】feature
1.
This machine incorporates a special child safety lock, which can prevent children from
carelessly
pressing keys or making the faultyoperation.
2.
When the dryer is at the operation state, press the
【
Anti-Crease
】
and
【
Signal
】
buttons
atthesametime
for over 3 seconds to start child lock function.When child lock function is set, the display will show child
lock icon and no key can effect to the dryer except【On/Off】button.
Under the start state of the child lock, the
【
Anti-Crease
】
and
【
Signal
】
buttons shall
be pressed
at the same time for over 3 seconds to release the child lock function.

13
Operation Instructions
Program
Weight
(max)
Application/Properties
Delay
Time
7.0kg
Cott
on
For cottons and colour made of cotton or linen.
Extra
7.0kg
To dry cotton pieces of clothing. Drying level: extra dry.
Y
N
Standard
To dry cotton pieces of clothing. Drying level: cupboard dry.
Iron
To dry cotton pieces of clothing. Drying level: applicable to iron.
Y
N
Quick
Quick
3.0kg
For washing which is to be dried quickly, eg, made of acrylic fibres
or for individual small items. Also for subsequent drying.
Y
N
Synthetics
For non-iron washing made of synthetics and blended fabrics, cotton.
Extra
3.5kg
To dry thick or multi-layered synthetic fabrics. Drying level: extra dry.
Standard
To dry thin synthetic fabrics which are not ironed, such as easy care shirts,
table linen, baby clothes, socks.
Y
N
BabyCare
Baby Care
1.0kg
To dry the clothes of the baby at lower temperature.
Y
N
Special
Jean
5.0kg
To dry jeans or leisure clothes that is spun at high speeds in the
washing machine.
Y
N
Bed linen
5.0kg
To dry bed linen and similar large clothes.
Mix
3.5kg
If you cannot determine what the clothing's material is, please choose
Mix.
Sports
3.0kg
To dry sportswear, thin fabrics, polyester, which are not ironed.
Shirts
1.0kg
For easy care clothes such shirts and blouses with anti-crease
mechanism for minimum ironing effort. Place clothes loosely in
the dryer. Once dried, hang it on a clothes hanger.
My Cycle
My Cycle
Define and save your favorite program.
Y
Time
Warm
To warm clothes from minimum 10 minutes to maximum 120 minutes
(in 10 minutes steps).
Y
Y
Cool
To cool clothes without blowing hot air from minimum 10 minutes to
maximum
30 minutes (in 10 minutes steps).
Refresh
To refresh the clothes that have been kept at closed environments for
a long time from minimum 20 minutes to maximum 150 minutes (in 10
minutes steps).
Drying Program Table
Operation Instructions
13

14
Operation Instructions
•This symbol means the energy efficiency test program “standard cotton program”, which is accordance with
the applicable EN 61121 standard and most suitable to dry normal cotton load at rated load capacity.
•Thick or multi-layered fabrics, e.g. bedlinen, jeans, jackets etc, are not easy to dry. You'd better choose
Cotton Extra program.
•As the uneven material, thick and multi-layered clothes are not easy to dry, it is better to choose the
appropriate time drying program to dry them if some parts of the clothes still damp after program finished.

15
Cleaning and Maintenance
Cleaning and Care
Clean the lint filter
Leave the dryer to cool down.
1. Open the machine door.
2. Take out the lint filter, pull upward to take it out.
3. Clean the lint filter; wipe off the scrap threads accumulated
on the lint filter, with your hand or rinse with water and
dry thoroughly.
4. Reinstall the lint filter.
•The lint filter accumulated on the filter will block the air circulation, which will cause the extension
of drying time and energy use; therefore, the scrap thread filter shall be cleaned after each use.
•Do disconnect the power cord before cleaning!
•Do not operate the dryer without the lint filter!
•Clean the lint filter after each use to prevent lint accumulation inside the dryer.
Wash air condenser
Leave the dryer to cool down.
Residual water may escape, place an absorbent cloth under the maintenance
cover.
1.
Unlock the maintenance cover.
2.
Completely open maintenance cover.
3.
Screw both locking levers towards each other.
4.
Pool out the air condenser.
5.
Clean the air condenser completely, drains thoroughly.
6.
Clean the seals.
7.
Re-insert the air condenser, handle at the button!
8.
Unscrew both locking levers.
9.
Cloth the maintenance cover until it locks into position.
Please clean the air condenser approx, once every 3 months if frequently used.
Do not damage the air condenser.
•
Clean with water only; do not use hard/sharp-edged objects!
Do not operate the dryer without the air condenser!
•During drying, water may collect between the window and the
seal, but this does not affect the function of your dryer!
Note!
Warning!

16
Cleaning and Maintenance
Empty the water container
1. Hold and pull out the water container with two hands.
2. Tilt the water container, pour out the condensate water.
3. Insert the water container
•Empty the water container after each use, the program will be paused and the “ ”icon will light if the water
container is full during the drying process. After the container is emptied, the dryer can be restarted by
pressing【Start/Pause】button.
•Do not drink the condensate water.
•Do not use the dryer without the water container.
Warning!

17
Troubleshooting
Alarm Problem
Alarm Reason
Release
“ E30 ”
Heating problem
Please contact your local service center if the problem persists.
“ E32 ”
Humidity sensor error
“ E33 ”
Temperature sensor error
•Only authorised technicians can carry out repairs.
•Before you call service, please check if you have dealt with the fault yourself or if you
have followed the user instructions.
•A technician will charge you for advice, even during the warranty period.
Problem
Solution
•Display does not on
•Check if the power supply works.
•Check if the mains plug is inserted.
•Check the selected program.
•Press the 【On/Off】button.
•
“”is lighting
•Empty water container.
•If the light is still on, please call the service.
•
“”is lighting
•Clean heat exchanger.
•Clear lint filter.
•Dryer does not start
•Check the door has closed.
•Check the program has set.
•Check the start button has selected.
•Degree of dryness was not
reached or drying time too
long
•Clean lint filter and heat exchanger.
•Empty container.
•Check drain hose.
•Dryer installation place is too restricted.
•Clean the moisture sensors.
•Keep the Air inlet clean.
•
Use higher drying intensity level program or
time
program.
If you cannot deal with the fault by yourself and need help:
•Press the 【On/Off】button.
•Pull out the mains plug and call the service
Warning!
Warning!

18
Warranty Certificate (New Zealand)
Terms and Conditions
The following conditions apply in respect of the warranty given in this certificate:
1. Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and
faulty materials, under normal use and subject to the exclusions in this certificate, for a period of:
Rangehood, Ovens, Cooktops, Dishwashers, Refrigeration - 24 months from date of original purchase for domestic
use.
Uniduct –12 months from date of original purchase for domestic use.
Ironing centre –12 months from date of original purchase for domestic use.
Sinks sets–5 years on stainless steel sink including draining bench from date of original purchase for domestic use, 6
months on all stainless steel accessories, including wire rack, colander and tray from date of original purchase for
domestic use.
Laundry Tub - 5 years on stainless bowl, 24 months on Tap, Cabinet and other components from the date of original
purchase for domestic use.
“Original purchase”, when used in this certificate, means purchase by the customer directly from Monaco or one of its approved
suppliers.
2. This warranty is limited to the repair or replacement, at our option, within the warranty period of any component part
which we at our discretion determine to contain faulty materials or a manufacturing defect in breach of this warranty. This
warranty is subject to terms and conditions set out in this certificate.
3. The warranty only applies within New Zealand.
4. The customer must produce the original invoice or other purchase documentation as proof of the original purchase date.
Warranty exclusions
1. The warranty does not apply where, in Monaco’s opinion:
The defect is caused by misuse, wear and tear, dirt, fire or accidental damage. The product has been repaired or
serviced by an unauthorised person.
The product was not installed in accordance with our instructions.
The product was purchased overseas or was not designed for use in New Zealand. The product was not used, cleaned
or cared for in accordance with our instructions.
The product was used outdoors.
2. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or
are due to:
Exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;
Using inappropriate household cleaning products such as abrasive cream or powder cleansers, furniture polish,
bleach, mentholated spirits, drain cleaners, sugar soap, metal pads and strongly alkaline or acidic cleaners;
Heat damage, including from washing the product at high temperatures;
Impact or mishandling the product, including the impact caused by objects scraped along, thrown or dropped on the
product surface or excessive weight being placed on the product;
Structural or support changes in or affecting the building or the application where the product has been installed;
Failure to clean or maintain the product as recommended; or any other causes specified in the product information as
being excluded from this warranty.
3. Variations with the colour or gloss within the product or any ageing or fading of colour, shine or gloss level over time are
not covered by this warranty. The warranty does not cover visual imperfections or blemishes in the surface and edges of
the product that were not brought to your supplier’s attention at the time you inspected the product.
4. Costs incurred on installation or removal of a product, or any reinstallation of a product, or any associated costs, are not
covered by this warranty.
5. Monaco will not be liable for consequential or indirect loss or damage whatsoever and however arising out of or in
connection with the supply, performance or removal of the product, including (but not limited to) loss of profit, loss of
revenue, loss of contract, loss of goodwill or increased cost of workings, even if due to the negligence of Monaco or any of
its approved suppliers, employees or agents.
6. Charcoal filters and light bulbs are not covered by this warranty
7. This warranty and the statements contained in this certificate or other documents given to you do not exclude, restrict or
modify the application of any term implied into this warranty by statute, provided that (to the extent any statutory
provision permits Monaco to limit its liability for a breach of an implied condition or warranty) Monaco’s liability for such
breach is limited to the payment of the cost of replacing the product, repairing the product or acquiring an equivalent
product.
8. Subject to clause 5, our obligations under this warranty are limited to those set out in this certificate, and this warranty is
expressly instead of all other warranties, express or implied, including any implied warranty of merchantability or fitness
for a particular purpose and notwithstanding any course of dealing between the parties or custom and usage in trade to
the contrary.
Terms and conditions are subject to change.
Table of contents
Other ROBINHOOD Dryer manuals
Popular Dryer manuals by other brands

Bosch
Bosch WTW87565AU Installation and operating instructions

AEG
AEG LAVATHERM T500 operating instructions

Miele
Miele TOUCHTRONIC T 9820 operating instructions

Hisense
Hisense HDHA80 User's operation manual

Bosch
Bosch WTG864H2 User manual and installation instructions

LaboGene
LaboGene Scanvac Basic instruction manual
