ROBINHOOD RHSD7W User manual

Installation and Operating Instructions Issue: 1
Description: ROBINHOOD SENSOR DRYER 7KG WHITE
Model Number: RHSD7W
Model pictured: RHSD7W
Actual unit may differ from image above

Contents
Congratulations!
Thank you for choosing one of our appliances. Before you use the appliance, we strongly recommend that you read
through the whole user manual which provides important safety instructions and description of the product and the
proper use of its functions.
To avoid the ever-present risks involved with using an electrical appliance it is vital that the oven is installed
correctly and that you read the safety instructions carefully to avoid misuse and hazards. It is important that you
retain these instructions and your proof of purchase along with any other important documents about this product
for future reference.
Due to continual product development, Robinhood reserves the right to alter specifications or appearances without
notice.
Important Safety Instructions……………………………………………………………………………………………………………………..1-2
Appliance Details……………………………………………………………………………………………………………………………………………3
Installation……………………………………………………………………………………………………………………………………………………..4
Operating Instructions…………………………………………………………………………………………………………………………………5-8
Cleaning and Maintenance………………………………………………………………………………………………………………………..9-10
Troubleshooting……………………………………………………………………………………………………………………………………………11
Warranty certificate (New Zealand) ………………………………………………………………………………………………………….12
Warranty certificate (Australia) ……………………..……………………………………………………………………………………………13
Disposal Information
Most of the packing materials are recyclable. Please dispose of these materials through your local recycling
depot or by placing them in appropriate collection containers.
If you wish to discard this product, please contact your local authorities and ask for the correct method of
disposal.

1
Important Safety Instructions
When using electrical appliances, in order to reduce the risk of fire, electric shock, and/or
injury to persons, basic safety precautions should always be followed, including
•This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been
given supervision or instruction concerning use of the appliance by a person responsible for their
safety. Young children should be supervised to ensure that they do not play with the appliance.
•The tumble dryer is not to be used if industrial chemicals have been used for cleaning.
•The lint trap has to be cleaned frequently.
•The lint trap must to be allowed to accumulate around the tumble dryer.
•Adequate ventilation has to be provided to avoid the back flow of gases into the room from
appliance burning other fuels, including open fires.
•Do not dry unwashed items in the tumble dryer.
•Items that have been soiled with substances such as cooking oil, acetone, alcohol, petrol,
kerosene, spot removers, turpentine, waxes and wax removers should be washed in hot water
with an extra amount of detergent before being dried in the tumble dryer.
•Items such as foam rubber (latex foam), shower caps, rubber backed articles and clothes or
pillows fitted with foam rubber pads should not be dried in the tumble dryer.
•Fabric softeners, or similar products, should be used as specified by the fabric softener
instructions.
•The final part of a tumble dryer cycle occurs without heat (cool down cycle) to ensure that the
items are left at a temperature that ensures that the items will not be damaged.
•The exhaust air must not be discharged into a flue which is used for exhausting fumes from
appliances burning gas or other fuels.
•The appliance must not be installed behind a lockable door, a sliding door or a door with a hinge
on the opposite to that of the tumble dryer, in such a way that a full opening of the tumble
dryer door is restricted.
•If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or
similarly qualified persons in order to avoid a hazard.
•Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in
a tumble dryer. The items become warm, causing an oxidation reaction in the oil. Oxidation
creates heat. If the heat cannot escape, the items can become hot enough to catch fire. Piling,
stacking or storing oil-affected items can prevent heat from escaping and so create a fire
hazard.
•If it is unavoidable that fabrics that contain vegetable or cooking oil or have been contaminated
by hair care products be placed in a tumble dryer they should first be washed in hot water with
extra detergent - this will reduce, but not eliminate, the hazard.
•The maximum mass of dry load is 7 Kg.
•WARNING: Never stop a tumble dryer before the end of the drying cycle unless all items
quickly removed and spread out so that the heat is dissipated.
•WARNING: The appliance must not be supplied through an external switching device, such as a
timer, or connected to a circuit that is regularly switched on and off by a utility.
•WARNING: This appliance is only to be serviced by a qualified person. There are no user-
serviceable parts inside.
Symbol
Meaning
Read operator’s manual
Warning: Risk of fire / flammable material

2
Important Safety Instructions
•In certain circumstances electrical appliances may be a danger hazard. Check the
conformity of voltage and power settings, which are specified on the information plate
attached to the appliance and/or packaging, with the usage conditions available.
•Do not place heavy objects in or on these appliances, or use for storage, or let children play or
swing from the door. Do not use the appliances until fully installed.
•The electrical connection must be accessible after installation. The appliance must be
electrically isolated before any maintenance can be performed. The appliance is not
intended to be operated by means of an external timer or separate remote control system.
• Fabric softeners or similar products should not be used in a tumble dryer to eliminate
the effects of static electricity unless this practice is specifically recommended by the
manufacturer of the fabric softener or product.
• Undergarments that contain metal reinforcements should not be placed in a tumble
dryer. Damage to the tumble dryer can result if metal reinforcements come loose
during drying. When available a drying rack could be used for such items.
• Plastic articles such as shower caps or babies’ waterproof napkin covers should not be
placed in a tumble dryer.
• Rubber-backed articles, clothes fitted with foam rubber pads, pillows, galoshes and
rubber-coated tennis shoes should not be placed in a tumble dryer.
• Do not cover the air inlet or exhaust openings.
• If appliance has ventilation openings in base, ensure carpet does not obstruct the
openings.
• The appliance must not be installed behind a lockable door, a sliding door or a door with
a hinge on the opposite side to that of the tumble dryer in such a way that a full
opening of the tumble dryer door is restricted.
•Undergarments that contain metal reinforcements should not be placed in a tumble dryer.
Damage to the tumble dryer can result if metal reinforcements come loose during drying. When
available a drying rack could be used for such items.
•Do not cover the air inlet or exhaust openings.
•If appliance has ventilation openings in base, ensure carpet does not obstruct the openings.
•Do not operate the dryer without the filter door and filter base.
•Do not install the dryer in the humid and drenching environment.
•Unplug the appliance before cleaning and maintenance.
•Save these instructions.
INDOOR USE ONLY - this appliance is not intended for outdoor use.

3
Appliance details
Model
RHSD7W
Maximum Drying Capacity
7 kg
Rated Voltage
220 –240 V
Rated Frequency
50 Hz
Rated Wattage
2000 W
Net Weight
35 kg
Dimension (WxDxH)
595 × 555 × 840mm (without door frame)
595 × 610 × 840mm (with door frame)

4
Installation Instructions
Installation Area
Dryer should be placed in a ventilated area with
not less than 10cm distance from the wall. It is suggested
there are no obstacles within 1.5m in front of dryer and
keep ventilated. Dry
Level Adjusting
Once the dryer is in its permanent operating position,
check that the dryer is absolutely level with the aid of a
spirit level. If it is not, adjust the feet with a tool.
If dryer could not be placed horizontally (the lean angle is no more than 2°, the dryer will work unbalanced
or stop working sometimes. Notice when installing:
•Do not install the dryer in the open air or place easily damaged by rain;
•Do not place the back of dryer near curtain or something in the wind;
•Do not place the dryer near gas or flammable area.
Flex tube fixing
•Connect one end of flex tube with whorl to the back vent, then fix it deasilly till tight.
•The other end of flex tube will be extended to outdoor, please refer the right assemble way to the
below pictures.
Note!

5
Operation Instructions
Quick Start
Before using, please make sure it's installed properly.
Drying
After Drying
Buzzer beep or “0:00” on display
• If socket provided with on/off switch, please switch off the power.
Plug in
Load
Close door
On
Select
program
Select
function
or default
Start
Open the door and
take out laundry
Clean the
filter
Power off
Note!
Note!

6
Operation Instructions
Before Each Drying
1. Before drying thoroughly spin the laundry in washing machine. High spin speed can reduce the drying
time and save energy consumption .
2. For uniform drying result, sort the laundry according to fabric type and drying program.
3. Before drying, please close zips, hooks and eyelets, button up, tie fabric belts, etc.
4. Do not over dry the clothes, because over dried clothes can easily get creases.
5. Do not dry the articles containing rubber or similar elastic materials.
6. The door can be opened only after the program of the drying machine finishes to prevent human skin
from being scalded by hot steam or over heated drying machine.
7. Clean the lint filter and empty container after each use to avoid extension of drying time and energy
consumption.
8. Do not dry these clothes after dry-clean process.
The reference weight of dry clothes (each)
• Never overload.
• Not for textile with dropping water. The dryer could be damaged, even fire.
• Not suitable for silk or woolen textiles.
Please pay attention to use the drying machine if the materials of your clothes can not bedried by it or contain
the symbols as follows:
Note!

7
Operation Instructions
Control Panel
On / Off
Product is switched on or off.
Dryness Level
(Extra/Standard/Less)
Start / Pause
Press the button to start or pause the drying cycle.
Anti-Crease
At the end of the drying cycle, the anti-crease
phase time is 30 minutes (default) or 120
minutes (selected).
Program
Different dryer cycle can be selected according to
the user’s needs to make the clothes have more
effective drying results.
•Press the [ Program ] button to select the desired program.
•Press the [ Dryness Level ]button to select the desired program.
•Press the [ Anti-Crease ] button to start Anti-Crease function.
•Press the [ Start/Pause ]button.
•Press the [ Delay ]button to booking the drying process.
•If users need child lock function, pressing the [ Program ] and [ Dryness Leve ] buttons
simultaneously for over 3 seconds to start child lock function. Press the two button 3sec. also to be
released the function. The “Child Lock” will lock all buttons except 【On/Off】. Cut off the power
supply , the kid’s protection is to be released.
•The buzzer will prompt from the dryer when finishing the cycle. Press the
【On/Off】button and pull out the power cable.
•Clean the filter, cabinet and inner tube.
•Clean the filter when the “Filter” light is flashing, after the dryer stop.
Note!

8
Operation Instructions
Drying Program Table
Clothing
Type
Approximate amount
of remaining humidity
Capacity
(kg)
Programs
Dryness
Level
Note
Cotton
80 % - 90 %
7
Cotton
Extra
According to the Type and
Capacity of the clothing to
select the most suitable
Program and Dryness Level.
60 % - 70 %
7 / 3.5
Cotton
Standard
7
Cotton
Less
Mix
70 %
7 / 3.5
Mix
Extra
60 %
7 / 3.5
Mix
Standard
Synthetic
50 %
3.5
Synthetic
Extra
40 %
3.5
Synthetic
Standard
Cotton
--
1
1 Hr
--

9
Cleaning and Maintenance
Filter clean
•Clean the lint filter after each use.
•Remove by pulling straight up. Cleaning filter
•Use wiping cloth or your fingers. Install filter
If the filter is cleaned by damp cloth
or water, please install after the sun dry.
Cleaning cabinet and inner tube
•Use soft damp cloth wipe when cleaning cabinet
and inner tube.
•Not to rinse by water direct.
•Not to use neutral scour wipe.
•Not to use gasoline and alcohol wipe.
•Make sure open the front door for aeration after
cleaning the inner tube.
Safety reset
1. These dryers have a safety cut out switch which is activated by temperature.
2. The safety reset button is on the backboard. If your dryer not heating this button must be
reset before the dryer can heat again. You may need to wait 10 minutes for cooling down.
3. The most common reason for the dryer if overheat is a blocked filter.
4. Clean the line filter after each load to prevent overheating of the dryer.
The cut out switch may operate for the following reasons:
1. Lint filter is blocked.
2. Exhaust outlets blocked at the front of the dryer.
3. Poor ventilation in the laundry or room-open a window or door
4. Lightweight garment eg. handkerchief, sucked over the filter.
Safety Reset Button
Use your finger or a pencil to press the button in until you feel it click.

10
Trouble Shooting
Trouble
Cause
Solution
Will not start
•Power cut.
•The power plug is not plugged tight.
•Dry clothes exceed.
•Wait for switching on electricity.
•Check the power socket, make sure plug
tight.
•The clothes in drier must be after spinning,
and drying clothes cannot exceed 7kg.
External hot or
can smell hot
The lint filter is dirty.
The uptake or exhaust duct is dirty.
Make sure clean the lint filter in time.
Clothes too dry
The clothes in machine are too full.
Not to take out the clothes in time
when finish.
The clothes don’t assort properly.
The temperature is enacted too high.
Make sure the clothes are not too full.
Take out the clothes immediately when
finish.
Observe the maintenance label on
clothes.
Clothes shrink
Too dry
Observe the maintenance label on
clothes. If easy to shrink, should examine
the clothes when dry. Take out the
clothes when tiny damp for too dry. Then
hang the clothes until full dry.
Hairball on clothes
It is right for synthetic fibre and
permanent press fibre causing
hairballs. This is because the right rubs
causing.
Use fabric softener lubricate fibre, please
spray settled glue on cuff and neckline
when iron clothes. Turn the sarcenet out
for reducing rub.
Cleaning and Maintenance

11
Troubleshooting
The sound of dryer when runs can cause due to heavy wet clothes’ turning and bumping, and
this will cause noise accordingly.
Air bumping: When drying, machine will generate steam which will come out from pipe and this will cost
bumping with the bottom of inner tub.
Error
code
Description
Criteria
E1
Over-temperature
NTC- PCB fault
E3
Temperature sensor error
Temperature sensor opened or PCB fault
E4
Temperature sensor is short or
PCB fault
Temperature sensor shorted or PCB fault

12
Warranty Certificate (New Zealand)
Terms and Conditions
The following conditions apply in respect of the warranty given in this certificate:
1. Monaco Corporation Limited (“Monaco”) warrants the following Robinhood products against manufacturing defects and
faulty materials, under normal use and subject to the exclusions in this certificate, for a period of:
Rangehood, Ovens, Cooktops, Dishwashers, Refrigeration - 24 months from date of original purchase for domestic
use.
Uniduct –12 months from date of original purchase for domestic use.
Ironing centre –12 months from date of original purchase for domestic use.
Sinks sets–5 years on stainless steel sink including draining bench from date of original purchase for domestic use, 6
months on all stainless steel accessories, including wire rack, colander and tray from date of original purchase for
domestic use.
Laundry Tub - 5 years on stainless bowl, 24 months on Tap, Cabinet and other components from the date of original
purchase for domestic use.
“Original purchase”, when used in this certificate, means purchase by the customer directly from Monaco or one of its approved
suppliers.
2. This warranty is limited to the repair or replacement, at our option, within the warranty period of any component part
which we at our discretion determine to contain faulty materials or a manufacturing defect in breach of this warranty. This
warranty is subject to terms and conditions set out in this certificate.
3. The warranty only applies within New Zealand.
4. The customer must produce the original invoice or other purchase documentation as proof of the original purchase date.
Warranty exclusions
1. The warranty does not apply where, in Monaco’s opinion:
The defect is caused by misuse, wear and tear, dirt, fire or accidental damage. The product has been repaired or
serviced by an unauthorised person.
The product was not installed in accordance with our instructions.
The product was purchased overseas or was not designed for use in New Zealand. The product was not used, cleaned
or cared for in accordance with our instructions.
The product was used outdoors.
2. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or
are due to:
Exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone;
Using inappropriate household cleaning products such as abrasive cream or powder cleansers, furniture polish,
bleach, mentholated spirits, drain cleaners, sugar soap, metal pads and strongly alkaline or acidic cleaners;
Heat damage, including from washing the product at high temperatures;
Impact or mishandling the product, including the impact caused by objects scraped along, thrown or dropped on the
product surface or excessive weight being placed on the product;
Structural or support changes in or affecting the building or the application where the product has been installed;
Failure to clean or maintain the product as recommended; or any other causes specified in the product information as
being excluded from this warranty.
3. Variations with the colour or gloss within the product or any ageing or fading of colour, shine or gloss level over time are
not covered by this warranty. The warranty does not cover visual imperfections or blemishes in the surface and edges of
the product that were not brought to your supplier’s attention at the time you inspected the product.
4. Costs incurred on installation or removal of a product, or any reinstallation of a product, or any associated costs, are not
covered by this warranty.
5. Monaco will not be liable for consequential or indirect loss or damage whatsoever and however arising out of or in
connection with the supply, performance or removal of the product, including (but not limited to) loss of profit, loss of
revenue, loss of contract, loss of goodwill or increased cost of workings, even if due to the negligence of Monaco or any of
its approved suppliers, employees or agents.
6. Charcoal filters and light bulbs are not covered by this warranty
7. This warranty and the statements contained in this certificate or other documents given to you do not exclude, restrict or
modify the application of any term implied into this warranty by statute, provided that (to the extent any statutory
provision permits Monaco to limit its liability for a breach of an implied condition or warranty) Monaco’s liability for such
breach is limited to the payment of the cost of replacing the product, repairing the product or acquiring an equivalent
product.
8. Subject to clause 5, our obligations under this warranty are limited to those set out in this certificate, and this warranty is
expressly instead of all other warranties, express or implied, including any implied warranty of merchantability or fitness
for a particular purpose and notwithstanding any course of dealing between the parties or custom and usage in trade to
the contrary.
Terms and conditions are subject to change.

13
Warranty Certificate (Australia)
Terms and Conditions
If you are a consumer under the Australian Consumer Law, our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.
1. Shriro Australia Pty Limited (“Shriro”) also warrants the following Robinhood products against manufacturing defects and faulty
materials, under normal use and subject to the exclusions in this certificate, for a period of:
Rangehood, Ovens, Cooktops, Dishwashers, Refrigeration - 24 months from date of original purchase for domestic use.
Uniduct –12 months from date of original purchase for domestic use.
Ironing centre –12 months from date of original purchase for domestic use.
Sinks sets–5 years on stainless steel sink including draining bench from date of original purchase for domestic use, 6 months
on all stainless steel accessories, including wire rack, colander and tray from date of original purchase for domestic use.
Laundry Tub - 5 years on stainless bowl, 24 months on Tap, Cabinet and other components from the date of original
purchase for domestic use. “Original purchase”, when used in this certificate, means purchase by the customer directly from
Shriro or one of its approved suppliers.
2. This warranty is limited to the repair or replacement, at our option, within the warranty period of any component part which we at
our discretion determine to contain faulty materials or a manufacturing defect in breach of this warranty. This warranty is subject
to terms and conditions set out in this certificate.
3. The warranty only applies within Australia.
4. For warranty service outside of capital city metropolitan area or 30 km from nearest authorised service agent you will be liable for
reasonable travelling expenses and the cost of transport of the product or parts to and from the service agent
5. To make a claim under this warranty, you must produce the original invoice or other purchase documentation as proof of the
original purchase date. You must send your claim to Shriro Australia Pty Limited, 104 Vanessa Street, Kingsgrove, NSW, 2208,
within 7 days of any alleged defect or failure of the product first becoming apparent. You are responsible for the expense of
making a claim under this warranty.
This warranty is given by:
Shriro Australia Pty Ltd, ABN: 28 002 386 129
Telephone: [phone]
Facsimile: 1800 628 577
Email: [e-mail]
www.robinhood.com.au
Attention: Customer Services Manager
Warranty exclusions
1. The warranty does not apply where, in Shriro’s opinion:
The defect is caused by misuse, wear and tear, dirt, fire or accidental damage. The product has been repaired or serviced by
an unauthorised person.
The product was not installed in accordance with our instructions.
The product was purchased overseas or was not designed for use in Australia.
The product was not used, cleaned or cared for in accordance with our instructions.
The product was used outdoors.
2. All Robinhood Rangehoods are suitable for indoor use only and not suitable over BBQs or charcoal cookers designed for outdoor
use.
3. In addition, this warranty does not extend to damage or defects which in our opinion, directly or indirectly arise from or are due
to: exposing the product to acidic or corrosive materials or chemicals such as dyes, solvents, denture cleaner or acetone; using
inappropriate household cleaning products such as abrasive cream or powder cleansers, furniture polish, bleach, mentholated
spirits, drain cleaners, sugar soap, metal pads and strongly alkaline or acidic cleaners; heat damage, including from washing the
product at high temperatures; impact or mishandling the product, including the impact caused by objects scraped along, thrown
or dropped on the product surface or excessive weight being placed on the product; structural or support changes in or affecting
the building or the application where the product has been installed; failure to clean or maintain the product as recommended; or
any other causes specified in the product information as being excluded from this warranty.
4. Variations with the colour or gloss within the product or any ageing or fading of colour, shine or gloss level over time are not
covered by this warranty. The warranty does not cover visual imperfections or blemishes in the surface and edges of the product
that were not brought to your supplier’s attention at the time you inspected the product.
5. We will not be responsible under this warranty for, nor pay the costs of, removing the existing product, or reinstalling the new
product, or any associated costs or damages.
6. Charcoal filters and light bulbs are not covered by this warranty.
The benefits given by this warranty are in addition to other rights and remedies of consumers under any law in relation to the goods which
cannot be excluded.
This warranty certificate is not intended to create a contract between Shriro Australia Pty Limited and the purchaser.
New Zealand
Monaco Corporation Ltd Telephone:
[phone]
Facsimile: [phone]
Email: [e-mail]
www.robinhood.co.nz
Australia
Shriro Australia Pty Limited
ABN 28 002 386 129
Telephone: [phone]
Facsimile: 1800 628 577
Email: [e-mail]
www.robinhood.com.au
