Robitronic R01502 User manual

R01502 - TL-3C 3-Channel 2.4GHz RC-System
USERMANUAL
2,4G FHSSTechnology
DIGITAL PROPORTIONAL RADIO CONTROL SYSTEM

2
Thank you for purchasing our R/C-System!
Before using, read this manual carefully!
Warranty
With the purchase of this product you purchased at the same time a two-year
warranty from date of purchase. The guarantee applies only to the already existing
material on the purchase of the product and / or functional defects.
Excluded from the guarantee:
•Damage caused by incorrect use
•Damage caused by neglect of duty of care
•Damage caused by improper handling and maintenance errors
•Liquid damage
For warranty claims, please contact your local dealer.
Should it be necessary to send the product, you must enclose a copy of the invoice
and a repair order. You can download it at www.robitronic.com. With direct sending to
the service department must be consulted beforehand (held by telephone or e-mail).
The postage costs borne by the consignor. Paid packages are not accepted.
Everyone sent in warranty case is first examined by our service department on
admissibility. For reject warranty claims will be charged back to a control and
processing fee before we return the product. Repairs not covered under warranty,
before the start of the repair must be paid.
Robitronic assumes no liability for damages and losses directly or indirectly, by the
sequence of use or misuse of this product and its required accessories products
needed for their operation, arise.
Disclaimer
As compliance with the instructions, the operations and conditions when using the
device at no time can be monitored by the manufacturer; the manufacturer assumes
no liability for damages, costs and / or losses arising from incorrect use and / or
incorrect operation or in any way connected.
Intended Use
The remote control is designed exclusively for private use in model construction. The
remote control is not for industrial use, e.g. to control machines and equipment,
determined.
Any use other than as described above, can lead to damage of the product, and
beyond this, with the associated risks, such as short circuit, fire, electric shock, etc..
Contact with water must be avoided!
The remote control must not technically be changed or rebuilt!
The safety precautions are essential to follow!
You as a user are solely responsible for the safe operation of your remote
control and your model!

3
Table of content
Caution..........................................................................................................................4
1.1 Transmitter Chart....................................................................................................5
Edit Buttons...........................................................................................................5
1.2 „Binding“ the receiver ............................................................................................. 6
2.1 Characteristics of system .......................................................................................7
2.2 Menu-introduction...................................................................................................8
2.3 Main-Menu overview ............................................................................................ 10
2.4 EPA.......................................................................................................................10
2.5 D/R........................................................................................................................11
2.6 S_TRIM.................................................................................................................11
2.7 REV ......................................................................................................................12
2.8 ST_CURV.............................................................................................................12
2.9 TH_CURV.............................................................................................................12
Adjustment method for EXP curve...................................................................... 13
Adjustment method for CUR curve ..................................................................... 14
Adjustment method for VRT curve......................................................................14
2.10 ABS.....................................................................................................................15
2.11 MODEL...............................................................................................................16
2.12 SPEED................................................................................................................17
Steering Speed....................................................................................................17
Throttle Speed..................................................................................................... 18
2.13 ATS.....................................................................................................................18
2.14 BR_MIX .............................................................................................................. 19
2.15 MIX .....................................................................................................................20
2.16 TH_HOLD........................................................................................................... 21
2.17 F/S ......................................................................................................................21
2.18 NEUTRAL...........................................................................................................22
2.19 SOUND...............................................................................................................22
2.20 RESET................................................................................................................23
2.21 MODEL RESET.................................................................................................. 23
2.22 TIMER.................................................................................................................23
3.1 TRIM_ADJ............................................................................................................24
3.2 Handling procedure for batteries.......................................................................... 25
3.3 Wiring of the receiver............................................................................................ 26
3.4 Technical data ......................................................................................................26
Transmitter: ......................................................................................................... 26
Receiver: .............................................................................................................26
4. Declaration of Conformity (DOC) ...........................................................................27

4
Caution
To work your R/C with your models correctly and safely, read this manual carefully
and keep it in a safe way as a reference introduction in the future.
•This product is only equipped for radio controlled models.
•The usage of this product should be approved by local relevant law or
regulations.
•We will not be responsible for the damages caused by unauthorized
modification, adjustment or replacement of parts of this product.
•The manual may be altered without prior notice. Please contact us if you have
any corrections or clarifications that should be made in the manual.
•Please pay more attention to the parts in this manual, which are marked with
„Warning“.
•Because of disturbance, do not work your radio control system simultaneously
with others at the same frequency.
•Before starting the transmitter, make sure the transmitter batteries are well
loaded. The voltage of transmitter batteries is never lower than 8,6 V, And
please check and confirm that the servos are all well and properly connected.
•Please check and have a test on control surfaces to confirm the transmitter
handling of each part prior to each take off. The frequencies of the module and
the receiver should be the same.
•Keep the radio system away from moist, high temperature and strong shake.
Do not clean the product with solvent.
•The antenna does not touch anything else when power switch is turned on. Do
not leave this product and ist accessories within the reach of small children.
•Please use this product according to our local relevant law or regulation, we
are not responsible for any incidents or damages.

5
1.1 Transmitter Chart
Antenna 3. Channel
Steering trim
LC-Display Steering wheel
Power switch
Throttle trim
Charging jack
Edit Buttons Throttle trigger
Throttle hold
Dual Rate
Battery box
Edit Buttons

6
1.2 „Binding“ the receiver
With the binding process the receiver is coupled to the transmitter.
Turn on the transmitter, then connect the power of receiver keeping the receiver
„BIND“ button till the light turn on GREEN which means the binding is successful.
After that, it’s unnecessary to bind again.
•Caution: making sure that the RX and TX within one meter, and around 10
meters no similar device.
•If the LED is flashing, showing the binding failure, please do again as above
indication.

7
2.1 Characteristics of system
•3 channels End Point Adjustment.
•Support dual rate function for the STEERING.
•Sub-trim for THROTTLE channel and STEERING channel.
•Model names can use up to 5 letters and numbers, so that easily understood
names can be set. A model memory with different fine setups can be created
by using the model copy function. Sixteen models can be added.
•Brake mixing for large cars (BRAKE)
oBrake mixing of the front and rear wheels of 1/5GP and other large cars
can be adjusted independently.
oAnti-skid braking system (A.B.S) This function applies the brakes so
that the tires of gasoline engine cars, etc. do not lose their grip on the
road even when braking at corners.
•SPEED
oTH-SPEED: Sudden trigger operation on a slippery road surface will
only cause the tires to spin and the model to not accelerate smoothly.
By setting the throttle speed function, operation can be performed
smoothly and easily. It also suppresses battery consumption.
oST-SPEED: When you sense that the steering servo is too fast, etc.,
the servo operating speed (direction that suppresses the maximum
speed) can be adjusted.
•Auto-Start funktion (ATS)
oA pre-set throttle position, less than full throttle, to be used for the initial
acceleration off the line without having wheel spin. When the trigger is
released, auto-start is turned off and throttle operates normally again.
•TIMER: The TC-3 has two timers: Down_Timer and UP_Timer.
•Digital trim function: The current trim position is displayed on the LCD screen.

8
2.2 Menu-introduction

9

10
2.3 Main-Menu overview
Voltage Dual Rate
Model Name Steering
Timer
Throttle Hold
Steering Trim
Throttle Trim Modulation
2.4 EPA
Use this when performing left and right steering
angle adjustments, throttle high side/brake side
operation amount adjustment, and channel 3 servo
up side/down side operation amount adjustment
during linkage.
•EPA adjusting value range: 0-120 %,
•default is 100%
1. Press "ENTER" in the power on interface and
enter function menu. Press “+” or “-“ to choose "EPA".
And press "ENTER" and enter EPA adjusting interface.
2. Press "ENTER" to choose each adjusting item,
and then press “+” to increase and “-“ to decrease the
value of the corresponding item.
3. Press "EXIT" to save your setting and leave EPA
interface, and back to the function menu interface.
TERMS: F-FORWARD, B-BACK,ST-STEERING,
TH-THROTTLE.AUX-AUXILLIARY

11
2.5 D/R
D/R is used to change the action range of steering
servo when turning the steering wheel. Increasing D/R
will make the steering wheel action more sensitive.
•D/R adjusting value range: 0-120%,
•POS0 default value is 100%,
•POS1 default value is 70%.
•Press the ST.D/R dial to select POS0 or POS1,
and the value will display in the LCD when it is
on the main screen.
1. Press "ENTER" to see FUNCTION MENU.
2. Press “+” or “- “ to choose D/R and press "ENTER"
to enter D/R adjusting interface.
3. Press "+" to increase and to decrease D/R value.
4. Press "EXIT" to save your setting and leave D/R
interface, and back to the function menu interface.
TERMS: POS-POSITION
2.6 S_TRIM
Use this function to adjust the neutral position of
the steering and throttle servos.
Tip:
When installing a new servo always ensure that it is
already in the neutral position!
SUB TRIM adjusting value range: -100-100
Default is 0
1. Press "ENTER" to see FUNCTION MENU.
2. Press "+" or "-" to choose TRIM, and press
"ENTER" to enter SUB TRIM adjusting interface.
3. Press "+" to increase and "-" to decrease SUB TRIM value.
4.Press "EXIT" to save your setting and leave SUB TRIM interface, and back to the
function menu interface.
TERMS: ST-STEERING, TH-THROTTLE

12
2.7 REV This function reverses the direction of operation of
the servos related to transmitter steering, throttle,
and channel 3 operation.
1. Press "ENTER" to see FUNCTION MENU.
2. Press "+" or "-" to choose REVERSE, and press
"ENTER" to enter REVERSE adjusting interface.
3. Press "ENTER" to choose each Channel.
4. Press "+" to increase and "-" to choose
"REV" or "NOR" .
5. Press "EXIT" to save your setting and leave REVERSE interface, and back to the
function menu interface.
Note: However, when the position set by trim or sub trim shifts from the center, the
center becomes the opposite side.
TERMS: ST-STEERING, TH-THROTTLE, AUX-AUXILLIARY
2.8 ST_CURV
This function is used to change the sensitivity of the steering servo around the neutral
position. It has no effect on the maximum servo travel.
Note: When the setting is not determined, or the characteristics of the model
are unknown, start with 0% (when EXP is set to 0%, servo movement is linear)
1. Press "ENTER" to see FUNCTION MENU
2. Use the +/- Keys to select the ST CURV function and press ENTER.
3. Use the +/- Key to change the value.
4. Press EXIT to save and return to FUNCTION MENU, press EXIT again to return to
the Main Screen.
•STEERING CURVE adjusting value range: -100% ~ +100%
•Default is 0% (Linear)
Steering EXP adjustment
When you want to quicken steering operation, use the "+" button to adjust the + side.
When you want to make steering operation milder, use the "-" button to adjust the -
side.
When ending setting, return to the function menu by pressing the "EXIT" button.
TERMS: M-MODE, R-RATE
2.9 TH_CURV
This function makes the throttle high side and brake side direction servo operation
quicker or milder. It has no effect on the servo maximum operation amount. For the

13
high side, selection from among three kinds of curves (EXP/VTR/CUR) is also
possible.
Note: When the course conditions are good and there is no sense of torque at the
power unit, set each curve to the + side (quick side). When the road surface is
slippery and the drive wheels do not grip it, set each curve to the - minus (mild) side.
Note: Brake side only has EXP curves.
1 Press "ENTER" to see FUNCTION MENU
2 Use the +/- Keys to select the TH CURV function and press ENTER.
3 Press ENTER to select a setting.
4 Use the +/- Key to change the value.
5 Press EXIT to save and return to FUNCTION MENU, press EXIT again to return to
the Main Screen.
Adjustment method for EXP curve
•Select EXP at setup item "M"
•Select setup item "R" and make the following adjustments:
1 .Forward side adjustment:
Use the "+" button to adjust the + side when you want to quicken the rise and use the
"-" button to adjust the - side when you want to make the rise milder.
2. Brake side adjustment:
Select the setting item "BR" by ENTER button and use the "+" button to adjust the +
side when you want to quicker the rise and use the "-" button to adjust the - side
when you want to make the rise milder.
3. When ending setting, return to the initial screen by pressing "EXIT".

14
Adjustment method for CUR curve
•Select CUR at setup item "M"
•Select setup item "R" and make the following adjustments:
1. Curve setup:
Select the setting item '"1:" (1st point), by ENTER button and use the "+" and "-"
buttons to set the 1st point.
Set the throttle curve by sequentially setting "2:" (2nd point) ~ "3:" (3th point).
2. When ending setting, return to the initial screen by pressing the EXIT
TERMS: M-MODE, R-RATE,BR-BRAKE,VTR-VERTICAL,CUR-CURVES
P-TRIGGER POS ,1 ~ 3 - Curves point 1-3.
Adjustment method for VRT curve
•Select VRT at setup item "M"
•Select setup item "R" and make the following adjustments:
1. Forward side adjustment:
Use the "+" button to adjust the + side when you want to quicken the rise and use the
"-" button to adjust the side when you want to make the rise milder.
2. Curve switching point adjustment:
When you want to change the curve switching point relative to the throttle trigger,
select the setting item "P" by ENTER button, and use the "+" and "-" buttons to move
to the point you want to set.

15
2.10 ABS
ABS— Anti-Lock Brake System
When the brakes are applied while cornering with a 4 Wheel Drive or other type of
vehicle, under-steer may occur. The generation of under-steer can be eliminated and
corners can be smoothly cleared by using this function.
•When the brakes are applied, the throttle servo will pulse intermittently. This
will have the same effect as pumping the brakes in a full size car.
•The brake return amount, pulse cycle, and brake duty can be adjusted.
•The region over which the ABS is effective can be set according to the
steering operation.
1. Press "ENTER" to see FUNCTION MENU
2. Use the +/- Keys to select the ABS function and press ENTER.
3. Press ENTER to select PT item. Use +/- to change the value. Range: 0%-100%.
4. Press ENTER to select WD item. Use +/- to change the value. Range: 0-100
5. Press ENTER to select CY item. Use +/- to change the value. Range: 0-30.
6. Press ENTER to select DL Item. Use +/- to change the value. Range: 0-100.
7. Press ENTER to select DT item. Use +/- to change the value. Range: 0- 5
8. Press ENTER to select SM item. Use +/- to change the value. Range: 0-100%.
If this value is 0, disable the steering mix.
9. Press ENTER to select MODE item. Use +/- to change INH, TH, AUX or TH &
AUX.
10. Press EXIT twice to save and return to FUNCTION MENU, press EXIT again to
return to the Main Screen.
TERMS:
PT-Operation Throttle Trigger point
WD-Brake return amount. Sets the rate at which the servo returns versus trigger
operation for brake release. When set to 0%, the ABS function is not performed.
CY-Cycle speed. The smaller of the set value, the faster the pulse cycle.
DL-Delay amount. Sets the delay from brake operation to ABS operation. When set
to 0%, the ABS function is activated without any delay.
SM-Steering Mix
DT-Cycle duty ratio. Sets the proportion of the time of the brakes are applied and the
time of the brakes are released by pulse operation.
MODE-lf it is selected to INH, the function disable. If it is selected to TH, the ABS
function for THROTTLE brake.

16
2.11 MODEL
Press "ENTER" in the power on interface, and enter function menu interface. Press
"+" or "-" to choose MDL, and press "ENTER" to enter MODEL adjusting interface.
1. Press "ENTER" to choose "modOO". (SEL)
2. Press "+" or "-" to choose "mod00~mod15"
3. Press "EXIT" to save your setting and leave SEL interface, and back to the
function menu interlace.
1. Press "+" or "-" to choose "EDT".
2. Press "ENTER" to enter rename mode. Press "+" or "-" to choose "0.1.2....I"
3. Press " " to save your modified and return to the MODEL Screen..
4. Press "EXIT" to save your setting and leave EDT interface, and back to the
function menu interface.
1. Press "+" or "-" to choose "CPY".
2. Press "ENTER" to enter copy mode. Press "+" or "-" to choose "Mod01 … Mod15"
3. Press "ENTER" to save your setting and Press "EXIT" and leave CPY interface,
and back to the function menu interface.

17
2.12 SPEED
Steering Speed
This function include tow items: STEERING SPEED and THROTTLE SPEED.
1. Press "ENTER" to see FUNCTION MENU
2. Use the +/- Keys to select the SPEED function and press ENTER.
3. Press ENTER to select a setting.
4. Use the +/- Key to change the value.
5. Press EXIT twice to save and return to FUNCTION MENU, press EXIT again to
return to the Main Screen.

18
•Quick steering operation will cause momentary under steering, loss of speed, of
spinning. This function is effective in such cases.
•This function limits the maximum speed of the steering servo. (Delay function)
•The steering speed when the steering wheel is operated (TURN direction) and
returned (RETN direction) can be independently set.
•If the steering wheel is turned slower than the set speed, the steering servo is not
affected.
Throttle Speed
•Sudden throttle trigger operation on a slippery road only causes the wheels to
spin and the vehicle cannot accelerate smoothly. Setting the throttle speed
function reduces wasteful battery consumption while at the same time
permitting smooth, enjoyable operation.
•Throttle servo (amp) operation is delayed so that the drive wheels will not spin
even if the throttle trigger is operated more than necessary. This delay function
is not performed when the throttle trigger is returned and at brake operation.
•- Adjustment:
•1 .Select the TH button by +/- Keys.
•2. Press Enter to select SPD. FL item.
•3. Use +/- Keys change the value.
•4. Press exit twice return to the function menu.
Terms
SPD.FL- SPEED FORWARD DELAY Bereich: 0~100%, Standard: 0.
SPD.Bk- SPEED BACKWARD DELAY Bereich: 0~100%, Standard: 0.
2.13 ATS

19
ATS Automatic Start
When the throttle trigger is set to full throttle simultaneously with starting when the
track is slippery, the car wheels will spin and the car will not accelerate smoothly.
When the Start function is activated, merely operating the throttle trigger slowly
causes the throttle servo to automatically switch from the set throttle position to a
preset point so that the tires do no lose their grip and the car accelerates smoothly.
•When the throttle trigger is moved to the preset trigger position (TRI), the
throttle servo moves to the preset position (POS).
•When the throttle trigger is operated slowly so that the wheels will not spin, the
car automatically accelerates to the set speed.
•This function is effective only for the first throttle trigger operation at starting.
This function has to be activated before every start.
•When the throttle trigger is returned slightly, the Start function is automatically
deactivated and the set returns to normal throttle trigger operation.
1. Press "ENTER" to see FUNCTION MENU
2. Use the +/- Keys to select the ATS function and press ENTER.
3. Press ENTER to select TRI item. Use +/- to change the value.
Range: 0%~+100%..
4. Press ENTER to select POS item. Use +/- to change the value.
Range: -100%~100%.
5. Press ENTER to select DLY item. Use +/- to change the value. Range: 0-100.
6. Press ENTER to select MOD item. Use +/- to change INH or RUN.
7. Press EXIT to save and return to FUNCTION MENU, press EXIT again to return
to the Main Screen.
TERMS:
TRI - Throttle trigger position.
POS - Preset position
DLY - ATS Delay time
MOD - ATS Ready setting
2.14 BR_MIX
BR_MIX —BRAKE MIXING
When using a secondary brake system set the BRAKE MIX value to a percentage of
the Throttle Brake.

20
This mixing uses the 2nd channel to control the rear brakes and the 3rd channel to
control the front brakes. This function can be used in conjunction with the TH TRIM
and TH EPA to fine tune the power and balance of the overall braking system.
1. Press "ENTER" to see FUNCTION MENU
2. Use the +/- Keys to select the BR_MIX function and press ENTER.
3. Press ENTER to select a item.
4. Use the +/- Key to change the value.
5. Press EXIT to save and return to FUNCTION MENU, press EXIT again to return
to the Main Screen.
TERMS:
RATE - the rate of brake between 3rd channel and 2nd channel. Default value:
-120% ~ +120%.
EN - the start or close switch of this function. Select "ON" to start the function,
and "OFF" to close the function
2.15 MIX
This function allow customer to apply mixing between the steering, throttle and
channel 3 channels.There are main channel and sub-channel in the MIX selection.
The servo travel value of the sub channel is changed along with the change of the
main channel according to the setting rate.
1. Press "ENTER" to see FUNCTION MENU
2. Use the +/- Keys to select the BR_MIX function and press ENTER.
3. Press ENTER to select a item.
4. Firstly main channel setting. Select channel No. (ST, TH.AUX) by "+" or "-". L and
R separately correspond to the rate of Left and Right servos of the main channel mix
5.Secondly sub channel setting. Select channel No. (ST, TH.AUX) by "+" or "-". L and
R separately correspond to the rate of Left and Right servos selected in the sub
channel.
6. Third Press ENTER to select EN item. Use +/- to select "ON" to enable the
function and "OFF" to disable the function.
7. Press EXIT to save and return to FUNCTION MENU, press EXIT again to return
to the Main Screen.
For example: current setting: ST: L 50% R 30%
TH: L 20% R 50%
EN: select "ON"
If throttle servo is 60% on the right and rudder servo is 50% on the right, and then
after setting, throttle servo is: 50*30%+60%*50%=45%. Throttle servo will act along
withthe action of STEERING servo.
