ROCAM MERCURIO F/1 Quick start guide

INSTRUCTION MANUAL
ASSEMBLY, INSTALLATION, USE AND MAINTENANCE.
Rev. 07/2015
Rocam Losi s.r.l. declines every responsibility on any print and/or transcription mistake contained in this booklet
Rocam Losi s.r.l. can change features and data of this booklet with the proposal of keeping on increase the quality of its products.
Anytime and without notice, this booklet can’t be considered as contract with third parties.
1
Item:
MERCURIO F/1
MERCURIO F/2
Summary
1. Instruction warnings.........................................................................................................2
2. Safety and Right Use Warning.........................................................................................2
3. Warranty..........................................................................................................................2
4. Installation and assembly.................................................................................................2
4.1 Components...............................................................................................................3
5. Cleaning and maintenance ..............................................................................................3
5.1 Burner ........................................................................................................................3
6. Disposal...........................................................................................................................5
EN

INSTRUCTION MANUAL
ASSEMBLY, INSTALLATION, USE AND MAINTENANCE.
Rev. 07/2015
Rocam Losi s.r.l. declines every responsibility on any print and/or transcription mistake contained in this booklet
Rocam Losi s.r.l. can change features and data of this booklet with the proposal of keeping on increase the quality of its products.
Anytime and without notice, this booklet can’t be considered as contract with third parties.
2
1. Instruction warnings
The user must hold the whole instruction manual and store it up in case of use. The
manufacturer does not assume any responsibility for damages incurred due to the failure
of improper use of this manual. All measures in this manual are expressed in mm.
2. Safety and Right Use Warning
Rocam Losi’s products meet the latest technological evolutions and current safety
guidelines. Trolley line MERCURIO, object of this booklet, is projected to be in
compliance with directives and field laws, in order to guarantee a safe and
reliable product.
Any other use will be considered inapposite to the original destination.
Producer do not assume any responsibility for damages caused by an
improper use. Responsibility lies only on user. A proper use also includes
compliance with the instructions for use and installation and any additional documentation
as well as the conditions of inspection and maintenance.
3. Warranty
We thank you for purchasing a Rocam Losi product, designed and produced for a
professional environment. Due to commercial and construction requirements, the
manufacturer reserves the right to make changes in order to enhance the quality and use
of product. Rocam Losi, in compliance with European Community legislation, grants its
products for 12 months. This warranty does not include labour and all replacements
related to an improper use of the good. Any manipulation carried out automatically
excludes the liability of the manufacturer. The products or parts to be replaced or repaired
for unequivocal defects in workmanship and materials used must be in a “free port” at the
offices of the producer, who after a careful inspection, will repair or replace them. The
repairs are carried out exclusively at the headquarters of the manufacturer, and none cost
incurred by the customer for repairs will be refunded by the manufacturer unless expressly
agreed.
4. Installation and assembly
This article is packed and delivered assembled. The manufacturer declines every
responsibility of damage of someone or something caused by the failure to comply with the
instructions of this manual.
Do not make any structural change to the trolley. The elements
composing the trolley (plastic, polyurethane foam, bubble wrap, Styrofoam,
cardboard and so on) must be kept away from children as potential sources
of danger and must be collected and disposed off separately in accordance
with local regulations.

INSTRUCTION MANUAL
ASSEMBLY, INSTALLATION, USE AND MAINTENANCE.
Rev. 07/2015
Rocam Losi s.r.l. declines every responsibility on any print and/or transcription mistake contained in this booklet
Rocam Losi s.r.l. can change features and data of this booklet with the proposal of keeping on increase the quality of its products.
Anytime and without notice, this booklet can’t be considered as contract with third parties.
3
4.1 Components
5. Cleaning and maintenance
The solid wood must be cleaned with a soft cloth. In case of stubborn stains we
recommend the use of a small amount of mild detergent. Do not use corrosive products
nor diluents. WARNING: The solid wood colour may vary during its lifetime due to
several reasons like the direct exposure to the sunlight and the humidity.
Do not insist for too long on the same area during the cleaning operations
and do not press too hard with the cloth in order to avoid the halos and
polishing fading.
Use a soft cloth moistened with a small amount of alcohol or non abrasive products
for the cleaning of the chromed steel parts. After the
cleaning, dry carefully in order to avoid the
persistance of halos.
5.1 Burner
It is recommended to connect a butane or
propane gas cylinder to the provided tube.
A scheme of each knob connected to the
burner is printed on the front panel.
After opening the cylinder valve, light up the
burners in this way:
Press and turn to the left the corresponding
knob, put it on the “Max” position and bring a lighted
match to the burner.
MERCURIO F/1 –F/2
Ref.
Code
Qty.
Description
1
RS125
4
Castor with brake
2
F/1
1
Burner 1 fire
F/2
1
Burner 2 fires
3
1
Tip up dish-holder
4
1
Chromed bottle holder

INSTRUCTION MANUAL
ASSEMBLY, INSTALLATION, USE AND MAINTENANCE.
Rev. 07/2015
Rocam Losi s.r.l. declines every responsibility on any print and/or transcription mistake contained in this booklet
Rocam Losi s.r.l. can change features and data of this booklet with the proposal of keeping on increase the quality of its products.
Anytime and without notice, this booklet can’t be considered as contract with third parties.
4
MERCURIO F/1
N°
Burner
Gas
Pressure
Heat
input
Ø
Nozzle
Heat input
(W)
Min.
Max.
1
Medium
semi-rapid
G30-BUTAN
30 mbar
127 g/h
65mm
450
1750
G 31 PROPANE
37 mbar
127 g/h
65mm
450
1750
MERCURIO F/2
N°
Burners
Gas
Pressure
Heat
input
Ø
Nozzle
Heat input
(W)
Min.
Max.
2
Medium
semi-rapid
G30-BUTAN
30 mbar
127 g/h
65mm
900
1700
G 31 PROPANE
37 mbar
127 g/h
65mm
900
1700
3
Auxiliary
G30-BUTAN
30 mbar
73 g/h
50mm
400
1000
G 31 PROPANE
37 mbar
73g/h
50mm
400
1000
WARNING: check if the cylinder is provided with a pressure regulator in
accordance to the norm UNI-CIG 7432. In case the cylinder is not equipped
with it, insert the regulator when connecting the cylinder to the burner. The
junciton between tube and cylinder has to be done through a mechanical
seal in accordance to the norm UNI80050.

INSTRUCTION MANUAL
ASSEMBLY, INSTALLATION, USE AND MAINTENANCE.
Rev. 07/2015
Rocam Losi s.r.l. declines every responsibility on any print and/or transcription mistake contained in this booklet
Rocam Losi s.r.l. can change features and data of this booklet with the proposal of keeping on increase the quality of its products.
Anytime and without notice, this booklet can’t be considered as contract with third parties.
5
6. Disposal
At the end of its life cycle the device must be disposed according to current
regulations and must, where possible, has to be disassembled and disposed
according to the nature of the various components. The packing materials
(plastic, foam, bubble wrap, styrofoam,cardboard, etc..) Must be kept away
from children as potential sources of danger and must be collected and
disposed separately in accordance with the local regulations. This marking shown on the
product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life.To prevent possible harm to the environment or human
health from uncontrolled waste disposal, please separate this from other types of wastes
and recycle it responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take this item for
environmentally safe recycling. Business users should contact their supplier and check the
terms and conditions of the purchase contract. This product should not be mixed with other
commercial wastes for disposal.
