Rockford Fosgate RFC10HB Guide

Installation &
Operation
RFC10HB – 10 FARAD
HYBRID CAPACITOR
Serial Number: Date of Purchase:

2
INTRODUCTION
TABLE OF CONTENTS
Thank you for purchasing the Rockford Fosgate Hybrid Capacitor.The Rockford Hybrid Capacitors, also known as
Electric Double Layer Capacitors (EDLC) or Super Capacitors, are passive electrostatic energy storage devices.They
are state of the art technology that allows you to put massive power storage in a very small space
What are Rockford Hybrid Capacitors good for?
Some of the most promising applications that have been found for Rockford Hybrid Capacitors are battery and
large audio system performance enhancement. Even the very best batteries, that present day technology has to
offer, have performance limitations determined by the laws of physics and chemistry that govern their operation.
Rockford Hybrid Capacitors supply their energy much faster than a battery.A properly installed Rockford Hybrid
Capacitor can deliver the instantaneous power (Amps) that are commonly demanded by today's large audio
systems.
How do Rockford Hybrid Capacitors compare with Batteries?
Rockford Hybrid Capacitors have approximately 10 times the power density of a same sized battery and the
capability of being charged and discharged over 100 times faster than a battery.This is why they make such great
intermediate power sources. However, Rockford Hybrid Capacitors do not have the characteristic battery limitations
of a short life span, cold intolerance, and critical charge and discharge rates.
What makes Rockford Hybrid Capacitor Cells so special?
The electrode forming process, which produces ultra-dense yet porous hybrid electrodes, and the continuous
operating voltage of 2.7 volts (per cell) give the Rockford Hybrid Capacitor the highest energy storage capacity and
power density of any other commercially available components of comparable size and weight.
To add the finishing touch to your new system order your Rockford Fosgate apparel, which include everything from
T-shirts and jackets to hats and sunglasses.
To get a free brochure on Rockford Fosgate products and apparel,
in the U.S. call 480-967-3565 or FAX [phone].
For all other countries, call +001-480-967-3565 or FAX [phone].
Or, visit our web site at www.rockfordfosgate.com
Introduction . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Instructions . . . . . . . . . . . . . . . . . . . 3
Contents of Carton. . . . . . . . . . . . . . . . . . . 3
Design Features. . . . . . . . . . . . . . . . . . . . . . 4
Safety Features. . . . . . . . . . . . . . . . . . . . . . . . 4
NOTE: Review each section for more detailed information.
If, after reading your manual, you still have questions regarding this product, we recommend
that you see your Rockford Fosgate dealer. If you need further assistance, you can call us direct at
1-800-669-9899. Be sure to have your model number and date of purchase available when you call.
(Outside U.S. call 1-480-967-3565)
Installation . . . . . . . . . . . . . . . . . . . . . . . . 4-7
Installation Considerations . . . . . . . . . . . . . . 4
Mounting Locations. . . . . . . . . . . . . . . . . . . . 5
Wiring the System. . . . . . . . . . . . . . . . . . . . . 5
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Specifications . . . . . . . . . . . . . . . . . . . . . . . . 8
Limited Warranty Information . . . . . . . . . 9
2006 Rockford Corporation.All rights reserved.
Rockford Fosgate, the Rockford Fosgate logo, and the PUNCH logo are either
registered trademarks or trademarks of Rockford Corporation.

3
SAFETY INSTRUCTIONS
Visit our web site for the latest information on all Rockford products.
www.rockfordfosgate.com
This symbol with “WARNING” is intended to alert the user to the
presence of important instructions. Failure to heed the instructions
will result in severe injury or death.
This symbol with “CAUTION” is intended to alert the user to the
presence of important instructions. Failure to heed the instructions
can result in injury or unit damage.
CAUTION: To prevent injury and damage to the unit, please read and follow the
instructions in this manual.We want you to have enjoyment from this
system, not a headache.
CAUTION: If you feel unsure about installing this system yourself, have it installed by a
qualified Rockford Fosgate technician.
CAUTION: Before installation, disconnect the battery negative (-) and positive (+)
terminal to prevent damage to the unit, fire and/or possible injury.
WARNING:To prevent serious personal injury, fire and/or damage, ensure the capacitor
has been properly discharged before servicing the vehicle and/or system
components.
CAUTION: Failure to observe the following safety precautions could result in damage
to the capacitor, vehicle and/or personal injury.
•DO NOT allow metal objects, such as screwdrivers or other tools, to touch both
capacitor terminals at the same time.The result may cause arcing and
possible fire.
•DO NOT use capacitor cells that have signs of damage, including cracks, leaks, or
swelling.
•DO NOT expose capacitor cells to flames, sparks or heat at any time.
•DO NOT immerse capacitor cells in water or allow water to come into contact with
them at any time.
•DO NOT remove the electrolyte filling bolt from the top of a capacitor cell at any
time.
•DO NOT connect the positive (+) wire from the battery to the negative (–) terminal
of the capacitor.
•DO NOT connect the negative (–) wire from the battery to the positive (+) terminal
of the capacitor.
•DO NOT make any connections to a capacitor if the connecting polarity cannot be
properly identified.Applying reversed polarity will damage capacitor cells.
CONTENTS OF CARTON
A model RFC10HB Hybrid Capacitor Module
Installation & Operation Manual
Charging Resistor
Warning Label

4
INSTALLATION
INSTALLATION CONSIDERATIONS
The following is a list of tools needed for installation:
Volt/Ohm Meter
Wire strippers
Wire crimpers
Wire cutters
Felt-tip pen or center punch
#2 Phillips screwdriver
3/16” Allen wrench
5/32” Allen wrench
Battery post wrench
Hand held drill w/assorted bits
Electrical tape
Rubber or snap grommets
Nylon tie straps
Assorted connectors
Adequate Length—Red Power Wire
Adequate Length—Black Grounding Wire
DESIGN FEATURES
The following features are the results of the unique patented manufacturing process that enables the
Rockford Hybrid Capacitor to deliver many charge and discharge cycles with greater energy and power
per unit weight and volume.
High Energy
The amazingly high specific capacitance and lower weight of Rockford's Hybrid Capacitor yields an energy
per kilogram figure that is twice that of any other commercially available Electric Double Layer Capacitor
(EDLC).
More Power
Both the 'per weight' and 'per volume' power density of Rockford's Hybrid Capacitor exceeds that of
other hybrid capacitors in production today.The extremely low internal resistance (ESR) characteristic of
Rockford's Hybrid Capacitor enables them to supply large amounts of instantaneous peak power, when
demanded by the load.
Long Life
Rockford's Hybrid Capacitor has a very long life span as well.They have been subjected to more than
500,000 charge and discharge cycles and only show a small typical loss of capacitance (less than 20%) and
an even smaller than typical increase in ESR (less than 2X).The long life span of the Rockford's Hybrid
Capacitor means that it may never need to be replaced.
Excellent Low Temperature Performance
Rockford's Hybrid Capacitors show very little loss of effective capacitance or ESR, even at temperatures as
low as -°40F (-°40C).
SAFETY FEATURES
LED Display
The display at the top of the Rockford Hybrid Capacitor will show the current voltage at the capacitor.
Warning Buzzer
The warning buzzer will sound if the Rockford Hybrid Capacitor has been wired to a reverse polarity.
Safety Vent
The safety vent ruptures when the internal pressure of capacitor cell has reached 5 ~ 10 kg/cm2.
CAUTION: To prevent injury due to hazardous chemicals, do not touch the capacitor
if the safety vent has ruptured. Have the system looked at by a qualified
technician for repair and/or disposal.
ATTENTION: Safety vent ruptures caused by improper wiring is not covered under
warranty.

5
INSTALLATION
This section focuses on some of the vehicle considerations for installing your new Rockford Fosgate
Hybrid Capacitor. Pre-planning your system layout and best wiring routes will save installation time.
When deciding on the layout of your new system, be sure that each component will be easily accessible
for making adjustments.
CAUTION: If you feel unsure about installing this system yourself, have it installed by
a qualified Rockford Fosgate technician.
CAUTION: Before installation, disconnect the battery negative (-) and positive (+)
terminals to prevent damage to the unit, fire and/or possible injury.
Before beginning any installation, follow these simple rules:
1. Be sure to carefully read and understand the instructions before attempting to install the unit.
2. For safety, disconnect the negative lead from the battery prior to beginning the installation.
3. For easier assembly, we suggest you run all wires prior to mounting your unit in place.
4. Route all of the high current wires close together and away from any RCA cables.
5. Use high quality connectors for a reliable installation and to minimize signal or power loss.
6. Think before you drill! Be careful not to cut or drill into gas tanks, fuel lines, brake or hydraulic lines,
vacuum lines or electrical wiring when working on any vehicle.
7. Never run wires underneath the vehicle. Running the wires inside the vehicle provides the best
protection.
8. Avoid running wires over or through sharp edges. Use rubber or plastic grommets to protect any
wires routed through metal, especially the firewall.
9. ALWAYS protect the battery and electrical system from damage with proper fusing. Install the
appropriate fuse holder and fuse on the +12V power wire within 18” (45.7 cm) of the battery
terminal.
10. When grounding to the chassis of the vehicle, scrape all paint from the metal to ensure a good, clean
ground connection. Grounding connections should be as short as possible and always be connected to
metal that is welded to the main body, or chassis, of the vehicle.
MOUNTING LOCATIONS
Select a dry location that will provide good ventilation around the Rockford Hybrid Capacitor.We
recommend that you mount the capacitor on the floor of the trunk or in a location where
it will be protected from water damage.
• Mount in a location free from grease, water, flames, sparks or heat. Preferably in the trunk of the
vehicle.
• The capacitor should be mounted with the supplied screws as close to the amplifier as possible
keeping the wire runs short. It is recommended that runs be kept less than 24 inches, as this will
help to reduce voltage loss in the cables.
• Mark the location where the capacitor is to be mounted.After wiring the system, mount the
capacitor into place.
WIRING THE SYSTEM
CAUTION: If you do not feel comfortable with wiring your new unit, please see your
local Authorized Rockford Fosgate Dealer for installation.
CAUTION: Before installation, disconnect the battery negative (-) and positive (+)
terminals to prevent damage to the unit, fire and/or possible injury.
CAUTION: Avoid running power wires near the low level input cables, antenna, power
leads, sensitive equipment or harnesses.The power wires carry substantial
current and could induce noise into the audio system.
CAUTION: Improper wiring connections can seriously damage the capacitor and/or
your vehicle. Be sure to carefully follow the connection instructions in this
manual. Improper wiring will void warranty.

6
ATTENTION: Make sure the battery and all other power sources are disconnected.
ATTENTION: When installing high voltage audio equipment, such as capacitors and
amplifiers, we recommend using “full-spec” AWG (American Wire Gauge)
type wire for your power and ground wires.
CAUTION: Ensure correct polarity during the following connections. Failure to do
so may cause damage to the unit when power is applied.
NOTE:If a reverse polarity has been connected to the capacitor, a warning buzzer will sound when
power is applied. Immediately disconnect the capacitor from power, ensure it has been
discharged and reconnected to correct polarity.
1. Attach the ground wire to the negative terminal block of the capacitor.The negative terminal is
marked with a (–) Negative Connections.Attach the other end of the ground wire to the chassis
of the car, ensure there is good metal to metal contact. Ensure that no stray wires are visible.
Ensure all wires are secured. Loose connections will affect the performance of your capacitor,
possibly leading to failure.
2. Attach a fused Power wire to the positive terminal of the capacitor.The positive terminal is the
platinum colored block marked with a (+) Positive Connections. Ensure that no stray wires are
visible. Ensure all wires are secured. Loose connections will affect the performance of your capacitor,
possibly leading to failure.
3. To hook up your amplifier or distribution block, use the available 1/0 AWG and/or 4 AWG
connections.
4. Mount the unit securely in the location decided upon.
Charging and connecting the Hybrid Capacitor to the battery
ATTENTION: Charging your capacitor will ensure that the battery and capacitor voltage
are equalized.This will help prevent arcing when the initial power connection
to the capacitor is made.
Overcharging cells will reduce their useful life span. HINT: Charging cells at an ambient temperature
of less than +77°F (+25°C) will minimize the deterioration of their useful life span (keeping it near their
500,000 cycle expectation).
1. Make sure all power and ground connections are made at the capacitor module.
2. Reconnect the battery and any other power source that may have been disconnected.
INSTALLATION
Keep Grounds
as short as
possible.
Connect to
chassis ground
of vehicle.
Connected to
Amplifier or System
Distribution Block
Can be used as
Ground
Distribution Block
Connected to
Amplifier or System
Distribution Block
Can be used as
Ground
Distribution Block
CHARGING CAPACITOR
Capacitor is charged
when voltage is equal
FINAL CONNECTION
Connect to
chassis ground
of vehicle.
Keep Grounds
as short as
possible.
Blue Wire
Charge
Card
Yellow Wire
Black Wire
Red Wire

7
INSTALLATION
OPERATION
NOTE:If a reverse polarity has been connected to the capacitor, a warning buzzer will sound when
power is applied. Immediately disconnect the capacitor from power, ensure it has been
discharged and reconnected to correct polarity.
3. Connect the Blue wire from the charge card to the Positive (+) power wire leading to the capacitor
module. It is highly suggested that you place a fuse before the capacitor.This is to insure that if the
capacitor were to be placed in reverse polarity it would blow the fuse first, not the cap.
4. Connect the Yellow wire from the charge card to the Negative (-) post on the capacitor.
5. Connect the Red wire to the Positive (+) side and the Black wire to the Negative (-) side of a
12 volt DC power source.When the Green LED light goes out, the capacitor is charged.This will
take approximately 10 minutes.
NOTE:To achieve a more accurate reading, place the red lead of a voltmeter on the side of the charging
resistor leading to the capacitor module (cap side of the fuse) and the black lead to chassis of the
vehicle or to the negative battery clamp.
6. Once a full charge has been reached and the capacitor module reads the same voltage as the battery,
connect the power wire leading to the capacitor module to the positive battery post.Attention, small
sparks may occur.
7. At this point, it is very important to place the yellow warning label on the top of the battery or a
highly visible location.This will let any persons know that an auxiliary form of power is hooked up. It
is very very important that the capacitor module be discharged before performing any kind of service
on the vehicle. It is important to remember that your Rockford Hybrid Capacitor could still be fully
charged and could cause personal injury if not discharged.
8. The Rockford Hybrid Capacitor is now ready for use.
Discharging the Hybrid Capacitor
WARNING:To prevent serious personal injury, fire and/or damage, ensure the capacitor
has been properly discharged before servicing the vehicle and/or system
components.
1. Disconnect the power wire going to the
capacitor module from the battery.
2. Connect the Blue wire from the charge card to
the Positive (+) power wire leading to the
capacitor module.
3. Connect the Yellow wire from the charge card
to the Negative (-) post on the capacitor.
4. Connect the Red and Black wires from the
charge card together.When the Red LED light
goes out, the capacitor is discharged.
NOTE:Again to gain a more accurate reading,
place the red lead of a voltmeter on the
side of the charging resistor leading to the
capacitor module (capacitor side of the
fuse) and the black lead to chassis of the
vehicle or to the negative battery clamp.
Capacitor is discharged
when voltage is Zero
Connect
wires
together
to discharge.
Connect to
chassis groun
d
of vehicle.
Blue Wire
Charge
Card
Yellow Wire
Black Wire
Red Wire
On the top of the Hybrid Capacitor is a blue LED display
that will show the current voltage of the system while it is
on.When the system is off, you can check the current
voltage by pressing the button to the left of the display.
The voltage will be displayed for about 10 seconds.
Voltage Display
Display
Button

8
SPECIFICATIONS
MODEL- 10 Farad Hybrid Capacitor RFC10HB
Rated Capacitance – 77°F (25°C) 10 Farad
(Constant Current Discharge (5A) 15.0v–>3.0v)
Capacitance Tolerance ±10%
Rated Voltage,VR 16.0 Volts
Surge Voltage 18.0 Volts
Maximum Internal Resistance (ESR): <6.5m
Operating Temperature Range* -40 to 140°F
(-40 to 60°C)
Storage Temperature Range -40 to 158°F
(-40 to 70°C)
Input/Output Connections (6) 1/0 AWG and/or 4 AWG
(AWG-American Wire Gauge)
Dimensions:
Height 2.25" (5.72cm)
Width 10.25" (26.04cm)
Length 6.5" (16.51cm)
Weight: 3.31 lbs. (1.5kg)
*Prolonged operation above the operating temperature limit of a cell will greatly reduce its useful life
span. Exposure to temperatures below the operating temperature will reduce the ability of the cell to
easily accept a charge.
Specifications subject to change without notice
INSTALLATION
DISPOSING OF HYBRID CAPACITOR CELLS
A Rockford Hybrid Capacitor cell contains hazardous material, such as Acetonitrile (ACN).You must
follow federal, state, and local laws when disposing of failed or aged cells. For more information, contact
the Customer Support department of Rockford Corp. 1-800-669-9899. Capacitor modules that have
reached their end-of-life can be recycled. Rockford Corp. will take back capacitor modules that need to
be recycled. Rockford does not pay for shipping of returned capacitor modules that are to be recycled.
CAUTION: To prevent injury due to hazardous chemicals, do not touch the capacitor if
the safety vent has ruptured. Have the system looked at
by a qualified technician for repair and/or disposal.

9
Rockford Corporation offers a limited warranty on Rockford Fosgate products on the
following terms:
Length of Warranty
One (1) Year (Proof of purchase required)
If installed by an Authorized Rockford Fosgate Dealer, two (2) years
(Proof of purchase required)
What is Covered
This warranty applies only to Rockford Fosgate products sold to consumers by Authorized
Rockford Fosgate Dealers in the United States of America or its possessions. Product purchased
by consumers from an Authorized Rockford Fosgate Dealer in another country are covered
only by that country’s Distributor and not by Rockford Corporation.
Who is Covered
This warranty covers only the original purchaser of Rockford product purchased from an
Authorized Rockford Fosgate Dealer in the United States. In order to receive service, the
purchaser must provide Rockford with a copy of the receipt stating the customer name,
dealer name, product purchased and date of purchase.
Products found to be defective during the warranty period will be repaired or replaced
(with a product deemed to be equivalent) at Rockford's discretion.
What is Not Covered
1. Damage caused by accident, abuse, improper operations, improper wiring, water, theft.
2.Any cost or expense related to the removal or reinstallation of product.
3. Service performed by anyone other than Rockford or an Authorized Rockford Fosgate
Service Center.
4.Any product which has had the serial number defaced, altered, or removed.
5. Subsequent damage to other components.
6.Any product purchased outside the U.S.
7.Any product not purchased from an Authorized Rockford Fosgate Dealer.
8. Broken or stripped screws.
Limit on Implied Warranties
Any implied warranties including warranties of fitness for use and merchantability are limited
in duration to the period of the express warranty set forth above. Some states do not allow
limitations on the length of an implied warranty, so this limitation may not apply. No person is
authorized to assume for Rockford Fosgate any other liability in connection with the sale of
the product.
How to Obtain Service
Please call 1-800-669-9899 for Rockford Customer Service.You must obtain an RA# (Return
Authorization number) to return any product to Rockford Fosgate.You are responsible for
shipment of product to Rockford.
EU Warranty
This product meets the current EU warranty requirements, see your Authorized dealer for
details.
LIMITED WARRANTY INFORMATION

10
NOTES

11
NOTES

Rockford Fosgate
Rockford Corporation
546 South Rockford Drive
Tempe,Arizona 85281 U.S.A.
In U.S.A., [phone] - Customer Service 1-800-669-9899
In Europe, Fax [phone]
In Japan, Fax [phone]
www.rockfordfosgate.com
04/07 B.M.
1230-53683-02 Printed in China
