Rockford Fosgate Punch PP4-T Original operating instructions

2012
1230-57459-01
Pro speakers
PP4-T PP8-T

•(1) Punch Pro Tweeter
•Mounting hardware
red ring.

3
Specifications subject to change without notice.See figures on following pages.
Punch Pro Tweeters PP4-T PP8-T
Nominal Diameter - inch (mm)
Description
Nominal Impedance (ohms) 4Ω
Frequency Response (Hz)
Crossover Frequency (Hz)
12dB/octave Butterworth Crossover
Voice Coil Diameter - inch (mm)
Fs - Free Air Resonance (Hz)
Qts
Vas - cu. ft. (Liter)
Xmax - inch (mm)
SPL (dB @ 1w/1m)
Power Handling-Watts (RMS / Peak)
Mounting Diameter-inch (mm)
Mounting Depth-inch (mm)
Includes Grille/Trim Ring
Trim Ring Diameter-inch (mm)
Trim Ring Height-inch (mm)
1.5 (38.1)
Pro tweeter
4kHz-20kHz
8Ω
1.5 (38.1)
Pro tweeter
4kHz-20kHz
4.5kHz
-
1.475 (37.5)
3kHz
-
-
0.001 (0.25)
105dB
50/100
4.375 (111.00)
2.59 (65.8)
-
Includes Adapter Plate -
-
-
4.5kHz
-
1.475 (37.5)
3kHz
-
-
0.001 (0.25)
105dB
50/100
4.375 (111.00)
2.59 (65.8)
-
-
-
-
SPECIFICATIONS
FEATURES
ICC (Integrated Concealed Crossover)
For the PP4-T and PP8-T, the crossover is
integrated into the back cover of the tweeter.
This crossover allows for easy connection of
the tweeter without the need for an external
crossover. Just connect the terminals at the
speaker,see below.

5.28"
(134.00mm)
3.45"
(87.68mm) 4.88"
(124.00mm)
Diameter
2.59"
(65.80mm)
4.33"
(110.00mm)
3.24"
(82.27mm)
4

Pour les modèles PP4-T et PP8-T, le filtre de coupure est intégré au haut-parleur, si Para el PP4-T y el PP8-T, el cruce es un diseño integral del altavoz. Por lo tanto, no se
ment. La borne positive du haut-parleur est indiquée par un anneau rouge.positivo del altavoz está identificado con un símbolo anillo rojo.

Per progettazione, il crossover del PP4-T e del PP8-T è incorporato nel diffusore.
Bei den Modellen PP4-T und PP8-T ist das Cr
ossover ein integrales Design des
Der positive Anschluss des Lautsprechers ist mit einem roter Ring markiert.
identificato dal anello rosso.

7
4.375" (111.00mm)
Hole Cutout
Mounting Holes
4.88" (124.00mm)
1.00"
(25.40mm)
Verify Scale
Before Using
Template
1.00"
(25.40mm)
Mounting Template

8
1, Hold the phase plug firmly,release
screw from back of motor to remove
phase plug.
2, Disconnect the connectors and
remove motor cover.
3, Unscrew the screws from housing
to remove it from motor.
4, Lift diaphragm/coil assembly from motor.
8, Fit the screw with flat washer from motor
cover,make sure screw tip extends above
diaphragm,then carefully fit the phase plug
from front and move the screw back a little
until phase plug sits in pole piece.Hold the
phase plug firmly and secure it with screw.
7, Align connectors in motor cover
with tweeter and fit cover.
6, Align the pins on housing with holes in
plastic then secure housing with screws.
5, Take out new diaphragm/coil assemly,
align holes in plastic with rivets on top
plate and fit to motor carefully.
Pro Tweeter Diaphragm Replacement
