Rockford Fosgate T4652-S Guide

I )
vv
E
Component
Systems
T4652-S
-
6.5''
Serial
Number:
------
Installation
&
Operation
Installation
et
fonctionnement
lnstalacion
y
funcionamiento
Einbau
und
Betrieb
lnstallazione
e
funzionamento
Date
of
Purchase:
------

SAFETY
CAUTION:
Before installation, disconnect
the
battery
negative
(-)
terminal
to
prevent damage
to
the
unit, fire
and/or
possible injury.
Lt.
PRACTICE
SAFE
SOUND™
Continuous
exposure
to
sound
pressure
levels
over
I
OOdB
may
cause
permanent
hearing
loss. High
powered
auto
sound
systems
may
produce
sound
pressure
levels well
over
130dB.
Use
common
sense
and
practice
safe
sound.
CARTON CONTENTS
(1)
Set
T4
Series
Speakers
with
Tweeters
and
2-Way
Cros
s
overs
• (1)
Set
of grilles/trim rings
(1)
Set
of
tweeter
trim
rings
Tweeter Mounting
Hardware
with
Surface,
Angle,
and
Flush
Mounts
INSTALLATION CONSIDERATIONS
Before
beginning
any
installation, follow these simple rules:
I.
Be
sure
to
carefully read and understand the instructions before attempting
to
install
these speakers.
2. For safety, disconnect the negative lead from the battery prior
to
beginning
the
in
stallation.
3.
For easier
assembly,
we
suggest
you
run
all
wires prior
to
mounting your speakers
in place.
4. Use
high
quality connectors for a reliable installation and
to
minimize
signal
or
power loss.
5.
Think
before
you
drill!
Be
careful not
to
cut
or
drill
into gas tanks,
fuel
lines,
brake
or
hydraulic
lines,
vacuum lines
or
electrical wiring when working
on
any
vehicle.
If
installation
in
a boat, take care
not
to
cut
or
drill
through
the
main
hull.
6. Never run wires underneath the vehicle.
Running
the wires inside
the
vehicle
or
hull
area provides the best protection.
7.
Avoid
running wires over
or
through sharp edges.Use rubber
or
plastic
grommets
to
protect any wires routed through metal, especially the
firewall.
2
I.
MouNTING
Determine where the speakers
will
be mounted. Ensure
an
area large enough for
the speaker
to
mount
evenly.
Be
sure that the mounting location
is
deep enough
for the speaker
to
fit;
if
mounting
in
a door, operate
all
functions (windows, locks,
etc.) through their entire operating range
to
ensure there
is
no obstruction.
2.
Refer
to
the specification chart
to
determine the proper diameter hole
to
cut
for your speaker model.The template provided also
gives
the proper cutout size.
3.
Mark
the locations for the mounting screws.
Drill
the holes with a
1/8"
bit.
4.
Feed
the
speaker wires through
the
cutout and connect
to
the
speaker terminals.
Be
sure
to
observe proper polarity when connecting the wires.The speaker's
positive terminal
is
indicated with a
"+".
5.
On models with slotted holes,
fit
the speaker into the cutout and
install
the
screws
in
the slots
at
the top and bottom.This
will
allow you
to
rotate
the
speak-
er
to
match the remaining mounting holes.When
aligned,
tighten the screws.
6. Tighten the screws
until
the
speaker
is
snug
in
place
to
prevent rattling. Do not
over tighten the screws.
Discreet
Dual
Clamp
(DOC™)
Tweeter
Mount
Every
aspect
of
the
new
Tweeter
design
has
been
completely
re-engi-
neered
to
allow
for
maximum
ease
of
installation
and
fitment.This
opti-
mized
patent
pending
design
provides
concentric
clamping
pressure
around
the
perimeter
of
the
mounting
hole
.
The
"mounting
cups"
are
in
fact
not
"cups"
at
all,
but
rather
unobtrusive
"clamps
"
th
at quickly
and
easily
mount
in
a
standard
1.75 inch
(45mm)
hole
saw
opening
with
a single
center
screw
securing
with
balanced
pres-
sure
to
both
faces
of
the
mounting
surface.
From
there,
the
tweeter
sim-
ply
snaps
into
place
and
is
secured
by
a
snap-on
trim
ring.
Removal
is
easy
if
needed.
The
protective
grille
on
the
tweeter
is
non-removable
and
an
intergral
part
of
the
design.
Use
tip
of
a
small
flat
screwdriver
to
remove
tweeter
Example
of
Discreet
Dual
Clamp
(DDCTM)
Tweeter
Mounting
(Flush Mount}

SPECIFICATIONS
T4
Components
T4652-S
Nominal
Diameter-
inch
(mm)
6.5
(165)
Description
Component
System
Nominal
Impedance
(ohms)
Frequency
Response
(Hz)
Crossover
Frequency
(Hz)
High
-
Pass
Butterworth
Crossover
Low
Pass
Butterworth
Crossover
Voice
Coil
Diameter-
inch
(mm)
Fs
-
Free
Nr
Resonance
(Hz)
Qts
Vas
-
cu.
ft.
(Liter)
Xmax-
inch
(mm)
SPL
(dB@
1w/1m)
Power
Handling-Watts
(RMS
I
Peak)
Rec.
Amp
Power-Watts
(RMS)
Mounting
Diameter-inch
(mm)
Mounting
Depth-inch
(mm)
Includes
Grille/Trim
Ring
Trim
Ring
Diameter-inch
(mm)
Trim
Ring
Height-inch
(mm)
Woofer
6.69"
(170mm)
0
5.67"
(144mm)
40
40Hz-
30kHz
3kHz
12dB/octave
12dB/octave
1.5
(38)
52
0.58
0.59
(16.74)
0.5
(12.6)
89dB
150/300
37.5W-150W
5.
67
(144)
2.79
(71)
YES
7.14
(181)
0.95
(24)
6.18"
(157mm)
Diam
eter
3.22"
(82
mm)
10
10
-on-
Ax
is
100
100
SPL
(1
W1
M)
•Impedance
-30-D
eg
Off
Axis
1000
1000
Frequency (Hz)
-Impedance
10000
10000
Frequency responce includes summed
Far
-F
ield
and
Near-Field IEC60268-5 baffle measurements.
Tweeter MountingOptions
Surface
Mount
4.57"
1--
--
(116mm) _ _
......._,
4.09"
f--
--
(104mm)
--
.j
ComponentCrossover
Specifications
subject
to
change
without
notice.
3
100000

T4652-S Component
Wiring
I. Use illustration for
proper
connection.
2.
Be
sure
to
maintain speaker polarity.
Axis
ON-OFF
Switch
WIRING
I.
Set
to
ON
or
OFF
to
match position
of
tweeter
relative
to
listener. Default
OFF
position satis-
fies most installations.
dB
Switch
I.
OdB
matches
the
amplitude (no increase/no attenuation) of
the
tweeter
to
the
same level as
the
mid-range (woofer).
2.
+2dB increases and -2dB reduces
the
amplitude
of
tweeter
in
relation
to
the
mid-range, (ideal
when matching offset installation l
ike
tweeters located
high
in
door
panels and midranges low
in
kick panels).
Tweeter
On-Axis
Tweeter
Off-Axis
Tweeter
Axis
Switch
·----
------
-
--
-
-----------
--
--
--
--
-.---
--
--------
·
(
+::'
+2dB
Wo
of
er
(
WFR)
Tweeter
(TWT)
...
-2d8
/
-
-
-
~~~
......
·-.
.·
~--------------------------'
_____
....
..
.
..
Tweeter
Attenuation
Switch
\:?
.
9,!?_/
4

WIRING
T4652-S
Bi-Amp
Cossover
Wiring
I.
Use illustration for
proper
connection and be sure
to
maintain speaker polarity.
2.
Remove 4 screws from crossover bottom
to
detatch cover.
3.
When
BI-AMP
switched OFF for
one
amplifier, use only "TWT" input.
4.
When
BI-AMP
switched
ON
for
two
dedicated amplifier, use both"TWT" and "WFR" inputs.
\
Default
Setting
-----
....
/.··
81-AMP·
••
\
/OFF-,
rON
',
-
-
--
--
--------------------------------------------~-...1
IB
r)
Crossover
Cover
Removal
Remove
4
Screws
From
Bottom
to
Detatch
Cover
..
-
--
--
..
·...
..
..
....
..
...
\
~
~
..
T~l
\
. .
'.:TWT
-
+WFR
-
•TWT
,~
,'
·..
....
.
..
··"
·-
--
----
Standard
Mode
·----
.
..
.•.
:.:··/
WFR
Not
-
---
------~
-
i:-~~-~-~-~~~-
-
---
----------------
-
----
-
--·
• •
• •
• •
•
""'kfilldlbsqoro
•
• •
• •
• •
• •
5
..
----
....
/.··
81-AMP
·
·.
\
.:OFF-,
rON·.
~
..
j
~
r)
•
...........__ r
..
..
....·
··
'
Woofer
(WFR)
Tweeter
(TWT)
Tweeter
(TWT)

Fran~ais
Lh_ MISE EN GARDE: avant d'entamer !'installation, deconnectez Ia broche negative (-)
• de Ia batterie pour eviter tout risque de blessures,d'incendie ou de dommages al'appareil.
PRATIQUEZ UNE ECOUTE SANS RISQUESMo
Une exposition continue a des niveaux de pression acoustique supe r ieurs
a I 00 dB pe ut causer une perte d'acuite aud i tive perman enc e. Les
systemes audio de fo r te puissance pour auto peuvent produire des
niveaux de pression acoustique bien au-dela de I30 dB. Faites preuve de
bon sens et pratiquez une ecoute sans risques
Notes pour !'installation
Avant de commencer l'installation, suivez les reg!es ci-dessous :
I. Veillez abien lire et comprendre les instructions avant d'essayer d'installer les haut-par-
leurs.
2.
Par mesure de securite, debranchez le fil negatif de Ia batterie avant de commencer !' in -
stallation.
3.
Pour faciliter le montage des haut-parleurs, il est conseille d'installer taus les cables au
prealable.
4. Utilisez
des connecteurs de haute qualite pour assurer une installation fiable et reduire au
minimum
Ia perte de signal ou de puissance.
5. Reflechi
sse z bien avant de percer.Veillez a ne pas Couper ou percer le reservoir
d'essence , le diblage electrique ou les conduites de carburant, de freinage hydraulique ou
de depression en travaillant sur un vehicul e. En cas d'installation sur un bateau,veillez ane
pas
couper ou percer Ia coque principale.
6. Ne jamais faire passer de fils sous le vehicule. Leur installation al'interieur du vehicule ou
de Ia coque assure Ia meilleure protection.
7. Evitez de faire passer des fils sur des bords tranchants ou dans des orifices a aretes vives.
Utilisez
des bagues en caoutchouc ou en plastique pour proteger les fils traversant une
plaque de metal, notamment le tablier.
Montage
I. Determinez !'emplacement des haut-parleurs.Veillez ace que Ia surface plane soit assez
grande
pour assurer un contact uniforme du haut-parleur.Verifiez que I' emplacement est
assez profond pour le haut-parleur ; en cas de montage dans une portiere,actionnez toutes
les commandes (fenetres, serrures,etc.) jusqu'aux extremites de leurs courses pour vous
assurer qu'il n'y a pas d'obstruction.
2. Consultez
le tableau des caracteristiques pour determiner le diametre de I' orifice a decouper
pour votre modele de haut-parleur. Le gabarit fourni donne aussi le bon diametre de
decoupe.
3. Marquez
I' emplacement des vis de montage. Percez le s trous avec une m ec he de 1/8 de
pouce (3,2 mm).
4. Faites passer les
fils de haut-parleur atravers !'orifice decoupe et branchez-les aux barnes du
haut-parleur.Veillez abien respecter Ia polarite Iars du branchement. La borne positive du
haut-parleur est indiquee par un «+ ».
5. Sur les modeles a trous allonges, mettez le haut-parleur en place dans Ia decoup e et installez
les
vis dans les trous du haut et du bas.Vous pourrez alors faire tourner le haut-parleur pour
!'aligner sur les autres trous de montage. Une fois cet alignement effectue, serrez les vis.
6. Serrez les vis jusqu'a ce que le haut-parleur soit bien ajuste, de t.u;:on aprevenir tout cli-
quetis, mais evitez tout sen-age excessif.
T4652-S & S composants de cablage
I. Utiliser !'illustration pour une bonne connexion.
2. Assurez-vous
de maintenir orateur polarite.
Axis ON-OFF
I. Regie sur ON ou OFF match a Ia position relative de tweeter al'auditeur. Par defaut OFF satis-
fait
Ia plupart des installations.
Switch dB
I. OdB correspond a!'amplitude (pas d'augmentation I sans attenuation) des le tweeter au meme
niveau que le milieu de gamme (woofer).
2. +2dB augmen
te -2dB et reduit !'amplitude de tweet er en rapport a Ia moyenne gamme, (ideal
pour adapter!'installation offset comme les tweeters situe en haut des panneaux de porte et
Midranges faible en kick panneaux).
T4652-S Bi-Amp Cossover cablage
I. Utiliser !'illustration pour Ia connexion et assurez-vous de maintenir orateur polarite.
2. Suppression de 4 vis de liaison abas detatch couverture.
3. BI-AMP Lorsque l'arret d'un amplificateur, utilisez uniquement ' 1WT" input.
4. Lorsque BI - AMP tension pour deux dedies amplificateur, utiliser les deux "TWT" et 'WFR"
inputs.
6
Espanol
A\ PRECAUCION:Antes de Ia instalacion, desconecte el terminal negativo de Ia bater ia
~ (-)para prevenir dafio a Ia unidad, incendio y/o posibles lesiones.
PRACTIQUE EL SONIDO SEGURO
El contacto commuo con n1veles de pres16n de somdo supenorcs a I00 dB
puede causar Ia perd1da permanente de Ia aud1c1on Los Sistemas de somdo p ara
autom6v1les de alta potenCJa pueden producw niveles de pres1on de somdo
supenores a los 130 dB. Use su sentido comun y practique el sonido seguro.
Consideraciones para I~ instalaci6n
Antes de comenzar cualquier instalaci6n, si ga estas simples normas:
I. Asegurese de leer cuidadosamente y de entender las instrucciones antes de tratar de instalar
estos altavoces.
2. Por seguridad, desconecte el conductor negativo de Ia bateria antes de comenzar Ia insta-
lacion.
3. Para facilitar el montaje,sugerimos que tienda todos los cables antes de montar sus altavoces
en su sitio.
4. Utilice conectores de alta calidad para tener una instalacion confiable y para reducir al mini-
ma las perdidas de sefial o de potencia.
5. ;Piense siempre antes de perforar!Tenga cuidado de no cortar ni perforar en tanques de
combustible,tuberias de combustible, frenos o hidraulicas, tuberias de vacio o cableado elec-
trico al trabajar en un vehiculo. Si Ia instalacion se hace en un bote ,tenga cuidado de no cor-
tar ni perforar a traves del casco principal.
6. Nunca tienda cables abajo del vehiculo.Tender los cables
adentro del vehiculo o casco pro-
porciona Ia mejor protecci6n.
7. Evite tender cables arriba o a traves de bordes filosos. Use arandelas aislantes de caucho
para proteger los cables tendidos a traves
de metal, especialmente Ia mampara cortafuegos.
Montaje
I. Determine adonde se montara los altavoces.Asegurese de que haya un area suficientemente
grande para
montar de manera plana el altavoz.Asegurese de que ellugar de montaje sea
suficientemente profunda para
que quepa el altavoz, si se monta en una puerta,accione todas
las funciones (ventanas, cerradura, etc.) en toda su gama de funcionamiento para asegurarse
de que no haya obstrucciones.
2. Consulte
Ia tabla de especificaciones para determinar cuales son los diametros correctos
para el agujero a cortar para su modelo de altavoz. La plantilla proporcionada tambien le da
Ia medida correcta del recorte .
3. Marque las localidades para los tomillos de montaje. Perfore los ag uj e ros usa ndo una broca
de 1/8 pulg.
4. Tienda los cables del altavoz a traves del recorte y conecte a los terminales del altavoz.
Aseg(Jrese
de usar Ia polaridad correcta al conectar los cables. El terminal positive del altavoz
esci identificado con un simbolo "+ ...
5. En los modelos con agujeros ranurados, coloque el altavoz en el recorte e instale los tornil-
los
en las ranuras en Ia parte superior e inferior. Esto le permitiril h acer girar el altavoz para
que coincida con los agujeros de montaje restantes. Una vez alineados,apriete los tornillos.
6. Apriete los tornillos hasta que el altavoz este ajustado en su sitio para evitar vibraciones. No
apriete demasiado los tornillos.
T4652-S Componente de cableado
I. Utilice Ia ilustraci6n para una correcta conexi6n.
2. Aseg(J rese de mantener Ia polaridad de los altavoces.
Eje de encendido y apagado
I. En ON u OFF para que coincida con Ia posicion de los tweeter en re lacion con el oyente. Por
defecto posicion OFF cumple Ia mayoria de las instalaciones.
dB
I. Coincide con Ia amplitud OdB (sin aumento o no de atenuaci6n), de el tweeter en el mismo
niv el que los de gama media (woofer).
2. +2B
de aumento y -2dB reduce Ia amplitud de l os tweeter en relacion con Ia gama media, (ideal
cuando se pongan en venta compensar
Ia instalacion tweeters de alta como situado en los pan-
eles
de puerta y en el tiro bajo midranges paneles).
T4652 Bi-Amp Cossover de cableado
I. Utilice Ia ilustraci6n para Ia correctaconexi6n y asegurese de mantener Ia pol ar idad de los
altavoces.
2. Retire lo s 4 tornillos de Ia parte infe ri or de cruce detatch a cubrir.
3. Cuando BI-AMP apagado de un amplifi ca dor, utilice solo "TWT'' de entrada.
4. Cuando BI-AMP encendido durante dos dedicados amplificador, use tanto ''TWT" y "WFR"
insumos .

Deutsch
.&.
VORSICHT:
Entfemen Sie
vor
dem
Einbau
den
negative Batteriepol, um Schiiden am
Geriit, Feuer bzw. moglicheVerletzungen zu vermeiden.
PRAKTIZIEREN
SIE
SICHEREN
SOUND
Fortgesetzte
Ge
rauschdruckpegel von
uber
I
00
dB
konnen beim Menschen zu
perm
ane
nt
em
Horv
erlust fuhren.
Leis
tungsstarkeAutosoundsysteme konnen
Gerauschdruckpegel erzeugen, die weit
uber
130
dB liegen. Bitte wenden
Sie
gesunden Menschenverstand
an
und praktizieren
Sie
sicheren Sound.
Einbauuberlegungen
Befolgen Sie
vor
dem
Einbau
diese
einfachen Regeln:
I.
Lesen Sie dieAnleitung sorgf.iltig, bevor
Sie
versuchen diese l.autsprecher einzubauen.
2. Entfemen
Sie
vor dem Einbau aus Sicherheitsgriinden das negative
Kabel
von
der
Batterie.
3.
Um
die Montage zu erleichtem,empfehlen wir aile Kabel
vor
der
Befestigung lhrer l.autsprecherzu
verlegen.
4. Vervvenden Sie nur Qualitiitsstecker, um einen zuverlassigen Einbau zu gew3hrleisten und S
ignal-
und Stromverlust zu minimieren.
5. Denken Sie nach,bevor Sie bohren!Achten
Sie
darauf, niche
in
den Benzintank, die Benzin-, Brems-
oder
hydraulischen Leitungen,Vakuumleitungen
oder
Elektrokabel zu schneiden
oder
zu bohren,
wenn Sie am Fahrzeug arbeiten.Achten
Sie
beim Einbau
in
einem Boot darauf, niche durch den
Bootsrumpfzu schneiden
oder
zu bohren.
6.
Verlegen
Sie
Kabel
nie
unter
dern Fahrzeug. Die Kabel
im
Fahrzeug
oder
Bootsrumpfzu verlegen,
bietet
den
besten Schutz.
7. Vermeiden
Sie
es,Kabel iiber scharle Kanten zu verlegen.Verwenden
Sie
Gummi-
oder
Plastikrlnge,
um Kabel zu schiitzen, die durch Metall verlegt werden (besonders die Feuerwand).
Befestigung
I.
Entscheiden,
wo
die l.autsprecher befestigt
werden
sollen. Gewahrleisten,dass
der
Pl
atz
ausre-
icht,
um
den
l.autsprechergleichmaBig zu befestigen. Gewahrleisten, dass die Befestigungsstelle
ausreichendeTiefe fur
den
l.autsprecher hat; beim Einbau in
einer
Tiire a
ile
Funktionen (Fenster,
Schloss usw.)
in
ihrem ganzen Bereich ausprobieren
um
zu gewahrleisten,dass keine
Blockierung
eintritt
2. Die
Tabelle
in
denTechnischen
Daten
gibt
den
richtigen Lochdurchmesser fur lhr
l.autsprechermodell
zum
Ausschneiden an. Die beiliegende Schablone zeigt ebenfalls die richtige
AusschneidegroBe an.
3. Die Stellen fur die Befestigungsschrauben markieren. Die L
och
er
mit
einer
118-Zoll (3,2 mm)
Bohrerspicze bohren.
4. Die l.autsprecherkabel durch das Loch fuhren und an den l.autsprech
era
usgiingen anschlieBen.
Beim AnschlieBen d
er
Kabel die ordnungsgemiiBe Polaritiit beachten.
Der
positiveAnschluss
des
l.autsprechers ist mit einem
,+"
markiert.
5.
Bei
Mod
ellen mitgeschlitzten Lochern den l.autsprecher
in
das Loch einpassen und die
Schrauben in
den
Schlitzen
oben
und unten befestigen. Dadurch konnen Sie den Lautsprecher
so
drehen
, dass die iibrigen Befestigungslocher passen. Nach
der
Ausrichtung die Schrauben
anziehen.
6. Die Schrauben anziehen, bis
der
l.autsprecher eng an seinem Platz anliegt,
um
Klappem zu ver-
hindem.
Die
Schrauben niche zu fest anziehen.
T4652-S KomponenteVerdrahtung
I. Verwenden
Sie
fur die richtigeVerbindung
Illu
stration.
2. Stellen Sie sicher, dass dieAufrechterhaltung l.autsprecher Polaritiit.
Axis ON-OFF-Schalter
I. Auf
ON
oder
OFF.
um Position
der
HochtOner relativ zum Horer.Standard-OFF-Position
entspricht den meisten lnstallationen.
dB-Schalter
I. Mit
der
Amplitude 0 dB (keine Zunahme
I
keine Diimpfung) v
on
der
Hoch
toner
auf
der
gle-
ichen Ebene wie die Mid-Range-(TT).
2. +2dbB -2dB
erh
oht und verringert dieAmplitude
der
Hochtoner
in
Bezug aufdie
Mid
-Range-,
(ideal,
wenn
Offset-Installation
Hocht
o
ner
hoch wie inTiirverkleidungen und MitteltOner gering
Kick
Pl
atten).
T4652-S Bi-Amp CossoverVerdrahtung
I. V
erwe
nd
en
Sie
fur
di
e richtigeVerbindung Illustration und v
ergew
iss
er
n
Sie
sich, um
l.autsprecher Polaritiit.
2. Ne
hm
en
Si
e 4 Schrauben von uncen nach
Crossover
detatch
deck
en.
3.
Bei
der
Bi-Amp ausgeschalt
et
fu
r einenVerstiirker,
verw
e
nden
Sie nur
''TWT"
In
put.
4.
Bei
der
Bi-Amp eingeschaltet fur zwei spezie
ll
eVerstiirker, sowohl
"'TWr'
und
'W
F
R"
Eingiinge.
7
Italiano
A\
ATTENZIONE:
Prima dell'installazione, scollegate
il
terminale
~
negativo (-) della bacteria
per
evitare danni all'unici, pericoli d'i
nce
ndio
e/o
potenziali lesioni
personali.
OSSERVATE LE
REGOLE
DEL
"SUONO
SENZA
PERICOLI"
La
costantc cspos1Z1ore
a
'
,e
ll d1
il
'
ess1onc
acust10 al d1sopr
il
cl
e1
I
C>Jc
8
posso
no
ca
u
sa
le ld
pe1
dta
pc1
rnc.nente dell'ud1
to
I s1s:ern
aucl
1o ad a
ltc1
po'cr
' Zo
po
sso
no p1o
du1
re l
1vcl
l' d1
pr
ess
1one
ac
us
l1
ca
ben
SL..pe
,·,orl dl I30dB S1
co'"
'c
a
d
b.Jor sen
so
e l'os
se
1
Jdnza
delle
re~ole
eel suo
no
se
n
za
per1co
l ·
Considerazioni sull'installazione
Prima di iniziare qualsiasi
operazione
d'installazione,
vi
consigliamo
di
seguire
queste
semplici
regole:
I. Assicuratevi
di
aver letto
tutte
le istruzioni con cura e
di
averle capite prima
di
effettuare qualsiasi
tentativo d'installazione neiconfronti de
ll'
uniti.
2. Per motivi
di
sicurezza,scollegate
il
cavo negativo dalla batteria prima
di
dare
l'avvio
all'installazione.
3.
Per
facilicare
il
montaggio,
vi
suggeriamo
di
far sconrere
tutti
i
fili
prima di montare
Ia
vostra unitii
nella sua ubicazione.
4. Usate connettori
di
alta
qualici.
per
garantire un'installazione che
di
affidamento e
per
ridunre
al
minimo
Ia
perdita
di
segnali o
di
potenza.
5.
State attenti prima
di
trapanare! Cercate
di
non trapanare e
di
non incidere i serbatoi della benzina;
le
co
ndutture del carburante,dei freni, del sistema idraulico e a depressione; nonche i
fili
elettrici
quando state lavorando su qual
siasi
veicolo.
6.
Non
fate
mai
sconrere i
fili
sotto
il
veicolo.Avrete
Ia
protezione migliore faccendo sconrere i
fili
all'intemo del veicolo.
7.
Evicate
di
far
sconrere i
fili
sopra o attraverso delle estremitii
affilate.
Usate guamizioni
di
tenuca
in
gomma o in plastica
per
proteggere
qualsiasi
filo
che
passi attraverso
de
l metallo, soprattutto
il
parafiamma.
Montaggio
I.
Decidete
dove
montare
gli
altoparlanti.Assicuratevi
che
sia un'area abbastanza grande
per
poter
montare
l'altoparlante a livello e abbascanza profonda
per
poterfo collocare
comodament
e.
Se
lo
montate
all'intemo
di
uno
sportello,controllate
tutte
le funzioni (finestre,
serrature
,ecc.), una
alia volta,
per
assicurarvi
che
non
ci siano ostruzioni.
2.
Fate riferimento alia tabella delle specifiche
per
stabilire
il
diametro
conretto
del foro
che
dovrete
praticare
per
il
modello del
vostro
altoparlante.
II
modello
fomito
anche da
Ia
dimen-
sione adeguata del ritaglio.
3.
Marcare
le
posizioni
per
le
viti
di
montaggio. Praticare ifori
con
una punta da trapano
di
liB
di
pollice (3,2 mm).
4. Passare i
cavi
del diffusore tramite l'apertura e collegarli
ai
terminali.Verificare che
Ia
polarici sia
corretta
quando
si
collegano i cavi.
II
terminale positivo del diffusore eidentificato dal "+".
5. Nei modelli
con
fori a slot,adattare
il
diffusore nel
foro
ricagliato e inserire
le
viti
negli
slot
in
alto e
in
basso. Cosl facendo
si
potr.\
ruotare
il
diffusore
per
allinearlo
con
i rimanenti
for
i di
montaggio.
Serrare
le
viti
quando
si
e
ottenuto
l'allineamento.
6.
Per
evitare
rumore
dovuto
a vibrazioni
serrare
le viti finche
il
diffu
sore
non
sia
sa
ldamente
in
posizione.
Non
serrare le viti in
modo
eccessivo.
T4652-S Componente Cablaggio
I
. U
sa
illustrazi
one
per
Ia
conretta connessione.
2.
Ricordati di ma
ntenere
Ia
polarici dei diffusori.
AsseON-OFF
I. lmpostato su
ON
o OFF
per
corrispondenza di posizione rispetto
al
cweeter
ascoltatore.
Default OFF posizione
so
ddis
fa
Ia
maggior
parte
degli impianti.
dB
I.
OdB
corr
i
spo
nde
l'ampiezza (nessun aume
nto
I
no
atte
nuazione) di
il
tweeter
eallo
stesso
livel-
lo,
co
me
il
m
id
-range (woofer).
2. +2dB aumenta -2dB e riduce l'ampiezza del
tweeter
nella rispetto
al
mid-range, (ideale quando
corrispondenti
compensare
l'installazione
come
tweeter
situato
in
alto pannelli
porta
e
midrange a basso
contenuto
di calcio pannelli).
T4652-S Bi-Amp
Wiring
Cossover
I. Usa illustrazione
per
Ia
corretta
conness
io
ne
ed
esse
re
centi di
mantenere
Ia
polariti d
ei
diffu-
sori.
2. 4 Rimuovere le
viti
dal fondo di crosso
ver
deta
tch
cope
ntina.
3.
Quando
BI
-AMP s
pento
p
er
un amplificatore,utilizzare
so
lo
"'TVVT''
in
put.
4.
Quando
BI-AMP
attivata
per
due amplificatore dedicate,l'uso sia
'
'TWT
"
e
'WFR"
ingressi.

T4652-S
Component
System
1.00"
(25mm)
Verify Scale
Before Using
Template
Mounting
Template
T4652
Midrange
Mounting
Holes
6.18"
(157mm)
_
__,
+
T
4652
Midrange
Hole
Cutout
5.67"
(144mm)
/
I
I
I
I
,
....
I
\
'
/
'
/
Tweeter '
'
\
'
+-
\
\
.,,
I
1.75"
(44mm)
/
'
/
'
-----

LIMITED
WARRANTY
STATEMENT
Rockford Corporation offers a limited warranty
on
Rockford Fosgate products
on
the
following terms:
Length
of
Warranty
Speakers-
IYear. Any Factory Refurbished
Product-
90 days
(receipt
required)
What
is Covered
This warranty applies only
to
Rockford Fosgate products sold
to
consumers
by
Authorized Rockford Fosgate
Dealers
in
the
United States
of
America
or
its possessions. Product purchased
by
consumers from an
Authorized Rockford Fosgate Dealer
in
another
country
are
covered only
by
that
country's Distributor and
not
by
Rockford Corporation.
Who
is
Covered
This warranty covers only
the
original purchaser
of
Rockford product purchased from an Authorized
Rockford Fosgate Dealer
in
the
United States.
In
order
to
receive service,
the
purchaser must provide
Rockford with a copy
of
the
receipt stating
the
customer
name, dealer name, product purchased and date
of
purchase. Products found
to
be defective during
the
warranty period
will
be repaired
or
replaced
(with a product deemed
to
be equivalent)
at
Rockford's discretion.
What
is
Not
Covered
I.
Damage caused
by
accident, abuse, improper operations,water, theft, shipping
2.
Any
cost
or
expense related
to
the
removal
or
reinstallation
of
product
3.
Service performed
by
anyone
other
than Rockford
or
an Authorized Rockford Fosgate Service
Center
4.
Any product which has had
the
serial number defaced, altered,
or
removed
5.
Subsequent damage
to
other
components
6.
Any product purchased outside
the
U.S.
7.
Any product
not
purchased from an Authorized Rockford Fosgate Dealer
Limit
on
Implied
Warranties
Any
implied
warranties
including
warranties offitness for use and merchantability are limited
in
duration
to
the
period ofthe express warranty set forth above. Some states
do
not
allow limitations on the length
of
an
implied
warranty, so this limitation
may
not
apply.
No
person
is
authorized
to
assume for Rockford Fosgate
any
other
liability
in
connection
with
the sale
of
the product.
How
to
Obtain
Service
Contact
the
Authorized Rockford Fosgate Dealer you purchased this product from.
If
you need further
assistance,
call
1-800-669-9899 for Rockford
Customer
Service.You must obtain an RA#
(Return
Authorization
number)
to
return any product
to
Rockford Fosgate.You are responsible for shipment
of product
to
Rockford.
E.U
Warranty
This product meets
the
current
EU
warranty requirements, see yourAuthorized dealer for details.
Rockford
Fosgate
Rockford
Corporation
600 South Rockford Drive
Tempe,Arizona 85281 U.S.A._
In
U.S.A., [phone] -
Customer
Service 1-800-669-9899
www.rockfordfosgate.com
Designed
and
Engineered
by Rockford
Fosgate,
Tempe,
AZ.
USA.
©
20
13
Rockford
Corporation.
All
Rights Reserved.
ROCKFORD FOSGATE and associated logos
where
applicable
are
registered
trademarks
of
Rockford
Corporation
in
the
United States
and/or
other
countries.
All
other
trademarks
are
the
property
of
their
respective
owners.
Specifications subject
to
change
without
notice.
1230-58449-0I Printed
in
China
