Rockford Fosgate RFX8320J Installation and operating manual

Installation Reference Sheet
Japanese Tuner
RFX8320J
®®

RFX8320J AM / FM ST / CD Player / CD Changer Controller
Detachable Faceplate w/ IR Remote
Specification
Reference
Sheet
General
• ISO Mountable –178mm x 50mm
(trim ring removed)
•Any Button Wake–Up
•Clock
•Switchable Loudness –Enables bass response
to be boosted at low listening levels
•Green Illumination
•Internal Amplifier 25w RMS x 4
Preamp
•Low Source Impedance –Enables multiple
amplifiers to be driven without signal loss
Specifications
Specifications subject to change without notice
•6 Pre-Outs W/Adjustable Sub Leevel - Front/Rear
w/ Front/Rear summed out
•Source Tone Memory –Enables separate Bass and Treble
memory for Radio/CD Player/CD Changer modes
Tuner
•MIR (Multipath Interference Rejection) Improves audio
performance when radio reception is poor
•World Wide Tuner –American/Europe/Australia
•30 Station Presets –12 AM/18 FM Presets
•Auto Store –Auto programming of all 30 presets
•Programmable Station Titles - Customizes the LCD to
display name of radio station
Compact Disc
•5.0 Hologram laser –one piece laser with fewer parts
•Dual 1 Bit D/A Converters w/8x Oversampling
•Digital Servo Control w/Auto Focus –Adjusts to CD
manufacturing tolerances for accurate tracking
®®
BAND
DISP AS
/
PS
LOUDMODE
MUTE
TUNE
123456
SEL
VOL
COMPACT DISC PLAYER WITH DIGITAL TUNER
RPT
TRACK SCAN RDM DISC
PUSH
SEEK
MENU
ST RPT RDMLOUDLOCAL
CD CHANGER CONTROL
Features
FM Tuner
Frequency Response ...................................30Hz-12kHz
Usable Sensitivity....................................10dB(S/N 30dB)
IF Rejection.............................................................90dB
Image Rejection......................................................50dB
Signal-to-Noise Ratio..............................................60dB
Channel Separation...................................≥25dB@1KHz
CD Player
Usable Discs....................................................5”and 3”
Frequency Response........................20Hz-20kHz (±3dB)
Signal-to-Noise Ratio............... ............................>90dB
Channel Separation.................................................86dB
Dynamic Range....................................................100dB
AM Tuner
Sensitivity..........................20dBf max @ 10dB Sensitivity
-6dB Bandwidth..........................5KHz min-12 KHz max
General
Operating Voltage.......................................+10.8 to +16V DC
Continuous Power Output....................................25 x 4 Watts
Dynamic Power Output........................................40 x 4 Watts
Pre-Out Voltage (vol. max.).........................................2.4 Vrms
Preamp Output Impedance..............................................100Ω
Equalization...........................................
Overall Dimensions......2-9/32”H x 7-13/32”W x 7-1/4”D
(with trim-ring)...........................(58mm x 188mm x 183.7mm)
Nosepiece Dimensions...1-27/32”H x 6-3/4”W x 13/16”D
(without trim-ring)..................(46.5mm x 171.5mm x 20.2mm)
Weight..............................................3.18 lbs. (1441g)
IR Remote
Dimensions.................................3-3/8”H x 2-1/8”W x 9/32”D
(85.6mm x 54mm x 7mm)
Bass: ± 10dB @ 60Hz
Treble:± 8dB @ 15kHz

RFX8320J AM / FM ST / CD Player / CD Changer Controller
Detachable Faceplate w/IR Remote
Specification
Reference
Sheet
2-Speaker
System
4-Speaker
System
14 1513 16
8675
910
123
11
4
12
2
3
5
6
4
7
9
10
8
1
12
13
15
14
16
11
1
4
3
6
5
8
7
71
543
862
2
C
F
B
A
G
D
H
D
H
G
A
FB
C
Top View
LEFT SIDE VIEW
EE
RIGHT SIDE VIEW
EE
GHFEDCBA
*
*
*
*
*
*
*
*
*
*
*
1.2mm to 11.3mm
5.2mm to 10.4mm
2.9mm to 10.4mm
6.3mm to 8.8mm
18.3mm to 20.8mm
14.0mm to 19.8mm
2.0mm to 7.0mm
**
1.2mm to 1.5mm
INSTALLATION METHODS
Standard Installation- Install the mounting sleeve in the instrument panel thickness
(see chart). Secure the backstrap to the rear of the radio(use the supplied M5 x 6mm
screw) and tighten the screw. Slide the radio into the mounting sleeve until it
“clicks”into postion.Replace the factory trim panel if used.
ISO-DIN Installation- Use the supplied screws (M5 x 6mm) to secure the factory
mounting brackets into at least two holes on each side of the radio. Install the radio
into the dash and tighted the brackets. Replace the
factory trim panel.
Antenna Input
-
+
-
+
-
+
-
+
DESCRIPTION
PIN NO.
Mounting Sleeve Sleeve Retaining
Clip
Secure factory brackets to
at least 2 holes
FRONT (L-) SPEAKER OUTPUT
FRONT (L+) SPEAKER OUTPUT
FRONT (R+) SPEAKER OUTPUT
FRONT (R-) SPEAKER OUTPUT
REAR (L+) SPEAKER OUTPUT
REAR (L-) SPEAKER OUTPUT
REAR (R-) SPEAKER OUTPUT
BATTERY - 12V
CHASSIS GROUND
IGNITION (SWITCHED) (INPUT)
POWER REMOTE (400mA MAX)
POWER ANTENNA (175mA MAX)
AUX INPUT WHITE (L)
REAR (R+) SPEAKER OUTPUT
AUX INPUT RED (R)
WHITE/BLACK
WHITE
GRAY/BLACK
GRAY
GREEN/BLACK
GREEN
PURPLE/BLACK
PURPLE
BLUE/RED
LT. BLUE
RED
WHITE
RED
WHITE
YELLOW
CHOKE &
FUSE BOX
(Looking into the Radio Connector)
MAIN CONNECTOR CONNECTION (RFX8320)
BATTERY + 12V (YELLOW)
CHASSIS GROUND (BLACK)
IGNITION + 12V RED
POWER REMOTE (LT. BLUE)
POWER ANTENNA (BLUE/RED
AUX INPUT LEFT (WHITE)
AUX INPUT GROUND
AUX INPUT RIGHT (RED)
REAR (R+) (PURPLE)
REAR (R-) (PURPLE / BLACK)
REAR (L+) (GREEN)
REAR (L-) (GREEN/BLACK)
FRONT (R+) (GRAY)
FRONT (R-) (GRAY/BLACK)
FRONT (L+) (WHITE)
FRONT (L-) (WHITE/BLACK)
CD Changer Input
8P CONNECTOR NO. NOTE
(R) CH
CD ON
BUS
B+
M. GROUND
NC
(L) CH
A. GROUND
Instrument Panel
Thickness
Tabs to Bend
FRONT OUTPUT
REAR OUTPUT
SUM OUTPUT
Pre-Amp Outputs
Connect to
front
Amplifier
Connect
to rear
Amplifier
Connect to
subwoofer
Amplifier
Pre-Amp Outputs
RCA COLOR
LEFT WHITE
RIGHT RED
LEFT WHITE
RIGHT RED
FRONT OUTPUT
REAR OUTPUT
SUM OUTPUT
LEFT WHITE
RIGHT RED

Rockford Fosgate
Rockford Corporation
546 South Rockford Drive
Tempe, Arizona 85281 U.S.A.
In U.S.A., [phone]
In Europe, Fax [phone]
In Japan, Fax [phone]
www.rockfordfosgate.com
E.W.R. 11/99
For 2000 Models
PRINTED IN CHINA
