Rockwell Automation 1757-FFLDC2 User manual

Installation Instructions
ControlNet Foundation Fieldbus Linking
Device
Catalog Numbers 1757-FFLDC2, 1757-FFLDC4
About the ControlNet F OUNDATION Fieldbus Linking Device
The ControlNet FOUNDATION Fieldbus Linking Device bridges from the
ControlNet network to either two or four H1 networks. Each H1 segment
supports a maximum of 16 FOUNDATION Fieldbus devices
(recommended 8…10) with support for up to 64 publisher and 64 subscriber
virtual communication relationship (VCR) connections. By supporting H1
and ControlNet protocols, the linking device allows Logix controllers to
communicate with FOUNDATION Fieldbus devices.
Topic Page
Important User Information 2
Environment and Enclosure 3
North American Hazardous Location Approval 4
European Hazardous Location Approval 5
Before You Begin 7
Install the Linking Device 9
Reset the Linking Device 17
Status Indicators 21
Specifications 25
Additional Resources 30

2ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
Important User Information
Solid state equipment has operational characteristics differing from those of electromechanical
equipment. Safety Guidelines for the Application, Installation and Maintenance of Solid State Controls
(Publication SGI-1.1 available from your local Rockwell Automation sales office or online at
http://www.literature.rockwellautomation.com) describes some important differences between solid
state equipment and hard-wired electromechanical devices. Because of this difference, and also
because of the wide variety of uses for solid state equipment, all persons responsible for applying this
equipment must satisfy themselves that each intended application of this equipment is acceptable.
In no event will Rockwell Automation, Inc. be responsible or liable for indirect or consequential damages
resulting from the use or application of this equipment.
The examples and diagrams in this manual are included solely for illustrative purposes. Because of the
many variables and requirements associated with any particular installation, Rockwell Automation, Inc.
cannot assume responsibility or liability for actual use based on the examples and diagrams.
No patent liability is assumed by Rockwell Automation, Inc. with respect to use of information, circuits,
equipment, or software described in this manual.
Reproduction of the contents of this manual, in whole or in part, without written permission of Rockwell
Automation, Inc., is prohibited.
Throughout this manual, when necessary, we use notes to make you aware of safety considerations.
WARNING Identifies information about practices or circumstances that can cause an explosion in
a hazardous environment, which may lead to personal injury or death, property
damage, or economic loss.
IMPORTANT Identifies information that is critical for successful application and understanding of
the product.
ATTENTION Identifies information about practicesor circumstances that can lead to personal injury
or death, property damage, or economic loss. Attentions help you identify a hazard,
avoid a hazard and recognize the consequences.
Labels may be on or inside the equipment, for example, a drive or motor, to alert
people that dangerous voltage may be present.
Labels may be on or inside the equipment, for example, a drive or motor, to alert
people that surfaces may reach dangerous temperatures.
SHOCK HAZARD
BURN HAZARD

ControlNet Foundation Fieldbus Linking Device 3
Publication 1757-IN022B-EN-P - August 2009
Environment and Enclosure
ATTENTION This equipment is intended for use in a Pollution Degree 2 industrial
environment, in overvoltage Category II applications (as defined in IEC
60664-1), at altitudes up to 2000 m (6562 ft) without derating.
This equipment is considered Group 1, Class A industrial equipment according
to IEC/CISPR 11. Without appropriate precautions, there may be difficulties
with electromagnetic compatibility in residential and other environments due
to conducted and radiated disturbances.
This equipment is supplied as open-type equipment. It must be mounted within
an enclosure that is suitably designed for those specific environmental
conditions that will be present and appropriately designed to prevent personal
injury resulting from accessibility to live parts. The enclosure must have
suitable flame-retardant properties to prevent or minimize the spread of flame,
complying with a flame spread rating of 5VA, V2, V1, V0 (or equivalent) if
non-metallic. The interior of the enclosure must be accessible only by the use
of a tool. Subsequent sections of this publication may contain additional
information regarding specific enclosure type ratings that are required to
comply with certain product safety certifications.
In addition to this publication, see:
•Industrial Automation Wiring and Grounding Guidelines, for additional
installation requirements, Allen-Bradley publication 1770-4.1.
•NEMA Standards 250 and IEC 60529, as applicable, for explanations of
the degrees of protection provided by different types of enclosure.
ATTENTION To comply with the CE Low Voltage Directive (LVD), all connections to this
equipment must be powered from a source compliant with safety extra low
voltage (SELV) or protected extra low voltage (PELV).
To comply with UL restrictions, all connections to this equipment must be
powered from a source compliant with Class 2 or limited voltage/current.

4ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
North American Hazardous Location Approval
The following information applies when
operating this equipment in hazardous
locations.
Informations sur l’utilisation de cet
équipement en environnements dangereux.
Products marked "CL I, DIV 2, GP A, B, C, D" are suitable for
use in Class I Division 2 Groups A, B, C, D, Hazardous
Locations and nonhazardous locations only. Each product is
supplied with markings on the rating nameplate indicating
the hazardous location temperature code. When
combining products within a system, the most adverse
temperature code (lowest "T" number) may be used to help
determine the overall temperature code of the system.
Combinations of equipment in your system are subject to
investigation by the local Authority Having Jurisdiction at
the time of installation.
Les produits marqués "CL I, DIV 2, GP A, B, C, D" ne
conviennent qu'à une utilisation en environnements de
Classe I Division 2 Groupes A, B, C, D dangereux et non
dangereux. Chaque produit est livré avec des marquages sur
sa plaque d'identification qui indiquent le code de
température pour les environnements dangereux. Lorsque
plusieurs produits sont combinés dans unsystème,le code de
température le plus défavorable (code de température le plus
faible) peut être utilisé pour déterminer le code de
température global du système. Les combinaisons
d'équipements dans le système sont sujettes à inspection par
les autorités locales qualifiées au moment de l'installation.
WARNING EXPLOSION HAZARD -
• Do not disconnect equipment unless
power has been removed or the
area is known to be nonhazardous.
• Do not disconnect connections to
this equipment unless power has
been removed or the area is known
to be nonhazardous. Secure any
external connections that mate to
this equipment by using screws,
sliding latches, threaded
connectors, or other means
provided with this product.
• Substitution of components may
impair suitability for Class I,
Division 2.
• If this product contains batteries,
they must only be changed in an
area known to be nonhazardous.
AVERTISSEMENT RISQUE D’EXPLOSION –
• Couper le courant ou s'assurer
que l'environnement est classé
non dangereux avant de
débrancher l'équipement.
• Couper le courant ou s'assurer
que l'environnement est classé
non dangereux avant de
débrancher les connecteurs. Fixer
tous les connecteurs externes
reliés à cet équipement à l'aide
de vis, loquets coulissants,
connecteurs filetés ou autres
moyens fournis avec ce produit.
• La substitution de composants
peut rendre cet équipement
inadapté à une utilisation en
environnement de Classe I,
Division 2.
• S'assurer que l'environnement est
classé non dangereux avant de
changer les piles.

ControlNet Foundation Fieldbus Linking Device 5
Publication 1757-IN022B-EN-P - August 2009
European Hazardous Location Approval
Preventing Electrostatic Discharge
European Zone 2 Certification (The following applies when the product bears the Ex or EEx
marking.)
This equipment is intended for use in potentially explosive atmospheres as defined by European Union Directive 94/9/EC.
Intertek certifies that this equipment has been found to comply with the Essential Health and Safety Requirements relating
to the design and construction of Category 3 equipment intended for use in potentially explosive atmospheres, given in
Annex II to this Directive. The examination and test results are recorded in confidential report 3172640DAL.
Compliance with the Essential Health and Safety Requirements has been assured by compliance with EN 60079-15
and EN 60079-0.
WARNING •This equipment must be installed in an enclosure providing at least IP54
protection when applied in Zone 2 environments.
•This equipment is not resistant to sunlight or other sources of UV
radiation.
•This equipment shall be used within its specified ratings defined by
Allen-Bradley.
•Provision shall be made to prevent the rated voltage from being exceeded
by transient disturbances of more than 40% when applied in Zone 2
environments.
•Secure any external connections that mate to this equipment by using
screws, sliding latches, threaded connectors, or other means provided
with this product.
•Do not disconnect equipment unless power has been removed or the area
is known to be nonhazardous.
ATTENTION This equipment is sensitive to electrostatic discharge, which can cause
internal damage and affect normal operation. Follow these guidelines when
you handle this equipment:
•Touch a grounded object to discharge potential static.
•Wear an approved grounding wriststrap.
•Do not touch connectors or pins on component boards.
•Do not touch circuit components inside the equipment.
•Use a static-safe workstation, if available.
•Store the equipment in appropriate static-safe packaging when not in
use.

6ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
Parts Illustration of the Fieldbus Linking Device
The sample illustration shows the parts that comprise the 1757-FFLDC
linking device, which links Rockwell Automation products on ControlNet and
FOUNDATION Fieldbus products on H1 networks.
Feature Description Feature Description
1 Reset configuration jumper 8 ControlNet network access port
(NAP) door
2 Factory-default reset button
(inside top cover)
9 ControlNet network-address
switch door
3 Factory use only 10 ControlNet status indicators
A and B
4 Diagnostic Ethernet port
(not shown)
11 ControlNet motherboard (CAM)
eject - Do not remove CAM
5 Status indicators 12 Fieldbus H1 interface terminals
6 H1 status indicators 13 ControlNet ports A and B
7 Power supply connection
(not shown)
14 Factory use only
14 13
11
10
9
8
75
6
43
2
1
12
31990-M

ControlNet Foundation Fieldbus Linking Device 7
Publication 1757-IN022B-EN-P - August 2009
Before You Begin
Before you install the linking device, read and complete the following
sections.
Software Requirements
The following software is compatible with this revision of the linking device:
• RSFieldbus software, version 2.03 or later
• RSLinx Classic software, version 2.52 or later
• RSNetWorx for ControlNet software, version 8.00 or later
• Logix5000 Clock Update tool
• RSLogix 5000 programming software, version 16.03 or later
WARNING This product contains a ControlNet daughtercard (CAM) that is not intended for
removal. Any attempt to remove this CAM or to operate the CAM release
mechanism may cause irreparable damage. If you insert or remove the CAM
while host power is on, an electrical arc can occur. This could cause an
explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous before proceeding.
IMPORTANT You must upgrade your linking device to RSLogix 5000 programming
software version 17 to program unscheduled Class 1 connections on the
ControlNet network. The upgrade is required if your system is running
RSLogix 5000 software version 16 without redundancy. If you are using
RSLogix 5000 software version 16 with redundancy, unscheduled Class 1
connections are not available on the ControlNet network.

8ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
Set the ControlNet Node Address
Use a small screwdriver to set the module’s ControlNet node address
switches.
WARNING When you change switch settings while power is on, an electrical arc can
occur. This could cause an explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous
before proceeding.
TIP You can select an address from 01…99. 00 is an invalid ControlNet
network address.
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
10’s digit
1’s digit
44418
Example shows ControlNet node
address switches set to 15.

ControlNet Foundation Fieldbus Linking Device 9
Publication 1757-IN022B-EN-P - August 2009
Install the Linking Device
Install the linking device by using the following instructions.
Mount the Linking Device
Most applications require installation in an industrial enclosure (Pollution
Degree 2) to reduce the effects of electrical interference (Over Voltage
Category II) and environmental exposure. Locate your linking device as far as
possible from power lines, load lines, and other sources of electrical noise
such as hard-contact switches, relays, and AC motor drives. For more
information on proper grounding guidelines, see the Industrial Automation
Wiring and Grounding Guidelines, publication 1770-4.1.
ATTENTION We do not recommend vertical mounting due to heat build-up considerations.
Be careful of metal chips when drilling mounting holes for your linking device
or other equipment within the enclosure or panel. Drilled fragments that fall
into the unit could cause damage.

10 ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
Product Dimensions
Mount on a DIN Rail
The linking device DIN-rail latch locks in the open position so that the
linking device can be easily attached to or removed from the DIN rail. The
maximum extension of the latch is 15 mm (0.67 in.) in the open position. You
need a screwdriver to remove the linking device. The linking device can be
mounted to 35 x 7.5 or 35 x 15 DIN rails (EN 50 022). See page 12
for DIN-rail mounting dimensions.
ATTENTION This product is grounded through the DIN rail to chassis ground. Use zinc
plated yellow-chromate steel DIN rail to assure proper grounding. The use of
other DIN rail materials (for example, aluminum or plastic) that can corrode,
oxidize, or are poor conductors can result in improper or intermittent
grounding. Secure DIN rail to the mounting surface approximately every
200 mm (7.8 in.) and use end-anchors appropriately.
43481-C
Dimension Measurement
Height (A) 138 mm (5.43 in.)
Width (B) 168 mm (6.62 in.)
Depth (C) 87 mm (3.43 in.)
B
A
C

ControlNet Foundation Fieldbus Linking Device 11
Publication 1757-IN022B-EN-P - August 2009
Do these steps to install your linking device on a DIN rail.
1. Verify that the placement of the linking device on the DIN rail allows
for 50 mm (2 in.) of space on all sides for adequate ventilation and
75 mm (3 in.) of space on the left side of the module if straight
ControlNet taps are used.
2. Hook the top slot over the DIN rail as shown in the illustration.
3. While pressing the linking device down against the top of the rail,
snap the bottom of the linking device into position.
Dimension Height
A 138 mm (5.43 in.)
B 69 mm (2.715 in.)
C 69 mm (2.715 in.) DIN latch closed, 76.1 mm (3 in.) DIN latch open
Middle of
DIN Rail
44421
Top Slot
DIN Rail A
B
C

12 ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
Mount on a Panel
Do these steps to install your linking device on a panel.
1. Verify that the placement of the linking device allows for 50 mm
(2 in.) of space on all sides for adequate ventilation and 75 mm
(3 in.) of space on the left side of the module if straight ControlNet
taps are used.
2. Use the following illustrations to mount the linking device to a panel
by using #8 or M4 screws tightened to 1.1…1.8 N•m (10…16 lb•in).
All dimensions are in mm (in.).
43580
DIN Rail Center Line
168
(6.62)
132
147
(5.78)
122
(4.813)
(5.19)
31991C-M

ControlNet Foundation Fieldbus Linking Device 13
Publication 1757-IN022B-EN-P - August 2009
Wiring the Linking Device
To wire the linking device, complete the following sections.
Wire Requirements
The FOUNDATION Fieldbus recommendation for the cable connecting
fieldbus devices is Type A, 0.8 mm2(18 AWG) shielded, twisted-pair wire. It is
important to calculate how the planned topology for your fieldbus segment,
selected wiring, supplied power, and intended mix of fieldbus devices may
impact the overall performance of a fieldbus network. For more information,
see the FOUNDATION Fieldbus specifications at http://www.fieldbus.org,
publication AG-140.
ControlNet Ports
WARNING If you connect or disconnect the communication cable with power applied to
this module or any device on the network, an electrical arc can occur. This
could cause an explosion in hazardous location installations. Be sure that
power is removed or the area is nonhazardous before proceeding.
IMPORTANT In a non-redundant system, connect the ControlNet cable to Port A on the
linking device. Port B is left unconnected.
In redundant system, all devices on a channel must be connected through
the same cable. That is, all channel A device ports connect to one cable; all
channel B device ports connect to the other cable.
44419
Connect your ControlNet cables to the ControlNet
p
ort on the side of the linking device. Two ports
(A and B) are provided for redundant media
ControlNet connections.

14 ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
Network Access Port
Ethernet Connection
The Ethernet port does not need to be wired for normal operation of the
linking device. The Ethernet port is used as a temporary connection to access
the embedded web pages for diagnostic purposes. The linking device has a
static IP address of 192.168.1.10.
Connect your Ethernet cable to the Ethernet port on the underside of the
linking device.
WARNING The NAP port is intended for temporary local-programming purposes only and
not intended for permanent connection.
If you connect or disconnect the NAP cable with power applied to this module
or any device on the NAP network, an electrical arc can occur. This could cause
an explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous before proceeding.
WARNING The Ethernet port is intended for temporary local-programming purposes only
and not intended for permanent connection.
If you connect or disconnect the Ethernet cable with power applied to this
module or any device on the Ethernet network, an electrical arc can occur. This
could cause an explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous before proceeding.
T
he ControlNet network access port (NAP) provides a
temporary connection for programming and troubleshooting
p
urposes to a ControlNet communication card, for example,
the 1784-PCIC, 1784-PCICS, 1784-U2CN, and
1784-PCC cards.
T
he 1784-PCC card is not supported by RSFieldbus software,
b
ut RSFieldbus software can be used with the 1784-PCIC,
1784-PCICS, and 1784-U2CN cards to configure the
1757-FFLDC and FOUNDATION Fieldbus devices.
Connect the linking device to a communication card
w
ith a 1786-CP cable (1784-PCIC or 1784-PCICS card) or a
1784-PCC1 cable (1784-PCC card).

ControlNet Foundation Fieldbus Linking Device 15
Publication 1757-IN022B-EN-P - August 2009
H1 Terminal Block
The linking device provides two parallel terminals on each H1 network. Use
one to connect to your fieldbus devices and the other for short-term
connection of diagnostic devices.
Do these steps to connect the H1 cables.
1. Strip about 5…7 mm (0.2…0.28 in.) of the insulation at the ends of
the cable leads.
2. Insert the stripped cable end into the desired RTB, and tighten the
screw to 0.34 N•m (3 lb•in).
3. Complete step 1 and step 2 for all H1 cables.
4. If you removed the RTB to insert the H1 cables, insert the RTB into
the corresponding socket and tighten the retaining screws.
WARNING When you connect or disconnect the removable terminal block (RTB) with field
side power applied, an electrical arc can occur. This could cause an explosion
in hazardous location installations.
Be sure that power is removed or the area is nonhazardous before proceeding.
ATTENTION Be careful when stripping wires. Wire fragments that fall into the linking
device could cause damage.
IMPORTANT The H1 RTBs are keyed so they fit only into the corresponding socket. Be
certain that you connect the cables to the correct RTBs.
You must use a power conditioner between your fieldbus power supply and
the devices on the fieldbus network. For more information, see the
FOUNDATION Fieldbus Wiring and Installation Application Guide at
http://www.fieldbus.org, publication AG-140.

16 ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
H1 Terminal Block Layout (catalog number 1757-FFLDC4 shown)
Power and Grounding
1. Insert the following wires into the corresponding connector and
tighten the screws to 0.34 N•m (3 lb•in):
•Chassis ground to connector 1 - CHASSIS GND
•24V common to connector 2 - DC GND
•+24V DC input power to connector 3 - 24V DC (±20%)
2. Apply power to the linking device.
WARNING If you connect or disconnect wiring while the field side power is on, an
electrical arc can occur. This could cause an explosion in hazardous location
installations.
Be sure that power is removed or the area is nonhazardous before proceeding.
ATTENTION Do not exceed 3 m (9.84 ft) total wiring length on the 24V DC power
connection.
H1-1
+ -+ -+ -+ -+ -+ -+ -+ -
H1-2 H1-3 H1-4
1
CHASSIS GND 2
DC GND
3
24V DC (+20%) 43576

ControlNet Foundation Fieldbus Linking Device 17
Publication 1757-IN022B-EN-P - August 2009
Install the EDS File
Installing the electronic data sheet (EDS) file lets you schedule the linking
device on the ControlNet network with RSNetworx for ControlNet software.
The EDS file can be uploaded directly from the linking device. This feature
lets you register the EDS file for your device from within RSLinx software by
following the steps listed below.
1. Open RSLinx software, and browse for the linking device.
2. Right-click the linking device and choose Upload EDS file from
device.
3. Complete the EDS wizard to register the EDS file.
The EDS file can also be downloaded from
http://www.ab.com/networks/eds.html and installed with the RSLinx EDS
Hardware Installation tool.
Reset the Linking Device
The linking device can be reset in the following ways. Shaded cells indicate the
reset types described in this document.
IMPORTANT When you reset the linking device, it no longer communicates with
other fieldbus devices. Make sure your process is shut down or under
manual control before you reset the linking device.
Linking Device Reset Types
Reset Type Description How Information Found In
Reset device This restarts the
linking device but does
not change any
configuration.
Web page
reset
(remotely)
ControlNet FOUNDATION
Fieldbus Linking Device User
Manual,
publication 1757-UM011

18 ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
Reset
configuration
This restarts the
linking device and
deletes all
downloaded fieldbus
configurations. The
linking device retains
its network
configuration and web
page password
information through
this reset.
Reset
jumper
(locally)
Following procedures
Web page
reset
(remotely)
ControlNet FOUNDATION
Fieldbus Linking Device User
Manual,
publication 1757-UM011
RSLogix
5000 reset
(remotely)
RSFieldbus User Manual,
publication RSFBUS-UM001
RSNetWorx
for
ControlNet
reset
(remotely)
Contact Rockwell Automation
Technical Support
Reset to
factory
defaults
This sets the linking
device’s static
Ethernet IP address to
192.168.1.10, resets
the web page user
name and password,
resets all services (for
example, web
services), and clears
all downloaded
fieldbus configuration.
Resetbutton
(locally)
Following procedures
Web page
reset
(remotely)
ControlNet FOUNDATION
Fieldbus Linking Device User
Manual,
publication 1757-UM011
RSNetWorx
for
ControlNet
reset
(remotely)
Contact Rockwell Automation
Technical Support
Reset function
block
parameters
This resets all block
parameters to default.
All blocks in the
linking device are
retained, including tag
names and macrocycle
timing.
RSFieldbus
Resource
Block,
Default
parameter
(remotely)
RSFieldbus User Manual,
publication RSFBUS-UM001
Linking Device Reset Types
Reset Type Description How Information Found In

ControlNet Foundation Fieldbus Linking Device 19
Publication 1757-IN022B-EN-P - August 2009
Reset Configuration
The Reset Configuration deletes all downloaded fieldbus configurations. The
linking device retains its Ethernet network configuration and web page
password information through this reset. To reset the configuration, complete
the following steps.
1. Remove power from the linking device.
2. Move the jumper from its original position (two right pins) to the two
left pins.
3. Wait 30 seconds.
4. Move jumper back to its original position.
5. Return power to the linking device.
Reset/delete
function blocks
This deletes all blocks
in the linking device
except for the
Resource Block. All
Resource Block
parameters are reset
to factory default,
including the tag
name.
RSFieldbus
Resource
Block,
Factory
parameter
(remotely)
RSFieldbus User Manual,
publication RSFBUS-UM001
IMPORTANT After you complete any type of reset, verify that the time and time zone are
still correct.
WARNING When you insert or remove the jumper while power is on, an electrical arc can
occur. This could cause an explosion in hazardous location installations.
Be sure that power is removed or the area is nonhazardous before proceeding.
Linking Device Reset Types
Reset Type Description How Information Found In

20 ControlNet Foundation Fieldbus Linking Device
Publication 1757-IN022B-EN-P - August 2009
Reset to Factory Default
The factory-default reset sets the linking device’s Ethernet network
configuration to use the static IP address of 192.168.1.10, resets the web page
user name and password, resets all services (for example, web services), and
clears all downloaded fieldbus configuration. To complete a factory-default
reset, complete the steps below.
1. Verify that the linking device is powered up and in a running state
(H1 status indicators are blinking).
2. Press the reset button.
WARNING When you press the reset button while power is on, an electrical arc can occur.
This could cause an explosion in hazardous location installations.
Be sure the area is nonhazardous before proceeding.
