INSTRUCTION MANUAL
FIBER-OPTIC PRESSURE TRANSDUCER
FOP Series
Roctest Limited, 2020. All rights reserved.
This product should be installed and operated only by qualified personnel. Its misuse is potentially dangerous. The
Company makes no warranty as to the information furnished in this manual and assumes no liability for damages resulting
from the installation or use of this product. The information herein is subject to change without notification.
Tel. : [phone] • 1.877.ROCTEST (Canada, USA) • 33 (1) 64.06.40.80 (Europe) • www.roctest.com • www.telemac.com
E10160-200722

i
TABLE OF CONTENTS
1PRODUCT ........................................................................................................................................... 1
1.1 GAUGE CONSTRUCTION OF FOP............................................................................................ 1
Models FOP and FOP-C.......................................................................................................... 2
Model FOP-P ........................................................................................................................... 2
Model FOP-F ........................................................................................................................... 2
Model FOP-MicroPZ and FOP-PZ.......................................................................................... 2
1.2 CALIBRATION ........................................................................................................................... 3
1.3 FOP SPECIFICATIONS............................................................................................................... 3
Filter types................................................................................................................................ 4
1.4 FOP-MICROPZ SPECIFICATIONS.............................................................................................. 5
1.5 FOP-PZ SPECIFICATIONS......................................................................................................... 5
2DATA READING AND ANALYSIS ................................................................................................. 6
2.1 FOP PREPARATION FOR INITIAL READING ..................................................................................... 6
2.2 PRE-INSTALLATION INITIAL READING ............................................................................................ 6
2.3 FOP-MICROPZ AND FOP-PZ INITIAL READING............................................................................. 7
2.4 ON-SITE FUNCTION CHECK (OPTIONAL)............................................................................. 8
2.5 PRESSURE EQUATIONS FOR STANDARD FOP PIEZOMETERS USING UNIQUE GAUGE FACTOR... 8
2.6 POLYNOMIAL PRESSURE EQUATIONS FOR FOP-MICROPZ AND FOP-PZ PIEZOMETERS.... 9
Equation with temperature compensation.............................................................................. 10
2.7 LINEAR PRESSURE EQUATION FOR PIEZOMETERS WITH GAUGE FACTOR 0001000 ........................ 12
3INSTALLATION............................................................................................................................... 13
3.1 FILTER SATURATION FOR FOP PIEZOMETERS ................................................................ 13
Low air entry sintered stainless steel filters ........................................................................... 13
High air entry ceramic filters ................................................................................................. 13
3.2 INITIAL READING AFTER INSTALLATION....................................................................................... 14
3.3 INSTALLATION IN FILL ......................................................................................................... 15
Compacted clay ...................................................................................................................... 15
Granular materials................................................................................................................. 15
3.4 INSTALLATION IN BOREHOLES .......................................................................................... 16
3.5 CABLE IDENTIFICATION....................................................................................................... 18
3.6 CABLE ROUTING..................................................................................................................... 18
Transition from vertical borehole to horizontal trench.......................................................... 18
Horizontal cable runs............................................................................................................. 18
4RELATION BETWEEN GAUGE FACTOR AND CALIBRATION FACTOR......................... 19

ii
4.1 READING THE FOP ...................................................................................................................... 20
4.2 EXAMPLE..................................................................................................................................... 20
4.3 DETERMINATION OF THE GAUGE FACTOR ................................................................................... 21
5TROUBLESHOOTING.................................................................................................................... 22
5.1 FIBER OPTIC READOUT UNIT......................................................................................................... 22
Battery charge and discharge cycles for portable readout unit ............................................. 22
Cleaning the connectors......................................................................................................... 22
5.2 FIBER OPTIC PIEZOMETERS TROUBLESHOOTING........................................................................... 23
Diagnostic and error messages.............................................................................................. 23
5.3 OTHER TROUBLES........................................................................................................................ 25
6MISCELLANEOUS.......................................................................................................................... 25

E10160-200722 FOP
Page 1
1 PRODUCT
The FOP Fiber optic piezometer is a stable, robust pressure transducer, designed to allow
remote measurements of piezometric level and pore pressure over long periods of time. It
can be installed in boreholes (model FOP, FOP-microPZ, FOP-PZ), driven into soft ground
(model FOP-P), laid in trenches prior to fill replacement, or buried in concrete (models FOP
and FOP-F). It can also be threaded to hydraulic or pneumatic lines (model FOP-C).
Each gauge is delivered with a calibration data sheet, which includes a gauge factor and/or
calibration factors and a temperature correction factor except for the FOP-microPZ and
FOP-PZ. These factors are determined through factory calibration.
Complete data logging systems are available, please consult Roctest website for details.
1.1GAUGE CONSTRUCTION of FOP
The design of the pressure sensor is based on a non-contact measurement of the
deflection of a stainless steel diaphragm, as opposed to the more conventional measuring
of the diaphragm’s deformation. When the gauge is under pressure, there is a variation of
the Fabry-Perot cavity length made by the inner surfaces of the stainless steel diaphragm
on one side and the tip of an optical fiber on the other side as illustrated in Figure 1. The
geometry and material of the transducer are selected in order to obtain a linear relationship
between the deflection of the diaphragm and the applied pressure.
Figure 1: FOP Pressure Transducer
Figure 1: Schematic view of a FOP sensor
The mechanical robustness of the sensor is assured by the all welded stainless steel
construction, with no epoxy, sealing rubber, or other sort of polymeric materials.
The pressure transducer comes in three different types: gauge, absolute or differential
type. In the case of gauge type, the transducer comes with a vented cable, which keeps
the cavity at ambient atmospheric pressure. In the case of absolute transducer, the cavity
length is sealed under vacuum. Finally in the case of differential sensor, the cavity is to an
arbitrary pressure and comes with a vent connection. The pressure value displayed by the
P
Diaphragm
Fabry-Perot
cavity length
Optical fiber
Filter
Stainless steel
diaphragm
Fiber-optic cable
Stainless steel housing
Feed-through
Connector

E10160-200722 FOP
Page 2
universal readout unit from Roctest is directly in engineering units either in imperial (psi)
or SI (bar) system.
Models FOP and FOP-C
The model FOP piezometer is designed to be embedded in earth fills and concrete, or
inserted into boreholes and pipes as small as 19 mm (3/4”). One end is fitted with an insert
that holds a micrometric high air or low air entry filter. The opposite end contains the cable
entry, fitted with watertight feed-through connector. All parts are made of stainless steel.
The filter is set in the front end of the piezometer and sealed with an o-ring. With the filter in
place, the diaphragm is protected from solid particles, and senses only the fluid pressure to
be measured. The filter housing easily removable for calibration and saturation can also be
replaced with a female or male pipe thread adapter to use the gauge as a pressure
transducer (Model FOP-C).
Model FOP-P
The model FOP-P piezometer is designed to be driven into unconsolidated fine grain
materials such as sand, silt, or clay. The external housing is a thick walled cylinder fitted
with a pointed shoe at one end, and a male thread adapter at the cable entry, fitting "EW"
standarddrillrods.Fourportholesabovethepointholdmicrometricfilters.Thecablepasses
through the threaded end, and can be fed through push rods leading to the surface. The
cable entry is fitted with watertight feed-through connector. Both high and low air entry filters
are available.
Model FOP-F
The model FOP-F piezometer is a thick wall version of the FOP piezometer with an outside
diameter of 25.4mm.
Model FOP-MicroPZ and FOP-PZ
The model FOP-MicroPZ and FOP-PZ piezometers are based on non-contact deflection
measurement of a miniature MOMS (Micro Optical Mechanical System) pressure sensor
manufactured using photolithographic techniques. The pressure transducer has a flexible
diaphragm assembled on top of a sealed vacuumed cavity, and the pressure measurement is
based on Fabry-Perot white-light interferometry. Pressure creates a variation in the length of a
Fabry-Perot cavity consisting of the inner surface of the flexible diaphragm on one side and a
reference optical surface attached to the lead optical fiber on the otherside.
The mechanical robustness for the FOP-microPZ is assured by the stainless protection sleeve
and a porous stainless steel filter which protects the sensing element from solid particles,
allowing thepiezometer to sense onlythe fluidpressure to be measured. The total diameter of
the sensor, including the housing, is only 4.8 mm and its total length is only 54 mm.
The MOMS pressure sensor is mass-produced in batches on glass and silicon wafers using
well established photolithographic technologies derived from the semiconductor industry.
The model FOP-PZ is composed of the same miniature MOMS pressure sensor but this one
isprotectedinsideaPVChousingof15.9mmofdiameter.Thefiberopticcablepassedthrough
a plastic cable gland on one side and at the pressure entry there is a porex HDP filter. The

E10160-200722 FOP
Page 3
advantage of this model is his ability to be protected against all forms of corrosion as there is
no metallic part on the sensor.
1.2CALIBRATION
All piezometers are individually calibrated before shipment. Each piezometer is tested over
its working pressure range and they are tested in temperature (except FOP micro-PZ and
FOP-PZ).
A calibration data sheet supplied with each gauge, lists the following:
Serial number
Gauge factor and/or calibration factors
Working pressure (in bar or psi)
Temperature at time of factory calibration
Barometric pressure at time of factory calibration
Fiber optic cable type and length.

1.3FOP SPECIFICATIONS
PERFORMANCE
Models:
FOP, FOP-C, FOP-F, FOP-P
Pressure range:
200, 350, 500, 750, 1000, 1500, 2000,
3000, 5000, 7000 kPa (1)
25, 50, 75, 100, 150, 250, 300, 500, 750,
1000 psi (1)
Resolution:
0.025% Full Scale
Accuracy:
+/-0.25% Full Scale
EMI / RMI susceptibility:
Intrinsic immunity
Proof pressure:
1.5x of rated pressure
(1) Other ranges available upon request.

E10160-200722 FOP
Page 4
CONSTRUCTION
Model:
FOP
FOP-P
FOP-C
FOP-F
Housing:
Miniature
Push-in
point with
EW thread
Threaded
(1/4-18NPT
female
standard)
Thick wall
Diaphragm Material:
17-4 PH Stainless steel
Outside diameter in mm:
19
33.4
19
25.4
Cable diameter:
3 or 7mm
Filter types
Two types of filters are available: high air entry ceramic or low air entry sintered stainless
steel filters.
The table below summarizes the main differences between the two filter models.
Stainless steel filter
low air pressure entry
pore diameter: ~50 µm
Ceramic filter
high air pressure entry
pore diameter: ~1 µm
Filter generally used.
Filter usually installed for use in
unsaturated fine grain material.
Does not allow suction measurements.
If water level drops below the
piezometer and that a suction builds up,
the filter can de-saturate. But as soon as
the water level comes up, it will re-
saturate easily.
Allow measuring suction to -100 kPa.
If negative pressure is more important,
the filter will de-saturate and readings will
become incorrect.
Air entry pressure: ~10 kPa
Air entry pressure: ~450 kPa
Small time lag.
More important time lag.
Easy to saturate and install.
Need to be saturated under vacuum.
Allows fine grain infiltration.
Helps prevent fine grain infiltration.

E10160-200722 FOP
Page 5
1.4FOP-MicroPZ SPECIFICATIONS
Range 100, 200, 350 (standard range), 500, 750, 1000 kPa
Accuracy ± 0.5% F.S.
Resolution 0.065% F.S.
Overload 1.5x F.S.
Outer diameter 4.8 mm
Length 54 mm
Body material Stainless steel 316
Cable PVC 3 mm outside diameter
Filter Stainless steel 316 (porosity 40 μm)
1.5FOP-PZ SPECIFICATIONS
Range 100, 200, 350 (standard range), 500, 750, 1000 kPa
Accuracy1± 0.5% F.S.
Resolution 0.065% F.S.
Overload 1.5x F.S.
Outer diameter 15.9 mm
Length 57 mm (without cable gland)
Body material PVC
Cable PVC 3 mm outside diameter
Filter Porex HDP (porosity 70 μm)
1Accurayof±0.25%F.ScanbeachievedwithaFPI-HRreadoutunitusingapolynomialregression
of 3rd degree.

E10160-200722 FOP
Page 6
2 DATA READING AND ANALYSIS
2.1FOP Preparation for initial reading
Gauge readings and diagnostic signal (see section 5) should be taken as soon as the
gauges are received to ensure they have not been damaged during shipment. All gauge
transducers are individually calibrated before shipment and a gauge factor (7-digit number)
and the gauge zero obtained at factory, in internal unit of Fabry-Perot cavity length, are
supplied with each gauge. Before using a transducer with the Universal fiber-optic readout
unit from Roctest and Fiso Technologies, its gauge factor must first be saved in the readout
memory and selected. The calibration factor is already recorded in the transducer's gauge
factor, which is registered on a label installed on the cable close to the fiber-optic
connector and you can also find it on the calibration sheet of the gauge. See section 4 for
relation between gauge factor and calibration factor. Please review the operating manual
of the readout unit before proceeding with readings.
First the gauge must be connected in a channel number and the appropriate gauge factor
must be assigned. Fiber-optic pressure transducers must be nulled at least once to
adjust the zero before taken an initial reading. For nulling your transducer follow the
instructions given in the operating manual of your readout. After nulling your transducer with
the appropriate gauge factor pre-selected, the reading will indicate 0 or a very small value.
Obviously, the transducer should not be submitted to pressure for a true zero reading and
should be stabilized in temperature (see below for more information about initial reading).
The zero adjustment of the transducer is necessary when using for the first time a
pressure transducer. It is also necessary to take note of the current value at
installation of the gauge zero (value between 11000 and 23000) when doing a zero
adjustment. Knowing it is possible to re-enter the initial gauge zero at installation
could be useful in the case the readout is reset or its memory content is lost. For
more information about zero adjustment and taking note of the gauge zero see the
operating manual of your readout.
You can also select the Imperial system of unit (in this case the reading will be displayed in
psi)orthe Metricsystemofunit(readingwillbedisplayedin bars).Seetheoperatingmanual
of your readout for more information about the system of units.
Summary steps before taking a reading
1. Save gauge factor into the readout memory
2. Connect each gauge to one of the channel input connectors
3. Associate appropriate gauge factor to the measuring channel
4. Null gauges and record the gauge zero in internal unit of Fabry-Perot cavity length
5. Select appropriate system of units
6. Take your initial reading in engineering unit
2.2Pre-installation initial reading
Before installing the sensor, it is necessary to take an initial reading. The procedure for
taking an initial reading is the following:

E10160-200722 FOP
Page 7
Take a pre-initial reading in air with the stainless steel filter removed at a stabilized
temperature and at a known barometric pressure (for ceramic filter see section 3.1.2 and
3.2). Record the reading, the temperature reading and the barometric pressure reading. Do
not touch the transducer body with your hand because you will change the temperature of
the transducer and you can see a variation of the reading.
Assemble the saturated porous element in a bucket filled with water onto the sensor. The
sensor must be held tip up to ensure that no air bubbles are entrapped behind the filter. For
lower pressure range transducers and for high air entry filters, monitor the pressure acting
on the diaphragm to ensure it does not exceed 125 percent of the operating range of the
piezometer. Leave the instrument in water at room temperature for 2 to 3 hours to stabilize
the temperature of the sensor. See section 3 for more detail information about filter
saturation.
It is even preferable to leave it overnight provided that arrangements are made to keep
the water at more or less uniform temperature. The instrument is temperature stabilized if
the water temperature (ambient) is uniform. All sudden changes of temperature must be
avoided.
With the water temperature and ambient temperature in equilibrium raise the sensor by
the cable until it is out of the water and take a second reading. Record the stabilized value.
Monitor three successive readings to ensure a stable value is recorded. This is the initial
reading. Record ambient and water temperature, barometric pressure and the initial
reading and diagnostic value of the sensor. See section 3 for advice about initial reading
after installation.
2.3FOP-MicroPZ and FOP-PZ initial reading
For piezometers FOP-MicroPZ and FOP-PZ there is two possibilities of calibration data
sheet. You can have a calibration sheet with linear or polynomial regression.
If you have a calibration data sheet with linear regression you will have these parameters
as example:
Gauge factor: 6013141
Calibration factor (CF) in psi/nm: -0.031835
If you want to get the output reading in engineering unit (bar or psi) directly on the display
of the readout unit then you must save the gauge factor number inside the memory of the
readout unit and follow the same steps as described in section 2.1 for the initial reading
measurement.
Or if you have many piezometers that you want to read with the raw data in nanometer
and convert it later using the calibration factor then you must assign the gauge factor
0001000 for all gauges. In this case you do not do any zero adjustment or nulling to adjust
the zero. You should follow the same step as described in section 2.2 for initial reading
without removing the filter however. To convert raw data in engineering unit you should
then follow instructions as explained in section 2.7. See section 4 for relation between
gauge factor and calibration factor.
However, if you have a calibration data sheet with a polynomial regression of third degree
then you do not need to follow all steps as described in section 2.1. In this case you should

E10160-200722 FOP
Page 8
assign the gauge factor 0001000 for all gauges. Do not do any zero adjustment or nulling
to adjust the zero. You should follow the same step as described in section 2.2 for initial
reading without removing the filter however.
After selecting gauge factor 0001000 you should have a reading between 10000 and
23000. Then this reading (L) must be inserted in the equation as described in section 2.6
to convert the raw value in nanometer in engineering unit.
2.4ON-SITE FUNCTION CHECK (OPTIONAL)
Piezometers are calibrated in factory with high precision calibrators having accuracy at least
four times better than the accuracy of the piezometer. However, it is tempting for the user
to make function/calibration checks.
The preferred method for an on site function check is to carry out the readings in a water
filled pipe at uniformtemperature. Variables that otherwise maybe present if the piezometer
is checked in an open borehole (i.e. temperature gradients, flow, unknown density
variations) and that were not present at time of factory calibration are eliminated.
The function check can be made relative to barometric pressure or to a difference of
piezometric head in the pipe. In both cases, barometric pressure should be measured and
recorded along with the readings. A protected function check pipe may be installed in a
borehole or in a building.
2.5PRESSURE EQUATIONS for standard FOP Piezometers using unique
gauge factor
The fiber-optic pressure transducer measures absolute pressure and must be corrected
for barometric pressure changes. The sensors are supplied with a temperature correction
factor (CT), which is used to correct the pressure reading for significant variations in
temperature.
To convert changes in readings to changes in pressure corrected for barometric pressure
and temperature changes, use the following equation:
Imperial units (psi)
Pcorr = Prec - CT (T1–T0) - 0.491 (B1- B0)
where: Pcorr = corrected pressure in psi
Prec = recorded pressure in psi
CT = temperature correction factor in psi/°F
ToT1= initial (at installation) and current temperature readings (°F)
BoB1= initial (at installation) and current barometric pressure in in. of Hg
0.491 = constant for all sensors in psi/in. of Hg.
Example:
Prec = 22.25 psi
CT = 0.01879 psi/°F
To= 65°F

E10160-200722 FOP
Page 9
T1= 80°F
Bo= 29.8 in. Hg
B1= 29.4 in. Hg
Pcorr = 22.25 - 0.01879 (80 - 65) - 0.491 (29.4 - 29.8)
Pcorr = 22.25 - 0.282 + 0.196 = 22.16 psi
SI units (bar)
Pcorr = Prec - CT (T1–T0) - (B1- B0)
where: Pcorr = corrected pressure in bar
Prec = recorded pressure in bar
CT = temperature correction factor in bar/oC
ToT1= Initial (at installation) and current temperature readings (oC)
BoB1= Initial (at installation) and current barometric pressure in bar.
Example:
Prec = 4.500 bar
CT = 0.00143 bar/°C
To= 20°C
T1= 25°C
Bo= 1.013 bar
B1= 1.002 bar
Pcorr = 4.500 - 0.00143 (25 - 20) –(1.002 –1.013)
Pcorr = 4.500 - 0.007 + 0.011 = 4.504 bar
2.6POLYNOMIAL PRESSURE EQUATIONS for FOP-MicroPZ and FOP-PZ
Piezometers
For piezometers FOP-MicroPZ and FOP-PZ with polynomial equation you should assign
the gauge factor 0001000 for all gauges. The calibration factors are obtained using a
polynomial regression of 3rd degree. Then to convert changes in readings (internal unit in
nm) to changes in pressure use the following equation:
Prec = c3 (L-Lc)3+ c2 (L-Lc)2+ c1 (L-Lc) + c0
where: Prec = Pressure in bar, kPa or psi
c0,c1,c2,c3: = Calibration factors (see on calibration data sheets)
L = Current reading in nm using gauge factor 0001000 inside the
readout unit
Lc (center) = Mean reading in nm (see value identified center on the
calibration data sheet.

E10160-200722 FOP
Page 10
Standard piezometers are sealed and unvented. Consequently they respond to barometric
changes. However this response will vary depending how they are installed. If they are
buried or installed in a sealed borehole, it is likely that full effect of the barometric changes
will not be felt immediately. It can be significantly attenuated. On the contrary, if the
piezometers are installed in a standpipe or a well open to atmosphere, barometric changes
will directly be felt. In that case, a systematic barometric correction is recommended
following the formula given below. In situations where the effects of barometric changes
on measurements are not clear, it is suggested to independently record barometric and
piezometric changes and correlate them to arrive at a correction factor.
It is suggested to use a barometer on site for measuring changes in atmospheric
pressures.
Use the following relation to apply barometric corrections:
Pcorr = Prec - (B1- B0)
Where
Pcorr = Corrected pressure in kPa
Prec = Pressure previously calculated in kPa (see above)
BoB1= Initial (at installation) and current barometric pressure in kPa.
Equation with temperature compensation
Temperature variations will slightly affect readings for piezometers FOP-MicroPZ and
FOP-PZ. For this reason, we do not provide normally a temperature correction factor.
However, if you want it you should request it at the time of the order and a thermal test
will be done during manufacturing. If you have a temperature correction factor, then the
equation should be:
Pcorr = (Prec1 - Prec0) - CT (T1–T0) - (B1- B0)
where: Pcorr = Corrected pressure in kPa
Prec1= Recorded pressure in kPa (see formula above)
Prec0 = Initial recorded pressure in kPa
CT = Temperature correction factor in kPa/oC
ToT1= Initial (at installation) and current temperature readings (oC)
BoB1= Initial (at installation) and current barometric pressure in kPa
Example with sensor FOP-PZ serial number: 1019101001
Information from the calibration data sheets (see bottom of the first page)
Lc=Center
14598
C0
88.16139984
C1
-0.0328627713

E10160-200722 FOP
Page 11
C2
7.978174494E-07
C3
-1.267945332E-10
Pressure unit psi
Considering the following initial condition without any pressure applied on the sensor at the
atmospheric pressure.
L0= 16924 nm
To= 20°C
Bo= 100.2 kPa
Then first we must compute the initial recorded pressure Prec0
Prec0= c3 (L0-Lc)3+ c2 (L0-Lc)2+ c1 (L0-Lc) + c0
Prec0= -1.267945332E-10 (16924-14598)3+ 7.978174494E-07 (16924-14598)2-
0.0328627713 (16924-14598) + 88.16139984
Prec0= 14.44 psi
Be aware of the unit. To convert the pressure from psi to kPa multiply by 6.8948
Prec0= 99.56 kPa
Note that the calibration in factory is done compared to the zero absolute, that explains the
initial value of 14.44 psi although there is no pressure applied to the sensor. This value
should be similar to the barometric pressure. You should consider this value as your initial
value.
Here is a series of value after the installation and reading stabilization.
L1= 15015 nm
T1= 25°C
B1= 101.3 kPa
CT = -0.0422 kPa/°C
Then we must compute the actual recorded pressure Prec1
Prec1= c3 (L1-Lc)3+ c2 (L1-Lc)2+ c1 (L1-Lc) + c0
Prec0 = -1.267945332E-10 (15015-14598)3+ 7.978174494E-07 (15015-14598)2-
0.0328627713 (15015-14598) + 88.16139984
Prec1 = 74.59 psi
Be aware of the unit. To convert the pressure from psi to kPa multiply by 6.8948
Prec1= 514.28 kPa

E10160-200722 FOP
Page 12
Now I can compute the corrected pressure using the formula.
Pcorr = (Prec1 - Prec0) - CT (T1–T0) - (B1- B0)
Pcorr = (514.28 –99.56) –(-0.0422) (25 –20) - (101.3- 100.2)
Pcorr = 414.72 + 0.211 –1.1
Pcorr = 413.831 kPa
2.7Linear pressure equation for piezometers with gauge factor 0001000
For piezometers with linear equation you can assign the gauge factor 0001000 and
convert the reading using the equation below. With this method also you assign always
the same gauge factor in the readout unit and you record always the reading in raw units
in nanometers (nm).
The calibration factor (CF) is obtained using a linear regression. Then to convert changes
in readings (internal unit in nm) to changes in pressure use the following equation:
SI units (kPa)
Prec= CF x (L1 –L0)
And Pcorr = Prec - CT (T1–T0) - (B1- B0)
where: Pcorr = corrected pressure in kPa
Prec = recorded pressure in kPa
LoL1= Initial (at installation) and current readings (nm)
BoB1= Initial (at installation) and current barometric pressure in kPa.
CF = Calibration factor in kPa/nm
CT = Temperature correction factor in kPa/oC
ToT1= Initial (at installation) and current temperature readings (oC)
CF and CT are defined on the calibration data sheet provided with each sensor.

E10160-200722 FOP
Page 13
3 INSTALLATION
Fiber optic piezometers can be installed in various ways to suit each individual application.
Specific guidelines for the installation of piezometers have been set for piezometer
installation by various agencies and specialists. A list of references is given in appendix.
The following instructions summarize the generally accepted practice for:
filter saturation,
initial reading after installation
cable identification,
piezometers installed in clay fill, granular material or boreholes,
piezometers driven into soft soil,
cable routing.
3.1FILTER SATURATION FOR FOP PIEZOMETERS
Two types of filters are available; high air entry ceramic or low air entry sintered stainless
steel filters. Saturation of the filter:
reduces the possibility of filter clogging,
decreases response time,
ensures hydraulic continuity between the pore water and the piezometer diaphragm
in unsaturated soils.
Low air entry sintered stainless steel filters
The filter on the FOP piezometer body is removed by holding the piezometer in one hand
and pulling and twisting the filter housing with the other hand.
Saturate the filter by placing it in a receptacle of clean water for at least 15 minutes.
Immerse the piezometer housing with the filterremoved in a water bath. With the diaphragm
end pointing upwards and submerged, reassemble the filter. Tap piezometer housing lightly
to remove any air bubbles present. As soon as the filter is saturated, it must stay
submerged until ready to install.
High air entry ceramic filters
The ceramic filter is delivered cased in a bottle and pre-saturated in water. If the ceramic
filter is not pre-saturated, install the filter in a receptacle of clean water and boil the porous
ceramic filter for a minimum of two-hour period.
Final installation must be carried out under water to avoid any air intrusion.
Connect the piezometer to a readout unit.
Put the piezometer upside-down in a container filled with clean water. The
piezometer tip should be up and completely submerged.

E10160-200722 FOP
Page 14
With the piezometer submerged, firmly grasp the housing with both hands and
push the filter assembly into its tip. Gradually increase the pushing force using
thumbs until it is fully inserted. This step may take a while to be completed.
Some resistance will be met; it is normal and due to the small porosity of the
ceramic filter. While pushing on the filter assembly, check the readings on the
readout unit to avoid excessive pressure variations that could damage the
piezometer. Refer to the calibration sheet for pressure range.
The filter installation is now completed.
Keep the piezometer underwater for at least 24 hours before proceeding with field
installation. This will allow the pressure induced by the filter installation to
decrease. When ready to be installed, the piezometer reading should be close to
the one of acceptance test with the filter removed (see details in section 2.2).
3.2Initial reading after installation
Before installing the piezometer in its final location on site, an initial reading has to be
taken to correctly convert readings into pressure measurements when the piezometer is
in operation. This process is also necessary to be able to apply later temperature and
barometric corrections.
Leave the instrument in water for two or three hours to let the temperature stabilize. It is
preferable to leave it overnight, provided that arrangements are made to keep the water
at more or less uniform temperature. All sudden changes of temperature and direct
exposure to the sun must be avoided.
With the water temperature, ambient temperature and piezometer temperature in
equilibrium, raise the piezometer by the cable until it is out of the water about two
centimetres. We recommend to take the initial reading in raw data in nanometer by
assigning the gauge factor 0001000. If you want read directly the pressure in engineering
unit with the readout unit then you will need to assign the appropriate gauge factor and
complete a nulling to adjust the zero as explained in section 2.1.
We recommend to take three successive readings to ensure a stable value and record it.
This is the initial reading (called L0). Record ambient temperature (T0) and barometric
pressure (B0). We recommend alsoto record the diagnostic function (DIAG), the signal and
light voltage and compare value of the table on section 5.2.1. This is important for
evaluating the performances for both the readout unit and the sensor.
However sometimes, it is very difficult to use the FOP readings just after installation for
proving that the sensors are working properly or not since it is normal after installation to
see slight variations in readings coming from temperature and barometric variations, and
from short term disturbance of the water and/or air pore pressures induced by installation
and construction activities. And the effects of these variations over the readings can be
hard to quantify accurately. This applies for installation both in boreholes or fills.
In the case of installations made according to the 'fully grouted' method, the level of
uncertainty is even higher because of the difficulty in making a grout perfectly adjusted to
the surrounding soil. See article from Marefat, Contreras for more information about this
technique of installation.

E10160-200722 FOP
Page 15
In non –or partially –saturated soils, one should not expect to read exactly 0 kPa after
installation because of the above mentioned factors, and because of the potential suction
in the soil and potential air infiltration in the piezometers in the case where these are fitted
with low-air entry filters. But from our experience, as soon as water gets back in the soil,
pressure increases to normal levels.
It is recommended after installation to take as many readings as possible and if possible
to use a datalogger to record the readings every hour for a period that can be up to one
week. This will greatly help assessing if the piezometers are responding normally or if
there is any problem and to define a stable initial reading.
If the readings remain stable and within a certain range, from about -25 to +25 kPa
(depending on the piezometers’ range), we should assume that the piezometers are still
working properly, unless other events lead us to believe otherwise. In such case, the best
method to check consists in retrieving and calibrating the piezometers.
It should be kept in mind that these piezometers are designed for giving reliable relative
readings, provided that temperature are stable and barometric pressures at the level of
the piezometers are properly measured. Accurate absolute readings are slightly more
difficult to obtain.
3.3INSTALLATION IN FILL
Compacted clay
Excavate a trench or recess about 30 cm deep by about 0.8 m2. Form a cylindrical hole in
the side wall of the trench. The hole diameter should be slightly smaller than the piezometer
body.
Push the piezometer into the side of the hole. Make sure that the piezometer filter is in direct
contact with the host material. If necessary to ensure continuity with the saturated high air
entry filter and the pore water, smear the filter with a thin paste of the saturated material.
Before backfilling, the cable must be laid with the utmost care. Loop the cable around the
recess, making sure it rests on a bed of hand placed and compacted screened clay.
Make sure that the cable does not cross over itself or other cables in the same area.
Backfilltherecesswithscreenedclaycontainingnoparticleslargerthan2.5mmindiameter.
The backfill should have a water content and density equal to that of the surrounding
material.
Make sure that the cable is protected from potential damage caused by angular material,
compacting equipment or stretching due to subsequent deformations during construction or
fill placement.
Granular materials
Install the piezometer as described above in a recess excavated for this purpose. Place the
piezometer within the trench, loop cable and backfill with screened material containing the
same moisture content and compacted to the same density as the surrounding fill. In rock
fill, it is necessary to place a graded filter around the piezometer. Use fine grain clean sand

E10160-200722 FOP
Page 16
around the instrument and increase the particle size as the backfill proceeds outwards to
the rock fill. The sand placed in the recess around the instrument and cable should range in
size from 0.5 mm to 2.5 mm in diameter.
3.4INSTALLATION IN BOREHOLES
The method used to install a piezometer in a borehole depends on the particular conditions
in which the installation must be carried out. Artesian conditions, borehole stability,
available drilling equipment and sealing material are among the factors that will influence
the method chosen. The method described below will cover most applications.
1. Drill the borehole below the required depth at which the piezometer is to be
installed. Drive the casing thirty centimeters below the required piezometer
elevation. Wash until the water (or biodegradable drilling mud) emerging from the
borehole runs clear. This will prevent the backfill materials from sticking to and
plugging the casing.
2. Raise the casing fifteen centimeters and pour sand below its bottom. Repeat the
operation once and lower the piezometer to the top of the sand. Check the
borehole depth after each operation.
3. While holding the instrument in place, repeat step 2 until thirty centimeters of sand
are placed above the piezometer.
4. Raise the casing fifteen centimeters and pour compressed dry bentonite below its
bottom. Repeat the operation until a seal of at least 1.2 m is in place. When
pouring bentonite, keep the cable taut to prevent the bentonite from hooking up in
the casing. Pour the bentonite slowly in the hole to avoid bridging. A brush or a
thirty centimetre layer road salt can be used to unplug a blocked hole. Check the
borehole depth after each operation.
5. Wait for the bentonite to set up. Two hours are generally enough. Refer to
supplier’s instructions for exact time. Keep the borehole filled with water. This will
prevent the bentonite of drawing water from surrounding soil during its setting.
6. If only one piezometer is to be installed in the hole, backfill the casing with a
bentonite/cement grout.
If more than one piezometer is to be installed in the borehole, backfill with a
bentonite/cement grout to an elevation of a meter and a half below the second
piezometer. Then use 1.2 m of bentonite. Repeat operations 1 to 5 for the second
piezometer. When all instruments are installed, backfill with a bentonite/cement
grout.
7. Pull the casing without rotating it during removal. Top off the borehole with grout.
If the deepest piezometer has for purpose to measure the pore water pressure in a specific
horizon, it is necessary to drive the casing below the instrument and set a 1.2 m bentonite
seal at the bottom of the borehole. Pull the casing as the bentonite is set in place. Proceed
by stages of fifteen centimeters. Be very careful not to plug or allow bentonite to stick to
the inside walls of the casing. This is accomplished by making sure the bentonite level is
at all times below the casing and by slowly dropping bentonite in single file down the hole.
Trying to feed bentonite too rapidly will result in bridging in the casing or borehole.

E10160-200722 FOP
Page 17
Tamping of compressed bentonite is not required. Prior to setting the sand in place, lower
a cylindrical weight down the borehole to ensure that it is clear from any obstructions and,
if necessary, rinse the borehole until clear water emerges.
Note:It is also possible to place the piezometer into a sand filled canvas bag. The bag
then acts as a sand filled intake zone.
Typical installation of piezometers in a borehole
Note that an alternate way to install piezometers in boreholes is to fill the entire borehole
with grout after having lowered the instruments. This method, known as the Fully Grouted
Borehole Installation, is peculiar in that:
Piezometers are installed with filter end upward.
Proper care must be taken for preparing a grout mix that will mimic as well as
possible the stiffness and permeability of the surrounding ground. This is achieved
by selecting the proper water-cement ratio. Mixtures shown in the table below can
be used as a starting point. The cement and water are mixed first. When proper
ratio is reached, bentonite powder is slowly added until as heavy as feasible to
pump.
