RODE Microphones STREAMER X User manual

STREAMER X SUMMARY V02
Professional
Audio Interface
Flexible
Control Surface
High-resolution
Video
ALL-IN-ONE STREAMING SOLUTION
The Streamer X is a professional audio interface, video
capture card and control surface integrated into one
compact, easy-to-use device.
It allows you to capture a number of different audio inputs
alongside a high-resolution video feed into your computer
via the included USB-C cable, which you can then stream
live or record.
TOP VIEW
BACK VIEW
Wireless Input Indicator
Headset Input Indicator
Phantom Power Indicator
Combo Jack Input Indicator
Input Rotary Encoder
Headphone Rotary Encoder
Microphone Mute Switch
Video Feed Cut Switch
SMART Pads
Bank Switching Buttons
USB Power Input
USB 2
USB 1
HDMI Thru
HDMI In
Headset Input/Output (TRRS)
Headphone Output (TRS)
XLR/TRS Combo Input
Phantom Power Switch
PodMic
PSA1+
NTH-100
Streamer X
Audio Interface &
Video Capture Card

STREAMER X SUMMARY V02
Below, we’ll take you through the process of setting up
and getting started with the Streamer X.
Getting Connected
Step 1: You can either power the Streamer X from your
computer using the included SuperSpeed USB-C
cable connected to USB 1, or you can use the
included power supply connected to the Streamer
X’s dedicated power input.
Step 2: Next, connect your HDMI source device (like your
console or camera) into the HDMI IN port and
connect your monitor or TV to HDMI THRU. Be
sure that your source device can provide – and is
set to output – one of the compatible resolution
and framerate settings, which you can nd in the
Streamer X user guide.
Step 3: Connect your XLR, headset or wireless
microphone and select your input type by
pressing the left encoder knob. You can adjust
the input gain by turning this encoder.
Step 4: Connect headphones (if you’re not using a
headset) and adjust your monitoring level with
the right encoder. You can press this encoder
to quickly mute your headphones.
Step 5: Download RØDE Central to congure your
Streamer X and access its processing, effects
and SMART pad customisation.
CUSTOMISE YOUR SETUP
You can set up your Streamer X exactly the way you
need it using our simple-to-use RØDE Central control
software. This allows you to congure powerful effects and
processing for your input audio, control your headphone
and stream mix levels and customise the SMART pads.
Advanced Mixing, Routing
and Streaming with UNIFY
STREAMER X SUMMARY V01
UNIFY is an incredibly powerful virtual mixing software for
streaming that gives you advanced control over your audio,
including giving you access to six virtual audio devices on
your computer that you can use to manage audio from apps
such as Discord, Spotify, Zoom, Teams, YouTube and more,
as well as creating different sub-mixes for headphones,
recording, streaming and communications. Combined
with the Streamer X, it’s the ultimate solution for advanced
streaming applications.
Check out the UNIFY section of the Streamer X user guide
for more information.
ALL-IN-ONE STREAMING SOLUTION
Note: You do not need UNIFY to use the Streamer X.
We recommend downloading RØDE Central to
congure your device and access its features. For most
users, RØDE Central will give you more than enough
control over your device – UNIFY is for more advanced
streaming applications.
