Rohm BM92A56MWV-ZE2 User manual

ROHM USB Type-C Power Delivery
Evaluation Board Manual
BM92A56MWV-EVK-001 Ver.1.00
1/8
ROHM Co.,Ltd.
URL http://www.rohm.com
ROHM USB Type-C Power Delivery
Evaluation Board Manual
BM92A56MWV-EVK-001
Ver.1.00
Date:03-Mar,2017

ROHM USB Type-C Power Delivery
Evaluation Board Manual
BM92A56MWV-EVK-001 Ver.1.00
2/8
ROHM Co.,Ltd.
URL http://www.rohm.com
Introduction
This board is dedicated to supplying power with USB Type-C Power Delivery, and voltage
profile (PDO) is 5V, 9V, 12V, 15V, 20V.
If you want to check the operation of Power Delivery, please prepare capable of receiving
power USB Type-C Power Delivery device and USB Type-C dedicated cable.
Please use selling separately “BM92A12MWV-EVK-001 (20V)”, “BM92A13MWV-EVK-001
(15V)” and “BM92A14MWV-EVK-001 (9V)” for capable of receiving power USB Type-C
Power Delivery device.
Figure1. Evaluation Board Photo

ROHM USB Type-C Power Delivery
Evaluation Board Manual
BM92A56MWV-EVK-001 Ver.1.00
3/8
ROHM Co.,Ltd.
URL http://www.rohm.com
Evaluation Board Circuit and Pin Explanation
VBUS
CC2
CC1
VEX
VSVR
Figure2. Evaluation Board Circuit

ROHM USB Type-C Power Delivery
Evaluation Board Manual
BM92A56MWV-EVK-001 Ver.1.00
4/8
ROHM Co.,Ltd.
URL http://www.rohm.com
Figure3. Evaluation Board Photo
・VEX pin：5V voltage input pin. Although it is named VEX pin on the board, it is connected
to the VSVR pin of the PDIC.
・VSVR pin：5V or 9V or 12V or 15V or 20V voltage input pin. Although it is named VSVR pin
on the board, it is connected to the VEX pin of the PDIC.
・CC1,CC2 pin：You can monitor the communication waveform (BMC waveform) with USB
Power Delivery.
・VBUS pin：It is connected to VB pin of PDIC and VBUS pin of Type-C Receptacle. You can
monitor the VBUS voltage to power the Sink side.
Type-C
Receptacle
VBUS
CC1
CC2
VEX VSVR

ROHM USB Type-C Power Delivery
Evaluation Board Manual
BM92A56MWV-EVK-001 Ver.1.00
5/8
ROHM Co.,Ltd.
URL http://www.rohm.com
How to use and evaluate
1. Please input 5V to VEX pin and 5V or 9V or 12V or 15V or 20V to VSVR pin of this
board.
Figure4. Evaluation Board Photo
2. Please connect to capable of receiving power USB Type-C Power Delivery device with
Type-C dedicated cable.
The following is a picture connected to the selling separately BM92A15MWV-EVK-001.
BM92A56MWV-EVK-001
Type-C Cable
BM92A15MWV-EVK-001
Figure5. Device connection photo using Type-C cable
5V or
9V or
12V or
15V or 20V
5V

ROHM USB Type-C Power Delivery
Evaluation Board Manual
BM92A56MWV-EVK-001 Ver.1.00
6/8
ROHM Co.,Ltd.
URL http://www.rohm.com
Power Delivery Operating Waveform
When connecting this board (Source side) and power receiving device (Sink side) using
Type-C dedicated cable, the Source side detects the Sink side and outputs 5V voltage to the
VBUS pin. After outputting 5V voltage on the Source side, it communicates with the Type-C
controller IC in the dedicated cable to acquire cable information.
After communicating with the cable on the Source side, the Source side transmits its own
power profile information to the Sink side. (Source Capability)
The Sink side requests an appropriate voltage from the power profile to the Source side.
(Request)
In response to the Sink side voltage request, if the Source side is able to deal with it, notifies
the Sink side that it acknowledged. (Accept)
The Source side outputs the requested voltage to the VBUS pin.
After outputting the required voltage, the Source side notifies the Sink side that the
requested voltage has been output. (PS_RDY)
After confirming the requested voltage, the Sink side turns on the FET switch on the VBUS
line.
・20V negotiation waveform (Board VSVR voltage:20V)
VBUS
CC1
CC2
Plug insert
VBUS output
From Source side
Scale up
Source
Capability
Request
Accept
PS_RDY
BMC negotiation
E-marked
Cable Detect
5V
20V
VBUS
CC1
CC2
Figure6. Power Delivery negotiation waveform

ROHM USB Type-C Power Delivery
Evaluation Board Manual
BM92A56MWV-EVK-001 Ver.1.00
7/8
ROHM Co.,Ltd.
URL http://www.rohm.com
Evaluation Board Layout
Figure7. Top Layer Layout
Figure8. Second Layer Layout

ROHM USB Type-C Power Delivery
Evaluation Board Manual
BM92A56MWV-EVK-001 Ver.1.00
8/8
ROHM Co.,Ltd.
URL http://www.rohm.com
Figure9. Third Layer Layout
Figure10. Bottom Layer Layout

R1102 B
www.rohm.com
© 2016 ROHM Co., Ltd. All rights reserved.
